STAINLESS STEEL TOOL HOLDER TROLLEYS
installation instructions
FITTING THE TROLLEYS.
Place the shelf on the ground and bring the handle
closer with the wheels.
Tighten with the screws TE 8x30, nut and washer,
loosely.
1
Made of austenitic stainless steel
first grade AISI 304 (EN 1.4301)
with moulded tray shelves.
0 tube frame 25mm with 4
shank swivel wheels 0 mm.
125 in dark grey thermoplastic
rubber and nucleus in light grey
polymer.
Capacity 80 kg.
Suitable for the food,
pharmaceutical and chemical
sectors.
Position the lower tray in the same way, as well as
the central tray if present.
2

C20
Via Bonazzi, 4 - 40013 Castel Maggiore (BO)
Tel. [phone] (10 linee) - Fax [phone]
[email protected] - www.tecnotelai.it
!/!2 2
ART.
C200
C201
C205
C206
3
890 x 590 x 950
SIZE
L x D x H (mm)
2
1090 x 590 x 950
890 x 590 x 950
1090 x 590 x 950
DETACHABLE TROLLEYS
SHELVES
2
3
*Do not walk on uneven grounds to prevent damage to the trolley.
"
*Do not leave the trolley stopped on sloping ground.
"
*Before each use check that the wheels are not blocked by dust or otherwise. If it is the case, thoroughly
clean, removing the impurities.
USE AND MAINTENANCE INSTRUCTIONS
Bring the 2nd handle closer and screw the trays
starting with the one on the ground.
3
Check that all joints fit snugly, then finally
tighten all bolts.
