TechniSat TECE9497 User manual

TechniSat
Dimmer
SKU: TECE9497
Quickstart
This is a secure Light Dimmer for Europe. To run this device please connect it to your mains power supply.
SmartStart enabled products can be added into a Z-Wave network by scanning the Z-Wave QR Code present on the product with a controller providing
SmartStart inclusion. No further action is required and the SmartStart product will be added automatically within 10 minutes of being switched on in the
network vicinity.
1. The Z-Wave QR-Code is located on the back of the product.
2. Please follow your SmartStart enabled Z-Wave gateways manual, on how to use SmartStart inclusion.
3. Install the TechniSat Double-Switch.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,
distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this
equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
Designed as a drop-in replacement for your single wall switch or dimmer from leading brand manufacturers, TechniSats Dimmer integrates your wall switch into
the Smart Home future.Featuring Z-Wave SmartStart and S2 security for easy installation and secure operation, yourdimmer can now be controlled from your
Smart Home as well. Full manual operation can trigger central scenes via multiple button clicks Integrated 230 V auxiliary input for push button or toggle switch
types, applicable in alternating switching and or intermediate switching circuitsShort circuit and overload protection monitoring
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
1. Press and hold position T2 for more than 20 seconds.
2. The LED will alternately flash red and green for 5 seconds after a successful reset.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to the
assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Installation

Circuit diagram
Note: Note the configuration of parameter 5 on page 22, which determines whether you use a pushbutton or switch at the extension input.
L Phase
~ Switched, dimmable output (to consumer) (T1 - T2)
N Neutral
S Extension input
3-Way wiring
Conversion of existing circuit with 2 x changeover switch to
1 x changeover switch and 1 x TechniSat dimmer.
The existing changeover switch must be bridged in this connection example.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the
devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
Inclusion
1. Install the TechniSat Double-Switch.
2. After checking the correct installation, re-enable electrical power at the main fuse or circuit breaker.
3. Start the Z-Wave device add mode on your Z-Wave gateway, according to the gateways manual.
4. Press position T1 3x within 1 second.
5. The red status LED is on while the device is added to the Z-Wave network.
6. The green LED
E l i

2. Press and hold position T1 for more than 10 seconds.
3. The red status LED is on while the device is removed from the Z-Wave network.
4. The green LED is on for 5 seconds after successfully removing the device.
Product Usage
LED... Status LED
T1... Button 1 up
T2... Button 2 down
Cental Scene
The Single-Switch can send central scene activation notifications to a Z-Wave gateway.
Pressing the respective button position multiple times, will send the corresponding scene number:
Button position / Scene Number
T1 / 1
T2 / 2
S / 3 (Configuration Parsmeter 6)
The following Z-Wave key attributes are available for all scenes:
Button position pressed / Z-Wave key attribute
two times / Key Pressed 2 times
three times / Key Pressed 3 times
four times / Key Pressed 4 times
five times / Key Pressed 5 times
Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
1. Make sure a device is in factory reset state before including. In doubt exclude before include.
2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing
Association - one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive controlling commands. These lists are called association groups and they are
always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a 'Basic Set' Command.
Association Groups:
Group Number Maximum
Nodes Description
11 The lifeline group reports the devices status.
210 Sends basic set commands to associated devices, according to the current state of the
device.
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better to user needs or unlock further
enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the
desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the

Enable/disable central scene notifications for 2x-5x button presses.
Size: 1 Byte, Default Value: 1
Setting Description
0Setting this parameter to 0 will disable central scene notifications for multiple (2x-5x) button presses.
1Setting this parameter to 1 will enable central scene notifications for multiple (2x-5x) button presses.
Parameter 2: Wattage Report Interval
Interval of current wattage meter reports in 10 seconds increments.
Size: 2 Byte, Default Value: 3
Setting Description
0Disable unsolicited meter reports of current wattage.
3 - 8640 Interval of current wattage meter unsolicited reports in 10s increments (30 seconds - 1 day)
Parameter 3: Energy Report Interval
Interval of active energy meter reports in minutes.
Size: 2 Byte, Default Value: 60
Setting Description
0Disable unsolicited meter reports of active energy.
10 - 30240 Interval of active energy meter unsolicited reports in minutes (10 minutes - 3 weeks)
Parameter 4: Operation mode of button T
Size: 1 Byte, Default Value: 0
Setting Description
0T1 turns output L1 on, T2 turn output L1 off
1T1 and T2 toggle output L1
Parameter 5: Switch Type (Connector S)
Configuration of switch type connected to extension connector S
Size: 1 Byte, Default Value: 0
Setting Description
0a toggle switch type is connected to extension connector S
1a push button switch type is connected to extension connector S
Parameter 6: Central Scene (Connector S)
Central Scene mapping of extension input S
Size: 1 Byte, Default Value: 1
Setting Description
1map extension input S to central scene of T1
2map extension input S to central scene of T2
3map extension input S to own central scene
Parameter 7: Dimming curve
Dimming curve selection
Size: 1 Byte, Default Value: 0
Setting Description
0select dimming curve 1
1select dimming curve 2
Technical Data
Dimensions 70 x 70 x 45 mm
Hardware Platform ZM5101

IP Class IP 20
Voltage 230V
Load 0,87A
Device Type Light Dimmer Switch
Network Operation Always On Slave
Firmware Version HW: 7 FW: 2.00
Z-Wave Version 6.82.00
Certification ID ZC10-20036883
Z-Wave Product Id 0x0299.0x0004.0x1A92
Firmware Updatable Updatable by Consumer by RF
Neutral Wire Required ok
Security V2 S2_UNAUTHENTICATED ,S2_AUTHENTICATED
Frequency Europe - 868,4 Mhz
Maximum transmission power 5 mW
Supported Command Classes
Association Grp Info
Association V2
Basic V2
Central Scene V3
Configuration
Device Reset Locally
Firmware Update Md V4
Manufacturer Specific V2
Meter V4
Notification V8
Powerlevel
Security
Security 2
Supervision
Switch Multilevel V4
Transport Service V2
Version V3
Zwaveplus Info V2
Controlled Command Classes
Basic V2
Explanation of Z-Wave specific terms
Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall
controllers.
Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote controls.
Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller in a Z-Wave network.
Inclusion — is the process of adding new Z-Wave devices into a network.
Exclusion — is the process of removing Z-Wave devices from the network.
Association — is a control relationship between a controlling device and a controlled device.

Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions.
(c) 2022 Z-Wave Europe GmbH, Antonstr. 3, 09337 Hohenstein-Ernstthal, Germany, All rights reserved, www.zwave.eu. The template is maintained by Z-Wave
Europe GmbH. The product content is maintained by Z-Wave Europe GmbH , Supportteam, [email protected]. Last update of the product data: 2020-06-16
