Technaxx TrendGeek TG-HR1 User manual

TrendGeek®* User Manual
Fitness Wristband TG-HR1
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom “Konformitätserklärung”). Before using the device the first time, read
the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: [e-mail]
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Features
Wristband to monitor your heart rate, your fitness, your sleep &
your active phases
Displays: heart rate, steps, distances, burned calories, clock &
date
Easy handling via touch button
Notifications: reminders, calls, SMS, Email, social media, achieved
goals
Anti-lost function for the wristband
Vibrating function
Sleep monitoring & wake up with vibrating alarm
Bluetooth 4.0 BLE (Bluetooth Low Energy) connection ~10m
Free iOS and Android APP (FunDo Pro)
IP65 protection class (dust proof & sprayed water protection)
Especially suitable for outdoor activities
Gestures to display date and time

Technical specifications
Display
0.42” OLED display (72x40pixel)
Processor
BK3431Q
Heart rate sensor
LST1303
Protection class
IP65
Bluetooth / Distance
Version 4.0 BLE / ~10m
BT transmitting frequency
2.4GHz
BT max. radiated output power
2.5mW
Power supply
Built-in rechargeable 50mAh
Lithium-ion battery 3,7V
Charging time
~1 hour (use the enclosed USB cable with
an USB charging adapter)
Working time
~5 days (depends on use)
Standby time
~15 days
APP
FunDo Pro
Supported APP
languages
EN, DE, FR, ES, PT, IT, PL, NL, RU, TR,
JP, CN (8th June 2018)
Weight / Dimensions
18g / (L) 40.3 x (W) 15.7 x (H) 10.5mm
Wristband
(L) 16.5 –22.0cm x (W) 1.5cm
Storage temperature /
Operation temperature
–20°C up to 45°C
Material device / strap
ABS + PC / TPU
Package Contents
TrendGeek®Fitness Wristband TG-HR1,
USB charging cable, User Manual
Compatibility
Android 4.3 or above & iOS 8.0 or above
1. Charging
Plug the USB charging cable to the bracelet and the other side to an
USB power adapter* (*not included), like shown in the picture below.
Charging will automatically power on the bracelet.

Low battery
Charging
Full
2. Install FunDo Pro APP on your Smartphone
Search for „FunDo Pro“APP in Play Store/APP Store or scan the
following QR code for the installation.
APP Icon
Android
iOS
3. Connect the bracelet with the FunDo Pro APP
Wait until the bracelet is fully charged. Activate the Bluetooth of your
Smartphone. Than open the APP. Confirm all requests to get the
most out of the APP.

Press „Add device“under „More“and search for “TG-HR1”. Choose
“TG-HR1”from the list and you are ready. Now the bracelet is
connected with your Smartphone and the APP.
iOS
Android
Android
4. Start using
When the bracelet is connected to the APP successfully, it will be
synchronizing the time. Automatically count steps, distance and
calories. Press the Touch Button (circle) to scroll through each
screen on the display.
Time
Steps
Heart rate

5. Functions
Note: The following settings and the order of the settings can
differ under iOS and Android!
Me:
Set personal information: sex, height, weight, birthday
Shows the current progress, your best scores, the averages and
last week’s scores.
Analysis: Sum of steps and duration of sleep divided over the
last 7 days, 1 month, 6 month or 1 year.
APP Icon:
Shows the daily steps, calories, distance, active time, sleep and
heart rate.
Set step target (target flag)
By clicking on Sport, Sleep or Heart rate the monthly report with
evaluation is shown.
Sport, Sleep and Heart rate is synced automatically when the
FunDo Pro APP is opened on the Smartphone and the bracelet is
connected by Bluetooth.
Sleep is monitored automatically in the time from 9PM (21:00) to
9AM (09:00).
Important: Synchronisate the bracelet with APP once a day,
otherwise you will lose the recorded data. The bracelet always
resets the data of steps, distance, calorie and heart rate at 12AM
(00:00).
Report: Overview of your sleep rate and heart rate.
More:
Connect the bracelet with Bluetooth.
Notification: Set the needed notifications. The notifications
include incoming call, SMS, WhatsAPP, Facebook, FB Messenger,
Twitter, Instagram, etc. It will vibrate and display an icon.
Find device: Anti-lost function for the wristband. Wristband starts
vibrating.

Sedentariness Alert: Set the period and the time you want to be
reminded to move.
Reminder Mode: Set screen backlight On / Vibration / Backlight
& Vibration.
Alarm Clock: Once the alarm is set, its icon will be animated, the
screen backlight is on and vibrates several times.
Gesture Control:
#Mode Setup: After click and activate this function, you need to
select the bracelet is going to be put on left or right hand.
# # Raising Hand: While raising your hand, the screen will be lighting
up.
# # # Turning Wrist: While turning your hand, the screen will be
lighting up.
Note: Enable Hand up bright to activate the above settings
Not disturb: Set the time you do not want notifications on the
bracelet.
Firmware Information click on it to update the firmware of
bracelet.
Unit of measure [metric units (SI) or imperial units (BS)].
Unbinding will unbind the bracelet. No messages can be
received while unbound. Reconnect the Bluetooth again for syncing
and receiving messages.
6. Wristband disassembling

Hints
Bluetooth connection becomes disconnected when the Bracelet
exceeds a certain distance.
Reconnect with Bluetooth if bracelet does not sync data for more
than 5 minutes.
Safety instructions
Rebuilding or modifying the product impairs product safety. All
modifications and repairs of the device or accessories must be
performed by the manufacturer or by persons expressly authorized by
the manufacturer. Handle the product carefully. It can be damaged by
knocks, blows or even by falling from low height. Keep the product
away from damp, moisture and extreme heat. Never immerse the
product in water or other fluids. Technical specifications are subject to
change without notice. Never heat the battery above 60°C and do not
drop or throw it into the fire, danger of explosion/fire hazard! Do not
short-circuit the battery. Do not subject the battery to mechanical
stress. Avoid dropping, striking, bending, twisting or cutting the battery.
Discontinue the charging process immediately should the battery
become overheated. A battery that becomes overheated or deformed
during the charging process is defective and should no longer be used.
Never drain the battery completely, as this shortens its lifetime. It is
essential to observe the correct polarity of the battery. An incorrectly
inserted battery can result in destruction of the product, danger of fire
hazard. If the battery must be stored, it is recommended that it be
stored at 30% of its loading volume. Store out of direct sunlight. Ideal
storage temperature: 10–20°C. Keep the product away from little
children.
Enjoy your product * Share your experience and opinion on one of the
well-known internet portals such as Amazon or idealo.de
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany
