Technics SA-GX670 User manual

‘Technics
AV control stereo receiver
|
SA-GX670
SA-GX470/SA-GX370
Operating Instructions
The photographs show SA-GX670
Note:
ee
3
:
The
“EB”
indication
shown
on
the
packing
case
indicates
United
Kingdom.
USO
og
:
efore connecting, operating or adjusting this product, please
2ad these-instructions completely.
.
RQT2510-B

Dear Customer
Thank you for purchasing this Technics product.
For optimum performance and safety, please read
these instructions carefully.
These operating instructions are applicable to models
SA-GX670, SA-GX470 and SA-GX370.
These operating instructions, however, are intended primarily
for model SA-GX670.
(United Kingdom only)
(“EB” area code model only)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere
and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark @ or the BSI mark yY
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is replac-
ed.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
CAUTION!
|
IF
THE
FITTED
MOULDED
PLUG
IS
UN-
SUITABLE
FOR
THE
SOCKET
OUTLET
IN
YOUR
HOME
THEN
THE
FUSE
SHOULD
BE
REMOVED
AND
THE
PLUG
CUT OFF
AND
DISPOSED
OF
SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring
code as shown below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accor-
dance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug, pro-
ceed as follows:
(For Australia and N.Z.)
Caution for AC mains lead
THIS TUNER/RECEIVER IS CAPABLE OF RECEIVING THE NEW AM STEREO BROADCASTS FROM THE AM BAND RADIO STATIONS.
HOWEVER LIKE MANY TUNERS AND RECEIVERS CURRENTLY AVAILABLE ON THE MARKET IT WILL REPRODUCE THIS AM STEREO
SIGNAL ONLY IN AM MONO, WHICH, IN EFFECT, IS OF NO LESSER QUALITY THAN YOUR EXISTING AM MONO TUNER/RECEIVER.
(For areas except United Kingdom, Europe, Australia and
N.Z.)
CAUTION:
The AC voltage differs according to the area.
Be sure to set the proper voltage in your area
before use.
(For details, please refer to the page 8.)
The wire which is coloured BLUE must be con-
nected to the terminal in the plug which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be con-
nected to the terminal in the plug which is marked
with the letter L or coloured RED.
Under no circumstances should either of these
wires be connected to the earth terminal of the
three pin plug, marked with the letter E or the Earth
Symbol = .
Before use
Remove the connector cover as follows.
Connector
How to replace the fuse
1. Remove the fuse cover with a screwdriver.
(5 ampere)

Before use
Suggestions
for
safety..................--.....5
4
AOCOSSOMNES
«200
os
kate
chess
as
eden
ies
5
Front
panel
controls.......................e
eee
6
Connections
Equipment
connections....................-....-
8
Antenna
connections...........................5.
10
Speaker
connections
....................-....-.5.
12
Listening
Basic
operations
....................6...:eeees
14
To
listen
to
a
desired
audio
source
while
watching
a
VIdO0
sec
kep
ee
died
WORE
AERO
Ses
Oh
ee
CREE
Reale
reid
hes
15
To
adjust
the
tone
quality
...........
eee
cee
ee
eee
ee
eee
15
To
mute
the
sound
level
............
6.
cece
ee
eee
eee
eee
15
To
adjust
the
sound
balance
.............-.-.-
sees
eee
15
To
emphasize
low-frequency
sound
PERCHA.
....
15
To
tisten
through
headphones
............-
ese
ee
eee
eee
15
If
sound
output
stops
during
use
MCC
RTINA
.......
15
Listening
to
radio
broadcasts..................-
16
Direct
access
tuning
..
0.2...
cece
eee
eee
eee
eens
16
Sequential
tuning
MRUMSEMCRGTAM.....e
17
Sequential
tuning
[GRIMSEMCRGMUREMCRGHON...........,
18
Preset
tuning
..........-
rieisale
sc
hiearelainaene
aaa
ae
PERO
WSR
18
Adjusting the sound field
Enjoying sound with DOLBY PRO LOGIC..... 21
SURROUNDS. 143s Shss6 sete ead Fact eas pend aes 21
3 STEREO }.. coi geiceseie eee ees Dede PAG ee ge cee te 21
Setting the center mode ........... 0... cece eee eee 21
Adjusting the output level of each speaker............... 22
Adjusting the delay time BEAWERCaZRTINA............... 23
Enjoying with SURROUND or 3 STEREO..............5-. 23
Recording
Making a recording .......................65.ees 24
Tape recording on the tape deck or digital compact
cassette deck (DCC).... 2... cee cece een eee enna 24
VCR (VCR 1) recording from an audio source ............ 24
Recording from VCR 2 to VCR 1....... cece eee 25
To record picture from VCR 2 and sound from
a different audio SOUrCE ©... 6... cece ee ee eee 25
When there seems to be a
problem
About
the
HELP
function
EieeG@arenia
.......
26
Technical
specifications.........................
26
Reference
Troubleshooting guide ............... Back cover

