Techroutes S5864H Assembly instructions

S5864H Hardware Installation Manual

-
Table of Contents
Table of Contents
Chapter 1 S5864H Introduction.....................................................................................................................1
1.1 Appearance Description for Standard Configuration...................................................................1
1.2 S5864H Systematic Characteristic Parameters...........................................................................2
1.3 ROHS Description............................................................................................................................ 4
Chapter 2 Installation Preparation................................................................................................................
5
2.1 Caution of Usage.............................................................................................................................. 5
2.2 Safety Advice.....................................................................................................................................5
2.2.1 Safety Principles....................................................................................................................5
2.2.2 Safety Notices........................................................................................................................5
2.2.3 Safety Principles for Live Working......................................................................................6
2.2.4 Electrostatic Discharge Damage Prevention.................................................................... 7
2.3 Requirements for Common Locations...........................................................................................7
2.3.1 Environment........................................................................................................................... 7
2.3.2 Location Configuration Prevention..................................................................................... 7
2.3.3 Cabinet Configuration...........................................................................................................7
2.3.4 Power Requirements............................................................................................................ 8
2.4 Installation Tools and Device..........................................................................................................
8
Chapter 3 Installing the S5864H Switch......................................................................................................
9
3.1 Installation Flow of S5864H............................................................................................................ 9
3.2 Installing the Machine Box of the Switch...................................................................................... 9
3.2.1 Installing the Machine Box on the Desk.............................................................................9
3.2.2 Installing the Machine Box on the Cabinet......................................................................10
3.3 Connecting the Port....................................................................................................................... 10

-
3.3.1 Connecting the Console Port............................................................................................ 10
3.3.2 Connecting 10GE Ethernet SFP+ Ports..........................................................................12
3.3.3 Connecting Ethernet Management Ports........................................................................
12
3.3.4 Connecting 40GE Ethernet QSFP+ Ports.......................................................................13
ITable of Contents
3.3.5 Connecting 100/40GE Ethernet QSFP28 Optical Ports............................................... 14
1.3.6 USB Interface.......................................................................................................................16
3.4 Checking After Installation.............................................................................................................16
Chapter 4 Maintaining Switch..................................................................................................................... 17
4.1 Opening the Machine Box.............................................................................................................17
4.2 Closing Machine Box..................................................................................................................... 18
Chapter 5 Hardware Fault Analysis............................................................................................................19
5.1 Fault Separation............................................................................................................................. 19
5.1.1 Faults Relative with Power and Cooling System........................................................... 19
5.1.2 Faults Relative with Port, Cable and Connection...........................................................19

-
5.2 Indicator Description...................................................................................................................... 19
II

S5864H Hardware Installation Manual
- 1
Chapter 1 S5864H Introduction
The section describes the characteristics and parameters of S5864H and gives an
overview of S5864H.
1.1 Appearance Description for Standard Configuration
The built-in ports of S5864H are: 48 10Gbps SFP+ ports, 4 100Gbps QSFP28 optical
ports, 2 40Gps QSFP+ optical ports, 1 console port, 1 gigabit management port and 1
USB interface. See table 1-1.
Table 1-1 Attributes of the built-in port
Port
Attribute
10Gbps optical port
SFP+ interface, with LINK/ACT indicator
40Gbps optical port
QSFP+ interface, with LINK/ACT indicator
100Gbps optical port
QSFP28 interface, with LINK/ACT indicator
Console port
RJ45 interface, a rate of 9600bps
Ethernet management port
RJ45 interface
USB interface
USB interface
S5864H has 4 hot swap fans and 2 two power sockets at its back.
Figure 1- 1 Front template of the S5864H switch
Table 1-2 Parts at the front template of the S5864H switch
No.
Abbrev.
Name
Description
1, 2, 5, 6
SFP+
10GE Ethernet optical ports
48 10GE SFP+ ports
3
QSFP28
100/40Gbps Ethernet optical ports
4 QSPFP28 100/40Gbps
optical ports
4
QSFP+
40Gbps Ethernet optical ports
2 QSFP+ 40Gbps optical ports
7
LED
Indicator
System/power supply indicators

