ADB EURODIM TWIN TECH User manual

_____________
Eurodim Twintech Dimmer Cabinet
_____________
User Manual V2.0

EURODIM TWIN TECH
Page 1sur 92
Summary
1Safety................................................................................................................................................4
2Foreword...........................................................................................................................................5
2.1 Description of the Unit ................................................................................................................... 6
2.2 Using the TTD HUMAN INTERFACE (HMI)....................................................................................... 8
2.2.1 LCD Display ................................................................................................................................. 8
2.2.2 Numeric Keyboard ...................................................................................................................... 8
2.2.3 Navigation Wheel ....................................................................................................................... 8
2.3 Accessing the TTD HUMAN INTERFACE (HMI) ................................................................................ 9
2.4 Screensaver................................................................................................................................... 10
2.5 Online Assistance.......................................................................................................................... 10
2.6 Menu Tree-Structure .................................................................................................................... 11
3Cabinet Configuration .....................................................................................................................13
3.1 Synchronization ............................................................................................................................ 13
3.2 Module Control............................................................................................................................. 14
3.3 Cabinet Ventilation ....................................................................................................................... 15
3.4 Initial User Configuration.............................................................................................................. 15
3.5 Description of the Laws and modes:............................................................................................. 16
3.5.1 Applications of Laws on Specific Modules................................................................................ 16
4Presentation of the Home Page.......................................................................................................18
5Presentation of the Cabinet Diagnostic Page...................................................................................19
5.1 Controller (CTRL) Information....................................................................................................... 20
5.2 EURODIM Twin Tech Information................................................................................................. 20
5.3 DMX Information .......................................................................................................................... 21
6Presentation of the ARTNET/sACN Information Page......................................................................23
7Description of the Menus................................................................................................................24
7.1 Patch Menu................................................................................................................................... 25
7.1.1 Range Key ................................................................................................................................. 28
7.1.2 A ═> B Key ................................................................................................................................ 29
7.2 Laws,Multiplying Factor, Flash and Preheat Menu....................................................................... 29

EURODIM TWIN TECH
Page 2sur 92
7.2.1 Range Key ................................................................................................................................. 32
7.3 Power Configuration Menu .......................................................................................................... 33
7.3.1 Module identification ............................................................................................................... 34
7.3.2 COMPARE Key........................................................................................................................... 35
7.3.3 REF. PRES. Key...................................................................................................................... 35
7.3.4 Range Key ................................................................................................................................. 36
7.4 Cues Menu.................................................................................................................................... 37
7.4.1 Cues Menu –Edit...................................................................................................................... 38
7.4.2 Cues Menu –Capture ............................................................................................................... 41
7.4.3 Cues Menu –Play ..................................................................................................................... 43
7.4.4 Cues Menu –Copy .................................................................................................................... 45
7.4.5 Cues Menu –Erase ................................................................................................................... 46
7.4.6 Cues Menu - Priority/DMX fail.................................................................................................. 48
7.4.7 Cues Menu –Play Chaser.......................................................................................................... 49
7.5 Search ........................................................................................................................................... 51
7.6 Test and Flash Menu..................................................................................................................... 53
7.6.1 Test Tab .................................................................................................................................... 53
7.6.2 Flash Tab................................................................................................................................... 54
7.7 Load/Save Menu........................................................................................................................... 55
7.7.1 Saving the parameters.............................................................................................................. 56
7.7.2 Loading the parameters............................................................................................................ 57
7.8 Settings Menu............................................................................................................................... 57
7.9 Load Scanning Menu..................................................................................................................... 58
7.9.1 Load Scanning Menu –Learn.................................................................................................... 60
7.9.2 Manually selecting the loads .................................................................................................... 60
7.9.3 Range Key ................................................................................................................................. 62
7.9.4 Automatically selecting the loads............................................................................................. 63
7.9.5 Loads Scanning Menu - Scan .................................................................................................... 64
7.9.6 Range Key ................................................................................................................................. 65
7.9.7 Scanning the Outputs ............................................................................................................... 66
7.10 Module Measurements Menu...................................................................................................... 67
7.10.1 Selecting the modules and circuits ........................................................................................... 68

EURODIM TWIN TECH
Page 3sur 92
7.11 Modules Diagnosis Menu ............................................................................................................. 68
7.11.1 Selecting the modules and circuits ........................................................................................... 69
7.12 ENET Patch Menu ......................................................................................................................... 73
7.12.1 Range Key ................................................................................................................................. 75
7.13 ENET Info Menu ............................................................................................................................ 76
7.13.1 ARTNET Information ................................................................................................................. 77
7.13.2 sACN Information...................................................................................................................... 79
7.14 ENET SET Menu............................................................................................................................. 80
7.14.1 Selecting Universe Mode .......................................................................................................... 81
7.14.2 ARNET Subnet and Universe Port or sACN univers................................................................... 81
7.14.3 IP configuration: ....................................................................................................................... 82
7.14.4 RDM setting: ............................................................................................................................. 83
7.15 Synchronisation Menu.................................................................................................................. 83
8Managing the Alarms ......................................................................................................................85
8.1 Errors List Screen Page.................................................................................................................. 86
8.1.1 List of Errors displayed in the EURODIM Twin Tech Frame ...................................................... 86
8.1.2 List of Errors displayed in the CTRL Board Frame ..................................................................... 87
8.1.3 List of Errors displayed in the Modules Frame ......................................................................... 87
9Fault-Clearing Guide........................................................................................................................89
9.1 Procedure to be followed in the Event of an Error....................................................................... 90

EURODIM TWIN TECH
Page 4sur 92
1SAFETY
The Eurodim Twintech is professional fully digital dimmers built in accordance with European safety
standards EN 62368.
It is a Class I equipment designed and manufactured to EN 62368 and requires imperatively a safety
earth connection in compliance with local regulations.
To prevent any risk of electric shock, do not remove any cover or part of the enclosure. Access to
internal parts is not required for normal operation. Refer servicing to skilled and trained service
personnel exclusively. Disconnect from the power supply prior to opening for inspection or service.
WARNING! LETHAL VOLTAGES ARE PRESENT INSIDE
Connection to an inappropriate power source may irreversibly damage the dimmer unit, it is the
user’s responsibility to use it for its intended purpose and to check the equipment connected to it.
The Eurodim Twintech is professional equipment developed with the simplicity of use in mind.
However, to obtain full benefits of the safety measures, the equipment shall be installed and
serviced by skilled and trained personnel exclusively.
This equipment is not suitable for use in locations where children are likely to be present
CAUTION!
Installation is entirely at your own risk. Read this installation and user manual from cover to
cover before attempting installation. Do not attempt installation unless you are suitably
qualified. Installation errors may endanger operators and cause system damage and failure. If
you do not understand a point in this manual, don’t guess. Contact ADB or one of our authorized
distribution partners for advice.
We recommend ordering commissioning and training through ADB or one of our authorized
partners prior energizing the system. Not following this recommendation may result in
equipment damage that may not be covered by your warranty!
The equipment shall be installed and serviced by skilled and trained personnel exclusively.

EURODIM TWIN TECH
Page 5sur 92
2FOREWORD
This user manual relates to the human-machine interface (HMI or TTD HUMAN INTERFACE) present on the
EURODIM Twin Tech plug-in dimmer cabinet.
The present manual describes the functions developed in the software version 7.315.
This manual will help you configure your Twin Tech cabinet following the initial installation of your
equipment, or when changing or adding a module within your cabinet.
Important note: The present manual does not describe the functions relating to the ADB service menu.
This menu is dedicated to qualified personnel trained by the hardware supplier, and to
the ADB Stagelight technical department.
Read this guide attentively before using the interface.
Important: The screen pages available in this manual are provided for information purposes only
and are subject to modification by ADB at any time.

