TECshow razor stream User manual

USER MANUAL / MANUAL DE USUARIO / MANUAL DO USUáRIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE /
POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR
LEIA AS INSTRUçõES CUIDADOSAmENTE ANTES DE USAR

English Version
Fast, precise and powerful the new Sniper 2R™ is a revolu-
tionary new hybrid eects projector, scanner and laser simu-
lator which features new lamp technology, the MSD Platinum
2R Lamp at 132 Watts / 6,000 hours. Capable of producing
powerful and precise beam and laser like eects - including
liquid sky, laser wave and cones, all moving at speeds nev-
er seen before. The Sniper 2R™ main functions include a X /
Y scan and Z rotation mirror system, 3 facet rotating prism,
variable speed shutter / dimmer / strobe, 14 dichroic colors,
17 static gobos including beam reduction gobos, 3pin DMX
and powerCON in/out connections, (4) button control panel,
220W max power consumption, and a multi-voltage univer-
sal auto switching power supply (110-240v).
RAZOR STREAM
ENGLISH VERSION
p. 2

Included items
• (1) Adjustable Mounting Yoke
• (1) powerCON Cable
p. 3RAZOR STREAM
ENGLISH VERSION

Channel DMX 21CH:
10---255 Pan Movement PAN
20---255 Pan Movement Fine[16 bit] PAN FINE[16 BIT]
30---255 Tilt Movement TILT
40---255 Tilt Movement Fine[16 bit] TILT FINE[16 BIT]
50---7 No Function PAN SHAKING
8---255 Pan Shaking Movement Slow To Fast
60---7 No Function TILT SHAKING
8---255 Tilt Shaking Movement Slow To Fast
7
0---2 Open
COLOR
3---4 Open + Color1
5---6 Color1
7---9 Color1 + Color2
10---11 Color2
12---13 Color2 + Color3
14---15 Color3
16---18 Color3 + Color4
19---20 Color4
21---22 Color4 + Color5
23---24 Color5
25---27 Color5 + Color6
28---29 Color6
30---31 Color6 + Color7
32---33 Color7
34---36 Color7 + Color8
37---38 Color8
39---40 Color8 + Color9
41---43 Color9
44---45 Color9 + Color10
46---47 Color10
48---49 Color10 + Color11
50---52 Color11
53---54 Color11 + Color12
55---56 Color12
57---58 Color12 + Color13
59---61 Color13
62---63 Color13 + Color14
64---65 Color14
66---67 Color14 + Open
68---128 Color Wheel Index - Color1 To Color15
129---190 Clockwise Color Rotation From Fast To Slow
191---193 Stop
194---255 CounterClockwise Color Rotation From Slow To Fast
p. 4
Channel 21
RAZOR STREAM
ENGLISH VERSION

8
0---7 Open
GOBO
8---14 Gobo1
15---22 Gobo2
23---29 Gobo3
30---37 Gobo4
38---44 Gobo5
45---52 Gobo6
53---59 Gobo7
60---67 Gobo8
68---74 Gobo9
75---82 Gobo10
83---89 Gobo11
90---97 Gobo12
98---104 Gobo13
105---112 Gobo14
113---119 Gobo15
120---126 Gobo16
127---133 Gobo17
134---194 Clockwise Gobo Rotation From Fast To Slow
195---255 CounterClockwise Gobo Rotation From Slow To Fast
Channel DMX 21CH:
p. 5RAZOR STREAM
ENGLISH VERSION

9
0---8 O
PATTERN MACROS
9---16 Pattern Macro 1
17---25 Pattern Macro 2
26---33 Pattern Macro 3
34---42 Pattern Macro 4
43---50 Pattern Macro 5
51---59 Pattern Macro 6
60---67 Pattern Macro 7
68---76 Pattern Macro 8
77---84 Pattern Macro 9
85---93 Pattern Macro 10
94---101 Pattern Macro 11
102---110 Pattern Macro 12
111---118 Pattern Macro 13
119---127 Pattern Macro 14
128---135 Pattern Macro 15
136---144 Pattern Macro 16
145---152 Pattern Macro 17
153---161 Pattern Macro 18
162---169 Pattern Macro 19
170---178 Pattern Macro 20
179---186 Pattern Macro 21
187---195 Pattern Macro 22
196---203 Pattern Macro 23
204---212 Pattern Macro 24
213---220 Pattern Macro 25
221---229 Pattern Macro 26
230---237 Pattern Macro 27
238---246 Pattern Macro 28
247---255 Pattern Macro 29
10
0---9 Stop
PATTERN ROTATION[Clockwise/Counter-
Clockwise]
10---120 Clockwise Pattern Rotation From Fast To
121---134 Stop
135---245 CounterClockwise Pattern Rotation From Slow To Fast
246---255 Stop
11
0---9 Stop
PATTERN ROTATION[Horizontal /Vertical]
10---120 Horizontal Pattern Rotation From Fast To Slow
121---134 Stop
135---245 Vertical Pattern Rotation From Slow To Fast
246---255 Stop
12 0---127 Pattern Zoom Manual PATTERN ZOOM
128---255 Pattern Zoom From Slow To Fast
Channel DMX 21CH:
p. 6RAZOR STREAM
ENGLISH VERSION

