TechnicalInformation forHi‐Fi Audio System
Premium
DirectDriveTurntableSystem
SL‐1500C

TechnicalInformation forHi‐Fi Audio System
Reference
Class
Reference
Class
Gland
Class
Gland
Class
Premium
Class
Premium
Class
•SB‐C700
•SU‐G30
•SL‐1200GAE
•SL‐1200G
•SL‐1200/1210GR
•SL‐1200MK7/1210MK7
•ST‐G30
•ST‐G30L
•SU‐R1 •SE‐R1 •SB‐R1
•ST‐C700
•SL‐C700 •SU‐C700
•SC‐C500
•SU‐C550
•SC‐C50
•SC‐C70
Turntable Turntable
System Server CDPlayer NWPlayer AMP Speaker
20142014 20142014 20182018 20182018
20172017
20162016 20162016 20162016
20142014 20142014 20142014 20142014
•SB‐G90
20172017
20152015
20182018
20192019
Allinone
MusicSystem
20142014
•SP‐10R •SL‐1000R
(NW+PreAmp)
・SU‐G700
20172017
Wireless
Speaker
System
•SL‐1500C
20192019
20192019
Lineup
2

TechnicalInformation forHi‐Fi Audio System
TheSL‐1500Cinheritsthebrand'shigh‐endsoundquality
conceptandaddsahostoforiginalTechnicstechnologies,
suchasacorelessdirectdrivemotorandhigh‐‐ sensitivity
tonearm.Tosimplifytheplayingofanaloguerecords,the
built‐inPhonoEQconnectstoawidevarietyofdevices.The
SL‐1500Calsocomesequippedwithahigh‐qualityOrtofon
2MRedphonocartridge.
TheSL‐1500Cisacompleteturntablesystemdesignedfora
widerangeofusers,evenoutsideofstrictlydedicated
audioenthusiasts.
A complete direct drive turntable system inheriting the high-sound-quality technology of
Technicsʼ acclaimed direct drive system
3

TechnicalInformation forHi‐Fi Audio System
SL-1500C Premium Direct Drive Turntable System
SL‐1500C
PremiumClassDirectDriveTurntableSystem
4
•Accuraterotationofphonorecordsandaccuratetrackingofrecordgrooves
forfaithfulsoundreproduction
‐ Corelessdirectdrivemotorandmotorcontroltechnologyforaccurateand
stablerotation
‐ Two‐layerstructureplatterofferingexcellentvibrationdamping
performance
‐ High‐sensitivitytonearmwithaheightadjustmentmechanism
‐ High‐rigiditycabinetandhigh‐dampinginsulatortoshutoutvibrations
•Completepackagefortheenhancementofrecordplayingenjoyment
‐ Built‐inphonoequalizer
‐ High‐sound‐qualityphonocartridge(Ortofon2MRed)included
•Superboperabilityforcomfortablerecordplayingandanattractive,high‐
gradedesign
‐ High‐grade,simpledesign
‐ Autolifterforthepreventionofunnecessarywearonrecordsandstylus

TechnicalInformation forHi‐Fi Audio System
Coreless Direct Drive Motor
5
Thehigh‐qualitysoundrealised bytheexceptionalS/Nratio
andhighrotationaccuracyofthedirectdrivesystem
employedinTechnicsturntableproductshascaptivatedthe
heartsofaudiophilestheworldover.TheSL‐1500Cinherits
thesamehigh‐qualitysoundfoundinTechnics’high‐end
turntablemodels.Itusesasingle‐rotor,corelessdirectdrive
motorinwhichthestatorhasnocoreandeliminatesthe
rotationirregularitycalledcogging.Inthismotor,the
magneticforceoftherotormagnetswasimprovedtothe
highestpossiblelevel,andthegapbetweenthecoreless
statorandrotormagnetswasoptimised,thusachievinghigh
torqueperformanceequalling thatoftheSL‐1200MK5while
eliminatingcogging.Furthermore,themotorcontrolwas
optimised inaccordancewiththeplatterweight.Asaresult,
theSL‐1500Chasrealised highrotationaccuracyandhigh
performance,andeliminatedtheneedforpartsreplacement
andmaintenance.Anotheradvantageofthedirectdrive
systemisitslong‐lasting,highreliability.
Achievesstablerotation
CorelessDirectDriveMotor
Shaft
Magnet
PCB Housing ShaftBearing
RotorYoke
Turntable
BackYoke