Placement
Avoid placing the unit in areas of:
e direct sunlight
*high temperature
@ high humidity
e excessive vibration
uneven surfaces (Place the unit on a flat level surface.)
Such conditions might damage the cabinet and/or other compo-
nent parts and thereby shorten the unit's service life.
Ventilation
¢ Place the unit in a well ventilated position at least 10 cms away
from wall surfaces etc.
Ensure that curtains and similar materials do not obstruct the
ventilation holes.
Stacking
Never place heavy items on top of the unit or the power cord.
Voltage
e It is very dangerous to use an AC power source of high voltage
such as for an air conditioner.
A fire might be caused by such a connection.
¢ A DC power source can not be used.
Be sure to check the power source carefully, especially on a
ship or other place where DC is used.
Power cord protection
® Avoid cuts, scratches or poor connection of the AC mains cord,
as this may result in fire or electric shock hazard.
Excessive bending, pulling or slicing of the cord should also be
avoided.
© Do not pull on the cord when you are disconnecting the power,
as this could cause an electric shock. Grasp the plug firmly
when you disconnect the power supply.
® Never touch the plug with wet hands or a serious electric shock
could result.
Foreign materials
eEnsure that no foreign objects, such as needies, coins,
screwdrivers etc., accidentally fall into the unit or through the
ventilation holes.
Otherwise, a serious electric shock or malfunction could occur.
e Be extremely careful about spilling water or liquid on/into the
unit, as a fire or electric shock could occur.
(Disconnect the power plug and contact your dealer immediate-
ly if this occurs.) :
e Avoid spraying insecticides onto the unit as they contain flam-
mable gases which can be ignited.
eln secticides, alcohol, paint thinner and similar chemicals
should never be used to clean the unit as they can cause flaking
or cloudiness to the cabinet finish.
Maintenance
Clean the cabinet, panei and controls with a soft cloth lightly
moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
© Never attempt to repair, disassemble or reconstruct the unit if
there seems to be a problem.
A serious electric shock could result if you ignore this precau-
tionary measure.
¢ if a problem occurs during operation (the sound is interrupted,
indicators fail to illuminate, smoke is detected, etc) contact
your dealer or Authorized Service Center immediately.
¢ Disconnect the power supply if the unit will not be used for a
long time. Otherwise the operation life could be shortened.
CAUTION
Do not place a tape deck or CD player on top of this unit.
Heat radiated from the top of this unit may cause damage to
the tape or CD software.

Please check and identify the supplied ac-
cessories
rei AC power supply cord
(For United Kingdom) (For Australia and N.Z.)
(RJAO036-K)
(For others)
(RJAQO19-2K)
AM loop antenna set (RSA0010)
© AM loop antenna
e AM antenna holder
e Screw
[| Remote control transmitter
For SA-GX670
(For areas except
United Kingdom and
Europe)
For SA-GX670 (For
United Kingdom and
Europe)/SA-GX470/
SA-GX370
(RAK-SA114XH) (RAK-SA704XH)
For details on remote control transmitter opera-
tion, refer to ‘How to use the remote control
transmitter” in the separate booklet.
[| Attachment plug (SUP9009)
(United Kingdom only)
Power plug adaptor (SJP5213-2)
(Not supplied for United Kingdom, Europe,
Australia and N.Z.)
Antenna plug (RFE0014)
(Not supplied for United Kingdom and Europe)

For SA-GX670
2 i ee
No. Name Ref. page
@ Power “STANDBY ( /ON” switch
(POWER, STANDBY () /ON) 14
Press to switch the unit from on to standby mode or vice ver-
sa. In standby mode, the unit is still consuming a small
amount of power.
@
Tuning
control
(TUNING)
17
@)
Tuning
mode
select
button
(TUNING MODE) 17
@ Numeric buttons (1—0) 16,19,20
(S) Remote control signal receptor
(SENSOR)
=
©
“STANDBY”
indicator
-
When
the
unit
is
connected
to
the
AC
mains
supply,
this
in-
dicator
lights
up
in
standby
mode
and
goes
out
when
the
unit
is
turned
on.
@) DOLBY PRO LOGIC SURROUND
ON/OFF button (SURROUND) 21,22,23
DOLBY PRO LOGIC 3 STEREO
ON/OFF button (3 STEREO) 21,22,23
) Test signal ON/OFF button (TEST) 22
(0 Center level adjust button
(CENTER LEVEL) 22
(
Display
a
(2 Rear level adjust button
(REAR LEVEL) 22
ie me pcoveruve |
No. Name Ref. page
(3) Center mode select button
(CENTER MODE) 21
(4 Memory button (MEMORY) 19
(5 Help/reset button (‘HELP — RESET) 15,26
(6) Volume control (VOLUME) 14
d7) Headphone jack (PHONES) 15
Direct tuning button
(DIRECT TUNING) 16
(9) Speaker select buttons (SPEAKERS) 14
@0 Band select button (BAND) 16
@i) FM mode select button (FM MODE) 16
@) Input select buttons 14
@ Tape/DCC monitor button
(TAPE/DCC [MONITOR] ) 14,24
@4 Delay time adjust button
(DELAY TIME) 23
@) Muting/loudness button .
((MUTING —LOUDNESS) 15
26 Balance control (BALANCE) 15
@) Bass control (BASS) 15
@ Treble control (TREBLE) 15

For SA-GX470/SA-GX370
nn
No.
Name
Ref.
page
@ Power “STANDBY © /ON” switch
(POWER, STANDBY () /ON) 14
Press
to
switch
the
unit
from
on
to
standby
mode
or
vice
ver-
sa.
In
standby
mode,
the
unit
is
still
consuming
a
small
amount
of
power.
@
Tuning
control
(TUNING)
18
@
Band
select
button
(BAND)
16
@
FM
mode
select
button
(FM
MODE)
16
©)
Direct
tuning
button
(DIRECT TUNING) 16
©
Numeric
buttons
(1
—0)
16,19,20
@ Remote control signal receptor
(SENSOR)
=
“STANDBY”
indicator
-
When
the
unit
is
connected
to
the
AC
mains
supply,
this
in-
dicator
lights
up
in
standby
mode
and
goes
out
when
the
unit
is
turned
on.
Q) DOLBY PRO LOGIC SURROUND
ON/OFF button (SURROUND) 21,22,23
(® DOLBY PRO LOGIC 3 STEREO
ON/OFF
button
(3
STEREO)
21,22,23
(> Test signal ON/OFF button (TEST) 22
No. Name Ref. page
(2 Center level adjust button
(CENTER LEVEL) 22
43)
Display
ee
(4 Rear level adjust button
(REAR LEVEL) 22
(5) Center mode select button
(CENTER MODE) 21
(6 Memory button (MEMORY) 19
(7) Treble control (TREBLE) 15
Bass control (BASS) 15
(9) Headphone jack (PHONES) 15
@0 Speaker select buttons (SPEAKERS) 14
@? Input select buttons 14
@ Tape/DCC monitor button
(TAPE/DCC [MONITOR}) 14,24
@ Muting button (MUTING) 15
@4 Balance control (BALANCE) 15
@) Volume control (VOLUME) 14

Connecting audio equipment
Stereo connection cable (not included)
Red (R)
CD player (or CD changer) Tape deck or digital compact cassette
(not included) deck (DCC) (not included)
REC (IN)
PLAY (OUT)
OUTPUT
Only for turntable
with ground terminal
Antenna terminals
See pages 10-11.
Speaker terminals
See pages 12-13.
Turntable
(not included)
Connect the connection cable for the remote control to a
Technics tape deck and/or CD player (or CD changer) which (For areas except United Kingdom, Europe, Australia and
has the appropriate remote control terminal as shown below. N.Z.)
If a tape deck is not being used, the CD player (or CD Set the voltage selector to the voltage setting for the area in
changer) can be connected directly (dotted line). which the unit will be used.
Note that this unit will be seriously damaged if this setting is not
made correctly.
CD player
Tape deck (or CD changer)
(not included) (not included)
REMOTE CONTROL REMOTE
IN@ O OUT ©
Voltage selector
Connection cables for remote control
BIO@Ge@® OO
(not included) 7
0600 ©9 ©
—
For aCD player (or CD changer) with a remote control sensor the
above connection is not necessary.

Connecting video equipment
Stereo connection cable (not included)
Red (R)
Second VCR (for playback only)
(not included)
Video connection cables
{not included)
(For areas except Australia
and N.Z.)
Cooling fan
The cooling fan operates at high
power output levels only.
Video connection cables
(not included)
‘Approx. 6 mms
Appliance inlet
AUDIO
OUT
VIDEO
OUT
Even when the connector is
perfectly inserted, the front
part of the connector jut out as
shown in the drawing.
However there is no problem us-
ing the unit.
AC power supply cord
(included)
VCR
Connect
this
cord
after
(not
included)
all
other
cables
and
cords
are
connected.
Household
AC outlet
To connect a video deck with 21 pin scart ter-
This unit
(United Kingdom only)
BE SURE TO READ THE CAUTION FOR THE AC
POWER SUPPLY CORD ON PAGE 2 BEFORE CON-
NECTION.
(For areas except United Kingdom, Europe,
Australia and N.Z.)
If the power plug will not fit your socket, use the
power plug adaptor (included).
CoE
VCR (not included)
21 pin scart cable (not included)

FM indoor antenna (included)
This antenna is normally sufficient for reception of FM broad-
casts.
FM indoor antenna
(included)
( 7 ye Tape
Attach to a wall (using a tape) facing in the direction of best recep-
tion.
For best reception sound quality:
An FM outdoor antenna is recommended.
Disconnect the antenna if an FM outdoor antenna is installed.
FM outdoor antenna (not included)
The outdoor antenna should be used when using the main unit in
mountainous areas or in spaces enclosed by reinforced concrete
where the FM indoor antenna (included) does not provide
satisfactory reception.
An outdoor antenna should be installed by a qualified technician
only.
For United Kingdom and Europe
FM outdoor antenna
(not included)
75-ohms coaxial cable
(not included)
United Kingdom only
Attachment plug
(included)
For areas except United Kingdom and
Europe
FM outdoor antenna
(not included)
a
300-ohms
feeder wire
(not included)
75-ohms
coaxial cable
(not included)
Antenna plug
(included)
See page 11 for using the antenna plug (includ-
ed).
