INERTIA-2464/64
Fire Indicator Panel
TECHNICAL & PROGRAMMING MANUAL
Revision 1.07e
A P P R O V A L S
Australian Standard AS1603.4 1987
Australian SSL Approval No 215
Australian SSL Quality Accredited
Hong Kong Fire Services Dept Approved.
PROC Standard GB4717-93
C-Tick Approval No. N1336
Serial No.
Date of Manufacture
7 COLUMBIA COURT
NORWEST BUSINESS PARK
BAULKHAM HILLS
NSW 2153
AUSTRALIA
Ph [phone]
Fax [phone]
E-mail: [email protected]
http://www.inertia.com.au

Page i INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
COMPATIBLE DETECTORS
Make Model Type Model Number
Apollo Thermal Type A Series 60
Apollo Thermal Type B Series 60
Apollo Thermal Type C Series 60
Apollo Thermal Type D Series 60
Apollo Smoke Ionisation Series 60
Apollo Smoke Photo Optical Series 60
Hochiki Thermal Type A DCD-A (DCC-A )
Hochiki Thermal Type B DFJ-60B (DFE-60B )
Hochiki Thermal Type C DCD-C (DCC-C )
Hochiki Thermal Type D FDJ-90D (DFE-90D )
Hochiki Thermal Cool Room Type B sealed DFG-60BLKJ
Hochiki Smoke Ionisation SIJ-ASN (SIH-AM )
Hochiki Smoke Photo Optical SLR-AS (SLK-A )
System Sensor Thermal Type A 5451AUS
System Sensor Thermal Type B 4451AUS
System Sensor Smoke Photo-Optical 2151AUS
System Sensor Smoke Ionisation 1151AUS
Olsen Thermal Type A T56B-T6A
Olsen Thermal Type B T56B-T6B
Olsen Thermal Type C T56B-T6C
Olsen Thermal Type D T56B-TSD
Olsen Smoke Ionisation C24B
Olsen Smoke Photo Optical P24B
Panelect Thermal Type A PFS-A
Panelect Thermal Type B PFS-B
Panelect Thermal Type C PFS-C
Panelect Thermal Type D PFS-D
Panelect Smoke Ionisation PFS-I
Panelect Smoke Photo Optical PFS-P
IEI VESDA E700 CONTACT DEVICE
IEI VESDA E70D CONTACT DEVICE
Please contact INERTIA Fire Systems for any additional detectors.

INERTIA-2464 Technical & Programming Manual Page ii
Copyright (c) 1996, INERTIA FIRE SYSTEMS
TABLE OF CONTENTS
TECHNICAL MANUAL --------------------------------------------------------------------------------------1
SPECIFICATION ----------------------------------------------------------------------------------------------2
SYSTEM EXPANSION............................................................................................. 3
ENVIROMENTAL LIMITS ........................................................................................ 4
POWER SUPPLY RATINGS AND SETTINGS........................................................ 4
BATTERY TYPE AND CAPACITIES ....................................................................... 5
TECHNICAL DESCRIPTION ------------------------------------------------------------------------------- 6
GENERAL ................................................................................................................ 6
TRANSIENT SUPPRESSION.................................................................................. 6
CURRENT CONSUMPTION.................................................................................... 6
AZF DESCRIPTION................................................................................................. 7
AZF SUPERVISORY CURRENT ............................................................................. 7
OVERLOAD PROTECTION..................................................................................... 7
ZONE OVERLOAD SELF RESET ........................................................................... 7
PRINTER OUTPUT.................................................................................................. 8
CABLE CONNECTION ............................................................................................ 8
PROGRAMMING BY COMPUTER .......................................................................... 8
ALIGNMENT AND ADJUSTMENT ----------------------------------------------------------------------- 9
INTERNAL 27VDC POWER SUPPLY..................................................................... 9
EXTERNAL 27VDC POWER SUPPLY (if fitted)...................................................... 9
INTERNAL 5VDC POWER SUPPLY TP4 ............................................................... 9
POWER SUPPLY COMPARATOR REFERENCE VOLTAGE TP1......................... 9
PLACING INTO OPERATION ----------------------------------------------------------------------------- 11
INITIAL CHECKLIST................................................................................................ 11
POWER UP CHECKLIST ........................................................................................ 11
FUNCTIONAL TESTING.......................................................................................... 12
FAULT RECORD ..................................................................................................... 13
INSTRUCTIONS TO OPERATORS ----------------------------------------------------------------------14
SUGGESTED ALARM PROCEDURE ..................................................................... 14
OPERATOR INSTRUCTIONS ................................................................................. 15
GLOBAL FUNCTIONS............................................................................................. 15
DOOR SWITCH ....................................................................................................... 15
INDICATORS ........................................................................................................... 16
BATTERY TEST ...................................................................................................... 17
AUTO TEST MODE ................................................................................................. 17
WALK TEST MODE................................................................................................. 18
SILENCE/ACKNOWLEDGE .................................................................................... 19
BUZZER ISOLATE................................................................................................... 19
BELL ISOLATE ........................................................................................................ 19
ACF ISOLATE.......................................................................................................... 20
ACF RESET ............................................................................................................. 20
ZONE FUNCTIONS ................................................................................................. 21
ALARM TEST........................................................................................................... 21
FAULT TEST............................................................................................................ 22
ISOLATE .................................................................................................................. 23
RESET ..................................................................................................................... 24
EQUIPMENT AS FITTED ----------------------------------------------------------------------------------- 25
PROGRAMMING MANUAL --------------------------------------------------------------------------------26
PROGRAMMABLE OPTIONS ----------------------------------------------------------------------------- 27
GLOBAL ................................................................................................................... 27
ZONES..................................................................................................................... 27
DEFAULTS............................................................................................................... 28
PROGRAM MODE--------------------------------------------------------------------------------------------29
TO ENTER PROGRAM MODE................................................................................ 29
PROGRAMMING MODE ......................................................................................... 29
PROGRAMMING HIERARCHY ............................................................................... 29
APPENDIX A --------------------------------------------------------------------------------------------------- 36
LATCHING TYPE..................................................................................................... 36

