TEFAL Uno xl User manual

www.tefal.com
Uno xl electronic
Turnspit
EN
ZH
KO
ID
TH
VI

3
AInterior light
BNon-stick walls
CConvection fan
D Heating elements
EDouble glass door
FControl panel
F1 Left rotating knob
F2 Manual mode selector
F3 Oven temperature selector
F4 Cooking time selector
F5 Keep warm
F6 Delayed start
F7 LCD screen
F7a Cooking settings
F7b Keep warm
F7c Delayed start
F7d Temperature
F7e Time display
F7f Temperature unit
F7g Weight
F8 Start cooking
F9 Stop/change during cooking
F10Automatic menu selection
F11Food weight selection/child safety
F12Right rotating knob
GTurnspit kit (1 rack, 2 forks, 2 turnspit frames,
1 rod, 1 baking tray)
HNon-stick tray
IReversible grill
JDrip tray
BEFORE USE
Unpacking
1234
Turn the box over so it is upside down. Open the box - g.1, remove the accessories - g.2 and to
make it easier to unpack turn the packaging and contents gently over - g.3. Remove the box and
lift off the polystyrene protection - g.4.
Installation
6
Using a damp cloth, wipe the interior and exterior of the appliance and dry it - g.5.
Wash all the accessories in warm soapy water. Rinse and dry thoroughly - g.6. Place the drip tray
back in the oven underneath the lower heating elements - g.7.
DESCRIPTION
EN
ZH
KO
ID
MS
TH
VI

4
Slide-in crumb tray
11
Slide the crumb tray into the oven above the lower element - g.7. Leave the crumb tray in place
while the appliance is in operation - g.8.
Do not touch the crumb tray during use or immediately afterwards. Always give it time to cool
down - g.9.
Remember to empty the crumb tray after each use - g.10-11.
Shelf position
7
5
3
1
8
6
4
2
For all functions of your appliance the position of the shelf has a major
impact on cooking results.
Your oven has 4 heights for positioning the shelf. However, as the shelf is
reversible, it is possible to obtain 8 different positions.
Place your dish in the centre of the shelf at the required height.
Do not place any container directly on the inner heating element.
Setting the time
13
14
15
16
17
18
After plugging in the oven - g.12, the digital display automatically shows the time as « 00:00 » with
the hours flashing - g.13. Set the hour using the left rotating knob - g.14. Validate by pressing the
clock button - g.15. The minutes will then flash automatically - g.16. Set the minutes using the left
rotating knob - g.17. Validate by pressing the clock button again - g.18.
To change the time press and hold the clock button for a few seconds.
WARNING! Do not confuse the clock button and the delayed start button .

5
. Leave the crumb tray in place
Do not touch the crumb tray during use or immediately afterwards. Always give it time to cool
For all functions of your appliance the position of the shelf has a major
Your oven has 4 heights for positioning the shelf. However, as the shelf is
16
, the digital display automatically shows the time as « 00:00 » with
Validate by pressing the
left
First use while empty
Before first use the oven must be operated while empty for 20 minutes to remove any
possible manufacturing residue.
19
20
21
22
23
The oven is now plugged in and the time has been set. Press « mode » - g.19. Select « convection »
cooking mode using the left rotating knob - g.20. The « convection » logo should appear on
the LCD screen - g.21. Validate by pressing « mode » again - g.22.
23
24
240°C
25
26
27
28
29
20 min
30
31
32
The temperature flashes - g.23. Select the temperature: 240° using the left rotating knob -
g.24. Validate by pressing « temperature » - g.25. The hours will flash - g.26. Leave the hours
at 0. Validate by pressing the clock button - g.27. The minutes will flash- g.28. Set the minutes:
20 minutes using the left rotating knob - g.29. Validate by pressing the clock button again - g.30
- g.31. Press once to stop cooking - g.32.
OK
20 min
35
On first use, some smoke may escape from the oven - g.33. This is normal and will gradually
disappear with use. After 20 minutes the oven will beep and then stop automatically - g.34.
Leave the appliance to cool - g.35.
EN
ZH
KO
ID
MS
TH
VI