EURODIM TWIN TECH
Page 6sur 92
2.1 DESCRIPTION OF THE UNIT
The
user is provided with:
1 - A backlit LCD touch-screen enabling access to all menus
2 - A numeric keyboard
3 - A navigation/validation pushbutton - wheel
When the right-hand side door of the cabinet is opened, the rear of the Unit gives access to the following:
1
2
3

EURODIM TWIN TECH
Page 7sur 92
1 - An opening on the rear face to activate the software reset button (in the event that the touch
screen becomes blocked)
2 - An opening in the side face for insertion of the SD memory card
3 - A connector to link up to the Twin Tech cabinet Controller units.
4 - A contrast potentiometer and a brightness potentiometer for the LCD touch-screen
An original memory card is provided with the Unit. The Unit and its interface are not operational as long as
the card is not inserted into its slot.
The SD memory card can be changed by another SD memory card if the conditions are respected:
1 - The maximum size is 2GB
2 - You can copy the following files from de origin card to new card:
•EDTT1BIN
•EDTT2BIN
•TRANSLAT (if it is present on the origin card)
•Help
•NAME (if it is present on the origin card)
•CHANNEL (if it is present on the origin card)
•EDTT_xx (if it is present on the origin card)
2
1
4
3

EURODIM TWIN TECH
Page 8sur 92
2.2 USING THE TTD HUMAN INTERFACE (HMI)
2.2.1 LCD Display
When the cabinet is activated, an initial home page appears on the LCD display, allowing access to the
“Cabinet diagnostic” screen page, which is considered as the main screen.
Manually pressing the touch-zones on the main screen or the screens of the different menus generally
enables the user to:
−Edit a field to be filled in,
−Validate the said field,
−Increment or decrement a value,
−Validate or cancel a function,
−Display one of the different available menus,
−Return to the main screen or the list of menus.
The key or zone selected is highlighted.
There is no recording confirmation when the screen page is changed.
When a field is edited and its value is modified, it is possible to cancel its recording before validation by
pressing another touch-zone on the screen.
2.2.2 Numeric Keyboard
The numeric keyboard enables the user to:
- Add a field’s value when the field is edited,
- Increment a field’s value (by pressing key 1) or decrement (by pressing key 0),
- Directly access a screen page: next page using key 1; previous page using key 0;
- Enter the access code in order to access the different user levels.
Note: Any value entered that is beyond the user range is limited to the maximum value.
2.2.3 Navigation Wheel
The wheel may be handled by rotating clockwise or anti-clockwise in order to:
−Select a field from a menu or choose a menu from the two menu screen pages,

EURODIM TWIN TECH
Page 9sur 92
−Cancel the validation of a field when the latter is edited.
Pressing the navigation wheel enables the user to:
−Edit a field to be filled in,
−Validate the highlighted field,
−Validate or cancel a function,
−Select a menu or function.
2.3 ACCESSING THE TTD HUMAN INTERFACE (HMI)
There are several possible user access levels. The first two screens (home and main screen) are accessible
to all users.
An access code needs to be entered in order to access the “Menu” screen. Depending on the authorised
access level, the user will be able to make modifications or launch functions.
The table below indicates the functions accessible to the user according to the access level:
Function/menu
Level 0
Code 5555
Level 1
Code 6666
Level 2
Code 7777
Level 3
Code 8888
View the parameters
No
Yes
Yes
Yes
Edit the patch
No
No
Yes
Yes
Test a dimmer
No
No
Yes
Yes
Alter the settings
No
No
Yes
Yes
Scan the loads
No
No
No
Yes
Edit the laws and
multiplying factor
No
No
No
Yes
Edit the ARTNET and
sACN parameters
No
No
Yes
Yes
Manage the Cues
No
No
Yes
Yes
Load/Save the
parameters
No
No
No
Yes
Manually synchronise
between controllers
No
No
No
Yes
ADB service
No
No
No
No