Page iii INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
NON LATCHING TYPE............................................................................................ 36
TIME DELAY AZF .................................................................................................... 37
APPENDIX B--------------------------------------------------------------------------------------------------- 38
ZONE OUTPUT CONFIGURATIONS...................................................................... 38
APPENDIX C--------------------------------------------------------------------------------------------------- 39
ALARM VERIFICATION FACILITY (AVF) ............................................................... 39
APPENDIX D--------------------------------------------------------------------------------------------------- 40
ANCILLARY TRIP (ACF).......................................................................................... 40
APPENDIX E --------------------------------------------------------------------------------------------------- 41
RELAY OUTPUT MAPPING .................................................................................... 41
AND MAPPING ........................................................................................................ 41
OR MAPPING .......................................................................................................... 41
FAULT MAPPING .................................................................................................... 41
FAULT/ISOLATE MAPPING .................................................................................... 41
ISOLATE MAPPING................................................................................................. 42
APPENDIX F --------------------------------------------------------------------------------------------------- 43
GLOSSARY OF TERMS.......................................................................................... 43
APPENDIX G--------------------------------------------------------------------------------------------------- 44
SUMMARY OF TERMINATIONS AND CAUTIONS. ............................................... 44
MCP LOOP .............................................................................................................. 44
DETECTION ZONES ............................................................................................... 44
RELAY OUTPUTS ................................................................................................... 44
BELL OUTPUTS ...................................................................................................... 44
ACF OUTPUTS........................................................................................................ 44
DOOR HOLDER OUTPUTS .................................................................................... 44
AUXILIARY POWER & MIMIC POWER .................................................................. 44
MAF ISOL & TRANSPONDER 0V ........................................................................... 45
MIMIC DATA & CLOCK ........................................................................................... 45
AC INPUT................................................................................................................. 45
BATTERY................................................................................................................. 45
DOOR HOLDER AC INPUT..................................................................................... 45
OUTPUT RELAYS ................................................................................................... 45
APPENDIX H--------------------------------------------------------------------------------------------------- 46
2464 PROGRAMMED OPTIONS ............................................................................ 46
APPENDIX I ---------------------------------------------------------------------------------------------------- 53
TECHNICAL DRAWINGS........................................................................................ 53

INERTIA-2464 Technical & Programming Manual Page 1
Copyright (c) 1996, INERTIA FIRE SYSTEMS
Section One
TECHNICAL MANUAL