6
AUTOMATIC MODE
Using the programmed menus
36
37
38
36
The oven is plugged in and the time set. Press « menu » - g.36. The menu and the cooking time
will flash - g.37. Select your menu using the right rotating knob - g.38. Press « menu » again to
validate - g.39.
40
41
42 43
The weight will flash - g.40. Select the weight (see table describing the automatic menu modes)
using the right rotating knob - g.41 and validate by pressing the « weight » button - g.42. The
cooking time is automatically displayed according to the validated weight.
To program a delayed start or keep warm mode see the appropriate chapters.
Press once to start cooking - g.43.
The cooking chart is for information purposes. Depending on your tastes, cooking can be continued
in manual mode.
At the end of cooking the oven will beep and stop automatically - g.44-45-46.

7
Description of programmed menus*
Weight Kg 0,5 0,6 0,7 0,8 0,9 1,0 1,1 1,2 1,3 1,4 1,5 1,6 1,7 1,8 1,9 2,0 2,1 2,2 2,3 2,4 2,5
N° Program Mode Shelf
height T°C Selection Time in minutes
P01
Beef
rare 5 220 0,5 -
2,5 kg
24 27 30 33 37 40 43 46 49 52 54 57 60 62 65 67 70 72 75 77 79
P02
Beef
medium 5 180 0,5 -
2,5 kg
40 42 44 47 49 52 54 57 59 61 64 66 69 71 73 76 78 81 83 86 88
P03 Veal 3 180 0,5 -
2,5 kg
57 62 67 72 77 81 86 90 94 99 103 107 110 114 118 121 125 128 131 134 137
P04 Pork 4 180 0,5 -
2,5 kg
79 84 89 94 98 102 106 109 112 115 117 119 121 123 124 125 126 126 126 126 125
P05 Poultry 4 200 0,5 -
2,5 kg
39 44 48 52 56 60 64 67 70 73 76 79 81 84 86 88 90 91 93 94 95
P06 Lamb 2 180 0,5 -
2,5 kg
64 69 74 79 84 88 92 96 100 103 107 107 113 115 118 120 122 124 125 127 128
P07
Fish
large 2 200 0,5 -
2,5 kg
27 28 29 30 32 33 35 36 38 40 42 44 46 49 51 54 57 60 63 66 69
P08
Fish
small 4 190 0,5 -
2,5 kg
26 27 28 28 29 30 31 32 33 34 35 36 38 39 41 42 44 45 47 48 50
P09
Frozen
chips 6 220 0,5 kg
33
P10
Chicken
nuggets 4 210 0,5 -
0,8 kg
29 30 37 43
Cooking C1 C2 C3
N° Program Mode Shelf
height T°C Size Time in minutes
P11
Frozen
pizza 5 210
C1 = Small
C2 =
Medium
C3 = Large
13 20 26
P12
Fresh
pizza 3 210
C1 = Small
C2 =
Medium
C3 = Large
12 14 23
P13 Pies 5 / 4 240
C1 = Small
C2 =
Medium
C3 = Large
30 33 39
P14
Gratinated
dishes 4 220
C1 = Small
C2 =
Medium
C3 = Large
45 54 83
P15 Cookies 5 180 1 setting 15
P16 Brownie 3 200
C1 = Small
C2 =
Medium
C3 = Large
16 34 40
P17 Chicken TB 240 55 58 60 61 62 64 67 71 88 94 100
P18 Roastbief TB 240 32 34 36 37 38 39 40 41 42 43 45 48
P19 Roast pork TB 240 43 54 58 62 65 69 72 73 74 75 76 78
Menus P01 to P08 allow you to select the weight of your food from 0.5 to 2.5 kg.
Menu P10 allows you to select between 0.5 and 0.8 kg of chicken nuggets.
Menus P11 to P14 and P16 offer 3 selections: C1 = Small, C2 = Medium and C3 = Large.
NOTE! There is only one selection possible for menus P09 and P15.
* The cooking chart is for information purposes only and is not to be taken as a reference.
EN
ZH
KO
ID
MS
TH
VI

8
MANUAL MODE
Description of manuals menus
Natural convection (or conventional oven): Natural convection (or conventional
oven): the heat is generated by the oven’s upper and lower elements. This traditional
cooking mode is suitable for cooking meat, fish and puddings.
Grill (upper element): the heat is generated by the oven’s upper element. This can be
used for traditional grilling/barbecuing and also to brown dishes.
Defrost: this special function operates the fan at the rear of the oven in order to reduce
the defrosting time of the ingredients that you put in your oven, without any risk of
them being cooked. The temperature cannot be changed in defrost mode.
Fan oven: the heat is generated then blown around by a fan located at the rear of the
oven which guarantees exceptionally even cooking anywhere in the oven. The blowing
around of the air allows your food to be cooked evenly.
Turnspit: Oven rotisserie for all types of meat and poultry.
For conventional, grill and convection modes, the temperature can be set at between 100°C
and 240°C.
Using the manuals menus
48 49 50 51
The oven is plugged in and the time set.
Place the shelf at the required height. Place the tray with the food in the oven - g.47 and close the
door. Press « mode » - g.48. The cooking mode will flash - g.49. Select the cooking mode using
the left rotating knob - g.50. Validate by pressing « mode » again - g.51.

9
Natural convection (or conventional
oven): the heat is generated by the oven’s upper and lower elements. This traditional
the heat is generated by the oven’s upper element. This can be
this special function operates the fan at the rear of the oven in order to reduce
time of the ingredients that you put in your oven, without any risk of
the heat is generated then blown around by a fan located at the rear of the
oven which guarantees exceptionally even cooking anywhere in the oven. The blowing
For conventional, grill and convection modes, the temperature can be set at between 100°C
51
and close the
Select the cooking mode using
52
53
54
56
The temperature will flash - g.52. Select the temperature using the left rotating knob - g.53.
57
PLEASE NOTE: the temperature cannot be changed in defrost mode.
Validate by pressing « temperature » - g.54. The cooking time will flash - g.55 :
set the time by turning the left rotating knob - g.56, validate by pressing the
clock button - g.57.
58
59
60 61
The minutes will flash - g.58 Set the minutes by turning the left rotating knob - g.59, validate by
pressing the clock button again - g.60. The maximum cooking time is 3h59.
To program a delayed start or keep warm mode see the appropriate chapters.
Press once to start cooking - g.61.
At the end of the cooking time, the oven will beep and stop automatically - g.62-63-64.
EN
ZH
KO
ID
MS
TH
VI

10
Using the turnspit function
65
66
67
68
To install the turnspit, place the two turnspit frames on the rack - g.65-66-67. Then place the tray
on the rack - g.68.
69
70
Place string around the meat and poultry before
skewering. Slide the skewers into the poultry - g.69, then
slide the two forks on to the skewers (with the points
facing outwards) - g.70.
71
72
73
Put the skewered poultry on the frame placed on the rack - g.71 and check that the skewer is
slotted into the frame so that it remains stable - g.72-73.
74
Slide all parts into the oven, making sure that the skewer is firmly placed in the
appropriate slot - g.74.
Then follow the previous instructions for the manual setting to start « turnspit »
cooking. - g.47 à 61.
IMPORTANT! For optimal cooking in turnspit mode, the thermostat must be set to 240°C
and the door must be closed.
IMPORTANT! When cooking certain dishes, steam may escape via the door: this is perfectly
normal.

11
Tableau de cuisson : mode manuel*
Program Mode Level Preheat T °C Time
Pie 4 0 233°C 37 min
Fruit cake 3 10 185°C 45 min
Quiche 4 0 233°C 37 min
Clafoutis 4 10 193°C 45 min
Sponge
cake
4 10 185°C 23 min
4 10 185°C 25 min
Roast pork
(1 kg) 5 0 193°C 1 h 20 min
* The cooking chart is for information purposes only and is not to be taken as a reference.
CHANGE DURING COOKING
75
Press once - g.75. Change your program (cooking
mode, temperature and/or cooking time), press once
to validate and start cooking again - g.76.
STOPPING COOKING
77
To stop cooking, press and hold - g.77 until the appliance switches to
standby mode.
EN
ZH
KO
ID
MS
TH
VI

12
DELAYED START
The delayed start function allows you to program the start of cooking from 5 minutes to 24 hours
later.
WARNING! Do not confuse the delayed start button and the clock button .
78
79
80
81
82
83
84
The cooking mode, time and temperature have already been set using manual mode or the
programmed menu mode (see appropriate chapters on programming). Press the « delayed start
» button - g.78. The « delayed start » pictogram and the clock will flash - g.79. Set the
cooking start time using the left rotating knob - g.80. Validate by pressing the « delayed start »
button again - g.81. The « delayed start » pictogram will then appear on the screen. This
means that the delayed start program has been entered correctly - g.82. Press once to start
cooking - g.83. When the timer has started, the two points separating the hours and minutes will
flash - g.84. This display allows you to be sure that the program has started.
PLEASE NOTE! When a delayed start has begun it is normal for the oven light not to come
on until cooking starts.
KEEP WARM
85
86
87
88
89
90

13
The delayed start function allows you to program the start of cooking from 5 minutes to 24 hours
82
The cooking mode, time and temperature have already been set using manual mode or the
programmed menu mode (see appropriate chapters on programming). Press the « delayed start
Set the
Validate by pressing the « delayed start »
pictogram will then appear on the screen. This
once to start
When the timer has started, the two points separating the hours and minutes will
89
The cooking parameters have been set. Press the « keep warm » button - g.85. The « keep warm »
pictogram and the clock will flash - g.86. Set the required time for keeping the oven warm
using the left rotating knob - g.87. Validate by pressing the « keep warm » button again - g.88
- g.89. Press once to start cooking - g.90. At the end of cooking, the oven will automatically
switch to « keep warm » mode.
N.B : The two delayed start and keep warm functions can be combined.
N.B: It is possible to set the keep warm function while cooking is in progress (see chapter
on changes during cooking).
PLEASE NOTE! Keep warm mode cannot be used with defrost mode.
LOCKING CONTROL PANEL
92
2-3
sec.
93
This safety feature prevents any change to the cooking settings by children under 8 years of age
who should not use this appliance unless continuous supervision by a responsible adult is given.
After starting cooking - g.91, press and hold the weight button - g.92. SECU will then appear on
the screen - g.93 and will disappear after a few seconds. The control panel is now locked.
To unlock the control panel, press and hold the weight button again. SECU will be displayed on
the screen and will disappear after a few seconds. The control panel is now unlocked.
PLEASE NOTE! When the control panel locking is activated, the button is still accessible
but the control panel remains locked. To access the other keys, unlock the control panel.
GENERAL REMARKS
PLEASE NOTE! If no action is carried out for 30 seconds the oven automatically goes into
standby mode.
EN
ZH
KO
ID
MS
TH
VI

14
TROUBLESHOOTING GUIDE
ERROR CODE CAUSES SOLUTIONS
ERR1 Faulty temperature probe Consult an After-Sales
Service Centre.
ERR2 Electrical problem Consult an After-Sales
Service Centre.
ERR3, ERR4 Temperature regulation
problem
Consult an After-Sales
Service Centre.
CLEANING AND CARE
Do not allow grease to build up on the appliance.
Before any maintenance, cleaning or storage unplug the appliance and allow it to cool down -
g.94-95. Do not use any harsh cleaning products (especially oven cleaning products and
metal or abrasive scouring pads) - g.96-97. To clean the outside of the appliance simply wipe
over with a sponge - g.98.
Clean the door, non-stick or lacquered surfaces and the glass components
with a damp sponge dipped in a gentle soap solution - g.99.
Do not use cleaning products intended for metal (for stainless steel, copper,
etc.).
Your oven has non-stick walls which can easily be cleaned with soapy water.
All accessories can be cleaned with soapy water.

15
WHAT NOT TO DO
NOTES
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
EN
ZH
KO
ID
MS
TH
VI
