Technaxx FMT300BT User manual

1
FMT300BT User Manual
Before using the device please read this user manual accurately.
Accessories: FMT300BT, Remote control for the steering wheel, Remote control for
manual mode,Audio cable 3.5 to 2.5 jack, Earphones, Fuse, User Manual
FMT300BT Feature
1. MP3 FM-Transmitter and Bluetooth hands-free talking for the car, compatible
with nearly all Bluetooth mobile phones.
2. CVC-technology for clearly speaking (restrain noise & echo).
3. Excellent sound quality with full Duplex Communication.
4. Priority: Bluetooth call Bluetooth music Line-in SD / USB.
5. Plays music from mobile phone via Bluetooth.
6. Mute function (music) for enjoyable speaking comfort.
7. Re-dial function* & voice-dial function* (* depend on mobile phone functions).
8. Automatically bluetooth connection (after first adjustment).
9. Equalizer-mode & Repeat-mode.
10. Function for folder and file selection.
11. Steering wheel remote control – and hand remote control.
12. Flexible, rotatable axis of device easily operated.
Technical Parameters
Bluetooth interface: Version 2.1, Class 2
Bluetooth frequency range: 2.402 ~ 2.480 GHz
Supported Bluetooth profiles: HSHF, Headset, A2DP
FM-transmitting frequency: 88.1 ~ 107.9 MHz
Operating voltage range: DC 12V ~ 24V (car cigarette lighter socket)
Charger output range: 5V DC, 1.5A
Microphone: Integrated with noise elimination
Supported memory format: SD / SDHC / MMC / USB
Display: LCD display with blue light
Supported Audio In / Audio Out: 2,5 mm
DSP (Digital Signal Processing) technology: Echo elimination
Background noise reduction

2
Installation
1. Insert the unit into the cigarette lighter socket.
2. Adjust the transmitting frequency of the FMT300BT to the corresponding channel
between FM 88.1 ~ 107.9 MHz.
3. Set the car radio unit to the same frequency as the FMT300BT.
Then the unit can play the music from a USB Flash Drive, a SD / SDHC / MMC
memory card or another audio source (through the audio-in).
Bluetooth Function Operations
(Pairing the device with a Bluetooth enabled mobile phone)
1. First set the FMT300BT (without memory card / without USB flash drive) in
ON status.
2. Press PLAY button for a longer time (at the unit directly or at the remote control)
until screen display shows “PAIRING” – indicating that the unit is ready to
be paired.
3. Set the Bluetooth mobile phone to search for Bluetooth devices.
The mobile phone displays “FMT300BT” in the list of available devices.
When using a “dongle-type” Bluetooth adapter, please follow the
manufacturer’s instructions for that device.
4. Select “FMT300BT” to pair with.
5. Put in the PIN Code “0000” at your mobile phone and it shows that pairing is
completed. When pairing is successful completed the FMT300BT screen
displays “Pair OK” and the Bluetooth icon is shown on the screen.

3
Operations at the FMT300BT
Play Play music under “Playing mode”
Answer a call Press once to answer a call under
“Speaking” mode
Pairing Press and hold for min. 3 seconds
“PAIRING” appears at the display
PLAY (►)
Stop Stop to play music under “Playing” mode
Adjust the FM
frequency Press short under “Playing” mode
CH + (►|)
CH ▬(◄|)
Music folder
changing Press long skip to last or next folder
under “Playing” mode
Change song Press short skip to last or next song
under “Playing” mode
PRE ( )
NEXT ( )
Change volume Press long decrease (-) or increase
(+) volume level under “Playing” mode

4
Operations at the Steering Wheel Remote Control
ATTENTION ! Both remote controls operate via infrared signal. Therefore a
„visual contact“ between device and remote control is essential (!), if
necessary, easily turn device and remote control to each other.
Play Play music under “Playing” mode
Answer a call Press once to answer a call under
“Speaking” mode
Pairing Press and hold for min. 3 seconds
“PAIRING” appears at the display
PLAY / Pause /
Answer call /
Pairing ( )
Stop Stop to play music under “Playing” mode
Adjust the FM
frequency Press short under “Playing” mode
CH + (►|) L ast
CH ▬(◄|) Next
Music folder
changing Press long skip to last or next folder
under “Playing” mode
Change song Press short skip to last or next song
under “Playing” mode
Last song / VOL ▬
( |)
Next song / VOL +
(| )
Change volume Press long decrease (-) or increase
(+) volume level under “Playing” mode
Re-dialing last No. Press long under “Playing” mode to
re-dial the last outgoing call-No.
End or reject a call
Press long under “Speaking” mode to
end or reject a call
RED (working
when FMT300BT is
connected to a
Bluetooth enabled
mobile phone) Transfer a call Press once under “Speaking” mode to
transfer a call to a mobile phone

