Raptor DL-Lite Drivers for HP-UX
Installation and Reference
Manual
Copyright © 2005 Tech Source, Inc.
442 S. North Lake Blvd.
Altamonte Springs, FL 32701
[phone]
Publication #65-0261-05 Rev A June 22, 2005

Addendum Information
Date Released June 22, 2005
Changes made to:
REVISION
NUMBER
CHANGES DATE
A Initial Release 06-22-05
The Tech Source, Inc. logo, Tech Source, Inc. and Tech Source,
Inc. Raptor are trademarks of Tech Source, Inc. X Window System
is a trademark and product of X.org.
All other products or services mentioned in this document are
identified by the trademarks or service marks of their respective
companies or organizations. Tech Source, Inc. disclaims any
responsibility for any references to those trademarks herein.
All rights reserved. No part of this work may be reproduced in any
form or by any means without prior written permission of the
copyright owner.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by
the U.S. Government is subject to restrictions of FAR 52.227-
14(g)(2)(6/87) and FAR 52.227-19 (6/87); or DFAR 252.227-
7015(b)(6/95) and DFAR 227.7202-3(a).
The product described in this manual may be protected by one or
more U.S. patents, foreign patents, and/or pending patent
applications.
PREFACE
This publication documents the Tech Source, Inc. Raptor Drivers for
HP-UX Installation for use with the Tech Source, Inc. Raptor cards.
This manual is intended for users who incorporate the Tech
Source, Inc. Raptor cards into Hewlett Packard’s
workstations/servers. This is a guide to the installation of the
Raptor Drivers for HP-UX software. All systems vary to a degree.

Knowledge of the features of your system is helpful during the
installation process.
WARRANTY
The Raptor cards are warranted for one (1) year from date of
shipment. During the warranty period, Tech Source, Inc. will, at its
discretion, repair or replace a defective system product at its
expense. Freight charges associated with the repair or replacement
of products under warranty are to be shared by Tech Source, Inc.
and the customer. All customers, domestic and international, shall
bear the freight charges for the product return.
Tech Source, Inc. shall bear the outbound freight charges up to
$13.00 (USD) per returned product, whether domestic or
international. Any additional freight charge shall be the responsibility
of the customer. We suggest that you contact your dealer first with
any questions you may have about the product. Unlimited technical
support (via telephone/facsimile/email) is provided for one (1) year
from date of shipment. The installation of any Tech Source, Inc.
hardware/software product is the sole responsibility of the customer.
Tech Source, Inc. offers a continuing hardware/software support
program that provides telephone consultation and any required
hardware repair after the expiration of the warranty period. This is a
billable annual maintenance contract. Contact Tech Source, Inc. for
the available maintenance plans.
Customers will be charged an hourly rate plus materials ($300.00
USD minimum) for repairs and/or maintenance performed by Tech
Source, Inc. that are not covered by a Tech Source, Inc. warranty or
maintenance contract.
DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESSED
OR IMPLIED CONDITIONS, REPRESENTATIONS AND
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE
EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE
LEGALLY INVALID.

This page is intentionally left blank

TABLE OF CONTENTS
INTRODUCTION 1-1
1.1 Overview 1-1
1.2 Conventions 1-1
HARDWARE INSTALLATION 2-1
2.1 Hardware Configurations Supported 2-1
2.2 Installation instructions 2-1
SOFTWARE INSTALLATION 3-1
3.1 Requirements 3-1
3.2 CD-ROM Installation 3-1
3.2.1 Installation on HP-UX 10.20 3-1
3.2.2 Installation on HP-UX 11.0 3-2
3.2.3 Installation on HP-UX 11i 3-3
3.2.4 Mounting the CD-ROM Manually 3-4
3.3 New Devices 3-5
3.4 Device Resolution 3-6
INVOKING X WINDOWS 4-1
4.1 Overview 4-1
4.2 Configuring X Windows 4-1
4.2.1 Single Screen Mode 4-1
4.2.2 Multi-Screen Mode 4-2
4.3 Setting Bit-Depth 4-2
4.3.1 Config File 4-3
4.3.2 STARSMODE Variable 4-3
4.4 startx 4-4
4.5 xinit 4-4
4.6 Common Desktop Environment (CDE) 4-5
UNINSTALLLING RAPTOR DRIVERS FOR HP-UX 5-1
5.1 Uninstalling Raptor Drivers 5-1
TECHNICAL ASSISTANCE 6-1
6.1 Who To Call For Help 6-1
6.2 Email Address 6-1
6.3 Website 6-2
CARD SPECIFICATIONS A-1
A.1 Raptor DL-Lite Specifications A-1