13
0---9 Stop
HORIZONTAL PATTERN MOVEMENT
10---120 Horizontal Pattern Movement Le
121---144 Stop
145---255 Horizontal Pattern Movement right
14
0---9 Stop
VERTICAL PATTERN MOVEMENT
10---120 Vertical Pattern Movement Up
121---144 Stop
145---255 Vertical Pattern Movement Dowm
15
0---127 0---360°
ECCENTRI128---191 Clockwise Rotation From Fast To Slow
192---255 CounterClockwise Rotation From Slow To Fast
16 0---7 Stop ECCENTRI SHAKING
8---255 Shaking From Slow To Fast
17 0---255 Prism Movement PRISM
18
0---127 RPrism Indexing
RPRISM128---191 Clockwise Rotation From Fast To Slow
192---255 CounterClockwise Rotation From Slow To Fast
19 0---255 Dimmer Intensity 0 To 100% DIMMER INTENSITY
20 0---7 No Function SHUTTER
8---255 Shutter From Slow To Fast
21
0---39 No Function
FUNCTION[Active Aer 5S]
40---59 Lamp On
60---79 Lamp O
80---89 All Motors Reset
90---99 Pan/Tilt Motors Reset
100---109 Color Motor Reset
110---119 Gobo Motor Reset
120---129 Shutter & Dimmer Motors Reset
130---139 Other Motors Reset
140---149 Enable Blackout While Pan/Tilt Movement
150---159 Disable Blackout While Pan/Tilt Movement
160---169 Enable Blackout While Color Change
170---179 Disable Blackout While Color Change
180---189 Enable Blackout While Gobo Change
190---199 Disable Blackout While Gobo Change
200---219 System Reset
220---255 No Function
Channel DMX 21CH:
p. 7RAZOR STREAM
ENGLISH VERSION

Channel 17
Channel DMX 17CH:
10---127 Pan Movement PAN
128---255 Pan Shaking Movement Slow To Fast
20---127 Tilt Movement TILT
128---255 Tilt Shaking Movement Slow To Fast
3
0---2 Open
COLOR
3---4 Open + Color1
5---6 Color1
7---9 Color1 + Color2
10---11 Color2
12---13 Color2 + Color3
14---15 Color3
16---18 Color3 + Color4
19---20 Color4
21---22 Color4 + Color5
23---24 Color5
25---27 Color5 + Color6
28---29 Color6
30---31 Color6 + Color7
32---33 Color7
34---36 Color7 + Color8
37---38 Color8
39---40 Color8 + Color9
41---43 Color9
44---45 Color9 + Color10
46---47 Color10
48---49 Color10 + Color11
50---52 Color11
53---54 Color11 + Color12
55---56 Color12
57---58 Color12 + Color13
59---61 Color13
62---63 Color13 + Color14
64---65 Color14
66---67 Color14 + Open
68---128 Color Wheel Index - Color1 To Color15
129---190 Clockwise Color Rotation From Fast To Slow
191---193 Stop
194---255 CounterClockwise Color Rotation From Slow To
Fast
p. 8RAZOR STREAM
ENGLISH VERSION

4
0---7 Open
GOBO
8---14 Gobo1
15---22 Gobo2
23---29 Gobo3
30---37 Gobo4
38---44 Gobo5
45---52 Gobo6
53---59 Gobo7
60---67 Gobo8
68---74 Gobo9
75---82 Gobo10
83---89 Gobo11
90---97 Gobo12
98---104 Gobo13
105---112 Gobo14
113---119 Gobo15
120---126 Gobo16
127---133 Gobo17
134---194 Clockwise Gobo Rotation From Fast To Slow
195---255 CounterClockwise Gobo Rotation From Slow To
Fast
Channel DMX 17CH:
p. 9RAZOR STREAM
ENGLISH VERSION

5
0---8 O
PATTERN MACROS
9---16 Pattern Macro 1
17---25 Pattern Macro 2
26---33 Pattern Macro 3
34---42 Pattern Macro 4
43---50 Pattern Macro 5
51---59 Pattern Macro 6
60---67 Pattern Macro 7
68---76 Pattern Macro 8
77---84 Pattern Macro 9
85---93 Pattern Macro 10
94---101 Pattern Macro 11
102---110 Pattern Macro 12
111---118 Pattern Macro 13
119---127 Pattern Macro 14
128---135 Pattern Macro 15
136---144 Pattern Macro 16
145---152 Pattern Macro 17
153---161 Pattern Macro 18
162---169 Pattern Macro 19
170---178 Pattern Macro 20
179---186 Pattern Macro 21
187---195 Pattern Macro 22
196---203 Pattern Macro 23
204---212 Pattern Macro 24
213---220 Pattern Macro 25
221---229 Pattern Macro 26
230---237 Pattern Macro 27
238---246 Pattern Macro 28
247---255 Pattern Macro 29
6
0---9 Stop
PATTERN ROTATION[Clockwise/Counter-
Clockwise]
10---120 Clockwise Pattern Rotation From Fast To Slow
121---134 Stop
135---245 CounterClockwise Pattern Rotation From Slow To
Fast
246---255 Stop
7
0---9 Stop
PATTERN ROTATION[Horizontal /Vertical]
10---120 Horizontal Pattern Rotation From Fast To Slow
121---134 Stop
135---245 Vertical Pattern Rotation From Slow To Fast
246---255 Stop
80---127 Pattern Zoom Manual PATTERN ZOOM
128---255 Pattern Zoom From Slow To Fast
Channel DMX 17CH:
