Technics SL-D212 User manual

ORDER NO. SD81082022C4
ervice Manual
* The colors of this model included silver and black.
* The black type model is provided with (K) in the
Service Manual.
Turntable System
SL- D212
[PA], [
SL- D212 K)
[PA], [PE], [PC]
Areas
* [PA] is available in far East PX.
* [PE] is available in European Military.
* [PC] is available in European Audio Club.
Please
use
this
manual
together
with
the
service
manual
for
Model
No.
SL-D212/SL-D212
(K),
Order
No.
$D81071976C8.
Specifications
@ General
Power supply:
Power consumption:
Dimensions:
(WxHxD)
Weight:
@ Turntable section
Type:
Drive method:
Motor:
Drive control method:
Turntable platter
Turntable speeds:
Pitch control:
Wow and flutter:
Specifications are subject to change without notice for further improvement.
Weight and dimensions shown approximate.
~110-—120/220~-240V, 50 or 60 Hz
7W
4310.6 x37.5cm
(16-15/16" x 4-7/32" x 14-3/4"')
Maximum height when top
(dust cover) is open.
43x37x42cm
16-15/16" x 14-9/16"’ x
16-17/32”"
5 kg (11 Ib.)
Automatic turntable
Auto return
Auto stop
Manual play
Direct drive
Brushless DC motor
F-G servo control
Aluminum die-cast
Diameter 31.2 cm (12-9/32’’)
33-1/3 rpm and 45 rpm
10% adjustment range
0.012% WRMS*
0.025% WRMS (JIS C5521)
+0.035% peak
(IEC 98A Weighted)
‘This rating refers to turntable assembly alone, excluding
effects of record, cartridge or tonearm, but including platter.
Measured by obtaining signal
from built-in frequency
generator of motor assembly.
Rumble:
Technics
— 56 dB (IEC 98A Unweighted)
—78 dB (IEC 98A Weighted)
@ Tonearm section
Type:
Effective length:
Overhang:
Tracking error angle:
Offset angle:
Friction:
Effective mass:
Stylus pressure
adjustment range:
Headshell weight:
Phono cable
capacitance:
Universal tonearm
‘*S”' shaped tubular arm
Static balanced type
230 mm (9-1/16’’)
15mm (19/32"')
Within 2°32’ at the outer groove
of 30 cm (12”’) record
Within 0°32’ at the inner groove
of 30 cm (12’’) record
22°
Less than 7 mg (lateral, vertical)
11 g (without cartridge)
0-2.5g
89
135 pF
@ Cartridge section
Type:
Frequency response:
Output voltage:
Channel separation:
Channel balance:
Load impedance:
Stylus pressure:
Replacement stylus:
Panasonic Tokyo
Matsushita Electric Industrial Co., Ltd.
1-2, 1-chome, Shiba-koen, Minato-ku, Tokyo 105 Japan
Moving magnet stereo cartridge
20 Hz to 25 kHz
2.5mV 1kHz,
5 cm/s. zero to peak lateral
velocity
(7 mV 1kHz,10 cm/s. zero to
peak 45° velocity [DIN 45 500))
22 dB 1 kHz
Within 2 dB at 1 kHz
47 kQ} to 100 kD
1.75+0.25 g (17.5+2.5mN)
EPS-74STSD (ATN71)
Matsushita Electric Trading Co., Ltd.
P.O. Box 288, Central Osaka Japan

m REPLACEMENT PARTS LIST
Change of Part No.
SL-D212/D212 (K)
(ORDER NO. $D81071976C8)
CAPACITOR
A ECQU2A473MF
ECQE2A473MZ
CABINET and CHASSIS PARTS
SJA139
C401
SJA137
20 SFUM190—12
SFUM190—11
TONEARM PARTS
| ___s«~s| EPs—2ses
SCREW and NUT
Addition
[ze
ACCESSORIES
SL-D212/D212 (K)
[PA, PE, PC]
EQ - marked parts are used for black type only.
Part Name & Description
Per Set Remarks
(Pcs.)
ha
ECQE2A473MZ
250VAC,
0.047 uF,
eens
Polyester,
+ 20%
SFNND21P01 [PA, PE]
Name Plate
SFNND21P02 [PC]
SFUM190-—12
SFPEN3302
Name Plate
AC Cord
Bushing, AC Cord
1103 || EPC—u25s EPC74SMAD Cartridge
EPS74STSD Stylus 1 —_———
Ne
[[srczvesco
«SP
ev7aca
[Screw
Carvidge
——SSCSCS~C~idSCi
—
Nut, Cartridge
|
SFNUD21S01
SFNUD21G01
SFNUD21X01
SFNUD21P01
Instructions Book, Printed Matter
Deletion
fas seen
a4 |_| Addition
PACKING PARTS
[O]srurozmor——SC*d
FO] srHPozicn SSCS
r
3
2 Pin Plug
QJPO603S
Adaptor, Gimens
© — SFHPD21M01
Carton Box (Silver)
Printed in Japan
81080450 ) TK/YW

ORDER NO. $D81071976C8
Service
Manual
Turntable System
oL-D212
- [EK], ied re [EB],
, [XM], [ ], [EC]
SL- D2120K
ne
6), [EBL LE FLIX M]
* (E] is available in Switzerland and Scandinavia.
* [EK] is available in United Kingdom.
* [XL] is available in Australia.
* [EG] is available in F.R. Germany.
* [EB] is available in Belgium.
* [EF] is available in France.
* [XA] is available in Southeast Asia, Oceania, Africa,
Middle Near East and Central South America.
* [XM] is available in Central South America.
* (EH) is available in Holland.
* [Ei] is available in Italy.
* [EC] is available in Czechoslovakia.
[EF], [X
Areas [E
* The colors of this model include silver and black.
* The black type model is provided with (K) in the
Service Manual.
English
Specifications are subject to change without notice for further improvement.
Drive contro! method:
Turntable platter
Turntable speeds:
Pitch control:
Wow and flutter:
F-G servo control
Aluminum die-cast
Diameter 31.2 cm (12-9/32"')
33-1/3 rpm and 45 rpm
10% adjustment range
0.012% WRMS*
0.025% WRMS (JIS C5521)
+0.035% peak
(IEC 98A Weighted)
Effective mass:
Stylus pressure
adjustment range:
Applicable cartridge
weight range:
Headshell weight:
Phono cable
capacitance:
Specifications Weight and dimensions shown approximate.
@
General
;
Power
supply:
~110—120/220-240V,
50
or
60
Hz
‘This
rating
refers
to
turntable
assembly
alone,
excluding
Power
consumption:
7W
effects
of
record,
cartridge
or
tonearm,
but
including
platter.
Dimensions:
4310.6x37.5cem
Measured
by
obtaining
signal
from
built-in
frequency
(WxHxD) (16-15/16" x 4-7/32"’ x 14-3/4"’) generator of motor assembly.
Maximum height when top Rumble: —56 dB (IEC 98A Unweighted)
(dust
cover)
is
open.
~78
dB
(IEC
98A
Weighted)
43x37x42cm A
16-15/16"x 14-9/16" x @ Tonearm section .
* Type: Universal tonearm
Weight: Testis “S$” shaped tubular arm
eight: ong (Tks Static balanced type
Effective length: 230 mm (9-1/16’’)
@ Turntable section Overhang: 15 mm (19/32”)
Type: Automatic turntable Tracking error angle: Within 2°32’ at the outer groove
Auto return of 30 cm (12”’) record
Auto stop Within 0°32’ at the inner groove
Manual play of 30 cm (12”’) record
Drive method: Direct drive Offset angle: 22°
Motor: Brushless DC motor Friction: Less than 7 mg (lateral, vertical)
11 g (without cartridge)
0-2.5g
5—7.5g
89g
135 pF
Matsushita Electric Trading Co., Ltd.