EURODIM TWIN TECH
Page 10 sur 92
Level 0 does not allow access to any menu or function.
Depending on the authorised access level, certain functions or menus remain blocked. Should you attempt
to access these, the software will ask you to enter the access code for the next level in order to authorise
access to the function or menu.
The access-level indication can be viewed on all the screen pages. It is located in the top right-hand corner
and is signalled by a figure representing the current access level (from 0 to 3), followed by a key symbol.
2.4 SCREENSAVER
If whilst accessing a screen page other than the home page, the user does not handle the touch-screen,
keyboard or wheel for a period of more than one minute, the software returns to the home page. The
access code will become 0. To access the "Menu" screen pages, an access code will again need to be
entered.
2.5 ONLINE ASSISTANCE
A "HELP" key is provided in the bottom right-hand corner of all of the screen pages, allowing touch-access
to a help function, relating to the page consulted.
Press the “BACK” touch-button to return to the screen page.

EURODIM TWIN TECH
Page 11 sur 92
2.6 MENU TREE-STRUCTURE
Screensaver
Cabinet
diagnostic
Menu 1
Patch A & B
Laws/M. Fact, Inrush,
preheat
Power Conf.
Mem./DMX fail
Edit cue
Capture cue
Play cue
Copy cue
Erase cue
Prior/DMX fail
Play chaser
Settings
Cont. Menu 2

EURODIM TWIN TECH
Page 12 sur 92
Menu 2
Scan loads
Learn
Scan
Mod.
measurements
mod.
Mod. Diag.
Artnet or sACN
Patch
See Artnet, sACN,
or IP config
Artnet, sACN and IP
config
ADB Service (functions not
described)
Synchronisation

EURODIM TWIN TECH
Page 13 sur 92
3CABINET CONFIGURATION
The upper part of the Twin Tech cabinet may be equipped with:
−Two Controller units,
−or a Controller unit and a backup power supply module.
The Controller units, control all of the circuits (128 max.) constituting the modules available in the cabinet
(32 max.), according to the configuration recorded by the Unit software (patch) and the channel values
present on the DMX A, DMX B and ARTNET/sACN/RDM inputs (ETHERNET connection).
3.1 SYNCHRONIZATION
The human interface is synchronized continuously between two controllers (if present).
If two controllers are present, data from a controller (the one inserted into the slot from the top), with the
exception of the page "Diagnosis of the cabinet" or information from the selected controller using the tabs
"CTRL1" and "CTRL2".
If the controller 1 is a not functional, timing continues with the controller 2.
If the cabinet has only one controller all the information obtained from this controller
Note: Only the controller in slot from the top is able to detect modules in the cabinet (see Chapter Power
Configuration) and to report the status of sinewave and thyristor modules with full diagnostic
option (see section "Module Measuring" and "Diagnostic Modules")
1

EURODIM TWIN TECH
Page 14 sur 92
If one controller is functional and inserted into the slot at the bottom, the cabinet will work but the
human interface will not be able to present the modules or diagnostic information modules
3.2 MODULE CONTROL
The selector allows the Controller unit in service to be chosen. It may be set to position 1, A/R or 2.
When a controller is selected (1 or 2), the DMX A, DMX B, ARTNET and sACN signals present at this
controller’s input are used.
The software configuration is HTP (Highest Take Precedence) by default. It is the highest value of the
DMX A, DMX B, ARTNET and sACN inputs (three available universes) and cue played and allocated to a
circuit that is taken into account in order to give the output dimming level.
When the selector is set to A/R, the circuits of each module are controlled according to the following rule:
the highest value amongst the DMX A, DMX B, ARTNET and sACN inputs of the two controllers is taken into
account when controlling this circuit.
Example: Control using DMX A and DMX B inputs
Controller 1
DMX A circuit 1=100%
DMX B circuit 2= 0%
Controller 2
DMX A circuit 1=90%
DMX B circuit 2=100%
Circuit 1=100%
Circuit 2= 100%

