Technique 99800 Installation guide

INSTRUCTIONS
FOR PROPER USE AND CARE
IMPORTANT!
Please keep these instructions and your original box packaging.
Model #99800, 99801, 99802, 99803, 99805, 99807, 99810
Troubleshooting
If you have not added sufficient liquid and you notice that the floating valve
has not risen, but the timer is counting down, perform the following steps:
1. Stop the pressure cooker by pressing the START/STOP button.
2. Turn the pressure regulator knob to STEAM, using short bursts, until
the pressure is fully released.
3. Remove the lid and add approximately 1]/2cups of water/stock or
any liquid. Stir food to disperse liquid.
4. Replace the lid and lock into position.
5. Set the pressure and time per page 6.
6. Press the START/STOP button to begin cooking again.
If steam is leaking from under the cover because the cover is not properly
closed, the gasket isn’t positioned properly or is damaged, or the
pressure cooker is over filled, follow these steps:
1. Unplug, release any pressure using the quick release method.
2. Remove the gasket and check for tears or cracks.
3. Check to be sure the gasket is positioned properly.
4. If too full, remove excess liquid and continue cooking.
If you can’t open or remove the cover:
1. Be sure all of the pressure has been released.
2. If you still cannot open it, bring the contents of the cooker up to
pressure again.
3. Release the pressure completely.
4. If the cover still won’t come off, call customer service at
1-800-336-4822.
ELECTRIC 6.5 QT.
VOICE PRESSURE COOKER

114
TABLE OF CONTENTS
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
How to Operate
Before First Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Pressure Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Warm Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Brown Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
Steam Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Slow Cook Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Delay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
Recommended Cooking Times . . . . . . . . . . . . . . . . . . . . . . .12-13
Hints and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .back cover
■To ensure the best cooking performance when cooking under pressure,
always use at least 11/2cups of water or liquid in your recipes to
enable enough steam to be created to produce pressure.
■Frozen foods can be cooked in a pressure cooker. Add appoximately
10 minutes to every inch of thickness.
■When using the pressure settings, the timer should not begin counting
down until there is enough pressure.
■When cooking under pressure, if you are unsure of the cooking time, it
is better to under cook and use the quick release method and check for
doneness. If not done, continue cooking under pressure.
■Never fill the Pressure Cooker more than half full with food or 2/3full
with liquid. The pressure cooker must have enough liquid to steam or
the food will not cook properly.
■If the electric circuit is overloaded with other appliances, your
appliance may not operate. The pressure cooker should be operated
on a separate electrical circuit.
■Tougher, less expensive cuts of meat are better suited for the pressure
cooker because cooking under pressure breaks the fibers down for
tender results.
■Fresh fruit should be cooked on low pressure.
■Add a tablespoon of oil to the water to reduce the amount of foaming
that beans produce.
HINTS AND TIPS

13 2
IMPORTANT SAFEGUARDS
When using this electrical appliance, safety precautions must always be
observed, including the following:
A Pressure Cooker is very safe when used properly.
■READ ALL OF THE INSTRUCTIONS BEFORE USE.
■Close adult supervision must be provided when this appliance is used by
or near children. Keep pressure cooker out of the reach of children.
■This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
■Children should be supervised to ensure that they do not play with the
appliance.
■The pressure cooker has a polarized AC (Alternating Current) plug (one
blade is wider than the other). This plug will fit in a polarized outlet only
one way, as a safety feature. Reverse the plug if the plug does not fit fully
in the outlet. Contact a qualified electrician if it still does not fit. Do not
attempt to defeat this safety feature.
■Short power cord should be used to reduce the risk resulting from becom-
ing entangled in or tripping over a longer cord. If a longer extension cord
is used, the marked electrical rating of the extension cord should be at
least as great as the electrical rating of the appliance, and the cord should
be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
■Do not operate with a damaged cord or plug. If the appliance is not
working as it should, has been dropped or damaged, left outdoors or
dropped into water, do not use it and return it to the manufacturer for
proper service, repair, or replacement.
■Do not let cord hang over the edge of the table or counter, or touch
hot surfaces.
■Do not place near hot gas or electric burner, or in a heated oven.
■Always use in a well ventilated area.
■For indoor use only.
■The pressure cooker is for household use only. The pressure cooker
should not be used for other than the intended use.
