Tech Source RAPTOR 1100T User manual

Raptor 1100T Features
•1920 x 1200 Resolution
•Drives a wide variety of monitors
including HDTV
•8/16/24/32-Bits Per Pixel
•32 MB Frame Buffer
•32 Independent Overlays
•2560 Dynamic Colors
•Single Slot PCI Long Card
•Supports Transparency &
Translucency
Markets
•Air Traffic Management
•Vessel Traffic Control
•Command & Control
•Satellite Imaging
Platforms
•Sun Ultra Workstations
•Digital Alpha Workstations
•Linux based platforms
Product Brief
Raptor 1100T
1920 x 1200 Color Video Graphics Adapter
The Tech Source Raptor 1100T high
resolution graphics accelerator
combines in a single slot PCI card a
comprehensive array of high-end
display subsystem features. The
Raptor 1100T uses Tech Source's
state-of-the-art graphics technology and
addresses all requirements specific to tar-
get markets like Air Traffic Management,
Vessel Traffic Control and other
Command & Control applications. Its
high level of integration achieves extreme
flexibility over a wide range of functions.
With 32MB of on-board framebuffer and
an efficient memory manager, the card
offers excellent drawing performance
with minimum host CPU usage. The card
provides 2560 independent dynamic col-
ors. That's ten times the number of in-
dexed colors available on traditional
graphics systems. Specialized layering
hardware allows for complete control of
up to 32 independently addressable
overlays with dynamic layer priority ad-
justment. This hardware supports both
transparency & translucency (blending).
The Raptor 1100T can also be configured
in a 24-bit True Color mode for other
high resolution image viewing applica-
tions.
The Raptor 1100T offers excellent 2D
acceleration for polygons, text, lines,
copy and other windowing operations.
This provides seamless ability to manage
over 5000 targets/tracks in real time.
Another feature of this high performance
product is the specialized fill hardware
that performs back buffer screen erases
at an extremely high speed. The video
output quality of the Raptor 1100T has
been meticulously fine tuned and is easily
the best among all graphics
products in this industry.

3340 Edgewater Dr.
Orlando, FL 32804
407.262.7100
www.techsource.com
Tech Source, the Tech Source logo, and Raptor 1100T are trademarks of Tech Source, Inc. All other trademarks are the property
of their respective owners. ©2002 Tech Source, Inc. All rights reserved. Information in this document is subject to change
without notice. Tech Source, Inc. assumes no responsibility for errors or omissions that may appear in this document.
Raptor 1100T Technical Specifications
Raptor 1100T PCI video graphics adapter, 1920 by 1080 color resolution, 32 MB frame buffer
includes DB-13-W3 to 4BNC or 5BNC video cable, operating system specific device
driver software and manuals.
X Window System with MOX on Solaris, Tru64, Linux and Windows 2000
(Multiple Overlay Extension)
Specifications
Frame Buffer Size 32MB SGRAM
PCI Interface 33/66 MHz, 32/64-bit, Revision 2.2
Video Interface Red, Green and Blue, at RS-343A (75 ohm)
Video Sync Separate or composite syncs at TTL levels, (75 ohm)
Video Connector DB-13W3
Temperature Rating 100to 500C (operating)
-100to 700C (non-operating)
Humidity Rating 5% to 90% (non-condensing)
Power Consumption Less than 25W
Dimensions 312 mm x 107 mm (12.28” x 4.2”)
Software Available
March 8, 2006