EURODIM TWIN TECH
Page 15 sur 92
Notes: The PCB3031 board also enables:
−the DMX A inputs to be connected between controllers (SW1, selectors 5 and 6 set to ON)
−the DMX B inputs to be connected between controllers (SW1, selectors 7 and 8 set to ON)
PCB 3031 board
3.3 CABINET VENTILATION
The cabinet is ventilated by three fans arranged at the top of the cabinet, which extract hot air from the
cabinet. These fans can operate at two different extraction speeds (1 and 2).
The fans start on speed 1 (normal air extraction) if one of the circuits is controlled at above 50% intensity.
Below 50%, all the fans are idle.
Speed 2 is engaged (high air extraction) when a sinewave module and/or a module fitted with four RCBO
(MCB + RCD) is present in the cabinet and it is controlled. The speed 2 is also engaged if the fans run in
speed 1 and the temperature is too much high. The speed is held up to that temperature is again
acceptable*.
When the conditions described above are no longer met, the fans continue to operate for a further five
minutes at speed 1 before stopping.
3.4 INITIAL USER CONFIGURATION
The identification of the modules present in the cabinet is controlled by the Controller 1.
This verification is automatic. A warning message signals any identification fault or error. See Power
Configuration menu in the event of an alarm.

EURODIM TWIN TECH
Page 16 sur 92
The user must then:
−Define or validate the control of each module’s circuits by allocating the DMX channels. See Patch,
ARTNET/sACN Patch and ARTNET/sACN Configuration menus.
−Define the laws or mode and multiplying factor applicable on each of the circuits constituting a
module with respect to the loads that are wired at each circuit’s output. These laws enable each of
the loads to be controlled correctly and risk-free (See Laws/Mult.Fact
1
. menu).
−Define the type of modules to be used in order to dim the light by accepting the list of modules
identified by the controller (see power configuration menu)
3.5 DESCRIPTION OF THE LAWS AND MODES:
The following laws are pre-recorded and available in the "Laws/Mult.Fact." menu: Linear, V120, Fluo,
Preheat, Square, Tv, BBC-TV, ON/OFF, TV2, VRT, as well as six user defined laws enabling free configuration
by the user.
The following modes are pre-recorded and available in the “Laws/Mult.Fact.” menu: DIM (Use of Dimmer
laws), SWITCH and BYPASS.
Important notes:
−The user defined laws (1 to 6) are configured by default in order to apply the Linear law.
−The six user laws are only editable via the optional RDM Dimmer manager software.
−ON/OFF law and SWITCH mode: presented in the form of a hysteresis, with a transition from 0 to 255
at 15% and transition from 255 to 0 at 12% (see switch curve).
−
3.5.1 Applications of Laws on Specific Modules
3.5.1.1 Fluo Module (TTD/F*)
The first two outputs are used for the dimmer. The law of one’s choice is applied here.
The last two outputs are used for the preheat: the switch mode shall be used.
3.5.1.2 Module DimSwitch with Dual filtering (TDD/HD*)
When the user chooses the SWITCH or BYPASS mode, the circuit is automatically configured with no
filtering.
1
Mult Fact. = Multiplication Factor or Reduction of the maximum possible output level of a dimmer circuit.

EURODIM TWIN TECH
Page 17 sur 92
For all other laws, the circuit uses a filtering characterised by a 400 µS rise time.
The rise time is 400 µS by default.
Law curve giving the relationship between the DMX input (0 to 255) of the function law and the output
after application of the law in the same units.

EURODIM TWIN TECH
Page 18 sur 92
4PRESENTATION OF THE HOME PAGE
This screen page is displayed as soon as the cabinet is switched on. It gives the information concerning the
name of the cabinet, the config (show played), the User identification, the start addresses for the DMX A
and B inputs and the three ARTNET/sACN universes, the status of the RDM (ON or OFF)
Information available for start address (valid for DMX and ARTNET/sACN):
−"x": channel value to address cabinet output 1, 1 < x <512
−"not used": channel value = 0 or > 512
−"- - - - -": no circuit physically present in cabinet location 1, or circuit identification error in cabinet
location 1 or operating fault
To access the diagnostic page, press the arrow.