■Do not cover the appliance or have it near flammable material
including curtains, draperies, walls, and the like when in operation.
■Do not cover the pressure valves with anything. An explosion may occur.
■Do not use without the removable cooking pot in place. This will reduce
the risk of electrical shock.
■Do not fill the pressure cooker more than 1
/2 full with food or 2/3full
High Pressure (15.0P)
Potatoes
Pieces, slices 5-8 mins
Whole, small 5-8 mins
Whole, medium 10-12 mins
Rice
Brown 15-20 mins
White 5-7 mins
Spinach, fresh 2-3 mins
Squash
Fall, 1” chunks 4-6 mins
Summer, sliced 1-2 mins
Meat and Poultry
Beef, Pork, Lamb (1-2” cubes) 15-20 mins
Beef/Veal
Roast, brisket 50-60 mins
Shank 11 /2” thick 25-35 mins
Meatballs, browned 8-10 mins
Lamb, boneless roast 45-55 mins
Pork
Loin roast 40-50 mins
Smoked butt 20-25 mins
Ham shank 30-40 mins
Chicken
Boneless breast, thigh 8-10 mins
Pieces 10-12 mins
Whole 30 mins
Turkey breast, whole 30-40 mins
Fish
Steaks, fillets
3
/4” 4 mins
1” 5 mins
11 /4” 6 mins
11 /2” 7 mins

312
with liquid. When cooking foods that expand during cooking do not fill
the unit over 1 /2 full.
■When cooking food under pressure, at least 11
/2cup (12 oz.) of liquid
must be used.
■Foods such as applesauce, cranberries, pearl barley, oatmeal or other
cereals, split peas, noodles and pasta, or rhubarb should not be cooked
under pressure in the pressure cooker. These foods tend to foam, froth
and sputter, and may block the floating valve.
■The exterior and the lid becomes hot during use. Do not touch hot
surfaces. Use handles or knobs.
■WARNING: Keep hands and face away from pressure regulator knob
when releasing pressure.
■While the unit is in operation, never remove the lid.
■Do not pick up regulator knob when inner tank full of steam pressure.
■To reduce the risk of electric shock, cook only in removable container.
■After cooking, use extreme caution when removing the lid. Serious burns
can result from steam inside the unit.
■CAUTION: When removing the lid, there could be a suction created
between the inner pot and lid.
■Extreme caution should be used when moving any appliance
containing hot food or liquid.
■Do not attempt to dislodge food when the appliance is plugged in.
■CAUTION: Perishable foods such as meat and poultry products, fish,
cheese and dairy products cannot be left at room temperature for
more than 2 hours. (No longer than 1 hour when the room
temperature is above 90°F). When cooking these foods, do not set
the delay time function for more than 1-2 hours.
■DANGER: Never deep fry or pressure fry in the pressure cooker. It is
dangerous and may cause a fire and serious damage.
■Using attachments not recommended or sold by the manufacturer may
cause hazards.
■Make sure appliance is off before unplugging from wall outlet.
■Always unplug before cleaning. Allow to cool before putting on or taking
off parts.
■To protect against electrical shock, do not immerse plug, cord or
housing in water or any other liquid.
■Servicing or repair should only be completed by a qualified technician.
■DANGER: Do not lift the unit with cover handle, use side handles only.
SAVE THESE INSTRUCTIONS
Cooking times are approximate times. Use these as general
guidelines. Size and variety will alter cooking times.
Vegetables High Pressure (15.0P)
Apples, chunks (low pressure) 2 mins
Artichokes, whole 8-10 mins
Asparagus, whole 1-2 mins
Beans
fresh green or wax 2-3 mins
shelled lima 2-3 mins
Beets
1
/4” slices 3-4 mins
whole, peeled 12-15 mins
Broccoli, florets or spears 2-3 mins
Brussel sprouts, whole 3-4 mins
Cabbage, quartered 3-4 mins
Carrots, 1 /4” slices 1-2 mins
Cauliflower, florets 2-4 mins
Corn on the cob 3-5 mins
Eggplant, 11 /4” 2-3 mins
Peas, shelled 1-11 /2mins
CLEANING & COOKING TIMES
7. Never use abrasive cleaners or scouring pads to clean any of the parts.
NOTE: Store the pressure cooker with the lid resting upside down on the
removable cooking pot. This will protect the valves, knobs and pressure
regulator on the top of the lid. If the pressure cooker is stored with the lid
sealed, stale odors may form inside.
