Teal Handeman Xtra User manual

Installation details: units operating using a 3 wire connection system
Euro 6 compliant vehicles: (Non-Voltage Sensing)
• Red wire to battery + using 4mm (minimum 30 amp
rated wire )
• Black wire to battery – or ground (chassis )
• White wire to ignition control
• In-line fuse – must be fitted to red + ve wire
• Wiring should be kept as short a practically possible to
prevent voltage drop/loss.
The PCB inside the unit has been developed so it has a third
white wire (this is connected into the ignition loom on EU6
vehicles). This removes the need for a relay on most models.
The unit operates when it sees a signal from the ignition
and also when the battery voltage is above 12.7-12.8v.
The unit will cut out when the ignition is switched off OR
if the battery voltage drops below 12.1v (this is a fail-safe
method in case the vehicle has the ignition switched on
without the engine running).
Some vehicles may require “Fuse Jumpers” if unable to
access the ignition fuse.
The TEAL Handeman Xtra
12 and 24 volt vehicle hand wash
units: installation and operating
instructions, 2018
E11 Approval No: 10R-055528, Extension No: 01
VCA registration number: VCS377871
The Handeman Xtra
12v/220w (red label), 24v/250w (blue label)
and 12v/90w (purple label)
Specications
Product Handeman
12v (red label)
Handeman
24v (Blue label)
Handeman
12v (Purple label)
Height 370 mm 370 mm 370 mm
Width 310 mm 310 mm 310 mm
D (closed) 220 mm 220 mm 220 mm
D (open) 370 mm 370 mm 370 mm
Litres 3.3 3.3 3.3
Fuse 30 amp 20 amp 15 amp
No. of 10 second
hand washes 15 15 15
Weight (empty) 3 kg 3 kg 3 kg
Weight (full) 6.3 kg 6.3 kg 6.3 kg
EU2-EU5 compliant vehicles (Voltage Sensing)
• Red wire to battery + using 4mm (minimum 30 amp
rated wire )
• Black wire to battery – or ground (chassis )
• White wire to battery +
• In-line fuse – must be fitted to the red +ve wire
• Wiring should be kept as short a practically possible to
prevent voltage drop/loss.
TEAL standard voltage sensing software will operate.
Unit switches on at 13.8 volts and cuts out at 12.8 volts.
• Red wire to battery + using 4mm (minimum 30 amp
rated wire)
• Black wire to battery – or ground (chassis)
• White wire to ignition control
• In-line fuse – must be fitted to the red + ve wire
• Wiring should be kept as short a practically possible to
prevent voltage drop/loss.
TEAL standard voltage sensing software will operate.
Unit switches on at 25.6 volts and cuts out at 25.1 volts.
24 Volt vehicles with 3 wire connection system
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB
AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS
PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO
ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB
AUTO ELECTRICS PB AUTO ELECTRICSPB AUTO ELECTRICS PB AUTO ELECTRICS PB AUTO ELECTRICS
PB AUTO ELECTRICS

Water temperature LED fault indicator
If the vehicle engine is running, the water temperature will
reach 43º C – the unit will then cut out.
When the water temperature drops to 40º C, the unit
will cut back in to heat the water again. The cycle will be
repeated whilst the engine is running.
NB: In freezing temperatures, the unit should be
drained overnight and/or at weekends. This will
prevent damage to your unit.
Do not ll units above the inner bae/water tank.
All TEAL hand wash units are fitted with an LED fault
indicator which remains on at ALL times (this draws 10Ma ).
The indicator is located at the front of the unit.
If the unit develops a fault there will be a series of ashes:
• Single ash = no water.
Fill with clean water, remove the fuse and replace after 60
seconds, or cycle the vehicle ignition. The unit will then
reset
• Double ash = PCB/thermistor issue
Return to the manufacturer
• Triple ash = over voltage
Check the wiring and battery voltage
• Quadruple ash = low vehicle battery
Check the battery.
Mounting instructions
The units are fixed using four bolts - two located beneath
the lid and two located behind the pull-down bowl.
Using the template provided, they should be fitted into an
area that allows clearance for filling, washing and bowl/
waste removal.
Cleaning instructions
Daily
Empty the bowl into a foul water drain. Rinse the bowl with
clean water. The bowl is removable on the Handeman Xtra.
Monthly
Empty as above. Wipe all surfaces with a mild detergent.
Flush waste bowl with mild detergent.
IMPORTANT
TEAL recommends cleaning and sterilising the unit
regularly with Milton or a similar product is to minimise
any possible build-up of water borne bacteria such as
Pseudomonas. Pseudomonas can create the environment
required for other bacteria such as Legionella.
Warranty terms
2 years on a return to manufacturer basis.
TEAL 12 and 24 volt vehicle hand wash units: operating instructions
Handeman Xtra®
12v/220w (red label) and
24v/250w (blue label)
TEALwash®
12v/220w (red label) and
24v/250w (blue label)
Compact Classic®
12v/180w (red label) and
24v/250w (blue label)
Motor vehicle products in the TEAL range
NB - the water is not suitable for drinking
