TECHWOOD TMP-7172 User manual


SET MIXER /BLENDER
INSTRUCTION MANUAL
1


IMPORTANT SAFEGUARDS
❑Please read these instructions carefully before use.
❑Keep present instructions for future references.
❑Check that your mains voltage corresponds to that stated on
the appliance.
❑Only use the appliance for domestic purposes and
household or similar applications such as:
-staff kitchen areas, in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
- Environment type like :
• Farm Houses • Bed and Breakfast.
❑Only use the appliance in the way indicated in these
instructions.
❑Never use this unit near bathtub, shower, wash-hand basins
or other containers with water.
❑Never use this apparatus near water projections.
❑Never use this apparatus with the wet hands.
❑If, unfortunately the apparatus is wet, immediately withdraw
the cord of the socket-outlet.
❑Inform potential users of these instructions.
❑Never leave the appliance unsupervised when in use.
❑The appliance must be used only for its intended purpose. No
responsibility can be taken for any possible damage caused
by incorrect use or improper handling.
❑Children and persons with disabilities are not always aware of
the danger posed by the use of appliances.
❑Always disconnect the appliance from the supply if it is left
unattended and before assembling, disassembling, or
cleaning.
❑This appliance shall not be used by children.
2


❑Appliance can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved.
❑Children shall not play with appliance, keep the appliance
and its cord out of reach of children.
❑Cleaning and maintenance must not be made by children.
❑This device is not a toy, do not leave small children or people
with disabilities to play with.
❑In order to ensure your children‘s safety, please keep all
packaging (plastic bags, boxes, polystyrene etc.) out of their
reach.
❑Caution ! Do not allow small children to play with the foil :
THERE IS A DANGER OF SUFFOCATION !
❑From time to time check the cord for damages. Never use the
appliance if cord or appliance shows any signs of damage.
❑Never immerse the appliance in water or any other liquid for
any reason whatsoever.
❑Never place it into the dishwasher.
❑Never use the appliance near hot surfaces.
❑If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
❑Disconnect the power source cable before any operation of
cleaning of maintenance and accessories assembly.
❑Never use the appliance outside and always place it in a dry
environment.
❑Never use accessories, which are not recommended by the
producer. They could constitute a danger to the user and risk
to damage the appliance.
❑Never use any other connector than the one provided.
3


❑Never move the appliance by pulling the cord. Make sure the
cord cannot get caught in any way.
❑Never wind the cord around the appliance and do not bend it
❑Ensure that the power cord does not come into contact with
hot parts of this unit.
❑Make sure the appliance has cooled down before cleaning
and storing it.
❑The temperature of accessible surfaces may be very high
when the appliance is operating. Never touch these parts, of
apparatus, to avoid burning itself.
❑Make sure the appliance never comes into contact with
flammable materials, such as curtains, cloth, etc...& the
power cord and plug do not come in contact with water.
❑Before cleaning, always unplug the appliance from the power
supply and let it cool down.
❑This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
❑Always place the unit on a flat surface. Ensure, also, not to
cover the device and not to put anything on it.
❑Always remove the plug from the wall socket when the
appliance is not in use.
❑When using an extension lead always make sure that the
entire cable is unwound from the reel. Use solely CE
approved extension leads. Input power must be at least 16A,
250V, 3000W.
❑Incorrect operation and improper use can damage the
appliance and cause injury to the user.
❑This device, designed for home use, complies with standards
relating to this type of product.
4


(*) Competent qualified person: after sales department of the
producer or importer or any person who is qualified, approved
and competent to perform this kind of repairs
5


SPECIAL WARNING FOR FOOD CHOPPER & STICK
BLENDER
Caution !
❑Always disconnect from power supply if it is left unattended
and before assembling, disassembling or during cleaning.
❑Switch off the appliance and disconnect from supply before
changing accessories or approaching parts that move in use.
❑Potential injuries can occur with misuse. Care shall be taken
when handling the sharp cutting blades, emptying the bowl
and during cleaning, as they are extremely sharp.
❑Regarding the instructions for cleaning surfaces in contact
with food or oil, thanks to refer to the below paragraph
"cleaning & maintenance" in manual.
❑Regarding the instructions for the use of accessories,
operation times and speed settings, refer to the below
paragraphs.
❑Potential injuries can occur with misuse. Care shall be taken
when handling the sharp cutting blades, emptying the bowl
and during cleaning, as they are extremely sharp.
GENERAL INFORMATION
The symbol "OPEN BOOK" means a recommendation
to read important things contained in the record.
The symbol "BIN" crossed out, abbreviation WEEE
(Waste of Electrical and Electronic Equipment) means
that at the end of life, it should not be discarded with
household waste, but filed to the sorting of the locality.
Waste recovery can help preserve our environment.
6


The symbol "CE" is the guarantee of compliance with
harmonized European standards, voluntary, reflecting
the essential requirements into technical
specifications. These standards are not mandatory
but are guarantees of compliance with essential
requirements.
The symbol ROHS (Restriction of use of some
Hazardous Substances) on the Environmental
Protection, certifies that for each of the five hazardous
substances • Lead • Mercury • (hexavalent) chromium •
products for protection against flames PBB and PBDE,
the peak concentration is equal to or less than 0.1% of
the weight of homogeneous material, and 0.01% for the
6th • cadmium.
The symbol "DOUBLE SQUARE" means a double
insulated. A basic insulation and supplementary
insulation. This device requires no connection to the
mass of a protective conductor grounded. The
materials are said : double insulation class II.
The symbol "GLASS / FORK" means that the device is
compatible and can come into contact with foodstuffs.
The symbol "TRIMAN" indicates that the consumer is
invited to dispose the product as part of a separate
collection (eg recycling bin, waste, voluntary intake
point).
For more information : http://www.quefairedemesdechets.fr
7