Cleaning the Pressure Regulator Knob
Check that the pressure regulator knob is in working order before each use.
1. After the unit has cooled, remove the lid, lift up the regulator knob.
2. Using a brush, check and remove any food or foreign particles
that may be lodged in the floating valve.
3. Replace the pressure regulator knob in the lid.
Recommended Cooking Times

11 4
FEATURES
Pressure/Steam
Regulator Knob
Floating Locking Valve Handle
Rubber
Gasket
Control Panel
Side
Handles
Lid/Cover
Removable Non-Stick
Cooking Pot
Sensor Pad
Heating Plate
Housing
Stationary Pot
Safety
Valve
Sliding Lock
Speaker
Delay Time Setting
This function allows you to begin cooking food up to 8 hours later in half
hour increments. You can use the delayed time setting with the slow cook,
steam, warm or pressure settings. CAUTION: Perishable foods such as meat
and poultry products, fish, cheese and dairy products cannot be left at
room temperature for more than 2 hours. (No longer than 1 hour when the
room temperature is above 90°F.) When cooking these foods, do not set the
delay time function for more than 1-2 hours.
1. If pressure cooking, set the pressure per directions on page 6 steps 1-
8. (Slow cook - see page 10, steps 1-7) (Steam page 9-10 steps 1-8)
(Warm page 8, steps 1-9).
2. Press the “Delay Time”. The delay time will illuminate on the display.
3. Press the “+” or “-” buttons to set the desired delayed time.
4. Press the “Start/Stop” button to begin the countdown of delay time.
Cleaning
Do not wash any parts of the pressure cooker in the dishwasher. Always
wash the pressure cooker thoroughly after every use, or if it has not been
used for an extended period of time.
1. Unplug and let the unit cool before cleaning.
2. Wash the removable cooking pot with warm soapy water. Rinse and
dry thoroughly.
3. Wipe the housing with a clean damp cloth. Do not submerge in water.
4. Turn the lid upside down, grasp the rubber gasket on either side and
pull up. Clean the rubber gasket in warm soapy water. Rinse and dry
thoroughly. Replace the gasket by pushing it down inside the edge of
the lid. Make sure the rim of the gasket is wedged in the groove
around the edge of the lid. Note: If the gasket is not positioned
properly, the unit will not work.
NOTE: The rubber gasket must always be properly positioned on the
underside of the lid. Check periodically to make sure that it is clean,
flexible, and not cracked or torn. (See pg. 6 “Before First Use”, #3.)
5. If the rubber gasket is damaged, do not use the appliance and contact
the Customer Service department at 1-800-336-4822.
6. In order to maintain good performance of your pressure cooker, the
bottom of the removable cooking pot, in the area of the sensor pad,
must be cleaned after each use. Wipe with a soft damp cloth and be
sure to dry thoroughly.
DELAY & CLEANING
Clip plate
Tab
Tab
Clip plate

510
Pressure/Steam In down position when cooking under
Regulator Knob: pressure, in up position when steaming.
Sliding Lock: Allows you to lock the lid to the pressure cooker.
Removable Cooking Pot: 6.5 qt. capacity non-stick removable pot provides
even heat distribution.
Rubber Gasket: Creates an air tight seal that is needed for the
pressure cooker to operate.
Control Panel Functions: Warm function reheats or keeps food warm.
Brown function allows you to brown your food
before cooking it under pressure.
Steam function quickly brings cooking liquid
to a boil for steaming food or cooking rice.
Slow Cook function cooks your food slowly
to retain flavor and tenderness (12 hour timer).
NOTE: 180°F is the lowest setting on a
traditional slow cooker. Most recipes using a
slow cooker require 8-9 hours.
Delay Time feature allows you to begin cooking food
up to 8 hours later. CAUTION: Perishable foods
cannot be left at room temperature for more than 2
hours. (Or 1 hour when the room temperature is
above 90°F.) When cooking these foods, do not set
the delay time function for more than 1-2 hours.
Cooking Status shows the preset cooking time,
temperature and the pressure
Setting Pressure allows you to choose 3
different pressure settings: 2.5 psi (low); 7.5
psi (medium); 15 psi (high).