Page 2 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
SPECIFICATION
Cabinet Zinc Sealed Steel 1.6mm
Powder Coated
Hinged Inner Door
Hinged Outer Door
Outside Dimensions 2464/24 750mm H x 390mm W x 160mm D
2464/32>64 750mm H x 780mm W x 160mm D
Battery Box 280mm H x 390mm W x 160mm D
AC Operational Voltage 240 VAC 50Hz + 10% Australian Version
200 or 220 VAC 50Hz + 10% Hong Kong Version
220 VAC 50Hz + 10% Chinese Version
Internal Power Supplies 24 VDC 3.0AMP in 8, 16, 24, 32, 40, 48, 56, 64 zones
5 VDC 2.0AMP
Microprocessor 80C52
Memory Type Non-volatile E2ROM
Liquid Crystal Display 2 Lines x 16 Characters LED Backlit
Fuses F1: Door Holder 3AG 3A
F2: AC Input M205 6.3A
F3: AUX & Mimic 3AG 1A
F4: ACF 3AG 1A
F5: Bell 3AG 1A
E.O.L Resistor On AZF's 4K7 Ohms

INERTIA-2464 Technical & Programming Manual Page 3
Copyright (c) 1996, INERTIA FIRE SYSTEMS
SYSTEM EXPANSION
Zones Qty Hardware Required Product Code
24 1 Main Control board PCB-800
1 Main Termination board PCB-801L
2 Zone Expansion board PCB-804G
2 Zone Indicator board PCB-802
32 1 Main Control board PCB-800
1 Main Termination board PCB-801L
3 Zone Expansion board PCB-804G
3 Zone Indicator board PCB-802
40 1 Main Control board PCB-800
1 Main Termination board PCB-801L
4 Zone Expansion board PCB-804G
4 Zone Indicator board PCB-802
48 1 Main Control board PCB-800
1 Main Termination board PCB-801L
5 Zone Expansion board PCB-804G
5 Zone Indicator board PCB-802
56 1 Main Control board PCB-800
1 Main Termination board PCB-801L
6 Zone Expansion board PCB-804G
6 Zone Indicator board PCB-802
64 1 Main Control board PCB-800
1 Main Termination board PCB-801L
7 Zone Expansion board PCB-804G
7 Zone Indicator board PCB-802

Page 4 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
Additional relay outputs:
Relays Qty Hardware Required Product Code
8 1 Relay board containing 8 relays PCB-803
16 2 Relay board containing 8 relays PCB-803
24 3 Relay board containing 8 relays PCB-803
32 4 Relay board containing 8 relays PCB-803
40 5 Relay board containing 8 relays PCB-803
48 6 Relay board containing 8 relays PCB-803
56 7 Relay board containing 8 relays PCB-803
64 8 Relay board containing 8 relays PCB-803
Open Collector Outputs 24VDC 1A each:
Relays Qty Hardware Required Product Code
8 1 Open collector output board 8 outputs 24VDC 1A each. PCB-813
16 2 Open collector output board 8 outputs 24VDC 1A each. PCB-813
24 3 Open collector output board 8 outputs 24VDC 1A each. PCB-813
32 4 Open collector output board 8 outputs 24VDC 1A each. PCB-813
40 5 Open collector output board 8 outputs 24VDC 1A each. PCB-813
48 6 Open collector output board 8 outputs 24VDC 1A each. PCB-813
56 7 Open collector output board 8 outputs 24VDC 1A each. PCB-813
64 8 Open collector output board 8 outputs 24VDC 1A each. PCB-813
ENVIRONMENTAL LIMITS
-10 Deg. C to +55 Deg. C Dry heat.
+40 Deg. C @ 93% Relative Humidity.
POWER SUPPLY RATINGS AND SETTINGS
27VDC 3A POWER SUPPLY
This supply's primary function is to power all external operations of the FIP, ie: Detection circuits, Ancillary
circuits, Charge batteries etc. This supply meets the requirements of AS1603.4 with the panel for up to 64
zones.

