About this Guide
1. About this Guide
This guide is for users trained to program the fire panel to work with connected devices.
1.1 Supplemental Documentation
The table below provides a list of documents for various users of STX / SMX fire panels.
1.2 Notice
The material and instructions covered in this guide have been carefully checked for
accuracy and are presumed to be correct. The images in the document are for reference
purpose only and are subject to change. However, the manufacturer assumes no
responsibility for inaccuracies and reserves the right to modify and revise this document
without notice.
These instructions cover the programming and commissioning of the STX / SMX Fire Alarm
Control Panels (FACP).
For any technical assistance email at [e-mail].
1.3 Documentation Feedback
Your feedback helps us keep our documentation up-to-date and accurate. If you have any
comments or suggestions about our on-line help or manuals, please e-mail us at
[e-mail].
On-Line Help - Please include the following information:
• Product name and version number (if applicable)
• Topic title
• The content you think should be corrected/improved
• Detailed suggestions for correction/improvement
Documents - Please include the following information:
• Document part number and title
• Page number and paragraph
• The content you think should be corrected/improved
• Detailed suggestions for correction/improvement
Document Name Document Number
Models: STX / SMX Device Compatibility Document NS-MS-0002
Model: STX Installation Guide NS-MN-0019
Model: SMX Installation Guide NS-MN-0025
Models: STX / SMX User’s Guide NS-MN-0018
Models: STX / SMX Programming Guide (This document) NS-MN-0017
SmartConfig™ PC Application User’s Guide NS-MS-0020
SmartConfig™ Mobile Application FAQ Not Applicable

5
About this Guide

6
Introduction
2. Introduction
The fire alarm control panel is available in two models: STX and SMX.
The STX model
• Comes with a plastic enclosure
• Available in 1 loop (98 devices or 198 devices) and 2 loop configurations
• Has a 5-inch touch screen
• Available in Red and Grey colors
• LED indicators to know the status of power, system, and so on
• Supports 160 zones
The SMX model
• Comes with a metal enclosure
• Available in 1 loop, 2 loop, and 4 loop configurations
• Has a 5-inch touch screen
• Available in Red and Grey colors
• LED indicators to know the status of power, system, and so on
• Supports 160 zones
2.1 Features
Following are some of the features of the fire alarm control panel:
• Connections to one, two, or four Signalling Line Circuit (SLC) loops
• Support for Morley UL variant detectors and modules
• Alarm, trouble, and programmable relays
STX Panel SMX Panel

7
Introduction
• Multi-colour touch screen display
• RS485 connections for wiring annunciators
• RS232 connection for printer
• Firmware upgrade or downgrade through USB
• Portable configuration settings (through USB or Bluetooth)
• Backing up the event logs (through USB or Bluetooth)
• Multi-level access control (Level 1, 2, 3, and 4)
• All sounder deactivation via programming
• 315-080 annunciator support
• 315-040 LED driver for customized graphic annunciators
• Auto-learning capability
• Configuration options: USB storage device, mobile app, and the panel interfaces
• 10000 event logs for SMX
• 5000 event logs for STX
• View pulse width (PW) values
• View voltage and analogue values
• Monitored input support for supervisory
• Printer support
• Set date and time
• Walk test
• Zone disablement
• 160 programmable zones
2.2 Standards
Underwriters Laboratories (UL)
• UL 864 (10th edition) Standard for Control Units
For standards related information, refer to Underwriters Laboratories (UL) documents.
2.3 User Control Levels
2.3.1 Level Definition
The FACP panel has four user control levels: Level 1, Level 2, Level 3, and Level 4.
At all the four levels, the touch display is the primary indicator for the status of installation
and provides detailed information about any current fire alarm, trouble, test, or disablement
condition.
USER LEVEL 1 - All the front panel displays are functional except the control keys.
USER LEVEL 2 - All front panel controls are functional. Some system operation parameters
and functions can be changed. User Level 2 is accessible by entering a passcode from level
1. Maximum 10 users with unique passcodes can be programmed in the panel.
NOTE: The default passcode for LEVEL 2 is 1234.

8
Introduction
USER LEVEL 3 - All front panel controls are functional. Full system configuration and
programming are possible. User Level 3 is reachable by entering a passcode from either
Level 1 or Level 2. User Level 3 is for the system installer. Level 3 user can configure
passcodes for Level 2 users.
NOTE: The default passcode for LEVEL 3 is 98989898.
USER LEVEL 4 - The user with Level 4 access can perform, all the operations of User Levels
2, and 3. User Level 4 can do the firmware update and manage users of Level 2, Level3 and
wipe the event log. The user with Level 4 access is the master user. Level 4 user can
configure passcode for Level 3 user.
NOTE: The default passcode for LEVEL 4 is 00000000.

9
Introduction

10
Unpacking
3. Unpacking
The fire alarm control panels are simple to install, program, and commission if you follow
the recommended procedures described in this guide.
Before installing the panel, ensure that all the equipment is received as per the table given
below.
The packing box should contain the following items as provided in the table below:
ITE
M
COMPONENT
UL
SKU
NO.

615-000-002,
615-000-002-R
615-000-102,
615-000-102-R,
615-000-202,
615-000-202-R
915-100-102,
915-100-102-
R, 915-100-
202, 915-100-
202-R, 915-
100-402, 915-
100-402-R
QUANTITY
1 FIRE ALARM CONTROL PANEL 1 1 1
2 QUICK START GUIDE 1 1 1
3INSTALLATION KIT ACCESSORIES 1 1 1
3.1 PLUG-IN TERMINAL BLOCK (2 PIN)
- GREEN
4 4 7
3.2 PLUG-IN TERMINAL BLOCK (3 PIN)
- GREEN
2 2 4
3.3 PLUG-IN TERMINAL BLOCK (4 PIN)
- GREEN
2 3 5
3.4 PLUG-IN TERMINAL BLOCK (5 PIN)
- GREEN
1 1 1
3.5 ASSEMBLY, END-OF-LINE DEVICE,
4.7K
4 4 4
3.6 ASSEMBLY, END-OF-LINE DEVICE,
10K
1 1 2
3.7 CABLE HARNESS - BATTERY LINK
CONNECTIONS
1 1 1

11
Unpacking

12
Fastrack Panel Configuration
4. Fastrack Panel Configuration
The fire alarm control panels are provided with a built-in Fastrack configuration utility that
is simple to use. The Fastrack process allows the basic configuration parameters to be
programmed using a simple, step-by-step approach.
The Fastrack process has the following five simple steps:
1. Initializing system and upgrading the ULD Firmware
2. Setting panel language
3. Learn peripherals
4. Learn loops
5. Panel reboot
When the panel is powered up, the LCD shows the first configuration prompt. You will be
guided through the Fastrack configuration until completion. The entire procedure takes
only a few minutes.
Throughout this process the internal buzzer activates intermittently, but this may be muted,
and the SYSTEM FAULT and FAULT LEDs are illuminated; the LEDs are extinguished upon
completion. The intermittent internal buzzer is also silenced, if this was not muted.
4.1 Fastrack Setup
Refer the following procedure for Fastrack setup:
1. Switch ON the panel, the system will initialized followed by the ULD Firmware Upgrade.
Figure 4.1 Upgrading ULD Firmware

13
Fastrack Panel Configuration
The following screen appears, tap NEXT.
Figure 4.2 Language screen
NOTE: The only, default language is English.
2. The following screen appears with the lists of peripherals that are connected to the
panel and tap NEXT.
Figure 4.3 Peripherals

14
Fastrack Panel Configuration
The following Loop Details screen appears.
Figure 4.4 Loop Screen
NOTE: The loop devices can be configured by using auto-learn, one loop at a time. If the panel has more than
one loop of devices the total devices configured for each loop is listed before the auto-learn process can
continue to the next loop, thereby, allowing you to go back to the previous step, if desired.
When the Fastrack setup is completed, panel reboots
.
Figure 4.5 Fastrack setup completion

15
Fastrack Panel Configuration
3. The following screen appears after the system reboot. Tap to access the main menu.
.
Figure 4.6 LCD Active State
NOTE: When the panel is in the normal state, it shows “No events present” message and the panel
screen goes to sleep mode, (screen would appear in grey), which helps in saving the power
consumption.With any event occurrence or action on the touch-screen, will switch it to active. The LCD
shows Date and time. The time is displayed in 24hr format.

16
Commissioning
5. Commissioning
This chapter describes how to configure the FACP using panel user interface, via USB
storage device and Bluetooth.
5.1 Commission Zones, Devices and Onboard I/O
1. Tap Commissioning from the Main Menu to configure all the devices and the zones in
the panel.
Figure 5.1 Main Menu
NOTE: For Manage, Maintenance, Event Log, and Quick Settings refer STX / SMX User's Guide.
2. Tap next to Zones, Devices & Onboard I/O.
Figure 5.2 Commissioning screen

17
Commissioning
3. Tap ZONES.
.
Figure 5.3 Zones, Devices & Onboard I/O
4. The ZONES screen opens with the list of zones in the panel. You can also view the
devices assigned to each zone.
5. Tap ADD ZONES to add a new zone and enter the Zone name. The Zone name must be
maximum 20 characters.
.
Figure 5.4 Zones in the Panel
NOTE: When you add a new zone, a successive zone gets created with a default zone name which is
editable using the qwerty keyboard. For example, if you add a new zone after zone 10, a “zone 11”
gets added with default zone name as “Zone 11".