This page is intentionally left blank

1-1
Chapter 1
INTRODUCTION
1.1 Overview
Thank you for purchasing a Tech Source, Inc. Raptor DL-Lite
graphics card for use with your HP-UX workstation/server. This
manual describes the installation and configuration of the Raptor
DL-Lite graphics card and the accompanying device driver software.
The Raptor DL-Lite graphics card supports 2560x1600 resolution
and drives the Apple 30-inch Cinema HD Display Flat Panel.
The graphics card supports B, C and J-class HP workstations. The
supported HP-UX versions include 10.20, 11.0 and 11i.
The Raptor DL-Lite Drivers for HP-UX software is provided on a
CD-ROM. It consists of:
•Raptor device-drivers for HP-UX
•X Windows loadable module (DDX) for Raptor DL-Lite
graphics card
All systems vary somewhat, therefore some knowledge of the
features of your system and a basic understanding of HP-UX are
helpful during the software installation process.
From this point forward, Tech Source, Inc. will be referenced as
Tech Source or TSI and all Raptor models will be referred to as
Raptor cards.
1.2 Conventions
This manual will follow certain conventions throughout.
Whenever a variable name, command name, directory, or file name

Raptor DL-Lite/HP-UX Installation and Reference Manual
1-2
is used in a paragraph, they will appear in a mono-spaced font.
At times the reader will be instructed to enter commands at a
prompt. In this case a transcript of a sample session will be
provided where a prompt will be followed by the commands the
reader is to enter. The entire transcript will be in a mono-spaced
font with the prompt in a normal weight and the user's entries in
bold.
The prompt used in a transcript varies depending on the
circumstances. The following are some common prompts and
when they are used:
prompt# used when the user is required to have root
privileges
prompt% used when the user is not required to have root
privileges

2-1
Chapter 2
HARDWARE INSTALLATION
2.1 Hardware Configurations Supported
The Raptor DL-Lite graphics cards have been tested on and
currently support the following PCI based HP workstations/servers:
•HP B-class
•HP C-class
•HP J-class
2.2 Installation Instructions
Installing a Raptor card is simple and consists of a few easy steps.
Step 1: Shut down the system and turn the power OFF. Remove
the system’s cover along with any cables that prevent you
from doing so. Find an available PCI slot, and remove the
bracket and screw. Ground yourself by touching the metal
part of the case.
Step 2: Install the Raptor card firmly into the PCI slot. Take care to
press it evenly and snugly into the slot. Once you are
certain the card is installed properly in the slot, secure it
with the bracket screw.
Step 3: Secure the system’s cover and reattach any previously
removed cables.
Step 4: Connect the Dual Link DVI cable from the Apple HD panel
NOTE: Remember which cables go to which connectors. You
may want to label the cables and connectors before
disconnecting them.

Raptor DL-Lite/HP-UX Installation and Reference Manual
2-2
to the Raptor DL-Lite card.
The Raptor card is now installed and the system is ready for
software installation. Chapter 3 covers the software installation
procedures.
NOTE: At most, one Raptor card can be installed in a 64-bit PCI
slot on a HP C-360 workstation. If multiple Raptor cards are
required, install remaining cards into 32-bit slots. Other HP
machines do not have this restriction.