INERTIA-2464 Technical & Programming Manual Page 5
Copyright (c) 1996, INERTIA FIRE SYSTEMS
PERFORMANCE DATA
27VDC Power Supply.
AC Input 30 VAC +10% - 15%
Output Current 3 AMPS (Incl 1A External)
Output Voltage 27.6 VDC
Current Limit 3 AMPS
Output Ripple 50 mV
Internal 5VDC 2A Power Supply.
This supply's primary function is to power all internal operations of the FIP, ie: Microprocessor, liquid crystal
display, LED's keypad etc.
AC Input 30 VAC +15% or 27.6VDC+15%
Output Current 2.0 AMPS
Output Voltage 5.0 VDC
Current Limit 2.0 AMPS
Output Ripple 150 mV
BATTERY TYPE AND CAPACITIES
ZONES FITTED BATTERIES REQUIRED
24 to 32 2 X 12V 10 A/H
40 to 64 2 X 12V 17 A/H

Page 6 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
TECHNICAL DESCRIPTION
GENERAL
The 2464 in its most basic form comprise of two boards, the main control board and the main termination
board.
The main control board contains the Microprocessor, EPROM, RAM and E
2
ROM. The main control board also
has the liquid crystal display and keypad attached. All of the "delicate" electronics have been placed on this
board. The main control board complete with the inner door is easily removed during installation to avoid
damage and allow greater access to the field terminals.
The main termination board contains the two power supplies (5V and 27V), the first eight zones, all common
outputs and the printer interface. All charger settings, fuses etc are located on this board.
Up to seven (7) zone expansion boards can be added to the system to increase its detection capability. These
boards contain the same electronics as on the main termination board for zone scanning. Addressing is by a
jumper that selects which group of eight zones the board refers to.
Up to seven (7) zone indicator boards can also be added. These boards will displays the status of the zone
expansion boards fitted.
Up to eight (8) relay boards can be added. These boards contain 8 change-over relay contacts, each rated at 1
amp. Open collector output boards can also be used in lieu of relay outputs boards. These boards require no
addressing they work on a serial data chain. Output 1 is the closest output to the main board up to output 64.
NOTE This product utilises state of the art components and materials and therefore boards must be returned
to our factory for proper troubleshooting, repair and retesting. Field component level repairs are not
recommended and would void all warranties on the product.
TRANSIENT SUPPRESSION
The INERTIA-2464's superior transient protection comprises of Dual Transorb input traps, treacherous paths
on incoming PCB tracks, balanced circuit boards and metal oxide varistors on outputs. These devices are all
self-resetting.
CURRENT CONSUMPTION
Zones Fitted Quiescent Current Quiescent + 2 AZF'S in alarm +1A of Bell +1 Amp ACF
8 150 mA 2.23 AMPS
16 250 mA 2.33 AMPS
24 350 mA 2.43 AMPS
32 450 mA 2.53 AMPS
40 550 mA 2.63 AMPS
48 650 mA 2.73 AMPS
56 750 mA 2.83 AMPS
64 850 mA 2.93 AMPS

INERTIA-2464 Technical & Programming Manual Page 7
Copyright (c) 1996, INERTIA FIRE SYSTEMS
AZF DESCRIPTION
The AZF's on the INERTIA-2464 are monitored and scanned by custom thick film hybrids. These hybrid IC's
significantly reduce the possibility of false alarms and improve product efficiency and reliability.
Alarm Zone loop resistance is the end of line resistor (EOLR 4K7) and any parallel connected detector.
AZF SUPERVISORY CURRENT
The supervisory current flows through the external terminal AZF+, through the field cable and to the end of line
resistor (EOLR), returning to the panel at AZF- terminal. Parallel connected, across the 2-wire pair field cable,
are a number of the previously listed detectors? Maximum number allowable is as per the relevant standards
is 40. During the quiescent state there is essentially an open circuit across the + and - terminals of the detector
base.
In an alarm state, a 560-ohm resistor is across the detector base causing additional loop current to flow. This
is sensed by the AZF to produce an alarm output. Removal of the E.O.L. resistor or the interruption of the
supervisory current will produce a fault signal in the AZF.
As described above, the level of current is used to define the status of the alarm zone: -
I=3.5 mA and below FAULT
I=4.0 - 5.0mA at 24V QUIESCENT
I=16 mA to 40 mA (current limited) ALARM
The zone current is used by the hybrid IC to determine the condition of the zone as above. This information is
then transferred to the microprocessor for processing.
OVERLOAD PROTECTION
Door Holder Circuit Fuse F1 3AG 3A
AC Input Fuse F2 1AG 6.3A
Aux & Mimic Fuse F3 3AG 1A
Ancillary Output ACF Fuse F4 2AG 1A
Bell Output Fuse F5 3AG 1A
Battery Input PTC Thermistor 3.6A MAX
AZF Circuits Current Limited 40mA
ZONE OVERLOAD SELF RESET
If a zone is overloaded by an accidental short to earth on an AZF circuit, the zone will automatically shut down
and produce a fault. Once this happens the panel will automatically recheck the zone every 60 seconds and
once the overload is removed, restore power and the fault will also clear.

Page 8 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
PRINTER OUTPUT
The printer port is designed to be used during testing and commissioning of the panel. The printer will report
alarms and faults together with the date and time of the event, the printer can also be used during walk test
mode to produce a history of the test and can be used to print current programming configuration.
A DB9 plug male is provided at the top of the main termination board. This communication port will
communicate with an IBM compatible serial printer (ASCII printer) with the following settings.
Baud Rate 1200 bps
Data Bits 8
Stop Bits 1
Parity None
Handshaking DTR
CABLE CONNECTION
Cabling to the printer requires a 4-core telephone style cable with a maximum length of 10 metres. A DB9
socket is required at the panel end. The printer end is dependent on the type of printer used but is usually a
male DB25. Connection is as follows.
INERTIA-2464 END PRINTER END
DB9 FEMALE DB25 M DB9 M
5 7 5
2 4 8
3 5 7
7 3 3
PROGRAMMING BY COMPUTER
Programming of the zones, relays, global functions and time can by set with the DOS based programme
“2464/SW” only on INERTIA-2464 panels with DATE and TIME.
After the cable is installed the programm can be run and the menu will prompt for the available functions.

INERTIA-2464 Technical & Programming Manual Page 9
Copyright (c) 1996, INERTIA FIRE SYSTEMS
ALIGNMENT AND ADJUSTMENT
INTERNAL 27VDC POWER SUPPLY
If the on-board supply ONLY is being used (JP4 is linked) :
With batteries disconnected and no alarms present, measure voltage across AUX 0V & AUX 24V on
PCB801 and adjust the multi-turn potentiometer VR4 until voltage is 27.6V 1% (27.32V - 27.87V).
(VR1 for 801L5).
Current limiting is factory preset by VR1 and adjustment is not required.
EXTERNAL 27VDC POWER SUPPLY (if fitted)
If an external supply input is being used (link J4 should be cut) :
With batteries disconnected and no alarms present, measure voltage across AUX 0V & AUX 24V on
PCB801 and adjust the voltage on the external power supply untill the AUX voltage is 27.6V 1%.
Current limiting is preset, adjustment is not required.
INTERNAL 5VDC POWER SUPPLY TP4
No adjustments are required, all parameters are preset.
POWER SUPPLY COMPARATOR REFERENCE VOLTAGE TP1
With the panel in the quiescent mode, measure voltage between system 0V and TP1. Adjust multi-turn
potentiometer VR2 until voltage is 7.0V 1%
ALARM THRESHOLD COMPARATOR TP3
With the panel in the quiescent mode, measure voltage between system 0V and TP3. Adjust multi-turn
potentiometer VR3 until voltage is 3.3V 1%
NON ADJUSTABLE TEST POINTS
TP2 = 0.6 VDC 5% FAULT THRESHOLD
TP4 = 5.0 VDC ‘5% 5VDC POWER SUPPLY
(If these test point voltages are not correct, please return the main termination board to the factory for
repair.)

Page 10 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
IFS800 - JP3 DEFAULT (MEMORY RESET)
Holding a short across these pins for 5 seconds during start-up causes the panel to reset to standard
factory defaults. The panel will give 4 beeps after reset, to acknowledge default on startup.
IFS800 - JP4 PROGRAM DISABLE
When fitted, jumper between these pins to inhibit program changes.
IFS800 - JP5 CPU RESET
With panel operating, a momentary short across these pins will cause a CPU restart.
IFS801L - JP3 DOOR HOLDER BYPASS
If zoned door holder outputs are required and is to be done external to the main termination board,
then the main door holder release needs to be disabled. Fitting a link across JP3 on IFS801 PCB does
this.
Note: Door holder output is only enabled if optional door holder transformer is fitted.
IFS801L - JP4 EXTERNAL POWER SUPPLY ENABLE/DISABLE
Jumper link remains fitted when the internal supply only is being used.
Jumper link is to be cut when an external power supply is being used.
IFS804G - JP1-7 ZONE BOARD ADDRESSING
Jumper JP1 to JP7 on zone expansion board IFS-804 selects the addressing for the zones.
Place jumper in link position for the appropriate 8 zones to which the expansion board applies.

