technoswitch AP-DIS-MCP2 User manual

www.technoswitch.co.za
E & OE Document No: DS AP-DIS-MCP2 AP-DIS-MCP2W 161018
MANUAL CALL POINTS - INTELLIGENT
DISCOVERY MCPS
DISCOVERY
MANUAL CALL POINT
PRODUCT CODE: AP-DIS-MCP2
FUNCTION
The Discovery Manual Call Point is designed to
operate on a loop of intelligent re detection devices
and, when activated, interrupts the polling cycle for a
very fast response.
The Discovery Manual Call Point is intended for indoor
applications.
FEATURES
The Discovery Manual Call Points offer the following
key features:
Resettable element
Easy access, front reset mechanism
Front facing addressing
E-Z t connector system for installation
Ergonomic reset key and keyring hole
Flashing LED Option
EN 54-11 Approved
180° viewable LED
Continuity link for cable insulation testing
10 Year Warranty
DISCOVERY WATERPROOF
MANUAL CALL POINT
PRODUCT CODE: AP-DIS-MCP2W
FUNCTION
This Waterproof Intelligent MCP is designed to
operate on a loop of intelligent re detection
devices and, when activated, interrupts the polling
cycle for a very fast response.
The AP-DIS-MCP2W has an IP67 rating and is
intended for outdoor applications or where water
and/or dirt is a problem.
FEATURES
The Discovery Waterproof Intelligent Manual Call
Points offer the following key features:
Resettable element
Easy access, front reset mechanism
Front facing addressing
Ergonomic reset key and keyring hole
Captive screws for easy installation
Flashing LED Option
EN 54-11 Approved
180° viewable LED
IP67 rated
10 Year Warranty
PRODUCT CODE
AP-DIS-MCP2 AP-DIS-MCP2W

Disclaimer
Although the contents of our product literature have been prepared with the greatest care, Technoswitch can accept no liability whatsoever for any direct or indirect damages of any kind
that may arise due to either errors or omissions in them, or amendments to products or other specications following publication.
www.technoswitch.co.za
E & OE Document No: DS AP-DIS-MCP2 AP-DIS-MCP2W 161018
HEAD OFFICE - JOHANNESBURG
Cussonia Park, Ridge Road, Laser Park, Johannesburg
PO Box 1752, Randpark Ridge, South Africa, 2156
T+27 (0)11 794 9144 F [phone] [e-mail]
CAPE TOWN
T+27 (0)21 948 4575 F+27 (0)86 638 5184
E [e-mail]
DURBAN
T+27 (0)31 266 8843 F+27 (0)86 750 6912
[e-mail]
MANUAL CALL POINTS - INTELLIGENT
SPECIFICATIONS
PROTOCOL COMPATIBILITY
The Discovery Manual Call Points will operate only with control equipment
using the Apollo digital protocol.
ELECTRICAL CONSIDERATION
The Discovery Manual Call Point is loop powered and operates at
17 - 28 V DC for all variants.
MECHANICAL CONSTRUCTION
The component parts of the call point are moulded in a robust re
retardant polycarbonate.
OPERATING PRINCIPLES
The address of each call point is set at the commissioning stage by
means of a seven-segment DIL switch. The address switch is accessible
without removing the call point from the mounting surface.
A red alarm LED is provided on the call point. This LED is controlled
independently of the call point, by the control panel.
Once activated, the Manual Call Point can be reset by inserting the reset
key into the front facing LED, turning clockwise until a positive click and
reset occurs.
The isolated version of the Manual Call Point incorporates a short circuit
isolator which will ensure its operation in the event of a short circuit fault on
the loop. Isolator operation is indicated by a yellow LED.
This Manual Call Point helps reduce installation time as all the initial
installation cabling is wired to a terminal block which ts neatly in the back
of the Call Point.
TECHNICAL DATA
Supply Voltage: 17 - 28 V DC
Communications Protocol: 5 - 9 V Peak to Peak
Operating Temperature: -40 °C to +70 °C
Humidity (no condensation): 0 - 95 % RH
IP Rating:
Indoor 45
Waterproof 67
Current Consumption (max) 24 V DC
Power-up Surge (1s typical): 1 mA
Quiescent: 100 μA
Alarm Current (LED on): 4 mA
Complies with EMC Directive 2004/108/EC
Red version complies with EN 54–11:2001
EN 54-17:2005 (Isolated version)
DIMENSIONS AND WEIGHT
Indoor: 88 x 88 x 59 mm weight: 180 g
Waterproof: 110 x 110 x 74 mm weight: 180 g
EMC DIRECTIVE 2004/108/EC
The Manual Call Point complies with the essential
requirements of the EMC Directive 2004/108/EC,
provided that it is used as described in this data sheet.
A copy of the Declaration of Conformity is available
from Apollo on request.
Conformity of the Manual Call Point with the EMC
Directive does not confer compliance with the directive
on any apparatus or systems connected to it.
CONSTRUCTION PRODUCTS DIRECTIVE
89/106/EEC
The Manual Call Point complies with the essential
requirements of the Construction Products Directive
89/106/EEC.
DISCOVERY MCPSPRODUCT CODE
AP-DIS-MCP2 AP-DIS-MCP2W
ORDERING INFORMATION
Product Code Product Description
AP-DIS-MCP Discovery MCP with Isolator, Red (Surface)
AP-DIS-MCP2 Discovery MCP2 (New Version)
AP-DIS-MCPW Discovery Waterproof Red MCP c/w Isolator (KAC Style)
AP-DISM-MCPW Discovery Marine Waterproof MCP c/w Isolator (KAC Style)
AP-DIS-MCP2W Discovery Waterproof MCP c/w Isolator (New Style)
AP-DISM-MCP2W Discovery Marine Waterproof MCP c/w Isolator (New Style)
AP-DISM-MCP Discovery Marine MCP c/w Isolator
SPARES
AP-DIS-MCP/F Discovery MCP Hinged Flap
AP-DIS-MCP2/K Discovery MCP2 Reset Keys (10 pack)
