Techni-Lux VectorLED 160 Spot User manual

V
Ve ec ct to or rL LE ED D 1 16 60 0
S
Sp po ot t
Information specifically for:
DM-VectorLED160S
V1.0
This manual contains important information.
Please read before operating fixture.

2
© 2010 Techni-Lux Inc.

3
IMPORTANT INFORMATION
Save original packing and documentation for warranty, service and return issues.
Limited Warranty: This warranty covers defects or malfunctions in this equipment. This warranty lasts for
a period of one year from date of purchase. It is the owner’s responsibility to provide invoices for proof of
purchase, purchase date and dealer or distributor. If purchase date can not be provided, warranty period
will start at manufacture date. It is the sole discretion of Techni-Lux to repair or replace parts or
equipment. All shipping will be paid by purchaser. This warranty does not cover lamps, fuses, belts,
power semiconductors, relays, cleaning, standard maintenance adjustments or normal wear items or any
problem resulting from the following: improper wiring, incorrect voltage (including low or over voltage
conditions and lightning), abuse, misuse, improper maintenance or an act of God or damage resulting
from shipping. Warranty will be null and void if the product is altered, modified, misused, damaged, or
subjected to unauthorized repairs. Lamps are covered by relevant manufacturer warranty. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. Any
liability for consequential and incidental damages is expressly disclaimed. No other warranty, expressed
or implied is made. Techni-Lux liability in all events is limited to, and shall not exceed, the purchase
price paid.
Returning equipment and Repairs: All returns must be accompanied by a Return Merchandise
Authorization (RMA) number and sent pre-paid. Contact the dealer or Techni-Lux directly to obtain an
RMA. The RMA number must be clearly listed on the shipping label. Due care must be exercised in
packing all merchandise to be returned. All repairs must be accompanied by a written explanation of the
claimed problem or error encountered. Techni-Lux is solely responsible for determining a product’s
eligibility for coverage under warranty. If returning for consideration of credit, all accessories and
documentation, original protective material and cartons must be included and the equipment, packing
and carton must be in new resalable condition. Credit for returned merchandise will be issued at the
lowest current price and is subject to a restocking fee. No returns accepted on discontinued items.
Techni-Lux is not responsible for merchandise damaged in transit and reserves the right to refuse any
return that is damaged by the carrier, not accompanied by a Return Authorization Number (RMA#) or
sent by freight collect.
Claims: All claims must be made within seven (7) days of receipt of merchandise. Any physical damage
must be reported to carrier upon receipt of merchandise.
Please record the following information for future reference:
Model Number: DM-VectorLED160S
Serial Number: ________________________________________
Dealer: ______________________________________________
Date of Purchase: ______________________________________
www.Techni-Lux.com
10900 Palmbay Drive
Orlando, FL 32824
U.S.A.

4
Table of Contents
Specifications .............................................................................................................................5
Fixture Overview.......................................................................................................................5
Physical.....................................................................................................................................5
Lamp Source.............................................................................................................................5
Environmental...........................................................................................................................6
Electrical ...................................................................................................................................6
Control ......................................................................................................................................6
Optics........................................................................................................................................6
Gobo Size.................................................................................................................................6
Rigging......................................................................................................................................6
Unit Parts.....................................................................................................................................7
Unpacking ...................................................................................................................................8
Power...........................................................................................................................................9
Voltage Selection........................................................................................................................9
LED Engine .................................................................................................................................9
Mounting ...................................................................................................................................10
Control Panel Menu..................................................................................................................11
DMX-512 Start Address............................................................................................................12
DMX-512 Channel Assignment................................................................................................12
CH 1 : Shutter / Strobe / Reset ...............................................................................................13
CH 2 : Dimmer ........................................................................................................................13
CH 3 : Color Wheel.................................................................................................................13
CH 4 : Rotating Gobo Wheel...................................................................................................14
CH 5 : Gobo Rotation and Index.............................................................................................14
CH 6 : Focus...........................................................................................................................15
CH 7 : Prism / Prism Rotation .................................................................................................15
CH 8-11 : Pan / Tilt Position....................................................................................................15
CH 12 : Pan / Tilt Speed, Auto, Sound....................................................................................15
DMX-512 Background...............................................................................................................16
Data Link DMX-512.................................................................................................................17
Adapter 5-to-3 pin ...................................................................................................................17
Data Terminator......................................................................................................................17
Maintenance..............................................................................................................................18
Troubleshooting .......................................................................................................................19
Accessory Items.......................................................................................................................20

5
Specifications
Fixture Overview
•Long Life 60W LED Engine
•Pan range of movement: 540°
•Tilt range of movement: 270°
•High resolution 16 Bit Pan/Tilt movement for accurate positioning
•Pan/Tilt motor speed
•Consistent & auto correcting Pan/Tilt positioning
•Color wheel with 6+open dichroic colors
•Bi-directional Color wheel continuous rotation for rainbow effect
•Gobo wheel with 7+open rotating
•Continuous Gobo wheel rotation
•3-facet rotating prism, variable speed in both directions
•Beam angle 11°
•Motorized focus
•Digital shutter for 0 – 20 FPS strobing effects and quick blackouts
•Digital dimming 0-100% for smooth fades and even fields
•DMX512 Control thru 12 Channels and 3 pin In/Out XLRs
•Remote reset
•Digital display for DMX addressing and fixture settings
•Forced Air Ventilation
•Precision Anti-Reflective Coated Optics
•Luminous output: 720 lumen
•Light weight 18.7 pounds
Physical
Color Black
Width 12.8 in (32.5cm)
Depth 9.8 in (25.0 cm)
Height 15.8 in (40.1 cm)
Weight 18.7 lbs (8.5 kg)
Gross Weight 24 lbs (10.9 kg)
Lamp Source
Lamp Type Long Life 60W LED Engine
Lamp Specs 720 lumens

6
Environmental
Environmental Protection Rating IP20
Maximum ambient temperature 105°F (40°C)
Maximum exterior surface temperature 176°F (80°C)
Minimum distance to flammable surface 3.3ft (1m)
Minimum distance to illuminated surface 3.3ft (1m)
Electrical
Selectable Voltages Auto Switching 90-240v @ 50 or 60Hz
Connection IEC (C13) Power Inlet with Fuse
Rated Power 170W, 1.5A @ 115v
Fuses 5A Fast Blow Size: 5x20mm
Control
Protocol USITT DMX512 (1990)
Channels 12
Pan/Tilt Resolution 16 bit
Data I/O 3 Pin XLR (Cannon)
Modes Master / Slave / DMX
Optics
Lenses Precision Anti-Reflective Coated Optics
Beam Angle 11°
Gobo Size
Gobo Rotating Outside Diameter 0.984” (25mm)
Image Diameter 0.787” (20mm)
Rigging
Position Floor or Truss mount
Orientation Any
Mounting Omega clamp adapter with 0.5” hole

7
Unit Parts
1 Head
2 Yoke
3 Base
4 Control Panel
5 Base Bottom
6 Omega Clamp Adapter

8
Unpacking
Immediately upon receipt, carefully unpack and inspect the fixture to verify that all parts are
present and have been received in good condition. If any parts appear damaged from shipping
or the shipping carton shows signs of mishandling, retain all packing material for inspection and
notify the shipper immediately. Save original carton and packing. In the event that the
merchandise is to be returned, the original carton and packing must be used. The customer will
be billed for a new carton and packing if merchandise is received without the original carton and
packing. The plastic bag shipped with the fixture can be used to keep the fixture clean if stored
or installed in a temporarily dusty environment. Do not operate fixture with plastic bag in place.
Save Shipping Materials
The packing and carton are designed to provide the fixture with protection during
shipping. Save original packing and documentation for warranty, service and return
issues. Additional charges will be applied to return items not received in original or
incomplete packing.
Claims
Physical damage must be reported to the Freight Carrier or Shipping Company upon
receipt of merchandise. Damage incurred in shipping is the responsibility of the Freight
Carrier or Shipping Company. It is the customer's obligation in the event that
merchandise is received damaged caused by shipping to notify the Freight Carrier or
Shipping Company immediately. All other claims not related to damage incurred during
shipping must be made to the Dealer or Distributor within 7 (seven) days of receiving
merchandise.
Returns
Returned merchandise must be sent prepaid, in the original packing with a Return
Merchandise Authorization number (RMA) clearly listed on the shipping label. Items
sent by Freight Collect or without a RMA number will be refused. Call your sales person
and request a RMA prior to shipping. Be prepared to provide the model number, serial
number and a brief description of the nature of the return. Shipping damage resulting
from inadequate packaging is the customer’s responsibility. Customer will be charged
additional shipping charges to return products received in non original packing and or
cartons.

9
Power
Power is connected to the fixture with an IEC power inlet and cord.
Before applying power to fixture, set the power switch to “OFF” and
verify input voltage matches the power source voltage. Check all power
cords to verify they are of proper type and sufficient rating for the
equipment attached. For protection against electric shock, fixture must be
connected to suitable earth ground. The listed current rating is its average draw
under normal conditions. All fixtures must be powered directly from a switched
circuit. This fixture cannot be run on rheostat or dimmer circuits - even if used
solely for a 0% to 100% switching. Consult a qualified electrician if there are any
concerns about proper connection to power.
Voltage Selection
This Fixture is equipped with an Auto Switching Power Supply. It will automatically adjust to any
line voltage within the specified range.
LED Engine
This unit is equipped with a Long Life LED Engine that is aligned at the factory. There is no
need for the user to change lamps or perform any alignment.
Do not stare directly into the light source.

10
Mounting
Always consult a qualified professional when rigging. This fixture may be placed on any flat
surface or truss that is capable of safely supporting the weight. When selecting a mounting
position, take into consideration access for routine maintenance. This fixture may be mounted in
any position provided there is adequate room for movement and ventilation. Mount the fixture
securely using an appropriate clamp and a safety cable. Safety cables must always be attached
to the fixture. Do not use handles as secondary mounting points. Do not mount in a place
where the fixture will be exposed to rain, high humidity, extreme temperature changes or
restricted ventilation. Do not obstruct the vents or fans. Keep fixture a minimum of 3.3ft (1m)
from flammable materials.
