Topcon Sokkia FX Series User manual

SURVEYING INSTRUMENTS
Class 3R Laser Product OPERATOR'S MANUAL
FX series
FX-101
FX-102
FX-103
FX-105
FX-107
Functional X-ellence Station

Li-ion S Li-ion
This is the mark of the Japan Surveying
Instruments Manufacturers Association.

Class 3R Laser Product
SURVEYING INSTRUMENTS
FX series
FX-101
FX-102
FX-103
FX-105
FX-107
Functional X-ellence Station
OPERATOR’S MANUAL
• Thank you for selecting the FX-101/102/103/105/107.
• Please read this Operator’s manual carefully, before using this product.
• FX has a function to output data to a connected host computer. Command operations from
a host computer can also be performed. For details, refer to "Communication manual" and
ask your local dealer.
• The specifications and general appearance of the instrument may be altered at any time and
may differ from those appearing in brochures and this manual.
• The content of this manual may be altered at any time.
• Some of the diagrams shown in this manual may be simplified for easier understanding.

ii
HOW TO READ THIS MANUAL
Symbols
The following conventions are used in this manual.
[Softkey] etc. : Indicates softkeys on the display and window dialog buttons.
{Key} etc. : Indicates keys on the operation panel.
<Screen title> etc.: Indicates screen titles.
Notes regarding manual style
• Except where stated, “FX” means FX-101/102/103/105/107 in this manual.
• The FX Series is available in "standard" and "Low Temperature" models. Users with a "Low
Temperature Model" should read the additional precautions specific to use under low temperatures.
●Low Temperature Model
Low Temperature Models display the seal shown at right.
G
• Do not remove the Low Temperature Model seal from the
instrument. This seal is used for model recognition by our
engineers during maintenance.
• Screens and illustrations appearing in this manual are of FX-103 (with Bluetooth module and
display on face 1 only). Face 2 display is available as standard or as a factory option depending on
the country of purchase.
• Location of softkeys in screens used in procedures is based on the factory setting. It is possible to
change the allocation of softkeys.
CSoftkey allocation: "20.6 Allocating Key Functions"
• Learn basic operations in "4. PRODUCT OUTLINE" and "5. BASIC OPERATION" before you read
each measurement procedure. For selecting options and inputting figures, see "5.1 Basic Key
Operation".
• Measurement procedures are based on continuous measurement. Some information about
procedures when other measurement options are selected can be found in “Note” ($).
G:Indicates precautions and important items which should be read before
operations.
C: Indicates the chapter title to refer to for additional information.
$: Indicates supplementary explanation.
&: Indicates an explanation for a particular term or operation.
Low temperature
seal

iii
HOW TO READ THIS MANUAL
• KODAK is a registered trademark of Eastman Kodak Company.
•Bluetooth®is a registered trademark of Bluetooth SIG, Inc.
• Windows and Windows CE are registered trademarks of Microsoft Corporation.
• All other company and product names featured in this manual are trademarks or registered
trademarks of each respective organization.

iv
CONTENTS
1. PRECAUTIONS FOR SAFE OPERATION......................... 1
2. PRECAUTIONS .................................................................. 4
3. LASER SAFETY INFORMATION ....................................... 8
4. PRODUCT OUTLINE........................................................ 10
4.1 Parts of the Instrument .............................................................. 10
4.2 Mode Structure .......................................................................... 13
4.3 Bluetooth Wireless Technology ................................................. 14
5. BASIC OPERATION ......................................................... 16
5.1 Basic Key Operation .................................................................. 16
5.2 Display Functions ...................................................................... 20
5.3 Disk Capacity ............................................................................ 28
5.4 Inputting Characters using the Input Panel ............................... 29
6. INSERTING USB MEMORY............................................. 30
7. USING THE BATTERY..................................................... 31
7.1 Battery Charging ....................................................................... 31
7.2 Installing/Removing the Battery ................................................. 32
8. SETTING UP THE INSTRUMENT.................................... 34
8.1 Centering ................................................................................... 34
8.2 Levelling .................................................................................... 36
9. POWER ON/OFF.............................................................. 38
9.1 Resolving Software Issues ........................................................ 39
9.2 Configuring the Touch Panel ..................................................... 39
10. CONNECTING TO EXTERNAL DEVICES ....................... 41
10.1 Wireless Communication using Bluetooth Technology ............. 41
10.2 Communication between the FX and Companion Device ......... 45
10.3 Connecting to USB devices ....................................................... 46
10.4 Connection via RS232C cable .................................................. 49
11. FOCUSSING AND TARGET SIGHTING .......................... 50
12. ANGLE MEASUREMENT................................................. 51
12.1 Measuring the Horizontal Angle between Two Points
(Horizontal Angle 0°) ................................................................. 51
12.2 Setting the Horizontal Angle to a Required Value
(Horizontal Angle Hold) ............................................................. 52
12.3 Angle measurement and Outputting the Data ........................... 53

v
13. DISTANCE MEASUREMENT........................................... 54
13.1 Returned Signal Checking ........................................................ 54
13.2 Distance and Angle Measurement ............................................ 56
13.3 Distance Measurement and Outputting the Data ...................... 57
13.4 REM Measurement ................................................................... 58
14. COORDINATE MEASUREMENT..................................... 60
14.1 Entering Instrument Station Data .............................................. 60
14.2 Azimuth Angle Setting ............................................................... 61
14.3 3-D Coordinate Measurement ................................................... 64
15. RESECTION MEASUREMENT........................................ 66
15.1 Coordinate Resection Measurement ......................................... 67
15.2 Height Resection Measurement ................................................ 71
16. SETTING-OUT MEASUREMENT .................................... 76
16.1 Using the Guide Light ................................................................ 76
16.2 Distance Setting-out Measurement ........................................... 77
16.3 Coordinates Setting-out Measurement ..................................... 82
16.4 REM Setting-out Measurement ................................................. 85
17. OFFSET MEASUREMENT............................................... 88
17.1 Single-distance Offset Measurement ........................................ 88
17.2 Angle Offset Measurement ....................................................... 91
17.3 Two-distance Offset Measurement ........................................... 93
18. MISSING LINE MEASUREMENT..................................... 96
18.1 Measuring the Distance between 2 or more Points .................. 96
18.2 Changing the Starting Point ...................................................... 98
19. SURFACE AREA CALCULATION.................................. 100
20. CHANGING THE SETTINGS ......................................... 104
20.1 Observation Conditions ........................................................... 104
20.2 Instrument Configuration ......................................................... 107
20.3 EDM Settings .......................................................................... 109
20.4 Allocating User-defined Tabs .................................................. 113
20.5 Customizing Screen Controls .................................................. 115
20.6 Allocating Key Functions ......................................................... 117
20.7 Changing Status Bar Icons ..................................................... 120
20.8 Units ........................................................................................ 122
20.9 Changing Password ................................................................ 123
20.10 Restoring Default Settings ...................................................... 124

vi
20.11 Date and Time ......................................................................... 124
21. WARNING AND ERROR MESSAGES........................... 125
22. CHECKS AND ADJUSTMENTS..................................... 128
22.1 Circular Level .......................................................................... 128
22.2 Tilt Sensor ............................................................................... 129
22.3 Collimation ............................................................................... 132
22.4 Reticle ..................................................................................... 133
22.5 Optical Plummet ...................................................................... 135
22.6 Additive Distance Constant ..................................................... 136
22.7 Laser Plummet (Option) .......................................................... 138
23. POWER SUPPLY SYSTEM ........................................... 141
24. TARGET SYSTEM.......................................................... 142
25. OPTIONAL ACCESSORIES........................................... 144
26. SPECIFICATIONS .......................................................... 146
27. EXPLANATIONS ............................................................ 152
27.1 Manually Indexing the Vertical Circle by Face Left,
Face Right Measurement ........................................................ 152
28. REGULATIONS .............................................................. 153
29. INDEX ............................................................................. 157

1
1. PRECAUTIONS FOR SAFE OPERATION
For the safe use of the product and prevention of injury to operators and other persons as well as
prevention of property damage, items which should be observed are indicated by an exclamation point
within a triangle used with WARNING and CAUTION statements in this operator’s manual.
The definitions of the indications are listed below. Be sure you understand them before reading the
manual’s main text.
Definition of Indication
General
CWARNING Ignoring this indication and making an operation error could possibly
result in death or serious injury to the operator.
CCAUTION Ignoring this indication and making an operation error could possibly
result in personal injury or property damage.
JThis symbol indicates items for which caution (hazard warnings inclusive) is urged.
Specific details are printed in or near the symbol.
DThis symbol indicates items which are prohibited. Specific details are printed in or near
the symbol.
IThis symbol indicates items which must always be performed. Specific details are printed
in or near the symbol.
CWarning
DDo not use the unit in areas exposed to high amounts of dust or ash, in areas where there
is inadequate ventilation, or near combustible materials. An explosion could occur.
GDo not perform disassembly or rebuilding. Fire, electric shock, burns, or hazardous
radiation exposure could result.
DNever look at the sun through the telescope. Loss of eyesight could result.
DDo not look at reflected sunlight from a prism or other reflecting object through the
telescope. Loss of eyesight could result.
DDirect viewing of the sun using the telescope during sun observation will cause loss of
eyesight. Use a solar filter (option) for sun observation.
EWhen securing the instrument in the carrying case make sure that all catches, including
the side catches, are closed. Failure to do so could result in the instrument falling out
while being carried, causing injury.
CCaution
DDo not use the carrying case as a footstool. The case is slippery and unstable so a
person could slip and fall off it.