PO. Box 288, Central Osaka Japan
Technics

@ Cartridge section
Type:
Frequency response:
Output voltage:
Deutsch
TECHNISCHE DATEN
@ Allgemeine Daten
Stromversorgung:
Leistungsaufnahme:
Abmessungen
(BxHxT):
Gewicht:
@ Plattenspieler
Typ:
Antrieb:
Motor:
Antriebsregel-Methode:
Plattenteller:
Plattenteller-
Drehzahien:
Drehzahi-
Feinregulierung:
Gleichlaufschwan-
kungen:
(EPC-U25S)
Moving magnet
10 Hz to 35 kHz
20 Hz to 10 kHz+1 dB
2.5 mV at 1 kHz
5 cm/s. zero to peak lateral
velocity
(7 mV at 1 kHz 10 cm/s. zero to
peak 45° velocity [DIN 45 500})
~110-120/220-240 V,
50/60 Hz
Wechselstrom
7W
43 x10,6x37,5cm
Maximale Hohe bei
vollstanding gedffnetem
Oberteil (Staubabdeckung)
43x37x 42cm
5kg
Automatischer Plattenspieler
Ruckfiihrautomatik
Stopautomatik
Manueller Betrieb
Direktantrieb
Kollektorloser
Gleichstrommotor
FG-Servo-Steuerung
Aluminium-SpritzguB
Durchmesser 31,2 cm
33-1/3 und 45 U/min
10% Einstellbereich
0,012% WRMS*
0,025% WRMS (JiS C5521)
+0,035% Spitze
(IEC 98A bewertet)
“Diese
Nennteistung
bezieht
sich
auf
das
Laufwerk-Bauteil
allein,
ausschlieBtich
Einflisse
von
Schallplatte,
Tonab-
nehmer
oder
Tonarm,
aber
einschlieBlich
Plattenteller.
Gemessen
anhand
von
Signalen
vom
eingebauten
Fre-
quenzgenerator
des
Motorbauteils.
Rumpel-Fremd-
Spannungsabstand:
Rumpel-Gerdusch-
sSpannungsabstand:
—56 dB (IEC 98A unbewertet)
—78 dB (IEC 98A bewertet)
Channel separation:
Channel balance:
Compliance (dynamic):
Stylus pressure:
Load impedance:
Weight:
Replacement stylus:
Anderungen de technischen Daten vorbehalten.
Die angegebenen Gewichts- und Abmessungsdaten sind circa Werte.
@ Tonarm
Typ:
Effektive Lange:
UOberhang:
Spurfehlwinkel:
Kroépfungswinkel:
Lagerreibung:
Effektive Masse:
Auflagekraft-
Einstelibereich:
Zulassiger Ton-
abnehmer-
Gewichtbereich:
Tonarmkopf-Gewicht:
Phonokabl-Kapazitanz:
@ Tonabnehmer
Typ:
Frequenzgang:
Ausgangsspannung:
Kanaltrennung:
Kanalabweichung:
Nachgiebigkeit
(dynamisch):
Auflagekraft:
impedanz:
Gewicht:
Ersatznadel:
22 dB at 1 kHz
Within 1.8 dB at 1 kHz
10x 107§ cm/dyne at 100 Hz
1.75+0.25 g (17.5+2.5mN)
47 kQ to 100 kO
5g (cartridge only)
EPS-25CS
(Equivalent replacement
stylus: EPS-25ES)
Unriversal-Tonarm
S-férmiger Rohrtonarm
Statisch ausbalanciert
230 mm
15mm
2°32’ bei der Einlaufrille einer
30 cm-Platte
0°32’ bei der Auslaufrille einer
30 cm-Platte
22°
Weniger als 7 mg
(horizontal, vertikal)
11g (ohne Tonabnehmer)
0—2,5g
5—7,59g
8g
135 pF
(EPC-U25S)
Magnetischer Tonabnehmer
10 Hz bis 35 kHz
20 Hz bis 10 kHz +1 dB
2,5 mV bei 1 kHz
5 cm/s. Null-zu-Spitze, lateral
[7 mV bei 1 kHz 10 cm/s. Null-
zu-Spitze, 45° (DIN 45 500)]
22 dB bei 1 kHz
Innerhalb 1,8 dB bei 1 kHz
10x 10°-& cm/dyn bei 100 Hz
1,75+0,25 g (17,5+2,5 mN)
47 kO bis 100 kN
5 g (nur Tonabnehmer)
EPS-25CS
(Gleichwertiger
Ersatztonabnehmer:
EPS- 25ES.)

Francais
CARACTERISTIQUES
@ Géneéralités
Alimentation:
Consommation:
Dimensions:
(L» H»>P)
@ Platine de lecture
Type:
Systeme d’entraine-
ment:
Moteur:
Groupe de réglage:
Plateau de lecture:
Vitesses de rotation:
Réglage d’écart:
Pleurage et scintille-
ment:
Alternatif 110-120/220-240V,
50 ou 60 Hz
7W
43x10,6*37,5cm
Hauteur maximum lorsque le )
dessus (couvercle protége-
poussiére) est ouvert.