TechnicalInformation forHi‐Fi Audio System
Coreless Direct Drive Motor
6
Inthedirectdrivesystem,themotorisconnecteddirectlytotheplattersothatthe
motorrotationspeedbecomestherotationspeedofthephonorecord.Therefore,itis
extremelyimportanttocontrolthedrivemotor’srotationspeedtoensurestability.
TheSL‐1500Cutilises thelatestmotorcontroltechnologyrefinedthroughthe
developmentofBlu‐raydiscproducts.Furthermore,theFGcoilpatternofthefull‐
circumferencedetectionFGsystemwasimprovedinprecisiontoachievemore
detailedmeasurementofplatterrotationspeed.
Plattershapeoptimised bysimulation
HighAccuracyMotorControl
Accuratesinewaveoutputbythemicrocomputerisusedasthecontrolwaveformfor
constantrotationspeedoperation.Thissinewaveissmootherthanthesimplified
sinewavegeneratedbytheexternalcoilusedintheSL‐1200MK5,thusensuring
accuratemotorcontrol.TheSL‐1500Calsoutilisesthenewestmotorcontrol
technologyrefinedthroughthedevelopmentofBlu‐raydiscproducts.Furthermore,it
incorporatestechnologiesusedinhigh‐endmodelstocorrectvariationsof
characteristicsinthepartsofthemotordrivecircuitandmagneticcircuit.
SL‐1200mk7/SL‐1500C
SL‐1200mk5

TechnicalInformation forHi‐Fi Audio System
Turntable Platter
7
Theplatteronwhichavinylrecordisplacedfeaturesatwo‐layerstructurewithdeadeningrubberontheentirebacksurfaceto
eliminateunwantedresonanceinthealuminium die‐castplatter.Theplatteroffershighrigidityandoutstandingvibration‐
dampingcharacteristicstopreventharmfulvibrationfrombeingtransmittedtotherecordanddeliversclearsound.
Toincreasetheinertialmassandminimise vibration,theshapeofthealuminium die‐castsectionwasoptimised through
simulation.Forextrarigidity,reinforcingribswereaddedtothebackside.Theincreasedareaofcontactwiththedeadening
rubbercontributestotheoutstandingvibration‐dampingcharacteristicthatismorethantwotimeshigherthanthatoftheSL‐
1200MK5.
Plattershapeoptimised bysimulation
Two-layer Structure with Improved Vibration Damping Performance
‐150
‐100
‐50
0
50
100
150
0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16 0.18 0.2 0.22 0.24 0.26 0.28 0.3
: 1500C
︓1200MK5

TechnicalInformation forHi‐Fi Audio System
Tonearm phono cartridge A
8
Thetonearm,whichisresponsibleforaccuratelyreadingthesignalbytrackingthegrooveonthe
phonorecord,isastatic‐balanceuniversalS‐shapetonearm,anotherTechnicstradition.Thetonearm
pipeismadeoflightweight,high‐rigidityaluminium.Thebearingsectionofthegimbalsuspension
constructiontonearmconsistsofamachinedhousingandhigh‐precisionbearingtoprovidehigh
initialsensitivity.Allinall,thetonearmaccuratelytracesthegrooveontherecordandreadsthe
signal.
Accuratelyreadssignalsfromthegrooveontherecord
High SensitiveTonearm
ThesupplieduniversalheadshellismountedwithanOrtofon 2MREDcartridge.So,youcanplaya
recordimmediatelyafterpurchasingtheSL‐1500C.
Thetonearmheightcanbeeasilyadjustedwithinarangeof6mmtoenabletheuseofvariousother
phonocartridges.Usingtheauxiliaryweightthatcomeswiththeproduct,acartridgeweighing14.3to
25.1g(includingthesuppliedheadshell)canbeused.
High‐sound‐qualityMMcartridgeprovided
PhonoCartridge