1. PRECAUTIONS FOR SAFE OPERATION
2
Power Supply
DDo not place the instrument in a case with a damaged catch, belt or handle. The case or
instrument could be dropped and cause injury.
DDo not wield or throw the plumb bob. A person could be injured if struck.
ESecure handle to main unit with handle locks. Failure to properly secure the handle could
result in the unit falling off while being carried, causing injury.
ETighten the adjustment tribrach clamp securely. Failure to properly secure the clamp
could result in the tribrach falling off while being carried, causing injury.
CWarning
DDo not short circuit. Heat or ignition could result.
DDo not place articles such as clothing on the battery charger while charging batteries.
Sparks could be induced, leading to fire.
DDo not use voltage other than the specified power supply voltage. Fire or electrical shock
could result.
DDo not use batteries other than those designated. An explosion could occur, or abnormal
heat generated, leading to fire.
DDo not use damaged power cords, plugs or loose outlets. Fire or electric shock could
result.
DDo not use power cords other than those designated. Fire could result.
EUse only the specified battery charger to recharge batteries. Other chargers may be of
different voltage rating or polarity, causing sparking which could lead to fire or burns.
DDo not use the battery, charger or AC (power) cable for any other equipment or purpose.
Fire or burns caused by ignition could result.
HDo not heat or throw batteries into fire. An explosion could occur, resulting in injury.
ETo prevent shorting of the battery in storage, apply insulating tape or equivalent to the
terminals. Otherwise shorting could occur resulting in fire or burns.
DDo not use batteries or the battery charger if wet. Resultant shorting could lead to fire or
burns.
DDo not connect or disconnect power supply plugs with wet hands. Electric shock could
result.
CCaution
FDo not touch liquid leaking from batteries. Harmful chemicals could cause burns or
blisters.

3
1. PRECAUTIONS FOR SAFE OPERATION
Tripod
Bluetooth wireless technology
Use under low temperatures (Low Temperature Model only)
CCaution
EWhen mounting the instrument to the tripod, tighten the centering screw securely. Failure
to tighten the screw properly could result in the instrument falling off the tripod, causing
injury.
ETighten securely the leg fixing screws of the tripod on which the instrument is mounted.
Failure to tighten the screws could result in the tripod collapsing, causing injury.
DDo not carry the tripod with the tripod shoes pointed at other persons. A person could be
injured if struck by the tripod shoes.
EKeep hands and feet away from the tripod shoes when fixing the tripod in the ground. A
hand or foot stab wound could result.
ETighten the leg fixing screws securely before carrying the tripod. Failure to tighten the
screws could lead to the tripod legs extending, causing injury.
CWarning
DDo not use within the vicinity of hospitals. Malfunction of medical equipment could
result.
EUse the instrument at a distance of at least 22 cm from anyone with a cardiac
pacemaker. Otherwise, the pacemaker may be adversely affected by the
electromagnetic waves produced and cease to operate as normal.
DDo not use onboard aircraft. The aircraft instrumentation may malfunction as a result.
DDo not use within the vicinity of automatic doors, fire alarms and other devices with
automatic controls as the electromagnetic waves produced may adversely affect
operation resulting in an accident.
CCaution
DIn temperatures around -30°C do not touch metal parts on the main unit, the
accessories and the carrying case with bare hands. Exposed skin may stick to parts
and cause burns and loss of skin.