43x37x42cm
5kg
Platine automatique
Retour automatique
Arrét automatique
Audition a commande manuelle
Entrainement direct
Moteur C.C. sans balai
Servocommande du générateur
de fréquences
En aluminium moulé sous
pression
Diamétre 31,2 cm
33-1/3 et 45 t/p.m
Plage de réglage de 10%
0,012% de valeur efficace*
0.025% de valeur efficace
(JIS C5521)
*0,035% de créte
(IEC 98A Pondére)
“Ce régime nominal se rapporte a l'ensemble du tourne-
disque seul, excluant les effets du disque, de la cellule
Pick-up ou du bras de lecture, mais comprenant le plateau,
Mesuré par |’obtention d'un signal provenant du généra-
teur de frequences incorpore de | ensemble du moteur.
Ronflement:
Espafiol
ESPECIFICACIONES
@ En general
Alimentacion de
corriente:
Consumo de corriente:
Dimensiones:
(AnchoxAltox Prof.)
—56 dB (IEC 98A Non pondéré)
—78 dB (IEC 98A Pondéré)
@ Bras de lecture
Type:
Longueur effective:
Porte-a-faux:
Angle d’erreur de piste:
Angle de décalage:
Frottement:
Masse reelle:
Plage de reglage de la
pression d'appui:
Gamme du poids des
cellules pick-up
utilisables:
Poids de la coque
porte-cellule:
Capacitance propre
du cable pick-up:
@ Celiule pick-up
Type:
Réponse en fréquence:
Tension de sortie:
Séparation de canal:
Equilibrage des
canaux:
Elasticité (dynamique):
Pression de Ja pointe
de lecture:
Impedance de charge:
Poids:
Pointe de lecture de
remplacement:
El peso y las dimensiones indicados son aproximados.
~110—120/220—240 V,
50 6 50 Hz
7W
43x10,6x37,5 cm
Altura maxima cuando la parte
de arriba (tapa contra el polvo)
esta abierta.
43x37x42 cm
5 kg
@ Seccion del plato g
Tipo:
Método de acciona-
miento:
Motor:
Les spécifications sont susceptibles d‘étre modifiées sans préavis.
Le poids et les dimensions donnés sont approximatifs.
Bras de lecture universel
Bras tubulaire en forme de 'S”
De type a équilibrage statique
230 mm
15mm
En deca de 2 32’ ausillon
extérieur d un disque de 30 cm
En deca de 0 32 ausillon
intérieur d'un disque de 30 cm
22
Moins de 7 mg (latéral et vertical)
11g (sans la cellule pick-up)
0-2.5g
5—7,59g
8g
135 pF
(EPC-U25S)
Aimant mobile
10 Hz a 35 kHz
20Hza10kHz+1dB
2,5mV a1kHz:5cm/s., zéroa
vitesse latérale de créte
(7 mV a1 kHz
10 cm/s., zero a vitesse 45 de
créte [DIN 45 500])
22 dB a 1kHz
En decade 1,8dB a1 kHz
10» 10°* cm/dyne a 100 Hz
1,75+0,259
(17.5+2,5 mN)
47 ki} to 100 KY)
5g (cellule seule)
EPS-25CS
(Pointe de lecture de
remplacement
equivalente: EPS-25ES.)
Las especificaciones quedan sujetas a cambios sin aviso previo.
iratorio
Plato giratorio automatico
Retorno automatico
Parada automatica
Ejecucién manual
Accionamiento directo
Motor de corriente continua sin
escobillas

Método de control de
accionamiento:
Platillo del plato
giratorio:
Velocidades del plato
giratorio:
Control de altura de
sonido:
Ululaciones y trémolo:
Sevocontrol por generador de
frecuencias
Aluminio fundido
Diametro 31,2 cm
33-1/3 y 45 rpm
Ambito de ajuste de 10%
0,012% WRMS
0,025% WRMS (JIS C5521)
+0,035% cresta
(IEC 98A Ponderado)
* Estas caracteristicas se refieren Unicamente al
conjunto del plato giratorio, con exclusién de los
efectos provenientes del disco, cartucho o del brazo
sonoro, incluyendo, empero, el platillo. La medida fue
tomada por medio de la sefial obtenida del generador
de frecuencia incorporado del conjunto del motor.