S5864H Hardware Installation Manual
- 2
Figure 1- 2 Back template of the S5864H switch
Table 1-3 Parts at the back template of the S5864H switch
No.
Abbrev.
Name
Description
1,3,9,11
/
Grounding column
The grounding must be fine.
2，10
POWER
AC power supply
AC220V, dual power backup, hot swap
7
CONSOLE
Console port
Manages the switch locally.
8
MNG
Gigabit Ethernet
management ports
Gigabit Ethernet Base-T ports,
100/1000Base-T ports
6
USB
USB
USB port
5
LED
Indicator
System/power supply indicator
4
FAN
Fan
Four hot swap fan modules
1.2 S5864H Systematic Characteristic Parameters
Protocol standard
Supported standard
IEEE 802.1d Spanning Tree Protocol
IEEE 802.1s multiple spanning trees
IEEE 802.1p Class of Service
IEEE 802.1q tagged VLAN
IEEE 802.3x Flow control
IEEE 802.3z asymmetric flow control
IEEE 802.3ad Link aggregation
IP routing
protocol
standard
RFC 1058 RIP
RFC 1723 RIP v2
RFC 1583 OSPF v2

S5864H Hardware Installation Manual
- 3
Network management
standard
RFC 1157 SNMP v1/v2
RFC 1213 MIB II
RFC 1757 RMON 1,2,3,9
Hardware
characteristics
Memory
Flash Memory: 64M Bytes
SDRAM: 512Mbytes;
Standard configuration
48 SFP+ 10GE optical ports;
4 QSFP28 100/40Gbps optical ports;
2 QSFP+ 40Gbps optical ports;
1 Console port
1 USB interface
1 gigabit management interface
Dimensions mm
(W×D×H)
442.5×404×44
Operating
temperature/
humidity
0℃～40℃; 10%～85% non-condensing
Storagetemperature/
humidity
-40℃～80℃; 5%～95% non-condensing
Power characteristics
Input voltage: AC100～240V,
Input frequency: 47～63Hz
Input current: 3A (MAX)
Output voltage: 12VDC
Output current: 40A(MAX)
Full power consumption
<316W

S5864H Hardware Installation Manual
- 4
1.3 ROHS Description
Chapter 2 Installation Preparation
2.1 Caution of Usage
Similar to other electronic products, the semiconductor chip easily gets damaged if you
power on or off abruptly and frequently. To restart up the switch of S5864H, you have to
open the power on-off after the power is cut down for three to five seconds.
Avoid severe collision or falling down from the height to protect the parts in the switch.

S5864H Hardware Installation Manual
- 5
Use correct outside ports to connect the switch of S5864H. Do not put the Ethernet plug
into the console port (RJ45 8-line socket). Similarly, do not put the console cable into the
console port (RJ45 8-line socket).
Note:
1) When you plug or dial the power line, keep the power line horizontal with the power
socket.
2) When the lifetime of our products ends, handle them according to national laws and
regulations, or send these products to our company for collective processing.
2.2 Safety Advice
2.2.1 Safety Principles
Keep dustless and clean during or after the installation.
Put the cover at the safe place.
Put tools at the right place where they are not easily falling down.
Put on relatively tight clothes, fasten the tie or scarf well and roll up the sleeve,
avoiding stumbling the machine box.
Put on the protective glasses if the environment may cause damage to your eyes.
Avoid incorrect operations that may cause damage to human or devices.
2.2.2 Safety Notices
The safety notices mentioned here means that improper operation may lead to body
damage.
Read the installation guide carefully before you operate the system.
Only professionals are allowed to install or replace the switch.
Pull out the AC power socket and close the direct-current power before operating
on the machine box or working beside the power source.
The final configuration of products must comply with relative national laws and
regulations.
2.2.3 Safety Principles for Live Working
When you work under electricity, following the following principles:

S5864H Hardware Installation Manual
- 6
Put off ornaments, such as ring, necklace, watch and bracelet, before you operate
under live working. When metal articles connect the power to the ground, short
circuit happens and components may be damaged.
Pull out the AC power socket and close the direct-current power before operating
on the machine box or working beside the power source.
When the power is on, do not touch the power.
Correctly connect the device and the power socket.
Only professionals are allowed to operate and maintain the device.
Read the installation guide carefully before the system is powered on.
Note:
1) Check potential dangers, such as the humid floor, ungrounded extensible power
line and tatty power line.
2) Install the emergent on-off at the working room for turning off the power when
trouble happens.
3) Turn off the power on-off of the switch and plug off the power line before installing
or uninstalling the machine box or working beside the power.
4) Do not work alone if potential dangers exist.
5) Cut off the power before checkout.
6) If trouble happens, take the following measures: A. Cut off the system's power.
B. Alarm.
C. Take proper measures to help persons who are hit by the disaster. Artificial
respiration is needed if necessary.
D. Seek for medical help, or judge the loss and seek for available help.
2.2.4 Electrostatic Discharge Damage Prevention
Electrostatic discharge may damage devices and circuits. Improper treatment may cause
the switch to malfunction completely or discontinuously.
Move or locate the devices according to the measures of electrostatic discharge
prevention, ensuring the machine box connects the ground. Another measure is to wear
the static-proof hand ring. If there is no hand ring, use the metal clip with the metal cable
to clip the unpainted metal part of the machine box. In this case, the static is discharged
to the ground through the metal cable of the clip. You can also discharge the static to the
ground through your body.
2.3 Requirements for Common Locations
This part describes the requirements for the installation locations.

S5864H Hardware Installation Manual
- 7
2.3.1 Environment
The switch can be installed on the desk or the cabinet. The location of the machine box,
cabinet planning and indoor cabling are very important for normal system’s function.
Short distance between devices, bad ventilation and untouchable control plate will cause
maintenance problems, systematic faulty and breakdown.
For location planning and device locating, refer to section 2.3.2 “Location Configuration
Prevention”.
2.3.2 Location Configuration Prevention
The following preventive measures assist you to design the proper environment for the
switch.
Make sure that the workshop is well-ventilated, the heat of electrical devices is well-
discharged and sufficient air circulation is provided for device cooling.
Avoid to damage devices by following the electrostatic discharge prevention
procedure.
Put the machine box at the place where cool air can blow off the heat inside the
machine box. Make sure the machine box is sealed because the opened machine
box will reverse the cool air flow.
2.3.3 Cabinet Configuration
The following content assists you to make a proper cabinet configuration:
Each device on the cabinet gives off heat when it runs. Therefore, the sealed
cabinet must have the heat-discharge outlet and the cooling fan. Do not put the
devices too close, avoiding bad ventilation.
When you install the machine box at the open cabinet, prevent the frame of the
cabinet from blocking the airway of the machine box.
Ensure that nice ventilation is provided for the devices installed at the bottom of
the cabinet.
The clapboard separates exhaust gas and inflow air, and boost cool air to flow in
the machine box. The best location of the clapboard is decided by the air flow
mode in the machine box, which can be obtained through different location tests.
2.3.4 Power Requirements
Make sure that the power supply has nice grounding and the power at the input side of
the switch is reliable. The voltage control can be installed if necessary. At least a 240 V,
10A fuse or a breaker is provided in the phase line if you prepare the short-circuit
prevention measures for a building.
Caution:

S5864H Hardware Installation Manual
- 8
If the power supply system does not have good grounding, or the input power disturbs
too much and excessive pulses exist, the error code rate of communication devices
increases and even the hardware system will be damaged.
2.4 Installation Tools and Device
The tools and devices to install the S5864H switch are not provided by the S5864H
switch. You yourself need to prepare them. The following are the tools and devices
needed for the typical installation of the S5864H switch:
Screwdriver
Static armguard
Bolt
Ethernet cable
Other Ethernet terminal devices
Control terminal
Chapter 3 Installing the S5864H Switch
Caution:
Only professionals are allowed to install or replace the devices.
3.1 Installation Flow of S5864H