INERTIA-2464 Technical & Programming Manual Page 11
Copyright (c) 1996, INERTIA FIRE SYSTEMS
PLACING INTO OPERATION
Suitably qualified technicians must install the panel. The following check procedures are recommended after
every installation and prior to initial power-up.
A thorough visual inspection should be made to every aspect of the fire panel. This includes loose wire
strippings, metal filings, loose circuit boards, loose cabling, damage in transit etc.
All problems must be rectified immediately as they could cause incorrect operation or permanent damage to
the equipment.
INITIAL CHECKLIST
 System General Appearance Good
 Cabinet Colour and Condition Good
 Cabinet Keyed 003
 All Circuit Boards Firmly Fastened
 Manual Call Point Fitted & Functional (Australian version only)

Viewing Window Clear and Firmly Secured
 Cable Entries Adequately Sealed
 200/220/240VAC Cabling Correctly Terminated

All Earthing Secured
 Transformer Securely Mounted
 Transformer Correctly Wired
 All Ribbon Cables Firmly Secured
 All Operational Zones Adequately Identified
 AC Fuse 2.5A Fitted And OK
 Door Holder Fuse 3A Fitted and OK

All Other Components Securely Inserted
 Auxilary and Mimic fuse 1A fitted and OK
 Manufacturing Label Affixed
You are now ready to power up the 2464 fire indicator panel.
POWER UP CHECKLIST
 Ensure Batteries Are Disconnected.
 Turn Mains Switch to "ON"
 The "Mains On" LED Should Light.
 Allow 15 Seconds for the Panel To Perform Its Start Up Tests.
 Connect Batteries

Page 12 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
FUNCTIONAL TESTING
 Primary AC Supply Voltage: 200 or 220 or 240VAC +10% as required
 Charger Output Voltage without Batteries: 27.6V DC

Keypad Functional
 Perform Auto Test
 LED's All Functional
 L.C.D Backlighting Functional
 Liquid Crystal Display Functional
 Zone Fault Detection

Zone Alarm Detection
 Internal Sounder Operating

MCP Loop Wired To Zone Number ______ (if applicable)
 Door Switch Functional
 Test Auxiliary Power Output
 Test Bell Output
 Test Door Holder Output (optional)
 Test Ancillary Output
 Test Bell Output Supervision

Test Ancillary Output Supervision
 Test Brigade Alarm Relay #1
 Test Brigade Alarm Relay #2

Test Standby Relay
 Test Fault Relay
 Test Mains Fail Relay
 Test Isolate Relay
 Test General Alarm Relays
 Test Relay Boards (if fitted)
 Test Open Collector Output Boards (if fitted)

Press "Battery Test" Once
 If Batteries Are Flat, Allow 24hrs To Charge And Then Re-test.

INERTIA-2464 Technical & Programming Manual Page 13
Copyright (c) 1996, INERTIA FIRE SYSTEMS
FAULT RECORD
FAULT CORRECTION DATE
TESTS SATISFACTORILY COMPLETED.
TESTED BY _______________________________
SIGNATURE _______________________________
DATE OF TEST ____________________________
If all faults have been rectified and all tests are completed satisfactorily, the 2464 fire indicator panel is now
ready for operation.

Page 14 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
INSTRUCTIONS TO OPERATORS
SUGGESTED ALARM PROCEDURE
The following is a suggested alarm procedure for use by building fire officers or duty wardens. The fire
indicator panel is designed for use by qualified fire fighters and it is strongly recommended that the fire panel
not be operated in an emergency situation by other than suitably qualified fire fighters.
•
Do not open fire indicator panel door or press any buttons until fire officers arrives.
• Determine location of the fire.
• Visually inspect area at a safe distance for actual fire or false alarm.
•
Notify fire-monitoring station of either result.
•
Perform evacuation and extinguishing operations as required.
• IF a FIRE, direct fire fighters to the fire indicator panel and cause of alarm as they arrive.
•
IF a FALSE ALARM, advise maintenance technicians to determine and rectify cause.
•
Record all events in logbook.
NOTE A suitably qualified fire officer should perform the above procedure. These are suggested procedures
only, and if specific fire procedures are available or issued, they MUST prevail.