3-1
Chapter 3
SOFTWARE INSTALLATION
3.1 Requirements
The following are prerequisites for installing the Raptor DL-Lite
Drivers for HP-UX software:
•The workstation/server is running HP-UX 10.20, HP-UX 11.0 or
HP-UX 11i
•Any previous versions of Raptor software have already been
uninstalled.
•At least 5MB of disk space available in /usr for drivers.
•A Raptor card is presently installed in the workstation/server
(See Chapter 2 for installing a Raptor graphics card).
The kernel will be rebuilt during installation.
3.2 CD-ROM Installation
The installation for each version of the HP-UX operating system is
discussed separately in the following sections.
3.2.1 Installation on HP-UX 10.20
The following are step-by-step instructions for installing the Raptor
Drivers for HP-UX 10.20 software from a CD-ROM.
1. Install a supported Raptor card in the HP workstation/server,
and boot the system.
2. Log in as root on the target system, using /sbin/sh as your
shell.
3. Uninstall any previous version of Raptor software in accordance

Raptor DL-Lite/HP-UX Installation and Reference Manual
3-2
with the instructions supplied with that software.
4. Insert the CD-ROM labeled “Raptor Drivers for HP-UX" into the
drive.
5. Run swinstall. Accept all the path defaults.
6. The swinstall program will automatically try to locate,
mount, and read any CD-ROM device present. If the program
is successful, it will display TSIRDHPUX_10 and
TSIFTHPUX_10. If this is not displayed, please proceed to the
section titled, “Mounting the CD-ROM Manually.” See Section
3.2.4.
7. Move the cursor down to the TSIFTHPUX_10 package and
highlight it by pressing <space>.
8. Press <tab> to activate the menu bar. Move the cursor across
to 'Actions' and press <Enter>. Move the cursor down to
'Install (analysis)' and press <Enter>.
9. Follow the on-screen instructions to complete installation. If
any warnings or errors are reported, check the Logfile (default:
/var/adm/sw/swagent.log), correct the errors, then
continue.
3.2.2 Installation on HP-UX 11.0
The following are step-by-step instructions for installing the Raptor
Drivers for HP-UX 11.0 software from a CD-ROM.
1. Install a supported Raptor card in the HP workstation/server,
and boot the system.
2. Log in as root on the target system, using /sbin/sh as your
shell.
3. Uninstall any previous version of Raptor software in accordance
with the instructions supplied with that software.

Chapter 3 - Software Installation
3-3
4. Insert the CD-ROM labeled “Raptor Drivers for HP-UX" into the
drive.
5. Run swinstall. Accept all the path defaults.
6. The swinstall program will automatically try to locate,
mount, and read any CD-ROM device present. If the program
is successful, it will display TSIRDHPUX_11 and
TSIFTHPUX_11. If this is not displayed, please proceed to the
section titled, “Mounting the CD-ROM Manually.” See Section
3.2.4.
7. Move the cursor down to the TSIFTHPUX_11 package and
highlight it by pressing <space>.
8. Press <tab> to activate the menu bar. Move the cursor across
to 'Actions' and press <Enter>. Move the cursor down to
'Install (analysis)' and press <Enter>.
9. Follow the on-screen instructions to complete installation. If
any warnings or errors are reported, check the Logfile (default:
/var/adm/sw/swagent.log), correct the errors, then
continue.
3.2.3 Installation on HP-UX 11i
The following are step-by-step instructions for installing the Raptor
Drivers for HP-UX 11i software from a CD-ROM.
1. Install a supported Raptor card in the HP workstation/server,
and boot the system.
2. Log in as root on the target system, using /sbin/sh as your
shell.
3. Uninstall any previous version of Raptor software in accordance
with the instructions supplied with that software.

Raptor DL-Lite/HP-UX Installation and Reference Manual
3-4
4. Insert the CD-ROM labeled “Raptor Drivers for HP-UX" into the
drive.
5. Run swinstall. Accept all the path defaults.
6. The swinstall program will automatically try to locate,
mount, and read any CD-ROM device present. If the program
is successful, it will display TSIFTHPUX_11i. If this is not
displayed, please proceed to the section titled, “Mounting the
CD-ROM Manually.” See Section 3.2.4.
7. Move the cursor down to the package and highlight it by
pressing <space>.
8. Press <tab> to activate the menu bar. Move the cursor across
to 'Actions' and press <Enter>. Move the cursor down to
'Install (analysis)' and press <Enter>.
9. Follow the on-screen instructions to complete installation. If
any warnings or errors are reported, check the Logfile (default:
/var/adm/sw/swagent.log), correct the errors, then
continue.
3.2.4 Mounting the CD-ROM Manually
When run, the "swinstall" program will automatically try to
locate, mount, and read any CD-ROM device present. If it fails,
you may need to mount the CD-ROM by hand.
1. Login as root.
2. Create a mount point, if one does not exist.
# mkdir /CD-ROM
3. Identify the CD-ROM drive device file.
# ioscan -fnC disk
This will display all recognized hard drives and CD-ROM devices.

Chapter 3 - Software Installation
3-5
From that list, select the appropriate entry, and make note of the
associated device file (e.g. /dev/dsk/c1t2d0 ).
4. Mount the device on the mount point created in step 2.
# mount -r /dev/dsk/c1t2d0 /CD-ROM
(Replace /dev/dsk/c1t2d0 with your device file from step 3.)
5. Verify that you can read the CD-ROM.
# ls /CD-ROM
6. Initiate "swinstall" and specify your mount point as the
source depot.
# swinstall -s /CD-ROM
7. Move the cursor down to the desired package and highlight it
by pressing <space>.
8. Press <tab> to activate the menu bar. Move the cursor across
to 'Actions' and press <Enter>. Move the cursor down to
'Install (analysis)' and press <Enter>.
9. Follow the on-screen instructions to complete installation. If
any warnings or errors are reported, check the Log file (default:
/var/adm/sw/swagent.log), correct the errors, then
continue.
3.3 New Devices
One new device name is created in the /dev directory for each
installed Raptor card. It is denoted by rapdlt#, where #
represents an instance number assigned by the operating system.
If the Raptor card was not present in the system during software
installation, or if for some other reason the device nodes are not
created, or if any Raptor cards are added to or removed from the

Raptor DL-Lite/HP-UX Installation and Reference Manual
3-6
system after the software has been installed, then the Raptor
drivers must be reconfigured in order to create the proper device
nodes under /dev (i.e. /dev/rapdlt0, /dev/rapdlt1, etc.). To
reconfigure the Raptor drivers, issue the following two commands:
On HP-UX 10.20:
# swconfig -u TSIFTHPUX_10
# swconfig TSIFTHPUX_10
On HP-UX 11.0:
# swconfig -u TSIFTHPUX_11
# swconfig TSIFTHPUX_11
On HP-UX 11i:
# swconfig -u TSIFTHPUX_11i
# swconfig TSIFTHPUX_11i
3.4 Device Resolution
The resolution for Raptor DL-Lite card is fixed at 2560 x
1600@60Hz.

4-1
Chapter 4
INVOKING X WINDOWS
4.1 Overview
There are several ways to invoke X Windows on your system:
•startx
•xinit
•Common Desktop Environment (CDE)
This section assumes the use of the csh environment. If you prefer
a different shell, make the appropriate changes from the examples.
All of the examples in this section, the device name /dev
/rapdlt0 is used. Your device name may differ, depending on
the instance number. Please refer to Section 3.3 for specific device
names.
4.2 Configuring X Windows
4.2.1 Single Screen Mode
Under HP-UX, the devices that X Windows will use are configured
in the file /etc/X11/X0screens. This file is used by the X Server
regardless of how it is invoked (e.g. startx, xinit, CDE, etc).
Edit the file /etc/X11/X0screens to configure display 0. For
display 1you would edit /etc/X11/X1screens.
This section assumes that display 0is to be configured. To run X
Windows on the Raptor card only, comment out /dev/crt in
/etc/X11/X0screens by placing a '#' at the beginning of that
line, and add the Raptor device by entering Screen
/dev/rapdlt0 on a new line:
#Screen /dev/crt
Screen /dev/rapdlt0