TechnicalInformation forHi‐Fi Audio System
Auto Lifter Function
9
EquippedwithanAutoLifterFunctionThatAllowsYoutoEnjoyPlayingRecordsMoreComfortably
Whenthetonearmreachestheendoftherecord,theAutoLifterfunctionautomaticallyraisesthecartridge.Thisprevents
unnecessarywearonyourvaluablevinylrecordsandstylus.ByembeddingtheAutoLifterfunctioninthebaseportionofthe
tonearm,iteliminatesimpactstothetonearm.Duetoasimpledesignthatdoesn’tusemotorpower,thereisnoelectricalor
vibrationalimpactanditwillnotpreventthemovementofthetonearm.Inresponsetorequestsfrommanyusersregarding
theAutoLifterfunction,adesignthatprioritizessoundqualitywasadopted.Thefunctionsrequiredtoplaybackrecords
werekepttoabareminimum,achievingsimpleandeasy‐to‐useoperability.

TechnicalInformation forHi‐Fi Audio System
Built-in Phono Equalizer and Cartridge
10
TheSL‐1500Chasabuilt‐inphonoequalizerampcompatiblewithMMcartridgessoitcanbeconnectedtoanaudio
productthatdoesnothavephonoinputterminals.Thededicatedpowersupplyforthephonoequalizerisisolatedfromthe
powersupplyforthemotorandcontrolcircuitrytoreducetheeffectofnoise.Furthermore,theshieldstructuresuppresses
theeffectofexternalnoise.Asaresult,high‐puritysignalamplificationisrealized.UsingtheSL‐1500Candtheaudio
equipmentyouhave,youcanenjoymusicfromavinylrecordinhighsoundquality.
Connectstoavarietyofdevices
Built‐inPhonoEQ

TechnicalInformation forHi‐Fi Audio System
Turntable Platter
11
Thechassis,anessentialpartforreducingexternalvibrations,inheritstheaudioqualityenhancementtechnologyfostered
throughthedevelopmentofhigh‐endturntables.Thealuminium die‐castchassisisrigidlyintegratedwithaspecialmaterial
consistingofABSmixedwithglassfibertoachieveatwo‐layerconstruction.Thecombinationofthisspecialhigh‐rigidity
materialandametalchassisraisedtherigidityandvibration‐dampingperformancetohigherlevels,realising arobustcabinet
forbeautifulsoundreproduction.
Theinsulatoriscomprisedofaspringandrubbertoprovideoptimalfrequencycharacteristics.Thisnotonlyassureshigh
soundqualityandsuperbhowlingresistance,butalsoeffectivelyshutsoutexternalvibrationsunderhighsoundlevel
conditions.
Cabinetfeaturingananti‐vibrationconstructionforthoroughshut‐outofallvibrations
HighRigidityCabinetandHighDampingInsulator

TechnicalInformation forHi‐Fi Audio System
Design
12
The SL-1500C sports a simple design without unnecessary frills, while retaining the superb operating feel that is a
Technics tradition. The attractive appearance lets you enjoy playing records to your heartʼs content.
High-grade design deepens the enjoyment of listening to music
SimpleDesignwithFunctionalBeauty

