Tecson LX-2 User manual

P. 1 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
Tank-Spion Digital LX-2
Measuring an monitoring device for tank contents.
Type option: LX-2-R - with 2 relays aditionally.
Mounting and Instructions
Content: Page:
IN GENERAL 1
STRUCTURE 2
LIQUIDS 2
LABELING 2
MOUNTING INSTRUCTIONS 2
MOUNTING OF MEASURING PROBE 3
ELECTRIC INSTALLATION 3
AUTOM. CHANGEOVER OF TANKS 4
INITIAL SETUP 5
SETUP MENU, COMPL. 7
ERROR CODES 10
FUNCTION CHECK 11
TECHNICAL DATA 11
ACCESSORIES 11
CONNECTION PLAN 12
IN GENERAL
The tank content display device LX-2 or LX-2-R is to be used for monitoring of tank levels in
pressureless liquid tanks. Aditional functions to liter displaying are e.g. temperature measuring,
data transmission or linking to facility management systems.
The LX-2-R type additionally provides two output relays, e.g. for controlling an alert unit, for
switching magnetic valve or dry protection of pump.
The displayed liter values are not to be used for billing purpose.
For the intended use and to abide the rules for warranty do strictly follow the Mounting and
Instructions, which have to be handed out to the owner.

P. 2 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
STRUCTURE
The LX-2 (-R) has an eight characters LCD display and a measuring input for a level probe.
The LX-2-R type additionally provides 2 programable relays, with opening and closing contacts.
The measuring probe can be mounted with a screw joint of R1 “ or R1½ “.
A reduction for 2“ is not included in scope of delivery.
LIQUIDS
Liquid Liquid
Heating oil DIN EN 51603-1 Motor oil No used oil !
Diesel oil DIN EN 590 Hydraulic oil
Bio Diesel oil DIN EN 14214 Glycerin
Plant oil * after consulting Glycol
Petroleum Flash point > 55°C Water
Carbamide dissolution e.g. AdBlue Gasoline with
flash point < 55°C
Only with EEx-probe
and Zener barrier
LABELING
Confirming to EN 50081-1 , EN 50082-1 and EN 61010-1 / A2
MOUNTING INSTRUCTIONS
Only qualifyed persons are allowed to install the measuring probe and to connect the display
device. Follow the regulation for each liquid, especially for the risk of water pollution and for
flammable liquids.
Condition for proper operation of measuring device is a professional installation. Follow the
technical rules for planning, construction and operation of the entire facility. Additionally follow the
rules for tank mounting and operation.
•Condition for proper operation is a pressureless storage tank. The tank must have proper
ventilation. Oil tanks and gasoline tanks must be equipped with a level limiter.
•The cable entry in the tank has to be made watertight and vapor tight by using PTFE sealing
tape.
•The measuring probe and display device are not safety devices. They do not replace the level
limiter of a tank.
•Installation of the display device in explosive zones is not permitted.
In that case ask for an EEx-probe with Zener barrier. The tank probe must be mounted inside
the tank with a cable protection pipe.
•The display device is connected to 230V AC. Operating is only permitted with closed box lid.
In case of inappropriate installation you lose any warranty.

P. 3 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
MOUNTING OF MEASURING PROBE
•In case of cellar steal tanks or subgrounded tanks use the included
screwing joint for mounting the measuring probe.
•If an old fuel gauge was used dismount it and use the tank screwing port.
•Subgrounded tanks normally provide an idle screwing port. In that case
dismount the dummy plug.
Mounting:
•In case of a heating oil tank switch off the oil burner and lock the suction
pipe if necessary.
•Clear the tank’s screwing port.
•Put the cable of the probe through the screwing joint. Put the measuring
probe into the tank.
•Mount the screwing joint with PTFE sealing tape.
•Sink the measuring probe down to the ground of the tank. Fix the cable
with the PG screwing. The measuring probe may optionally lay or stand on
the ground of the tank.
•Zero-point calibration is not required in normal case.
•If nessecary unlock the suction pipe, switch on the oil burner and check
the functions.
ELECTRIC INSTALLATION
Interconnection of measuring probe to display device
Probe supply: DC 15 – 24 V
Connection: Connect the 2-wire probe cable in the way:
Red(+) => clamp 1 , Black (-) => clamp 2.
Air capillary: The air capillary must have ventilation to atmosphere.
The end of the probe’s cable and the air capillary must
be protected against humidity.
Extension: The cable of the probe can be extended up to 100 m,
e.g. with NYM or YR or NYY.
Line diameter at least 2 x 0,4 mm².
In case of cable extension in a manhole or outdoors
it is recommended to use a waterproof clamp box with
special air pressure ventilation (accessories).
Shielding: Near by power current cables it is recommended to use
a shielded probe signal line. (Cable shielding has to be
grounded.)
Supply voltage:
Voltage: AC 230 V 50 Hz
Clamps: PE (protective conductor), N (neutral conductor),
L (phase).
Power line is not included in accessories.
Refer to last page.
The capillary in the
probe’s cable must
have ventilation.
The capillary filter
stays attached !
Refer to probe
instructions.