4
2. PRECAUTIONS
Telescope
• Aiming the telescope at the sun will cause internal damage to the instrument. Use the solar filter
when observing the sun.
C"25. Optional accessories"
Tribrach Clamp and Handle
• When the instrument is shipped, the tribrach clamp is held
firmly in place with a locking screw to prevent the
instrument from shifting on the levelling base. Before using
the instrument the first time, loosen this screw with a
screwdriver. And before transporting it, tighten the locking
screw to fasten the tribrach clamp in place so that it will not
shift on the tribrach.
• The FX handle can be removed. When operating the FX
with the handle attached, always make sure that the handle
is securely fixed to the FX body with the handle locks.
Precautions concerning water and dust resistance
FX conforms to IP65 specifications for waterproofing and dust resistance when battery cover,
connector cap and the external interface hatch and are closed.
• Be sure to correctly attach the connector caps to protect the FX from moisture and dust particles
when the connector is not in use.
• Make sure that moisture or dust particles do not come in contact with the terminal or connectors.
Operating the instrument with moisture or dust on the terminal or connectors may cause damage to
the instrument.
• Make sure that the inside of the carrying case and the instrument are dry before closing the case. If
moisture is trapped inside the case, it may cause the instrument to rust.
• If there is a crack or deformation in the rubber packing for the battery cover or external interface
hatch, stop using and replace the packing.
• To retain the waterproof property, it is recommended that you replace the rubber packing once every
two years. To replace the packing, contact your local sales representative.
• Do not press the speaker hole using something with a pointed tip. Doing so
will damage an internal waterproof sheet, resulting in a degraded
waterproof property.
The Lithium Battery
• The lithium battery is used to maintain the FX Calendar & Clock function. It can back up data for
approximately 5 years of normal use and storage (Temperature = 20°, humidity = about 50%), but
its lifetime may be shorter depending on circumstances.
Speaker

5
2. PRECAUTIONS
Vertical and horizontal clamps
• Always fully release the vertical/horizontal clamps when rotating the instrument or telescope.
Rotationg with clamp(s) partially applied may adversely affect accuracy.
Backing up data
• Data should be backed up (transferred to an external device etc.) on a regular basis to prevent data
loss.
Use under low temperatures (Low Temperature Model only)
• Do not use force to scrape off frost from the lens or display unit screen. Frost is an abrasive material
and may scratch the instrument.
• If ice or snow attaches itself to the unit, wipe it off with a soft cloth, or place the unit in a warm room
until the ice melts, and then wipe off the meltwater. Operating the unit with ice or snow attached may
cause operation errors to occur.
• Wipe off condensation with a soft cloth before using the instrument. Not doing so may cause
operation errors to occur.
• The working duration of battery BDC70 will rapidly decline in cold temperatures. When using the
instrument in temperatures around -30°C, we recommend that you use an external battery (optional
accessory). However, if you unavoidably must use battery BDC70 for measurements in
temperatures around -30°C, recharge the battery in a warm room and keep the battery in a warm
place such as your pocket until it is used. (Working duration of battery will change with
environmental conditions.)
• The lens cap and lens hood may become difficult to attach in low temperatures. Keep them in a
warm place such as a pocket until attached.
• If the unit is carried between locations that have extreme temperature differences, protect the unit
from rapid temperature change by placing it in the carrying case.
• Please use the tribrach supplied as standard. If a different tribrach is used, angle measurement
errors may occur.
Other precautions
• Never place the instrument directly on the ground. Sand or dust may cause damage to the screw
holes or the centering screw on the base plate.
• Do not perform vertical rotation of the telescope when using the lens hood, diagonal eyepiece, or
solar filter. Such accessories may strike the FX causing damage.
• Protect the instrument from heavy shocks or vibration.
• Protect the instrument from rain or drizzle with an umbrella or waterproof cover.
• Never carry the instrument on the tripod to another site.
• Turn the power off before removing the battery.
• Remove the battery before placing the FX in its case.
• Make sure that the instrument and the protective lining of the carrying case are dry before closing the
case. The case is hermetically sealed and if moisture is trapped inside, the instrument could rust.
• Consult your local dealer before using the instrument under special conditions such as long periods
of continuous use or high levels of humidity. In general, special conditions are treated as being
outside the scope of the product warranty.