Ruido de rodadura:
—56 dB (IEC 98A No ponderado)
—78 dB (IEC 98A Ponderado)
@ Seccion del brazo sonoro
Tipo:
Longitud efectiva:
Proyeccion:
Angulo de error de
seguimiento:
m CONTENTS
CARTRIDGE INSTALLATION
Brazo sonoro universal
Brazo tubular en forma de “‘S”
Tipo equilibrado estatico
230 mm
15mm
Inferior a 2°32’ en el surco
exterior de un disco de 30 cm
Inferior a 0°32’ en el surco
interior de un disco de 30 cm
MESSUNGEN UND JUSTIERUNGEN (Deutsch). .........
MESURAGES ET REGLAGES (Frangais)..............
MEDICIONES Y AJUSTES (Espafiol) .............06.
STYLUS REPLACEMENT ........... 0.00 e ee euee
MEASUREMENTS AND ADJUSTMENTS (English)... ... | 9,10
Angulo de descentra-
miento: 22°
Fricci6n: Menos de 7 mg
(en sentido lateral y vertical)
Masa efectiva: 11 g (sin cartucho)
Radio de ajuste de la
presion de la aguja: 0a2,5g
Radio de peso de
cartucho utilizable:
Peso de la capsula de
la cabeza: 8g
Capacitancia de
cable de fono:
5—7,5g
135pF
@ Seccion del cartucho (EPC-U25S)
Tipo: Iman movil
Respuesta de
frecuencia: de 10 Hz a 35 kHz
de 20 Hz a 10 kHz+1 dB
2,5 mV a1 kHz
Con velocidad lateral
der cero a cresta de
5 cm/s
[7 mV a1 kHz Velocidad de
45°de cero a cresta de
10 cm/s (DIN 45 500)]
Separacion de canales: 22 dB a 1 kHz
Equilibrio de canales: Sin exceder 1,8 dB a 1 kHz
Elasticidad
(dinamica):
Presién de la aguja:
Impedancia de carga:
Peso:
Aguja de recambio:
Voltaje de salida:
10x10-* cm/dina a 100 Hz
1,75+0,25 g (17,5+2,5 mN)
47 k2. a 100 kQ
5 g (cartucho solo)
EPS-25CS
(Aguja de recambio equivalente:
EPS-25ES.)
Page
BLOCK DIAGRAM. ....... Ssacbictean ede ae Mewte Riayat tented Migs 14
CIRCUIT BOARD AND WIRING
CONNECTION DIAGRAM.............00006 15, 16
SCHEMATIC DIAGRAM ..............00 00 eee 17, 18
REPLACEMENT PARTS LIST
Electrical Parts 2... ee ee eee 19
Cabinet, Chassis and Packing Parts. ..........0..0205 20
EXPLODED VIEWS ........... 20.000 eee eee 21 ~ 23
PACKINGS 032 325. oneiae wan ea Ge eee a: Gath a oh 24

m LOCATION OF CONTROLS
Hinge 45-rpm adapor
a.
Counterweight
Turntable base Weight ring
Anti-skating control
Turntable mat
Cueing control
Arm rest
Center spindle
Arm clamp
Tonearm
Turntable platter
Locking sleeve
Strobe-illuminator/
pilot
lamp
Headshell/cartridge
Speed selector
(33-1/3 rom @ 45 rom-=)
Stop switch
Pitch control
Pitch control VR (VR201)
Speed selector switch ($201)
Neon lamp P.C.B.
Stop rod
Drive circuit P.C.B.
Stator frame
Automatic mechanism plate
Power transformer (T1)
Power switch (S1)
Shield plate
B | Power source circuit P.C.B.

SL-D212
m DISASSEMBLY INSTRUCTIONS
—
GN
How to remove the bottom board and automatic
mechanism plate
. Fix the tonearm on the rest.
. Remove the turntable.
. Close the dust cover, and turn over the unit, taking care
not to scratch it.
. Remove the bottom board setscrews @ ~ ©. Then, the
bottom board can be removed. (See Fig. 1)
. Remove the shield plate setscrews @ and @.
(See Fig. 2)
. Remove the regulator transistor P.C.B. setscrew @.
(See Fig. 2)
. Remove the earth lead wire setscrew @.