Voice Control: Will give you instructions on how to use. Once
you press the function, a voice will reply with the next
step of action. Turn off the voice function by
pressing the START/STOP button for 2 seconds
before selecting the cooking mode.
FUNCTIONS
8. Press the “Steam” button. The display will flash 15. (This equals 15
minutes of cooking time. Min is 1 minute; MAX is 99 minutes). Press
the “+” or “-” buttons to set the desired time.
9. Press the “Start/Stop” button to begin steaming. When the cooking
time is up, the unit will beep.
10. Press the Start/Stop button to turn the unit off.
NOTE: The lid can be opened while cooking to check the food. Use caution
when removing the lid. Never place your face over the pressure cooker
when removing the lid. Steam escapes as soon as the lid is opened and
can cause serious burns.
11. Take the inner pot out, using potholders, swivel counter clockwise, lift
up to remove.
Slow Cook Setting
1. Plug the cord into a wall outlet. The display will show --:--.
2. Position the removable cooking pot in the appliance at a diagonal.
Swivel the pot so the tabs are under the clip plate to stop the pot from
upward movement.
3. Place the food to be slow cooked in the cooking pot.
4. Place the lid on the pressure cooker and lock the lid in place.
5. Turn the pressure regulator knob to STEAM.
6. Press the “Slow Cook” button. 180°F is default. Press
the “+” or “-” buttons to set the desired temperature.
(min is 180°F; MAX is 190°F). Note: 180°F is the
lowest setting on a traditional slow cooker.
7. Press the “Slow Cook” button. The display will show 4:00. This equals
4 hours of cooking time. Press the “+” or “-” buttons to set the desired
cooking time. The longest cooking time is 12 hours.
8. Press the “Start/Stop” button to begin cooking. When the cooking time
is up, the unit will beep.
9. Press the “Start/Stop” button when cooking time is complete, or to
cancel or reset. Otherwise, the pressure cooker will automatically
switch to warm for 8 hours.
10. Take the inner pot out, using potholders, swivel counter clockwise, lift
up to remove.
Pressure
Regulator Knob

96
Before First Use
1. Remove all packing materials and literature.
2. Wash all removable parts in warm soapy water. Rinse and dry all
parts thoroughly. Wipe the outer housing with a clean damp cloth.
NEVER immerse the housing in water or any other liquid. NEVER clean
any parts in a dishwasher.
3. Make sure the rubber gasket is seated properly inside the lid. To ensure
the correct fitting, fill the removable cooking pot with two-thirds water
and run on HIGH PRESSURE (15.0p) for 15 minutes.
4. Release the pressure by turning the pressure regulator knob to STEAM.
The floating locking valve will drop.
5. Let the appliance cool to room temperature and then empty and clean.
Voice Feature
This pressure cooker will give you the instructions on how to use. Once you
press a function on the control panel, a voice will reply with the next step of
action. The VOICE will start as soon as you press a button on the control
panel. Turn off the voice function by pressing the START/STOP button for
2 seconds before selecting the cooking mode.
Using the Pressure Setting
Before using the pressure cooker each time, make sure the rubber gasket
and the pressure regulator knob are clean and positioned properly
(page 11.) Do not use metal utensils or knives on the cooking pot.
High=15psi=15.0P Medium=7.5psi=7.5P Low=2.5psi=2.5P
1. Plug the cord into a wall outlet. Display will show - - : - -
2. Position the removable cooking pot in the appliance at a
diagonal. Swivel the pot so the tabs are under the clip plate
to stop the pot from upward movement.
3. Place food in the cooking pot according to the recipe
or chart.
NOTE: When cooking foods under pressure, a
minimum 11 /2cups (12 oz) of liquid is needed.
4. Place the lid on the pressure cooker (lock is in the
front) and slide into the locked position.
HOW TO OPERATE
Locking the Lid
1. Plug the cord into a wall outlet. The display will show --:--.
2. Position the removable cooking pot in the appliance at a diagonal. Swivel
the pot so the tabs are under the clip plate to stop the pot from upward
movement.
3. Add the appropriate amount of oil as per recipe.
4. Press the “Brown” button. The lid should remain off.
5. The display will flash 30 minutes (this equals 30 minutes of cooking
time. MIN is 1 minute; MAX is 30 minutes). Press the “+” or “-” buttons to
set the desired browning time.
6. Press the “Start/Stop” button to begin browning.
NOTE: Do not leave pressure cooker unattended while browning foods.