TechnicalInformation forHi‐Fi Audio System
13
Specification
PublicInfo US/Canada Europe
TurntableSection
Yes DirectDrive DirectDrive
Yes BrushlessDCmotor BrushlessDCmotor
Yes 331/3,45,78rpm 331/3,45,78rpm
Yes - -
Yes 0.18N・m/1.8kg･cm(1.56lbs‐in) 0.18N・m/1.8kg･cm
Yes 0.7s.fromstandstillto331/3rpm 0.7s.fromstandstillto331/3rpm
Yes 0.025% W.R.M.S. 0.025% W.R.M.S.
Yes
Aluminumdiecast
Diameter：332mm(13‐5/64inch)
Weight：Approx.1.8kg(4.0lbs)(Includingslipmatandslipsheet)
Aluminumdiecast
Diameter：332mm
Weight：Approx.1.8kg(IncludingTurntableSheet)
TonearmSection
Yes Universal
StaticBalance
Universal
StaticBalance
Yes 230mm(9‐1/16") 230mm
Yes 15mm(19/32") 15mm
Yes Within2°32' (attheoutergrooveof30cm(12")record)
Within0°32' (attheinnergrooveof30cm(12")record)
Within2°32' (attheoutergrooveof30cm(12")record)
Within0°32' (attheinnergrooveof30cm(12")record)
Yes 22° 22°
Yes 0‐6mm 0‐6mm
Yes 0‐4g(DirectReading) 0‐4g(DirectReading)
Yes Approx.7.6g Approx.7.6g
Yes
(withoutauxiliaryweight)
5.6‐12.0g
14.3‐20.7g(includingheadshell)
(withauxiliaryweight)
10.0‐16.4g
18.7‐25.1g(includingheadshell)
(withoutauxiliaryweight)
5.6‐12.0g
14.3‐20.7g(includingheadshell)
(withauxiliaryweight)
10.0‐16.4g
18.7‐25.1g(includingheadshell)
Yes ‐ ‐
Yes 1.2mmφ4‐pinterminallug 1.2mmφ4‐pinterminallug
Terminals
Yes
PHONO(PinJack)x1
EARTHTERMINALx1
LINEx1
PHONO(PinJack)x1
EARTHTERMINALx1
LINEx1
General
Yes AC120V,60Hz AC110‐240V,50Hz/60Hz
Yes ?W
Approx.0.2W(Standby)
?W
Approx.0.2W(Standby)
Yes 453x173x372mm
17‐27/32×6‐13/16×14‐21/32inch 453x173x372mm
Yes Approx.11.5kg
Approx.25.35lbs Approx.11.5kg
Yes 0℃to+40℃(32°Fto+104°F) 0℃to+40℃(32°Fto+104°F)
Yes 35%to80%RH(nocondensation) 35%to80%RH(nocondensation)
Yes
Turntable,Turntablesheet,Dustcover,
EPrecordadaptor,Balanceweight,
Auxiliaryweight,
Headshell,Cartridge(Ortofon2MRed),PHONOcable,
PHONOearthlead,ACpowersupplycord,
Owner'sManual
Turntable,Turntablesheet,Dustcover,
EPrecordadaptor,Balanceweight,
Auxiliaryweight,
Headshell,Cartridge(Ortofon2MRed),PHONOcable,
PHONOearthlead,ACpowersupplycord,
Owner'sManual
Weight
Operating temperature range
Operating humidity range
Accessories
Cartridge Mounting Dimension
Head Shell Terminal Lug
Audio Output
PowerSupply
PowerConsumption
Dimensions(WxHxD)
TrackingErrorAngle
Offset Angle
Arm Height Adjustment Range
Stylus Pressure Adjustment Range
Headshellweight
ApplicableCartridgeWeightRange(includingHeadshell)
Build-up Characteristics
WowandFlutter
Turntable Platter
Type
Effective Length (from the tonearm pivot to the stylus)
Overhang
Criteria
Drive Method
Motor
Turntable Speeds
Adjust Range
StartingTorque
Weight:Approx.2.0(4.5lbs)(IncludingTurntablesheet) Weight:Approx.2.0(Includingrubbersheet)
8W8W
453x169x372mm
17‐27/32x6‐21/32x14‐21/32inch 453x169x372mm
Approx.9.9kg
Approx.9.9kg
Approx.21.2lbs
13