P. 4 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
LX-2-R :
Relay connection
The LX-2-R type has two relays for controlling
external electric circuits or for alert signaling.
In case of failure or minimum level (or temperature
limit) the relay outputs 6-7 and 9-10 are linked and
the relay outputs 5-6 and 8-9 are opened; refer to
PCB print.
Normal state / Event state Normal state / Event state
Relay 1 Clamp 5 - 6 opened / Contact links Clamp 6 – 7 linked / Contact opens
Relay 2 Clamp 8 - 9 opened / Contact links Clamp 9 -10 linked / Contact opens
Voltage Max. 250 V AC
Current Max. 3,5 A
AUTOM. CHANGEOVER OF TANKS
Example
LX-2-R

P. 5 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
INITIAL SETUP
Determine the tank data and enter them into the mode:
You find the push buttons (blue) on the PCB positioned between the connection clamps.
Press ENTER => Device enters the setup mode (Step „1.Sonde“).
You can step through the input menu items by pressing PLUS or MINUS.
Press ENTER to step into a sub-menu.
Press PLUS or MINUS for selection; press ENTER for confirming.
In step 8 you reach „8.Exit“. Press ENTER for returning to display mode.
For particular parameter setup refer to P.7.
Setup / Programming
Function Description Values
1. Probe „Sonde“ Select the probe range (refer to probe label) –
default is 250 mbar
250mbar
2. Liquid „Fluid“
Liquid selection (refer to P. 8) e.g. :
- Heating oil (preselection): Heat.oil
- Diesel: Diesel
- select other predefined liquids by + / -
- otherwise enter the specific weight ....kg/l
In case of unknown weight go to step 10.Set h
Heat.oil
3. Tank shape
„Tank“
Tank shape selection (refer to P. 8) e.g. :
- linear (preselection): Linear
- horz. cylinder: Cyl.
- horz. cylinder 50 to 100 m³: Cyl.>50m3
Linear
4. Tank volume
„Volume“
Enter the tank volume (100% of capacity):
Attention: If a bearing chart is available it is
recommended to take the largest value pair out of
the chart.
E.g. in case of a 100 m
3
subgrounded tank the
exact value could be of 100 600 liters.
40.000L
5. Tank height
(100% value)
„Height“
Enter the interior tank height in mm:
E.g. 2.500 mm (Max. value = 9.999 mm)
(Height without manhole)
Attention: If a bearing chart is available it is
recommended to take the largest value pair out of
the chart.
E.g. in case of a 100 m
3
subgrounded tank the
exact value chould be 288 cm = 2880 mm.
2.500 mm

P. 6 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
Step 6 + 7 set up only
in case of relays
EXIT or RELAY.
Relay parameters for LX-2-R type
6. Relay 1
„Relay1“
Enter relay switchpoint as %-value 01 – 99
(or as °C-value of -99 - +99 , only in case of
temperature measuring probes)
Deactive => Use + / - , press ENTER
Active => Use + / - , press ENTER
On 10% => Use + / - to set up the
switch-on point.
Off 12% => Use + / - to set up the
switch-off point
On +15°C => ditto for temp. switch-on point
Off+17°C => ditto for temp. switch-off point
deactive sets the relay out of order.
Values of 0% or 0°C for switch-on/-off points
deactivate the relay, too.
active
On 10%
Off 12%
On +15°C
Off +17°C
7. Relay 2
„Relay2“ Inputs for relay 2 are analog to 6. Relay 1
8. Exit
„Exit“ Press ENTER for returning to display mode
16.500L
Steps 9 – 24 In steps 10 – 25 you will find additional settings
Standard setup ends at step 8 by confirming EXIT.
Then the display shows the current tank content.
After setup close the box lid.
Programming Examples
Example 1 Cellar tank for 6000 L heating oil. Liter displaying. Linear steel tank.
Interior height 165 cm (Current level: 125 cm). Probe 0 - 250 mbar
Step Input
1. Probe: 250 mbar 250mbar
2. Liquid: Heating oil Heat.oil
3. Tank shape: linear Linear
4. Tank volume: 6000 Liter 6000L (select by +/-)
5. Interior tank height: 165 cm 1650mm (select by +/-)
6. Relay1 – no function deactive
7. Relay2 – no function deactive
8. Exit => press ENTER for display mode => 4550L

P. 7 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
Tank with interior mantle
In case of tank with interior mantle (e.g. horz. cyl. or cellar steel tank) correct the input values.
Example: Mantle thickness 2 cm => reduce interior height by ca. 4 cm
Volume 10 m³ => reduce volume by 5%
Volume 20 m³ => reduce volume by 4%
Volume 50 m³ => reduce volume by 3%
Volume 100 m³ => reduce volume by 2.5%
Example 2 Subgrounded tank for 100,600 L Diesel. Probe 0 - 250 mbar.
Interior height 2.88 m (Current level: 54 cm)
Step Input
1. Probe: 250 mbar 250mbar
2. Liquid: Diesel Diesel
3. Tank shape: horz. cylindric Cyl.>50m³
4. Tank volume: 100,600 liter 100600L (refer to bearing chart)
5. Interior tank height: 288 cm 2880mm (refer to bearing chart)
6. Relay1 – no function deactive
7. Relay2 – no function deactive
8. Exit => press ENTER for display mode => 12800L
Beispiel 3 Font, 7,50 m max. water level from ground (current level 4,20 m).
Probe TDS-6029 (0-1000 mbar). Displaying in m:
Step Input
1. Probe: 1000 mbar 1000mbar
2. Liquid: Water H2O
3. Shape: linear linear
4. Volume: 7,500 liter (or m) 7500L (select by +/-)
5. Height: 7.50 m 7500mm (select by +/-)
6. Relay1 – ON at 0.5% - OFF at 10% active => On: 05% => Off:10%
7. Relay2 – No function deactive
8. Exit => Step forward by pressing PLUS
12. Unit – m Unit: m
13. Rounding auto auto (press ENTER to confirm)
14. Exit => press ENTER for display mode => e.g. 4.20m
SETUP MENU, COMPL.
Step Function Description
0. Exit Go back to display mode
1. Probe 100mbar
150mbar
250mbar
500mbar
1000mbar
2000mbar
3000mbar
5000mbar
...mbar
Cal-Mode
Tank height: Heating oil up to 1,2 m / Water up to 1 m
Heating oil up to 1,8 m / Water up to 1,5 m
Default range: Up to 3 m of heating oil / Water up to 2,5 m
Heating oil up to 6 m / Water up to 5 m
Heating oil up to 12 m / water up to 10 m
Heating oil up to 24 m / Water up to 20 m
Heating oil up to 36 m / Water up to 30 m
Heating oil up to 60 m / Water up to 50 m
Enter the specific probe range value.
Is displayed in case of calibration via ‘10.Set H’ or ’11.Set V’.

P. 8 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
2. Fluid
Liquid
Heat.oil
H2O
Diesel
BioD
RME,FAME
Rapsoil
Palmoil
Motoroil
AdBlue
Normal-B
Super-B
...kg / liter
Cal-Mode
0,845 - default
0,999
0,830
0,880
0,880 (Raps Methyl Esther, Fatty Acid Methyl Esther)
0,915
0,910
0,865
1,090
0,743
0,750
Enter a density value
Is displayed in case of calibration via ‘10.Set H’ or ’11.Set V’.
If the density of the liquid is unkown the reference height can be entered in step 10 Set h.
Therefore determine the current fill level in mm and substract 10 mm from it. Enter this value and
confirm with YES.
In case the current fill level is less than 75% it is recommended to correct the value to the updated
value after the next filling for getting a good measuring accuracy.
3.Tank
Tank shape
/ type
Linear Default: Linear tank.
Rectangular tank; vertical cylinder; steel cellar
tank.
Cyl. Cylindric tank ( alternative: Cyl.>50m
3
).
Horizontal cylindric tank, up to 45 m³ .
Typical tank shape for outdoor tanks and
subgrounded steel tanks.
Ball Spherical tank.
Ball-shaped subgrounded tank;
common subgrounded plastic tanks (GRP).
Oval Oval cellar tank.
Typical shape of GRP tanks and single-walled
tank
Konvex Convex plastic tank.
Slightly bellied tank shape
Konkav Concave plastic tank battery.
Cave-bellied tank shape.
Plastic Plastic tank with large cavity.
Hollow in the middle of the tank’s body.
(No ring bandages)
Cyl. > 50m
3
Large cylindric outdoor tank
of 50.000 Ltr up to 100.000 Liter of volume
( alternative: ‘Cyl.’ - see obove ).
Table
(for input)
Reference table to be entered;
by up to 15 pairs of values ( cm => Liter ).
Unsymmetrical or
other tank shape.

P. 9 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
4.Volume
(capacity)
xxx xxx L Tank capacity (total 100%).
Presetting is 0 L . The value setup is required in any case.
5.Height
(interior)
x xxx mm Interior tank height.
Presetting is 2.000 mm
LX-2: Step 6 + 7 => EXIT. LX-2-R: Step 6 + 7 => RELAY 1+2
6.Relay1
or Exit
deactive
active
Selecting by (+).
ENTER for saving and forwarding to On value.
On: 10% Presetting is 10%, range is 0...99 .
Relay switches On when under-running e.g. 10% level.
Off:12% Presetting is 12% (Hysteresis).
Relay switches Off again when when level exceeds e.g. 12% again.
On: +15C Only in case of temperature measuring adaptor is inserted:
Range is –99C ... +99C.
If On=0 and Off=0 the temperature alerting is diabaled.
Presetting is 15 °C.
Relay switches On when under-running e.g. 15°C temperature.
Off: +17C Temperature presetting is 17 °C (Hysteresis).
Relay switches Off again when temp. exceeds e.g. 17°C again.
7.Relay2 Input for 7.Relay2 refer to 6.Relay1
8. Exit Return to displaying mode.
9.Offset ESC/Calibrat
Zero-point offset calibration for the measuring probe.
10.Set h x xxx mm
Cal: No
Cal: Yes
Input option for a reference height (2-points calibration),
usefull in case of unknown specific weight of the fluid.
Subtract* 10 mm from the beared liquid level, and enter that value.
After confirming with ’Cal: Yes’, then in step 1+2 ‘Cal-Mode’ will be
displayed instead of a value.
If this is done at a low tank filling level it is recommend to repeat this
later on at a higher filling level. Also refer to 11.Set V
11.Set V xxx xxx L Fine trimming of current liter value.
Use +/- buttons and confirm with ’Cal: Yes’
12. Unit
Unit: L
Unit: %
Unit: m
Uint: kg
Presetting is L (liter) ( max. value: 999,900L )
( max. value: 100.00% )
( max. value: 999.99 m )
( max. value: 999,900kg )
13.Round
Rounding
auto
off
or 2, 5,
10… 100
Rounding of displaying value: Presetting is ‘auto’.
off = highest resolution without rouding; wobbling values.
A certain rounding is recommended => sedation.
14. Show Show %-
Symbol Y/N
Displaying option: A grafical %-symbol corresponding to the current
content appears in 2 s alternation to the liter displaying.
15-19. Exit Return to displaying mode.
20. LCD Contr 60 Trimming the contrast of the LCD display.
21. Info Displaying
of:
Software version V3.00
Serial no. SN1234
Offset xxxx
Gain xxxx

