Raptor 2500T-DL Features
•2048 x 2048 Resolution
•8/16/24/32-Bits Per Pixel
•64 MB Frame Buffer
•32 Independent Overlays
•2560 Dynamic Colors
•Single Slot PCI Card
•Transparency & Translucency
•8+24 Bit Mode
•8+8 Bit Mode
Markets
•Air Traffic Management
•Vessel Traffic Control
•Command & Control
•Remote Auction Art
Platforms
•Sun Desktops/Servers
•Digital Alpha Workstations
•HP B,C & J-Class Workstations
•IBM RS/6000 Machines
•Linux based PCs
•Windows 2000
Product Brief
Raptor 2500T-DL
2048 x 2048 Color Video Graphics Adapter
The Tech Source Raptor 2500T-DL
graphics accelerator combines on a single
slot PCI card, a comprehensive array of
high-end display subsystem features. The
Raptor 2500T-DL uses Tech Source's
state-of-the-art graphics technology and
addresses all the specific requirements of
target markets like Air Traffic Manage-
ment, Vessel Traffic Control and other
Command & Control applications. Its
high level of integration achieves extreme
flexibility over a wide range of functions.
With a resolution of 2048x2048, it is de-
signed to work with high resolution digi-
tal flat panels that replace the Sony DDM
monitors.
With 64MB of on-board memory and an
efficient memory manager, the card
offers excellent drawing performance
with minimum host CPU usage. The
card provides 2560 independent
dynamic colors. That's ten times the
number of indexed colors available on
traditional graphics systems. Specialized
layering hardware allows for complete
control of up to 32 independently
addressable overlays with dynamic layer
priority adjustment. This hardware
supports both transparency & translu-
cency (blending). The card can also be
configured in a 24-bit True Color mode
for Remote Auction Art and other high
resolution image viewing applications. A
mode that supports 8 bit & 24 bit simul-
taneous visuals is also available.
The Raptor 2500T-DL offers excellent
2D acceleration for polygons, text, lines,
copy and other windowing operations.
This provides seamless ability to manage
over 5000 targets/tracks in real time.
Another feature of this high perform-
ance product is the specialized fill hard-
ware that performs back buffer screen
erases at an extremely high speed. The
video output quality of the Raptor
2500T-DL has been meticulously fined
tuned and is easily the best amongst all
graphics products in its category.

3340 Edgewater Dr.
Orlando, FL 32804
407.262.7100
www.techsource.com
Tech Source, the Tech Source logo, and Raptor 2500T-DL are trademarks of Tech Source, Inc. All other trademarks are the
property of their respective owners. ©2005 Tech Source, Inc. All rights reserved. Information in this document is subject to
change without notice. Tech Source, Inc. assumes no responsibility for errors or omissions that may appear in this document.
Raptor 2500T-DL Technical Specifications
Raptor 2500T-DL PCI video graphics adapter, 2048 by 2048 color resolution, 64 MB frame buffer, operating system
specific device driver software and manuals.
•Sun Microsystems Solaris 7, 8 and 9
•HP Tru64 UNIX V4.0f and higher
•HP-UX V10.20, 11.0 & 11i
•IBM AIX 4.3.3, 5.0, 5.1, 5.2 & 5.3
•Linux Red Hat & SUSE (various versions)
•Windows 2000 and XP
Specifications
Color Lookup Table 2048 entries from a palette of 16.7 million colors + 2 AUX 256
Bits Per Pixel 8, 16, 24 or 32 (software configurable)
Dynamic Color Plane Groups 32
PCI Interface 33/66 MHz 32/64-bit Revision 2.2
Video Connector Dual link DVI
Temperature Rating 100to 500C (operating)
-100to 700C (non-operating)
Humidity Rating 10% to 90% (non-condensing)
Power Rating Less than 25 watts
Physical 12.283 inches x 4.2 inches (PCI long format)
Frame Buffer Size 64MB
Software Environments Supported
January 18, 2006