TechnicalInformation forHi‐Fi Audio System
ON/OFF button
START/STOP
button
Tonearm
Turntable
Centerspindle
Balanceweight
Anti‐skatingcontrol
Cuelever
Headshellwithcartridge
*Theheadshellcomeswith
acartridgeequivalentto
“ortofon 2MRed”.
Turntablemat
リフトアップ
スイッチ
Backside
Arm‐height
adjuster
Speedselectbuttons
33
45
78（Press[33]and[45]
buttonsatthesametime）
Autolift‐up
switch
External
output
terminal
External
output
switch
PHONO
output
terminal
PHONOearth
terminal
Parts name
52mm
Whenplayingarecord,
removethestyluscover.
Whenplayingarecord,
removethestyluscover.
Adjusttheoverhangin
thatthestylustipisat
52mm fromtheheadshell
mountingend.
Adjusttheoverhangin
thatthestylustipisat
52mm fromtheheadshell
mountingend.
Whenreplacingstylus,
removeitasfollows.
Whenreplacingstylus,
removeitasfollows.
14

TechnicalInformation forHi‐Fi Audio System
Removetheturntablesheet,
turntableandheadshell.
Turntheunitupsidedown,placeit
onathickpadordustcoverand
removescrews.
Fixtonearmwith
thearmclamp
Need
unsoldering
(5cables)
Releasethearmlockandthen
pullitup.
Remove2screws Noneedto
remove
PhonoEqualizercircuit
Service information – Disassembly * Refer to service manual for more details
Putacushionsuchaswhat
isusedforpackingproducts,
tofixthetonearm
completely.
Releasethearm
lock.
15

TechnicalInformation forHi‐Fi Audio System
①Releasethearmclamper
②Lowerthecueleverslowlyonce
③Raisethecueleverandmove
thetonearmovertherecord
④Lowerthecueleverslowlytoletthemusicstart
⑤Thetonearmautomaticallyliftsupafter
arecordfinishesplaying(Thismaytakeup
toapprox.90seconds)
■Thisfunctionautomaticallyliftsupthetonearmaftera
recordfinishesplaying.Itpreventsthelastgroovefromplaying
backrepeatedly.
*1Itdoesnotstoptheturntablerotation
*2Thetonearmjustliftsupanditdoesn’treturntothe
originalposition.
■Theopticalsensorfordetectingthetonearmposition,aspring
forliftingthetonearmandtheelectromagneticcoilare
equippedinsidethetonearmunit.
Byloweringthecuelever,theelectromagneticcoilandspring
movetotheinitialposition.
Whenthetonearmmovestoneartheinnermost
circumference,theopticalsensordetectsit.Aftertheelapseof
acertainperiodoftime, itactivatestheelectromagneticcoiland
liftsthetonearmup.
Electromagnetic
coil
Opticalsensor
Spring
*Sincethesepartsrequirehighmanufacturingaccuracy,they
cannotbereplacedindividually.Pleasereplacethetonearmunit.
Service information – Auto Lifter Function
16

TechnicalInformation forHi‐Fi Audio System
1.Entertheservicemode.
2.Mounttheturntableandturntablemat.
3.Keeppressing[Start/Stop]forover3seconds.
Theturntablerotates,stopsandrotatesagain.
[33]LEDblinksforapprox.1minuteduringadjustment.
Theturntablestopsand[33]LEDturnsonwhenadjustmentiscompleted.
*Thisadjustmentisrequiredwhenreplacingthetonearmunit,MainPCB,and
DCmotorincludingwhenscrewsoftheDCmotor areunscrewed.
*ThisadjustmentisrequiredwhenreplacingtheDCmotorand/or
MainPCB.
1.Press[Power]whilepressing[Start/Stop].
2.Keeppressing[Start/Stop]andpress[Speedselect[33]→[33]→
[45]→[45]→[33]→[33]].
3.[45]LEDblinkswhenenteredtheservicemodeproperly.
4.Thenumberof[45]LEDblinkingshowsthesoftware
version.(Firstshipmentversion:3blinks)
Asthenumberofsoftwareversionincreases,thenumberofLED
blinkingincreasesbyone.
5.Toexittheservicemode,press[Power].
Toentertheservicemode
Service information – Service Mode & Adjustment
DCmotoradjustment
Auto lifter adjustment
1.Entertheservicemode.
2.Keeppressing[45]formorethan3seconds.
3.[45]LEDblinksat1sec.intervalduringAutolifteradjustmentmode.
4.Movethetonearmfromoutsidetoinside.
Whenthetonearmreachesadetectionpointoftherecordend,
[33]LEDturnson.
Measurethedistancebetweenthelateralfaceofspindleandthestylustip
whenreachedatdetectionpoint([33]LEDjustturnson).
[33]LEDON
[33]LEDOFF
17