S5864H Hardware Installation Manual
- 9
3.2 Installing the Machine Box of the Switch
The installation of the machine box has two modes:
Installing the machine box on the desk
Installing the machine box on the cabinet
3.2.1 Installing the Machine Box on the Desk
The S5864H switch can be directly put on the smooth and safe desk.
Note:
Do not put things weighing 4.5 kg or over 4.5 kg on the top of the switch.
3.2.2 Installing the Machine Box on the Cabinet
The machine box of the switch is fixed on the cabinet through the brackets. When you
fix the brackets, the front template of the switch faces forward. The detailed operations
are shown in Figure 3-1.
Figure 3- 1 Fixing the machine box of the switch
Caution: The switch shown in figure 3-1 does not represent the material S5864H.
After the brackets are installed, install the switch on the cabinet. See Figure 3-2.
Figure 3- 2 Installing the switch on the cabinet

S5864H Hardware Installation Manual
- 10
3.3 Connecting the Port
3.3.1 Connecting the Console Port
The rate of the console port is a value of 9600bps. It has a standard RJ45 plug. It is odd-
even optional and has traffic control. After you connect the console port to the serial port
of the terminal, such as STAR-510G+ or PC through a console cable, you can configure
and monitor the switch of S5864H by running a terminal emulation software, such as
super Windows terminal. The cable is provided according to the host. The
communication parameters of the terminal serial port can be set to a rate of 9600bps,
eight data bits, one stop bit, no sum check bit and traffic control.
Figure 3-3 RJ-45 connector of the console port
The RJ45 connector of the console port is shown in the following figure. The RJ45 plug
corresponds to the RJ45 socket, whose pins can be aligned from left to right with the
value from 1 to 8.
Figure 3-4 Connecting the console port of S5864H and computer
Caution: The switch shown in figure 3-3 does not represent the material S5864H.
Table 3- 1 Pins of the console port
NO.
Name
Remark
1
NC
No connection
2
RXD
Input
3
NC
No connection

S5864H Hardware Installation Manual
- 11
4
TXD
Output
5
NC
No connection
7
NC
No connection
8
SG
GND
Note:
The cable is used to connect the console port of R7308 router and the outside monitoring
device. One end is RJ45 8-core plug, and the other end of the console cable is 9-hole
plug (DB9). The RJ45 plug is put into the socket of the console port on the S5864H
switch. The inner line connection in the cable is shown in figure 3-1. The console cable
is numbered as RLC0301.
Figure 3-5 The inner connection of the 1-to-8 RJ45 cable (RLC0301)
3.3.2 Connecting 10GE Ethernet SFP+ Ports
The S5864H switch has 48 10GE SFP+ ports. Each port has its corresponding indicator:
1~48. You can connect the SFP+ optical module to the SFP+ port and then you can
connect other Ethernet terminal devices through the optical cable.
Figure 3-6 Connecting the 10GE SFP+ port and other Ethernet terminals
Caution: The switch shown in figure 3-5 does not represent the material S5864H.

S5864H Hardware Installation Manual
- 12
3.3.3 Connecting Ethernet Management Ports
S5864H provides 1 10/100/1000Base-T port. Each port has its corresponding MNG
indicator. The indicators are used to indicate the LINK/ACT state. The ports can connect
other Ethernet terminal devices through the UTP port and the direct-through or cross
network cable. The numbering order of the pins in the UTP port is the same as that in
the console port. See figure 3-6.
Figure 3-7 RJ-45 connector on the console port
Because the 10/100/1000Base-T ports of S5864H support the MDI/MDIX self-
identification of the cable, S5864H can adopt five types of direct-through/cross network
cables when it connects other Ethernet terminals.
Figure 3-8 Connecting the 1000Base-TX port and other Ethernet terminals
Caution: The switch shown in figure 3-8 does not represent the material S5864H.
Table 3- 2 Pins of Gigabit RJ45
No.
Pin Name
Remark
1
Sending/receiving the normal phase of data 0
TP0+
2
Sending/receiving the paraphase of the data 0
TP0-
3
Sending/receiving the normal phase of data 1
TP1+
4
Sending/receiving the normal phase of data 2
TP2+
5
Sending/receiving the paraphase of the data 2
TP2-
6
Sending/receiving the paraphase of the data 1
TP1-

