TECHLIGHTING Revel Pathway User manual

1.1
Installation Instructions for
Revel Pathway
700OARVL_
1
920OAREVEL
GP I :ENERAL RODUCT NFORMATION
This product is suitable for wet locations.
12VAC input only.
If using Tech Lighting magnetic transformers, this product be
dimmed with a low-votage magnetic dimmer. For all other
transformers, consult with the manufacturer for compatible
dimmers.
1A
Loosen the four set screws on fixture(Do Not Remove)
base with the provided Allen wrench and remove the
base plate.
1
Prepare the Fixture
CAUTION RISK OF FIRE-
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
OUTDOOR
ALLEN
WRENCH
1
1
1 1
For Stake Install - see section 2
For Concrete and
other Hard Surfaces
INSTALLATION OPTIONS:
- see section 3
2A
Attach the stake to the base plate by tightly screwing
down the provided stake bolt through the center hole
of the base plate and the stake.
Reattach the base plate assembly to fixture and tighten
down the set screws (reversal of Section 1A).
1
STAKE
STAKE BOLT
BASE PLATE
BASE PLATE
SET SCREW
2
Install the Fixture using a Stake
WARNING – Risk of Electric Shock. Install all luminaires
10 feet (3.05 m) or more from a pool, spa, or fountain.
Unit low voltage cable is to:
a) be protected by routing in close proximity to the
luminaire or fitting, or next to a building structure such
as a house or deck;
b) not be buried except for a maximum 6 inches (15.2
cm) in order to connect to the main low voltage cable;
and
c) have the length cut off so that it is connected to a
connector within 6 inches (15.2 cm) from a building
structure, a luminaire, or fitting.

2
2B
3
4
Bring the power wires to the fixture location in
accordance with local electrical codes.
Connect the white fixture wire to one of the low-
voltage power line wires with the provided outdoor
waterproof wire nut.
Connect the black fixture wire to the remaining low-
voltage power line with the provided outdoor
waterproof wire nut.
5
3
54
2C
6Stake the fixture to the desired location and properly
bury the wire and wire nut connections.
Install the Fixture to Concrete
(or other hard surfaces)
1
2
Bring the power wires to the fixture location in
accordance with local electrical codes.
Mount the base plate to an even and smooth surface
using the template provided on last page. Ensure that
length of the lag bolts or anchor bolts do not exceed
.58” from the mounting surface in order to leave
enough clearance for the fixture to fit properly over the
base plate.
3B
3Unscrew the 10 connection box cover screws under the
fixture and remove the connection box cover.
Remove the provided strip of cord by first disconnecting
the 3 wire nut connections; save the wire nuts.
Warning: do not disconnect the output driver
connections.
Unscrew the cord grip’s dome nut (save the nut),
remove the provided cord strip, and discard of cord
properly.
4
5
CONNECTION
BOX COVER DOME NUT CORD GRIP
CONNECTION
BOX COVER
SCREW
CORD STRIP
3
4
4
5
3A
.58”
1
2
FIXTURE
BASE PLATE
BASE PLATE

Caulk around the power line/cord where it enters the
cord grip with waterproof construction sealant.
10
3D
Carefully place the power line/cord inside the fixture,
install the fixture onto the base plate, and secure it in
place by tightening down the set screws.
11
3E
ALLEN
WRENCH
11
SET SCREW
6
3C
CONNECTION
BOX COVER DOME NUT CORD GRIP
CONNECTION
BOX COVER
SCREW
POWER WIRES/
CORD
9
8
7
6
Feed the previously installed power wires / cord through
the cord grip and dome nut, then screw the dome nut
tightly onto the cord grip.
Connect the white driver wire to one of the low-voltage
power line wire with a wire nut.
Connect the black fixture wire to the remaining low-
voltage power line with a wire nut.
Carefully place all wires and wire nut connections into
the connection box and reinstall the cover (reversal of
step 3).
7
8
9
3
11

MOUNTING PLATE TEMPLATE
7400 Linder Ave, Skokie, IL 60077
847.410.4400
www.techlighting.com
© 2016 Tech Lighting, L.L.C. All rights reserved. The "Tech Lighting" graphic is
a registered trademark of Tech Lighting, L.L.C. Tech Lighting reserves the right
to change specifications for product improvements without notification.
A Generation Brands Company
SAVE THESE INSTRUCTIONS!
4
WARNING: If printing this template, ensure printer settings
are set to actual size.