INERTIA-2464 Technical & Programming Manual Page 15
Copyright (c) 1996, INERTIA FIRE SYSTEMS
OPERATOR INSTRUCTIONS
The functions of the INERTIA-2464 are divided into two (2) categories,
• Global Functions
•
Zone Functions
GLOBAL FUNCTIONS
Global functions are those common to the overall system and are not specific to particular zones. Following is
an explanation of their operation and the keystrokes required to perform the function required.
DOOR SWITCH
A door-operated switch is provided on the inner door. This switch is activated by the opening/closing of the
outer door. It functions as follows;
If the panel door is opened and there are NO alarms present:
1. The BELL output is isolated.
2. The ACF output is isolated.
3. The DOOR HOLDER output is held energised
If the panel door is opened and there IS an alarm(s) present:
1. The BELL output is not effected.
2. The ACF output is not effected.
3. The DOOR HOLDER output is not effected.
Closing of the outer door will force the following events, regardless of their previous state;
1. The BELL output is de-isolated.
2. The ACF output is de-isolated.
3. The DOOR HOLDER output is returned to normal.
NOTE The panel may be left with AZF's isolated but cannot be left with any of the above 3 functions isolated.
The closing of the outer door ensures this.
The door switch is also used in selecting programming mode. See page 29 for details.

Page 16 INERTIA-2464 Technical & Programming Manual
Copyright (c) 1996, INERTIA FIRE SYSTEMS
INDICATORS
Qty Descriptor Colour Function Buzzer
1 MAINS ON Green Illuminates when there is 200/220/240 VAC supply to
the panel.
1 BATT FAULT Yellow Illuminates if the battery fails a battery test.
Illuminates if batteries are disconnected >30 seconds.
Illuminates if batteries are short circuit >30 seconds.
Yes
1 CHARGER HIGH Yellow Illuminates if the power supply / battery charger
exceeds the recommended float charge voltage.
Yes
1 CHARGER LOW Yellow Illuminates if the power supply / battery charger falls
below the recommended float charge voltage for > 15
seconds.
Yes
1 COMMON FAULT Yellow Illuminates if;
Any de-isolated zone goes into fault.
ACF output is open circuit
Bell output is open circuit
Battery Fault LED
Charger High LED is on.
MAF Isolate LED is on.
Yes
1 MAF ACT Red Illuminates if any zone goes into alarm and transmits
a general alarm signal.
1 MAF ISO Yellow Illuminates if an external brigade switch is isolated.
Also used for fault on added devices eg. Evac unit.
1 ACF ACT Red Illuminates if the ACF output has been activated.
1 ACF FLT Yellow Illuminates if there is no load on the ancillary circuit,
(an open circuit ), ie: no relay or EOL resistor. The
LED will extinguish if the load is restored.
Yes
1 ACF ISO Yellow Illuminates if the ancillary output has been manually
isolated.
1 BELL ACT Red Illuminates if the bell output has been energised. This
LED will extinguish if bells are silenced or the alarm is
removed.
1 BELL FLT Yellow Illuminates if there is no load on the bell circuit (an
open circuit ), ie: no bell or EOL resistor. The LED will
extinguish if the load is restored.
Yes
1 BELL ISO Yellow Illuminates if the bell output has been manually
isolated. Flashing = silenced.
1 BUZZER ISO Yellow Illuminates if the panel's internal piezo buzzer has
been manually isolated. Flashing = silenced.
8 ALARM LEDS Red This LED will flash if it's corresponding zone goes
into alarm. It will remain on until the alarm is reset. If
the zone is programmed as a time delay type, a steady
LED indicates the “pre-alarm” condition. If the zone is
isolated and in alarm it will also be steady.
Yes
8 FAULT LEDS Yellow This LED illuminates if it's corresponding zone goes
into fault. It will remain on until the fault is removed.
Yes
8 ISOLATE LEDS Yellow This LED illuminates if its corresponding zone is
isolated. It will remain on until the zone is de-isolated.