5
Operations at the 21 button Hand Remote Control
CH
(Channel Modulate)
Enter frequency
adjusting mode Press short to enter into the FM-channel
adjusting mode
Change EQ-mode Press short under “Playing” mode to
change the EQ-mode from NORMAL 
ROCK POP CLASSICLIVE
EQ /
Repeating Mode
Change Repeating
Mode Press long under “Playing” mode to
change the Repeating-mode from ALL
SINGLE FOLDER NORMAL 
RANDOM
MIC Mute
Mute Press short under “Speaking” mode to
mute or un-mute
Voice Switch
Transfer a call Press once under “Speaking” mode to
transfer a call to a mobile phone
Voice Dialing
Activate voice
dailing function Press once under “Speaking” mode to
activate (depends on the mobile phone)
Typing track No. Directly choose the wanted track No.
Number Buttons
Typing frequency Press short CH-button; then the
frequency No. can be typed in directly
(ONLY usable under “Playing” mode

6
Play Play music under “Playing” mode
Answer a call Press once to answer a call under
“Speaking” mode
Pairing Press and hold for min. 3 seconds
“PAIRING” appears at the display
PLAY / Answer
call / Pairing /
Stop (►)
Stop Stop to play music under “Playing” mode
Adjust the FM
frequency Press short under “Playing” mode
CH + (►|)
Last Folder
CH ▬(◄|)
Next Folder
Music folder
changing Press long skip to last or next folder
under “Playing” mode
Change song Press short skip to last or next song
under “Playing” mode
Last song / VOL ▬
( |)
Next song / VOL +
(| )
Change volume Press long decrease (-) or increase
(+) volume level under “Playing” mode
Re-dialing last No. Press long under “Playing” mode to
re-dial the last outgoing call-No.
End or reject a call
Press long under “Speaking” mode to
end or reject a call
RED (working
when FMT300BT is
connected to a
Bluetooth enabled
mobile phone) Transfer a call Press once under “Speaking” mode to
transfer a call to a mobile phone
FMT300BT in a car FMT300BT close view

7
Replacing the Remote Control Battery (in both remote controls)
1) Remove the battery compartment cover by pulling the cover in the direction of
the arrow.
2) Remove the battery.
3) Insert the replacement battery.
Keep attention on the direction of the correct polarization (+/-).
4) Put the cover back to the battery compartment.
ICONs on the FMT300BT Display
Progress Indicator
File Name
Folder Name
Memory Type
Frequency
Repeat Mode
Bluetooth
Volume
Track Number
Elapsed Time

8
Different status shown on the FMT300BT display
FMT300BT is powerd ON
Audio-In connected
Pairing with Bluetooth
devices
Pairing is succussful
completed
Bluetooth enabled
(connected)
FM frequency
FM frequency
Bluetooth enabled
(connected)
Audio-In connected
Playing music from USB
drive

9
Playing music from SD
card
Adjusting volume
Changing music track
Adjusting FM frequency
Music is paused
Switching EQ mode
Switching REPEAT mode

10
Changing folder
Pressing CH button
Typing music track No.
Voice dailing
(depends on the voice
dailing function of the
mobile phone)
Playing music from a
mobile phone over the
Bluetooth connection

11
Important Notice
1. Use at voltage DC 12-24V ONLY! Other voltage could affect the accurate work
of the device or – in worst case – damage of the device.
2. When starting the car engine – DO NOT insert the device to the car-
cigarette-lighter socket. Only insert the device when the car engine is running.
3. Take the device out of car-cigarette-lighter socket when not using it.
4. Use the car’s speaker to control the volume, DO NOT adjust the device’s
volume too high or music may noise or distorted phenomenon may appear.
Decrease the music volume when noise, storm sound or distorted
phenomenon occurs.
5. Avoid local strong radio stations when choosing a channel – it could affect the
sound quality.
6. Check the device’s frequency – it should be the same as the car audio’s
frequency. When no music can be heard - turn the volume to a higher level. It
could also be that in that moment the car audio is not receive the music
[e.g. dead spot].
Check & Repair
1. If the device does not power on reason for that could be a defective fuse.
2. Therefore check the fuse first and, if necessary, replace it by a new fuse.

12
Security and Disposal Hints for Batteries
•Hold children off batteries. When a child swallowed a battery by mistake go to a
doctors place or bring the child into a hospital promtly!
•Never short batteries.
•Look for the right polarity ( + ) and (▬) of batteries! Always change all batteries, never
use old and new batteries or batteries of different typs together.
•Do NOT open, deform or load up batteries!
There is a risk of injury by batterie leakage fluid!
•NEVER throw batteries into fire! There is a risk of explosion!
•Take out exhausted batteries from the device.
•Take out batteries from the device when its not used over a longer period of time.
Hints for Environment Protection
Cleaning
Protect the device from contamination and pollution. Only clean the device with soft cloth or
drapery, avoid to use rough or coarse-grained materials. Do NOT use solvents or other
aggressive cleanser. Wipe the device after cleaning accurately.
Important Notice
Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry and put in a
new battery!
Packages materials are raw materials and can be recycled.
Separate the packages by types and recirculate them to an adequate recycling
on behalf of the environment.
More detailed information you get from your official civil service.
Do not disposal old devices into the domestic waste.
Disposal old / defective devices professionally!
The environment will be grateful for that.
Information regarding places for disposal and opening hours you get from your
official civil service.
Do not disposal batteries into the domestic waste.
Disposal old / empty / defective batteries professionally!
The environment will be more than grateful for that.
Information regarding places for disposal and opening hours you get from your
official civil service.