8


USE
Before using for the first time
● Remove all the packaging and throw away the blade covers.
● Wash the parts, see cleaning.
●
Before pluging
● Unroll the power cord completely.
● Check that the tension in force in the country where you are corresponds to
that indicated on the apparatus.
● Connect the apparatus in a correct socket-outlet, (and connected to the ground
if the unit is Class I), to avoid any danger.
● Disconnect the power source cable before any operation of cleaning of
maintenance and accessories assembly.
● Stand the appliance on a table or flat surface.
● Never modify the appliance in anyway.
● The item must not be left unattended when it is connected to main supply.
● The item is not to be used, if it has been dropped or if there are visible signs of
damage or if it is leaking.
● Never modify the appliance in anyway.
IMPORTANT : Not to use the apparatus more than one minute.
Let cool it 30 seconds between each operation. At the end of 7 min maximum
use, Let cool the apparatus 5 minutes before re-using it.
Important
● With heavy mixtures, don’t use your hand blender for longer than 50 seconds
in any four minutes period, it will overheat.
● Only use your hand blender for its intended domestic use.
STICK BLENDER
FOR THIS MODEL, THE FOOT IS NOT DETACHABLE !
iT CANNOT BE DISASSEMBLED
HOW TO USE THE STICK BLENDER
The hand blenderisperfectlysuitedfor souppreparation, mayonnaise and baby food
as well, as for blends and milkshakes.
1. Insert the hand blenderinto the Bowl(You can use the hand blender in a
measuringbowl or anyother container).
2. Press the pressure switch to start the appliance.
3. After use, unplug the plunger,
9


4. Rinse the mixer foot withoutwetting the top of the engine block.
Notes: Whenmixingdirectly in a pan, becareful not to damage the hand blender or
the inside of the saucepan.
Never mix liquidswithtemperaturesabove 80 °C.
HAND BLENDER
1. Stick blender
A. Button
B. Body
C. Fixed foot
For saucepan blending
Note : Take the pan off the heat and let it cool slightly. Otherwise your hand
blender could overheat.
1. Plug in, to avoid splashing, place the blade in the food before switching on.
2. Hold the beaker steady, then press switch button.
Note : * Don’t let liquid get above the join between the power handle and blender
shaft.
* Move the blade through the food and use a stabbing action.
* If your blender gets blocked, unplug before cleaning.
3. After use, unplug and dismantle.
CLEANING AND MAINTENANCE
Before cleaning switch off the appliance, always disconnect the apparatus and to
let it cool before cleaning.
Clean the outside of the apparatus with a sponge or slightly wet linen.
Take special care when preparing food for babies, the elderly and infirm. Always
ensure that the hand blender shaft is thoroughly sterilized. Use a sterilizing
solution in accordance with the sterilizing solution manufactures instructions.
Some foods, eg. carrot, may discolour the plastic. Rubbing with a cloth dipped in
vegetable oil helps remove discolouring.
10


STORAGE
- Ensure the unit is completely cool and dry.
- Do not wrap the cord around the appliance, as this will cause damage.
- Keep the appliance in a cool, dry place.
GUARANTEE
Before being delivered, all our products are subjected to a rigorous control.
This apparatus is guaranteed 24 months starting from the date of purchase by the
consumer.
The documents in proof of guarantee are :
• The invoice and
• The filled and stamped warrantee plate (located on side or bottom of the gift
box). Without these documents in proof, no free replacement, nor no free repair,
can be carried out.
During the warranty period, we deal for free, the defects of the apparatus or the
accessories, rising from a defect of materials or manufacture by repair or,
replacement. The services within the framework of the guarantee do not involve
any extension of the warranty period and does not give right to a new guarantee !
In the event of recourse to the guarantee, bring back the complete apparatus to
your retailer, in its original packing, accompanied by the proofs of purchase.
The breakage of parts out of glass or plastic is, in all the cases, not warranted.
Defects on the accessories or the wearing parts (for example: coals of engines,
hooks, drive belts, remote control of replacement, teeth brushes of replacement,
webs etc) as well as cleaning, maintenance or it replacement of wearing parts are
not guaranteed and are thus to pay !
In the event of foreign intervention, the guarantee becomes null and void.
After flow of the warranty period, repairs can be carried out, against payment, by a
specialized trade or a repair service.
SPECIFICATIONS
Power supply 220-240V~ 50Hz
Power 170W
Norm Class II
Using Time 1 min
Made in PRC
The characteristics can change without prior notice
11


Always unplug the appliance before any cleaning or maintenance
operation and accessories assembly.
CAUTION: In order to minimize the risks of electric shock, In the event of
breakdown, not to open the case but to call upon a qualified technician
for repairs.
This apparatus satisfied EC directives, it was controlled according to all the
European current directives, like: electromagnetic compatibility (EMC) and low
tension (LVD).
This apparatus was designed and manufactured in respect of the last safety
regulations and technical specifications.
Imported by Sotech International
" LE PERIPOLE " N°A-107
33, Avenue du Marechal de Lattre de Tassigny
94120 Fontenay sous-bois - France
12