7. Press the Start/Stop button to turn the unit off.
8. Take the inner pot out, using potholders, swivel counter clockwise, lift up to
remove.
Note: Use this setting when you are finished to create gravies & sauces.
Steam Setting
This program quickly brings liquid to a boil for steaming food or cooking rice.
1. Plug the cord into a wall outlet. The display will show --:--.
2. Position the removable cooking pot in the appliance at a diagonal. Swivel
the pot so the tabs are under the clip plate to stop the pot from upward
movement.
3. Place a small, heat-resistant rack or basket (not included) in the bottom
of the removable cooking pot.
4. Add at least 11/2cups of water so that the bottom of the rack is above the
liquid.
5. Add the food. Do not fill the pot more than two-thirds full. Note: If steam-
ing rice, put the rice in a 7” or smaller bowl, place on the
rack.
6. Place the lid on the pressure cooker and lock the lid in place.
7. Turn the pressure regulator knob to STEAM. Pressure
Regulator
Knob

78
5. Turn the pressure regulator knob to PRESSURE.
6. Press the “Setting Pressure” button on the control
panel. 15.0p (high pressure) is the default.
7. Select a different pressure setting by pressing “+”
or “-” button to 7.5 p (medium pressure) or 2.5p (low pressure).
8. Press the “Setting Pressure” button again.
9. The cooking time will flash 15 (for 15 minutes) on the display. Press the
“+” or “-” buttons to set the cooking time.
10. Press the “Start/Stop” button to begin cooking.
11. The unit will begin to count down after the pressure has been reached.
It may take several minutes to begin counting down. This depends
on the fullness of the pot. When the pressure level is reached, only the
cooking time will be displayed and the timer will start to count down.
12. When cooking is finished, the unit will beep. Let the pressure drop on
its own (also called the natural release method), or release immediately
by turning the pressure regulator knob towards STEAM in short bursts
(also called the quick release method) until the pressure is reduced.
CAUTION: When turning the knob to release pressure, hot steam/
liquid will be ejected. USE A POTHOLDER.
NOTE: Press the “Start/Stop” button when cooking time is complete, or to
cancel and reset. Otherwise, the pressure cooker will automatically
switch to warm for 8 hours.
WARNING: Do not hold the pressure regulator knob. Hot steam/liquid will
be ejected. Keep hands and face away from steam vents, use pot hold-
ers when removing the inner pot or touching any hot items, and never
force the lid open. The lid will only open once the pressure is released.
Remove the lid by lifting it away from you to avoid being burned by
the steam.
13. To Open, slide to the UNLOCK
position. Lift lid up and away from you.
14. To take the inner pot out, using
potholders, swivel counter clockwise, lift up
to remove.
Pressure
Regulator Knob
Unlocking the Lid
UNLOCK
Warm Setting
This program keeps cooked food warm for a long period of time.
1. Plug the cord into a wall outlet. The display will show --:--.
2. Position the removable cooking pot in the appliance at a diagonal.
Swivel the pot so the tabs are under the clip plate to stop the pot from
upward movement.
3. Place cooked food in the cooking pot.
4. Place lid on pressure cooker and lock into place.
5. Turn the pressure regulator knob to STEAM.
6. Press the “Warm” button. The display will read 158°F. (MIN is 140°F;
MAX is 176°F).
7. Press the “+” and “-” buttons to set the desired warming temperature.
8. Press “Warm” button. The display will read 8:00 (This equals 8 hours
of warming time.)
9. Press the “+” and “-” buttons to set the desired warming time (MIN is
30 minutes; MAX is 8 hours).
10. Press the “Start/Stop” button to begin warming.
11. Press the Start/Stop button to turn the unit off.
12. To Open the lid, slide the lock to the UNLOCK position. Lift the lid by
lifting it away from you to avoid being burned by the steam.
13. To take the inner pot out, using potholders, swivel counter clockwise, lift
up to remove.
Brown Setting
This program allows you to brown your food before cooking it under
pressure. Brown your meat or poultry for the best flavor and texture, unless
otherwise indicated in the recipe. Food should be patted dry with a paper
towel before browning. For best results, make sure the oil is hot before
adding your meat or poultry. Brown in batches to keep the correct temper-
ature. The Brown temperature is 329°F.
Pressure
Regulator Knob
