Tech Source Raptor 4000-R User manual

High Resolution Color Video Graphics Adapters
FEATURES
To see the big picture, ATC and defense require efficient display of airspace.
The Raptor 4000‑R and 4000e‑R hardware
video rotation offers new display options
for greater efficiency through highly
configurable resolution support
including 1600 × 2560 portrait
mode.
•256MBframebuffer
•Hardwarevideorotation
•Multi-moderesolutionsupportand
layering via 8+8, 8 bit, 24 bit, 8+24 &
MOXmodes
•DVI-I×1(digital/analog)
•PCIandPCIExpress(shortcard)versions
•Comprehensivecustomercareincluding
long‑term technical support
•SupportforLinux,Solaris&Tru64
Hardware Video Rotation
The Raptor 4000-R and 4000e-R are the indus-
try’s only boards to offer portrait mode display for
monitors of up to 30" without sacrificing advanced
feature sets. These include 32 independent MOX
(Multiple Overlay eXtension) overlays and 8+8 video
mode supported on legacy ATC systems including
Tru64 UNIX and Solaris. They also offer these
same features to customers porting their applica-
tions to installations using Linux.
Maximum Performance and Flexibility
With 256 MB of on-board memory and an efficient
memory manager, the boards offer excellent draw-
ing performance and optimal pixmap management
with minimum host CPU usage. These products
offer maximum flexibility, supporting more video
modes than any other graphics boards currently
on the market. In addition, traditional video
modes such as 8 bit, 24 bit and 8+24 are available
and selection is easily achieved through software
configuration.
2K × 2K
PrimaryMonitor
30"PrimaryorAuxiliary
MonitorwithPortraitRotation

Specifications
© 2008 Tech Source, Inc.
All product names are trademarks or registered trademarks of their respective companies. Raptor and
Tech Source are trademarks of Tech Source, Inc. EIZO and FlexScan are registered trademarks of Eizo
Nanao Corporation.
Specifications are subject to change without notice.
442 Northlake Blvd
Altamonte Springs, FL 32701 USA
Phone: [phone]
www.techsource.com
High Resolution Color Video Graphics Adapters
Backward Compatibility
The boards are backward compatible with their
predecessors such as the Raptor DL-Lite, so custom-
ers can maintain the same functionality they are
accustomed to while enjoying the new features of
these boards.
Innovative Cooling System
Graphics board GPUs must be sufficiently cooled at
all times not only to ensure optimum performance,
but more importantly, to protect them from failure.
While most cards rely on cooling fans that may wear
out over time, the Raptor 4000-R and 4000e-R
employ an innovative passive heatsink. This increases
reliability while eliminating downtime and expense
required for fan inspections and maintenance.
Wide-Ranging Support
The Raptor 4000-R and Raptor 4000e-R support
drivers for Solaris, Linux and Tru64 UNIX. These
drivers are easy to install and are backed by our
renowned technical support. Because our drivers are
developed in-house, Tech Source is responsive to cus-
tomer needs, and in the unlikely event of a problem,
customers can contact an engineer directly.
Longest Product Life in its Class
While most vendors’ products are only available for
one or two years, Tech Source guarantees Raptor
4000-R and 4000e-R availability for at least five
years and support for at least ten years. For system
integrators, OEMs, and ATC centers, this means sig-
nificant savings on development costs by reducing the
frequency of configuration re-testing that is necessary
when replacing old cards with new ones.
About Tech Source
Tech Source, Inc. has provided computer graphics
hardware solutions to the ATC and military markets
for over 20 years. Tech Source is a subsidiary of Eizo
Nanao Corporation, a leading global manufacturer
of high-end display monitors. The companies offer
combined expertise, cutting-edge graphics solutions,
and complimentary product lines for ATC, defense,
and other markets.
Raptor 4000-R Raptor 4000e-R
Frame Buffer Size 256 MB
MOX Hardware Tech Source MOX Functionality; 32 layer management
Color Lookup Table 2048 entries from a palette of 16.7 million colors +
2 AUX 256
Graphics Modes 8 bit, 24 bit, 8+8, 8+24, MOX 16, MOX 24, MOX 32
(software configurable)
Dynamic Color Plane Groups 32
Interface 33/66 MHz 32/64-bit
Revision 2.2
PCI Express 1x, Compliant
with PCI Express Base Spec
Video Connectors Dual Link DVI-I × 1 (Second port not active)
Maximum Supported
Resolutions
Digital: 2560 × 2048
Analog 2048 × 2048
Temperature Rating 10° to 50° C (operating)
-10° to 70° C (non-operating)
Humidity Rating 10% to 90% (non-condensing)
Power Rating Less than 25 watts
Dimensions (L × W) 174.6 mm × 106.7 mm 167.7 mm × 111 mm
Software Environments* • Sun Microsystems Solaris
• Solaris x86
•HP Tru64 UNIX
•Linux Red Hat
•HP Tru64 UNIX
* Please contact for further details or additional environments.