Raptor DL-Lite/HP-UX Installation and Reference Manual
4-2
4.2.2 Multi-Screen Mode
To run X Windows on the console and the Raptor card, list the
devices in the order you wish to register them with X. The first
device listed will be screen :0.0; the next, screen :0.1.
Screen /dev/crt
Screen /dev/rapdlt0
NOTE: Multi-screen mode can be configured with multiple Raptor
cards only if the cards are not of the same type.
4.3 Setting Bit-Depth
Raptor DL-Lite supports the following bit-depths:
88-bit PseudoColor
24 24-bit TrueColor
8+24 Simultaneous 8-bit PseudoColor and 24-bit
TrueColor
8+8 Two 8-bit PseudoColor visuals
By default, X Windows comes up in 8-bit mode.
There are two ways to set bit-depth:
•By editing the config file /var/X11/TSIScreenConfig
•By setting the environment variable STARSMODE
The default visual in 8+24-bit mode is PseudoColor. In order to set
the default visual in the 8+24-bit mode to TrueColor, the
/etc/X11/X0screens file needs to be modified. The example
below shows how to set the default visual to TrueColor for the card
rapdlt0.
Screen /dev/rapdlt0
DefaultVisual
Class TrueColor

Chapter 4 – Invoking X Windows
4-3
NOTE: This method of setting the default visual has an effect only
in the 8+24-bit mode.
4.3.1 Config File
The depth of the Raptor card can be set using the
/var/X11/TSIScreenConfig file. Each row in the file
corresponds to a specific Raptor card that is identified by its device
name. The fields in each row are separated by spaces. In the
sample config file shown below the bit-depth of the Raptor
(rapdlt0) card is set to 8+24. The cached pixmap field is used for
debugging purposes only and should always be set to 1. The other
fields are irrelevant for this product.
# device Depth Resolution Sync Cached Resfile
pixmap
rapdlt0 8+24 DEFAULT 1 1 trzresinfo
4.3.2 STARSMODE Variable
The bit-depth of the Raptor card can be set using the STARSMODE
environment variable. This variable should be set before starting up
the X server.
For example, set the bit-depth of the Raptor card to 8+24
#setenv STARSMODE +8+24
To set the bit-depth of the Raptor card to 8+8
#setenv STARSMODE +8+8
Other bit-depths can be selected in a similar manner.
In a multi-screen configuration of Raptor cards, this method will set
the bit-depth of all the screens to the same value.
NOTE: In the case when both the methods to set bit-depth are
used, the STARSMODE variable takes precedence over the settings
in the TSIScreenConfig file.

Raptor DL-Lite/HP-UX Installation and Reference Manual
4-4
4.4 startx
This is the easiest way to start up the X Window System server.
The startx script is provided in /usr/contrib/bin/X11
directory.
To start up the X server in the default mode type:
prompt% startx
You may add command line arguments to the end of the line.
4.5 xinit
The xinit program can be directly used to start the X Window
System server. The xinit format is as follows:
xinit [[client] options] [ -- [server]
[display] options ]
If no specific client program is given on the command line, xinit
will look for a file in the user's home directory called .xinitrc to
run as a shell script to start up client programs. If no such file
exists, xinit will use the following as a default:
xterm -geometry +1+1 -n login \
-display :0
If no specific server program is given on the command line, xinit
will look for a file in the user's home directory called .xserverrc
to run as a shell script to start up the server. If no such file exists,
xinit will use the following as a default:
X :0
Note that this assumes that there is a program named X in the
current search path.