2. PRECAUTIONS
6
Exporting this product
• This product is equipped with the parts/units, and contains software/technology, which are subject
to the EAR (Export Administration Regulations). Depending on countries you wish to export or bring
the product to, a US export license may be required. In such a case, it is your responsibility to obtain
the license. The countries requiring the license as of January 2012 are shown below. Please consult
the Export Administration Regulations as they are subject to change.
North Korea
Iran
Syria
Sudan
Cuba
URL for the EAR of the US: http://www.access.gpo.gov/bis/ear/ear_data.html
Maintenance
• Wipe off moisture completely if the instrument gets wet during survey work.
• Always clean the instrument before returning it to the case. The lens requires special care. First,
dust it off with the lens brush to remove tiny particles. Then, after providing a little condensation by
breathing on the lens, wipe it with the wiping cloth.
• If the display is dirty, carefully wipe it with a soft, dry cloth. To clean other parts of the instrument or
the carrying case, lightly moisten a soft cloth in a mild detergent solution. Wring out excess water
until the cloth is slightly damp, then carefully wipe the surface of the unit. Do not use any alkaline
cleaning solutions, alcohol, or any other organic solvents on the instrument or display.
CFor temporal de-activating the touch panel, see "5.2 Display Functions", "20. CHANGING
THE SETTINGS"
• Store the instrument in a dry room where the temperature remains fairly constant.
• Check the tripod for loose fit and loose screws.
• If any trouble is found on the rotatable portion, screws or optical parts (e.g. lens), contact your local
dealer.
• When the instrument is not used for a long time, check it at least once every 3 months.
C"22. CHECKS AND ADJUSTMENTS"
• When removing the instrument from the carrying case, never pull it out by force. The empty carrying
case should be closed to protect it from moisture.
• Check the instrument for proper adjustment periodically to maintain the instrument accuracy.

7
2. PRECAUTIONS
Exceptions from responsibility
• The user of this product is expected to follow all operating instructions and make periodic checks
(hardware only) of the product’s performance.
• The manufacturer, or its representatives, assumes no responsibility for results of faulty or intentional
usage or misuse including any direct, indirect, consequential damage, or loss of profits.
• The manufacturer, or its representatives, assumes no responsibility for consequential damage, or
loss of profits due to any natural disaster, (earthquake, storms, floods etc.), fire, accident, or an act
of a third party and/or usage under unusual conditions.
• The manufacturer, or its representatives, assumes no responsibility for any damage (change of
data, loss of data, loss of profits, an interruption of business etc.) caused by use of the product or
an unusable product.
• The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of
profits caused by usage different to that explained in the operator’s manual.
• The manufacturer, or its representatives, assumes no responsibility for damage caused by incorrect
operation, or action resulting from connecting to other products.

8
3. LASER SAFETY INFORMATION
FX is classified as the following class of Laser Product according to IEC Standard Publication 60825-
1 Ed.2.0: 2007 and United States Government Code of Federal Regulation FDA CDRH 21CFR Part
1040.10 and 1040.11 (Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No.50, dated June 24, 2007.)
• EDM device in objective lens: Class 3R Laser Product
(When using prism or reflective sheet as target)Class 1 Laser Product
• Laser plummet (option): Class 2 Laser Product
G
• EDM device is classified as Class 3R Laser Product when reflectorless measurement is selected.
When the prism or reflective sheet is selected as target, the output is equivalent to the safer class 1.
CWarning
• Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
• Follow the safety instructions on the labels attached to the instrument as well as in this manual to
ensure safe use of this laser product.
• Never point the laser beam at another person. If the laser beam strikes skin or an eye, it could cause
serious injury.
• Do not look directly into the laser beam source. Doing so could cause permanent eye damage.
• Do not stare at the laser beam. Doing so could cause permanent eye damage.
• If an eye injury is caused by exposure to the laser beam, seek immediate medical attention from a
licensed ophthalmologist.
• Never look at the laser beam through a telescope, binoculars or other optical instruments. Doing so
could cause permanent eye damage.
• Sight the target so that the laser beam does not stray from them.

࡟࡯ࠩశߩ಴ญ
AVOID EXPOSURE-Laser radiation
is emitted from this aperture.

⋡߳ߩ⋥ធⵍ߫ߊࠍㆱߌࠆߎߣ
ࠢ࡜ࠬ4࡟࡯ࠩ⵾ຠ
,+5%
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
/#:O9.&PO
MAX 5mW LD 625-695nm
CLASS3R LASER PRODUCT
IEC 60825-1 Ed. 2.0 : 2007
࡟࡯ࠩశ
Laster beam emitted
from here
(only when laser plummet
function is mounted)
Laster beam
emitted from
here

