TECHTOP TOPDRIVE20 Series User manual

Insert the drip-cover DIN rail plate into the DIN
rail bracket on the back of the drive.
*Note installation of the drip-cover is optional and should
be considered based on the environment. The drip-cover
is used to protect from falling debris and water.
STEP 1*
TECHTOP GENERAL PURPOSE MICRO DRIVES, TD20 NEMA 1 KIT INSTALLATION GUIDE 1
Align the mounting holes of the drip-cover with
the mounting holes of the DIN rail plate. Use
the four screws to secure the drip-cover to the
mounting plate.
Screw quantity: 4
Screw specifications: M4x10
*Note installation of the drip-cover is optional and should
be considered based on the environment. The drip-cover
is used to protect from falling debris and water.
STEP 2*
Place the junction box base on the back of the
drive so the mounting holes align with the bottom
mounting holes of the drive.
STEP 3
TOPDRIVE20 SERIES
NEMA 1 KIT INSTALLATION GUIDE

Insert the grounding conductor from the junction
box frame into the ground terminal on the
drive.
TECHTOP GENERAL PURPOSE MICRO DRIVES, TD20 NEMA 1 KIT INSTALLATION GUIDE 2
TOPDRIVE20 SERIES
NEMA 1 KIT INSTALLATION GUIDE
Insert your (4) surface mounting screws through
the drive mounting holes and secure the drive
and junction box base to the wall.
STEP 4
STEP 5
Mount the junction box face plate to the junction
box base. Align the holes of the junction box face
plate with the junction box base. Use two screws
to secure the junction box face plate to the junc
-
tion box base.
Screw quantity: 2
Screw specifications: M4x10
STEP 6