TechnicalInformation forHi‐Fi Audio System
Turntablespeed Position‐1 Position‐2
33 After20sec. After70sec.
45/78 After45sec. After90sec.
Service information – Service Mode & Adjustment
c)IfthedetectionpointandLEDblinkareimproper,LEDblinksoncein
“Position‐2”oritblinkstwicein“Position‐1”.
Keeppressing[33]formorethan3secondsandconfirmthedetectionpoint
andLEDblinkisproper.
Autolifterfunctionworksafteralapseofthefollowingtimewhentonearm
reachesthedetectionpointoftherecordend.
a) In case that detection point of the auto lift-up function is in the
range between 51.5mm and 56.5mm, it is set in “Position-1”.
b) In case that detection point of the auto lift-up function is in the
range between 56.5mm and 60.5mm, it is set in “Position-2”.
c) In neither case above, the torn arm or detection sensor may be
defect and thus replace the torn arm unit.
５. Press [33] to confirm whether the detection point is set properly.
a)When the stylus tip reaches in “Position-1”: [33] LED
blinks once and it repeats 3 times a second.
b)When the stylus tip reaches in “Position-2”: [33] LED
blinks twice and it repeats 3 times a second.
Position‐1 Position‐2
500ms:ON 500ms:OFF
3times
100ms:ON
700ms:OFF
100ms:OFF
100ms:ON
3times
18

TechnicalInformation forHi‐Fi Audio System
200ms
200ms
700ms
200ms
200ms
700ms
200ms
700ms
LEDblink Abnormalcondition Defectpart
[33]LED
Motorspeederror
‐‐>Motorwillstop DCMotorand/or MainPCB
[33]LED
Motorspeederror
‐‐>Motorwillstop DCMotorand/orMainPCB
[45] LED
AbnormalFGsignalofmotorhallsensor
‐‐>Motorwillstop DCMotorand/orMainPCB
[45]LED
Abnormalinputsignalofmotorhallsensor
‐‐>Motorwillstop DCMotor
[33]and[45]LED
Abnormalmotorvoltage(+24Vline)
‐‐>Motorwillstop SMPS PCBand/orMainPCB
[33]and[45]LED
Abnormalclockswitchingsignal
‐‐>Motorwillstop MainPCB
Service information – LED indication in abnormal condition
200ms
19

TechnicalInformation forHi‐Fi Audio System
1)Removetheturntablemat,turntable,headshellandbalanceweight.
・Sincethetonearmisvulnerabletoimpact,usetheoriginalpackagingmaterialfortransportationandpackitinthereversemannerofunpacking(seebelow).
・Ifthereisnooriginalpackingmaterial,protectthetonearmaccordingtothefollowingstep1)to4)andwrapthebodywithablanketorsoftclothtopreventfromgettingscratches.
[Packingprocedure]
Ifnooriginal
packingmaterial
Service information – Handling procedure for transportation
20
Putacushionsuchaswhatis
usedforpackingproducts,
tofixthetonearmcompletely.
2)Fastenthetonearmwiththearmclamp. 3)Tapetheclampertofix. 4)Setabubblewrapunderthetonearmandfixithorizontally.
*Handlewithcautionbecausethetonearmwillbedeformed
ifthecushionistoothick.