S5864H Hardware Installation Manual
- 13
7
Sending/receiving the normal phase of data 3
TP3+
8
Sending/receiving the paraphase of the data 3
TP3-
3.3.4 Connecting 40GE Ethernet QSFP+ Ports
S5864H provides with 2 40GE QSFP+ ports. Each port has its corresponding indicator:
40G 1~2.
The four ports can be configured into 2 modes:
1. Set the rate of the port to 40Gbps
You can connect the QSFP+ optical port to the QSFP+ optical module and then you
can connect other Ethernet terminal devices with 40GE optical ports through the optical
cable.
Figure 3-9 Connecting the 40GE QSF+ port and other Ethernet terminals
2. Set the ports to 4 10GE ports
You can connect the QSFP+ optical module to the optical port and then you can
connect other Ethernet terminal devices with 10GE optical ports through the MPO-4*LC
optical cable.
Figure 3-10 Connecting the 40GE QSFP+ port (breaks out into 4 10GE ports) and other Ethernet
terminals

S5864H Hardware Installation Manual
- 14
Caution: The switch shown in figure 3-9 does not represent the material S5864H.
3.3.5 Connecting 100/40GE Ethernet QSFP28 Optical Ports
S5864H provides with 4 100/40GE QSFP28 ports. Each port has its corresponding
indicator: 40G/100G 1~4.
In use, the four ports can be configured into three modes:
1. Set the rate of the port to 100Gbps
You can connect the QSFP28 optical module to the optical port and then you can connect other
Ethernet terminal devices with 100Gbps optical ports through the optical cable.
Figure 3-11 Connecting 100GE QSFP28 optical ports and other Ethernet terminals
2. Set the rate of the port to 40Gbps
You can connect the QSFP+ optical module to the optical port and then you can connect other
Ethernet terminal devices with 40Gbps optical ports through the optical cable.
Figure 3-12 Connecting 100GE QSFP28 optical ports (configured to be 40GE ports) and other
Ethernet terminals
3. Set the rate of the port to 4 10Gbps ports

S5864H Hardware Installation Manual
- 15
You can connect the QSFP+ optical module to the optical port and then you can connect other
Ethernet terminal devices with 40Gbps optical ports through the MPO-4*LC optical cable.
Figure 3-13 Connecting 100GE QSFP28 optical ports (configured to be 4 10GE ports)
and other Ethernet terminals
1.3.6USB Interface
S5864H provides with 1 USB2.0 interface.
Figure 3-14 Connecting USB2.0 interface
3.4 Checking After Installation
Before electrically starting up the switch, perform the following checkups after the switch
is installed:
If the switch is installed on the cabinet, check whether the installation point between
the cabinet and the switch is strong. If the switch is installed on the desk, check
whether there is enough space for the switch to discharge its heat and whether the
desk is stable.
Check whetherthe connected power meets the power
requirements of the switch.
Check whether the grounding line is correctly connected.

S5864H Hardware Installation Manual
- 16
Check whether the switch is correctly connected to other terminal devices.
Chapter 4 Maintaining Switch
Caution:
1) Before opening the machine box, make sure that you have released the static you
carried and then turn off the power on-off of the switch. Before operating any step
in Appendix B, read the section “Safety Advice”.
2) Before performing operations beside the power source or on the machine box, turn
off the power on-off and plug out the power cable.
4.1 Opening the Machine Box
This section describes how to open the cover of the switch, required tools and operation
methods.
Caution:
When the power cable still connects the power source, do not touch it.
When you open the cover the switch, you may use the following tools:
Crossed screwdriver
Static armguard
Perform the following steps to open the cover of the switch:
(1) Turn off the power on-off of the switch.
(2) Plug out all cables connected the back of the switch.
(3) Take out the bolt from the machine box with the screwdriver.
Note:
The machine box comprises of two parts: cover and bottom.
(4) Open the cover by holding two sides of the cover towards the direction of the arrow
key shown in the following figure:
Caution: The switch shown in the above figure does not
represent the material S5864H.