9
3. LASER SAFETY INFORMATION
CCaution
• Perform checks at start of work and periodic checks and adjustments with the laser beam emitted
under normal conditions.
• When the instrument is not being used, turn off the power and replace the lens cap.
• When disposing of the instrument, destroy the battery connector so that the laser beam cannot be
emitted.
• Operate the instrument with due caution to avoid injuries that may be caused by the laser beam
unintentionally striking a person in the eye. Avoid setting the instrument at heights at which the path
of the laser beam may strike pedestrians or drivers at head height.
• Never point the laser beam at mirrors, windows or surfaces that are highly reflective. The reflected
laser beam could cause serious injury.
• Only those who have been received training as per the following items shall use this product.
• Read the Operator’s manual for usage procedures for this product.
• Hazardous protection procedures (read this chapter).
• Requisite protective gear (read this chapter).
• Accident reporting procedures (stipulate procedures beforehand for transporting the injured and
contacting physicians in case there are laser induced injuries).
• Persons working within the range of the laser beam are advised to wear eye protection which
corresponds to the laser wavelength of the instrument being used
• Areas in which the lasers are used should be posted with laser warning notices.
• When using the laser-pointer function, be sure to turn OFF the output laser after distance
measurement is completed. Even if distance measurement is canceled, the laser-pointer function is
still operating and the laser beam continues to be emitted.

10
4. PRODUCT OUTLINE
Parts and functions of the instrument
1 Handle 
2Bluetooth antenna
3 External interface hatch
(USB port / Reset button)
C"10. CONNECTING TO EXTERNAL
DEVICES"
4&Instrument height mark
5 Battery cover
6 Display unit
7A Serial connector
7B Serial / External power source connector
8 Circular level
9 Circular level adjusting screws
10 Base plate
11 Levelling foot screw
12 Optical plummet focussing ring
13 Optical plummet eyepiece
14 Optical plummet reticle cover
15 Luminance sensor
16 Guide light
17 Objective lens
(Includes "&Laser-pointer function")
18 Handle locking screw
19 Tubular compass slot
20 Vertical fine motion screw
21 Vertical clamp
22 &Trigger key
23 Horizontal clamp
24 Horizontal fine motion screw
25 Tribrach clamp
26 Telescope eyepiece screw
27 Telescope focussing ring
28 &Sighting collimator
29 Instrument center mark
4.1 Parts of the Instrument
4
4
16
1
2
3
8
6
5
7A
9
10
11
13
12
15
14
17
18
19
22
20
21
23
24
26
25
27
28
29
4
4
15
7B
FX-101,102 and low temperature models only

11
4. PRODUCT OUTLINE
&Guide light
Setting-out measurement etc. can be carried out effectively using the guide light. The guide light
is composed of a light that is divided into green and red sections. A poleman can ascertain the
present position by checking the guide light color.
Indication for positioning target during setting-out measurement
The guide light indicator is lit or flashes depending on the status of the guide light.
C"16.1 Using the Guide Light"
&Sighting collimator
Use sighting collimator to aim the FX in the direction of the measurement point.
Turn the instrument until the apex of the triangle in the sighting collimator is aligned with the
target. A circle surrounds the triangle to make it easier to locate.
&Instrument height mark
The height of the FX is 236mm (from tribrach dish to this mark). "Instrument height" is input when
setting instrument station data and is the height from the measuring point (where FX is mounted)
to this mark.
&Trigger key
When the Trigger key is pressed FX carries out the operation indicated by the softkey in bold
type on the screen. This allows the user to continue operation without having to return to the
display to press softkeys.
&Laser-pointer function
A target can be sighted with a red laser beam in dark locations without the use of the telescope.
Light status Meaning
Increased flashing speed (From position of poleman) Move target toward FX
Decreased flashing speed (From position of poleman) Move target away from FX
Fast flashing Target is at correct distance
Red (From position of poleman) Move target left
Green (From position of poleman) Move target right
Red and Green Target is at correct horizontal position
green red
Guide light
(When seen from the objective lens side
while the instrument is in the Face 1 state)

4. PRODUCT OUTLINE
12
Bluetooth antenna (Models with Bluetooth module only)
The Bluetooth antenna allows communication via Bluetooth wireless technology.
G
• Handle the antenna with care. The antenna may be damaged if struck during operation or while
being stored in the carrying case.
Handle
The carrying handle can be removed from the
instrument. To remove it, loosen the handle
rocking screw.
G
• To remove the handle, hold both sides of the handle
and lift it straight above. If you hold the handle by
one hand or incline it, the terminal attached on the
handle may be damaged.
Handle
Handle
rocking screws
