Tech Source RAPTOR 1000 User manual

Raptor 1000 Features
•Resolution up to 1920 X 1080
•8/16/24 -Bits Per Pixel
•Hardware Double Buffering
•12 MB Viewable Frame Buffer
•24 Independent Overlays
•1024 Dynamic Colors
•Single Slot PCI Long Card
•Hardware Support for MOX
(Multiple Overlay Extension)
Markets
•Air Traffic Management
•Vessel Traffic Control
•Command & Control
Platforms
•Sun UltraSPARC Workstations
•Digital Alpha Workstations
Product Brief
Raptor 1000
1920 x 1080 Color Video Graphics Adapter
The Tech-Source Raptor 1000 high reso-
lution graphics accelerator combines in a
single slot PCI card a comprehensive
array of high-end display subsystem fea-
tures that formerly required a box level
solution. The Raptor 1000 is designed
for use in high resolution, high perform-
ance, color graphics applications such as
Air Traffic Management and Vessel Con-
trol. It's high level of integration achieves
extreme flexibility over a wide range of
functions.
An advanced Application Specific Inte-
grated Circuit designed by Tech-Source
engineers provides the ability to display
1024 independent dynamic colors at the
same time. That’s four times the number
of colors available in traditional graphics
systems. Specialized frame buffer layering
hardware allows for complete control of
24 independently addressable overlays
with dynamic priority adjustment. That’s
12 times more than most advanced un-
derlay/overlay systems.
The Raptor 1000 offers two-dimensional
drawing acceleration for polygons, text
and windowing operations. The graph-
ics-processor can generate an excess of
900,000 X Window System characters per
second providing the ability to manage
over 2,000 targets/tracks in real time.
Multiple configuration modes are avail-
able for double buffering and multiple
overlay buffering support. True hard-
ware double buffering is supported using
standard software interfaces such as
MBX (Multi-buffering extension for X)
and DBE (Double buffering extension).
Specialized flash fill hardware performs
back buffer screen erases in under 100
microseconds.
442 S. North Lake Boulevard
Altamonte Springs, FL 32701
407.262.7100
www.techsource.com
Tech Source, the Tech Source logo, and Raptor 1000 are trademarks of Tech Source, Inc. All other trademarks are the property of
their respective owners. ©2002 Tech Source, Inc. All rights reserved. Information in this document is subject to change without
notice. Tech Source, Inc. assumes no responsibility for errors or omissions that may appear in this document.
Raptor 1000 Technical Specifications
Raptor 1000 PCI video graphics adapter, software configurable resolutions up to 1920 x 1080, 12 MB frame
buffer, includes DB-13-W3 to 4BNC video cable, operating system specific device driver software
and manuals.
Raptor OpenWindows for Solaris Loadable drivers for Sun PCI systems running Solaris 2.6, 7 or 8.
Raptor X Servers for Digital UNIX Loadable drivers for the Digital/Compaq Alpha workstations running Tru64
UNIX, 4.0f, 5.0, 5.1.
Specifications
Frame Buffer Size 12 MB
Color Lookup Table 1024 entries
Bits Per Pixel 8, 16 or 24 (software configurable)
Dynamic Color Plane Groups 24
Drawing Processor Number Nine PCI graphics accelerator
PCI Interface 33 MHz, 32-bit, Revision 2.1
Video Interface Red, green and blue at RS-343 levels (50 ohm)
Video Sync Separate sync at TTL levels (75 ohm)
Video Connector DB-13-W3
Temperature Rating 10 degrees to 50 degrees C (operating)
-10 degrees to 70 degrees C (non-operating)
Humidity Rating 10% to 90% (non-condensing)
Power Rating Less than 15 watts
Physical 12.283 inches x 4.2 inches (PCI long format)
Software Available