P. 10 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
22.Test I Displaying current measuring value in mA
and displaying the hex. value of the A/D converter.
23.Test R Rel1 ON
Rel1 OFF
Rel2 ON
Rel2 OFF
At LX-2-R type => Testing functions of both relays.
( At LX-2 type => without function )
24. Init - Reset -
ESC = Exit without resetting (Escape).
Reset = Restart of the internal micro program.
Defaults = Re-initializing (clearing) of all parameters
back to the delivery default setting.
26. Exit Return to displaying mode
ERROR CODES
Message Meaning
Error E 1 Invalid input value.
Error E 2 Measuring value of the probe is too small !
- E002 at zero-point calibration: If current is less than 3,5 mA => Probe error.
- E002 at input step 4: Make sure the probe is plunged. Or current fluid level
is under the calibration minimum level.
Error E 3 Measuring value is too high for zero-point calibration.
- The probe must not be plunged ! A probe’s current higher than 4,5 mA indicates
a problem with the probe.
Error E 4 Setup is possible only if zero-point calibration is done.
Execute the zero-point calibration again (=> 9. Offset).
Error E 5 Height input is larger than tank height. (Wrong input.)
Error E 6 The measuring value is too small for reference. Make sure the probe is plunged.
Settled height is too large (or means the measuring value is too small for setting).
Execute the zero-point calibration again (=> 9. Offset).
If it does not work check the probe current (mA) !
Error E 7 The current measuring value is too small for the corresponding tank height or
the volume input value. Make sure the probe is plunged.
Error E 8 The current measuring value (or mA) is too high. Check electrical connection and
check the measuring range of the probe.
Switch the 230V supply voltage off and on. Check input steps 3 and 4.
Execute the zero-point calibration again. (=> 9. Offset).
Otherwise the measuring probe has to be checked.
Error E 9 The current value is 0 mA. The probe’s connection could be broken. Check the probe
connection (polarity) and extension. Measure the voltage at the probe (red to black).
Error E10 Calbration error. Switch off an on the 230V supply voltage and retry.
Otherwise the probe is working not properly.
Error E11 Warning – The liquid level in the tank is too low for an exact calibration.
(Press OK to continue anyway.)
Error E12 Yet no measurement data is received from the external tanks 2 ... 4.

P. 11 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
FUNCTION CHECK
It is recommend to check if the displayed liters are correct after a complete fueling or once year.
Two practical options are: - Lift the probe and check the 0 Liter displaying
- Check the mm value displayed in Step ‘11. Set H’ (without trimming!)
TECHNICAL DATA
Display device
Supply voltage: AC 230 V 50 Hz Protection class: IP 30 or IP65
(by EN 60529)
Power consumtion: max. 2 VA
Measuring input: 4 - 20mA ; U
0
= 20V ; Resolution: 10 bit
Accuracy: ± 1 %
Relay output: LX-2-R has 2 relays
Voltage strength (U): max. 250 V AC Analog ouput: Adaptor 0-5 V DC
Current strength (I): max. 3,5 A Analog output: Adaptor 4-20 mA
Dimensions [mm] 120 x 120 x 49 (IP30)
or
130 x 130 x 60 (IP65)
Box material: Polystyrol (IP30)
or
Polycarbonat (IP65)
Measuring probe
Supply voltage: 24 V DC Protection class: IP 68 (by IEC 529)
Materials: V4A ; POM;
FPM; HD-PE
Probe length (without cable):
Cable length:
150 / 250 mbar type
107 mm
5 m / 6 m
Mounting orientation: Vertically or horizontally with contact to tank ground.
Temperature range: Liquid temperature 0 °C - +45 °C
ACCESSORIES
Order no.
Component Application
12080 Clamp box IP 65, special,
waterproof and ventilated
For extension of the probe’s cable (outdoors)
or in the tank’s manhole.
12064 Output adaptor 0 - 5 V Plugable module.
Provides an analoge voltage ( linearized ).
12065 Output adaptor 4-20 mA Plugable module.
Provides an analog signal of 4-20mA (passive),
2-wire principle ( linearized current signal ).
12036
12037
PC-Link Lite
PC-Link Extended
Add-on set for data transmission to a PC.
Data logging, Charting functions,
automatic emaiI generating.

P. 12 LX-2 / LX-2-R Mounting and Instructions Version: 07-2009
CONNECTION PLAN
for Tank-Spion Digital LX-2 and LX-2-R (with relays)
Complete set : LX-2 : Art-Nr. 12032
Complete set : LX-2-R : Art-Nr. 12033
Maintenance: Check if the displayed liters are correct:
Two practical options are:
- Lift the probe above the liquid level. Then check if ~ 0 L is displayed
- Check the mm value displayed in Step ‘11. Set H’ (without trimming!).
In case of deviation it is recommended to recalibrate the measuring probe
via step ‘9. Offset’.
Manufacturer:
TECSON-Digital
Wulfsfelder Weg 2a
D-24242 Felde
Tel. (+49) 4340 / 402530
Fax (+49) 4340 / 402529
Email: [email protected]
www.tecson.de