. Remove the automatic mechanism plate setscrews @ ~
@ . Then the automatic mechanism plate can be remov-
ed. (See Fig. 2)
Bottom board
Shield plate
How to remove the stator frame
.
Remove
the
bottom
board
and
automatic
mechanism
plate. (Refer to “How to remove the bottom board and
automatic mechanism plate’’.)
. Open the “lead holder” of the lead connector and pull
Out the lead wire of the arrow () in Fig. 3.
.
Remove
the
stator
frame
setscrews
@
~
@).
Then,
the
stator
frame
can
be
removed.
(See
Fig.
3)
Regulator transistor P.C.B. Fig. 2
Lead wire
Drive circuit P.C.B.
Fig. 3
Stator frame

~N
How to remove the drive circuit P.C.B.
. Remove the bottom board. (Refer to “‘How to remove
the bottom board and automatic mechanism plate’’.)
. Open the “lead holder’ of the lead connector and pull
out the lead wire. (Refer to “How to remove the stator
frame’”’)
. Remove the regulator transistor P.C.B. setscrew @) and
earth lead wire setscrew @. (See Fig. 2)
. Remove the drive circuit P.C.B. setscrews @ ~ ®.
Then, the drive circuit P.C.B. can be removed.
(See Fig. 4)
How to remove the tonearm and lift base plate
. Remove the bottom board and automatic mechanism
plate. (Refer to “How to remove the bottom board and
automatic mechanism plate’’.)
. Remove the canceller spring from the PU fixing plate,
loosen the PU fixing plate setscrew @ with a hexagon
wrench, then the PU fixing plate is disassembled when
lifted upward. (See Fig. 5)
. Disconnect the soldered five lead wires from the tone-
arm. (See Fig. 5)
. Disengage the screw @ of the lead wire fixing plate
and remove the tonearm stopper, then the tonearm
can be taken off. (See Fig. 5)
. To disassemble the lift substrate, diseangage the arm lift
fixing screw @ before turning over the body, then
remove the arm lift. (See Fig. 6)
Note: Remove the spring under the arm lift at the same
time.
. Remove the anti-skating control knob. (See Fig. 6)
. Turn over the unit and remove the PU fixing plate.
. Remove the lift base plate setscrews @ ~ @. Then,
the lift base plate can be removed. (See Fig. 5)
| Lead wire
Lead
connector
#—@
Drive circuit P.C.B. Fig. 4
Hexagon
wrench
PU fixing ptate
sropoe “SY
Canceller spring t@
Lead wires
PU output P.C.B.
——
SS Lead wire fixing plate
Fig. 5
Tonearm
Anti-skating control
knob
Arm base
Fig. 6

mM REPLACEMENT OF HALL ELEMENT
When replacing the Hall element of the stator frame, be
sure to place it with the marking side up as shown in Fig. 7.
* The leg position is not specified provided that the mark-
ing side is up.
@ CARTRIDGE INSTALLATION
When installing a cartridge, follow the instructions that
came with the cartridge.
During installation, attach the stylus protector to guard the
stylus tip from damage.
1. Connect the lead wires to the cartridge terminals.
The terminals of most cartridges are color coded.
Connect each lead wire to the terminal of the same color.
White (L+).......... Left channel +
Blue (L—-) .......... Left channel —
Red (R+)........... Right channel +
Green (R-)......... Right channel —
2. Mount the cartridge in the headshell using the screws
provided with the cartridge. (Fig. 8)
@ STYLUS REPLACEMENT trig. 9)
The cartridge has a diamond stylus.
Replace the stylus at the first sign of wear or after about
1000 hours of use. Correct stylus pressure (tracking force)
and proper record and stylus care will help extend stylus life.
Stylus life varies with the conditions of use.
Noise or scratchiness may indicate a worn or damaged
stylus.
To avoid damaging records, do not use a stylus that seems
worn. Replace it immediately.
The replacement stylus for this cartridge is EPS-25CS.
1. Loosen the tonearm locking sleeve to remove the head-
sheel and cartridge.
2. Hold the headshell firmly, and with your other hand pull
out on the stylus assembly in the direction of the arrow.
3. Line up the new stylus assembly with the cartridge and
push in firmly as far as it will go.
Marking
i
Ss
H1 y
| Stator frame
Fig. 7
Cartridge
Stylus protector
Fig. 8
Fig. 9
