Tek-Trol TEK-DP1650A User manual

Technology Solutions
T1650A
EK-DP
Instruction Manual
DProbar
Multiport Self-Averaging Flow Meter
Document Number: IM-1650A
www.tek-trol.com

© COPYRIGHT Tek-Trol LLC 2021
NOTICE
Read this manual before working with the product. For personal and system safety, and for optimum
product performance, make sure you thoroughly understand the contents before installing, using, or
maintaining this product.
For technical assistance, contact
Customer Support
796 Tek-Drive
Crystal Lake, IL 60014
USA
Tel: [phone]
www.tek-trol.com
No part of this publication may be copied or distributed, transmitted, transcribed, stored in a retrieval
system, or translated into any human or computer language, in any form or by any means, electronic,
mechanical, manual, or otherwise, or disclosed to third parties without the express written permission.
The information contained in this manual is subject to change without notice.

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
1
Table of Contents
1Safety Instructions.....................................................................................................................2
1.1 Intended Use ...................................................................................................................................2
1.2 Safety Instructions from the Manufacturer.......................................................................................2
1.2.1 Disclaimer............................................................................................................................................2
1.2.2 Product Liability and Warranty ...........................................................................................................2
1.2.3 Information Concerning the Documentation......................................................................................2
1.3 Safety Precautions ...........................................................................................................................2
1.4 Packaging, Transportation and Storage ............................................................................................3
1.4.1 Packaging.............................................................................................................................................3
1.4.2 Transportation.....................................................................................................................................3
1.4.3 Storage ................................................................................................................................................4
1.4.4 Nameplate...........................................................................................................................................4
2Product Description...................................................................................................................4
2.1 Introduction ....................................................................................................................................4
2.2 Measuring Principle .........................................................................................................................4
2.3 Dimensional Drawings .....................................................................................................................5
2.4 Specifications ..................................................................................................................................6
2.5 Model chart.....................................................................................................................................6
3Installation ................................................................................................................................8
3.1 Selection of Installation of Locations ................................................................................................9
3.1.1 NPE FBR-61 FLUlD BAR........................................................................................................................9
3.1.2 TYPE FBR-73 & FBR-75 FLUID BAR.................................................................................................... 10
3.1.3 TYPE FBR-76 FLUID BAR.................................................................................................................... 10
3.1.4 TYPE FBF-61 FLUID BAR.................................................................................................................... 11
3.1.5 TYPE FBF-75 & FBF-76 FLUID BAR .................................................................................................... 11
3.1.6 TYPE FBF-85 FLUID BAR.................................................................................................................... 11
3.1.7 TYPE FTL-73, FTL-75 & FTL-76 FLUID BAR......................................................................................... 12
3.2 Installation Procedure....................................................................................................................12
4Electrical Connection ...............................................................................................................13
4.1 Grounding of Measuring Device .....................................................................................................14
5Troubleshooting ......................................................................................................................14

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
2
1Safety Instructions
1.1 Intended Use
Tek-DP 1650A DProbar Multiport Self-Averaging Flow Meter measures the average pressure by
taking sample values at different points in the pipe.
1.2 Safety Instructions from the Manufacturer
1.2.1 Disclaimer
The manufacturer will not be held accountable for any damage that happens by using its product,
including but not limited to direct, indirect, or incidental and consequential damages. Any
product purchased from the manufacturer is warranted in accordance with the relevant product
documentation and our Terms and Conditions of Sale.
The manufacturer has the right to modify the content of this document, including the disclaimer,
at any time for any reason without prior notice, and will not be answerable in any way for the
possible consequence of such changes.
1.2.2 Product Liability and Warranty
The operator shall bear authority for the suitability of the device for the specific application. The
manufacturer accepts no liability for the consequences of misuse by the operator. Wrong
installation or operation of the devices (systems) will cause the warranty to be void. The
respective Terms and Conditions of Sale, which form the basis for the sales contract shall also
apply.
1.2.3 Information Concerning the Documentation
To prevent any injury to the operator or damage to the device it is essential to read the
information in this document and the applicable national standard safety instructions. This
operating manual contains all the information needed in various stages, such as product
identification, incoming acceptance and storage, mounting, connection, operation, and
commissioning, troubleshooting, maintenance, and disposal.
1.3 Safety Precautions
You must read these instructions carefully before installing and commissioning the device. These
instructions are an important part of the product and must be kept for future reference. Only by
observing these instructions, optimum protection of both personnel and the environment, as well
as safe and fault-free operation of the device can be ensured.
For additional information that is not discussed in this manual, contact the manufacturer.

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
3
Warnings and Symbols Used
The following safety symbol marks are used in this operation manual and on the instrument.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or severe injury
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury. It may also be used to alert against unsafe practices.
NOTE
Indicates that operating the hardware or software in this manner may damage it
or lead to system failure.
1.4 Packaging, Transportation and Storage
1.4.1 Packaging
The original package consists of
1. Tek-DP 1650A DProbar Multiport Self-Averaging Flow Meter
2. Documentation
NOTE
Unpack and Check the contents for damages or sign of rough handling. Report damage
to the manufacturer immediately. Check the contents against the packing list provided.
1.4.2 Transportation
•Avoid impact shocks to the device and prevent it from getting wet during transportation.
•Verify local safety regulations, directives, and company procedures with respect to hoisting,
rigging, and transportation of heavy equipment.
•Transport the product to the installation site using the original manufacturer’s packing
whenever possible.

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
4
1.4.3 Storage
If this product is to be stored for a long period of time before installation, take the following
precautions:
•Store your product in the manufacturer’s original packing used for shipping.
•Storage location should conform to the following requirements:
1. Free from rain and water
2. Free from vibration and impact shock
3. At room temperature with minimal temperature and humidity variation
•Before storing a used flowmeter remove any fluid from the flowmeter line completely.
Properties of the instrument can change when stored outdoors.
1.4.4 Nameplate
The nameplate lists the order number and other important information, such as design details
and technical data.
NOTE
Check the device nameplate to ensure that the device is delivered according to your
order. Check for the correct supply voltage printed on the nameplate.
2Product Description
This section covers the reference and specification data, as well as ordering information.
2.1 Introduction
The Tek-DP 1650A DProbar Multiport Self-Averaging Flow Meter functions as an obstruction that
changes the cross-section of the flow of the liquid in the pipe or conduit. In a differential pressure
flow meter, as the liquid passes through the obstruction, its potential energy is converted into
kinetic energy. The velocity of the liquid increases and is accompanied by a simultaneous decrease
in the pressure. When the liquid exits the obstruction, the velocity decreases, and the pressure
increases again. These pressure drops generated across the obstacle are proportional to the flow
rate square and calculated using Bernoulli's equation.
2.2 Measuring Principle
While the Tek-DP 1650A DProbar measures the pressure of a liquid at a single point, the more
modern averaging Tek-DP 1650A DProbar measures the average pressure by taking sample values
at different points in the pipe. It is inserted directly into the pipe and is perpendicular to the
direction of flow. The side of the tube facing the flow of the liquid consists of several impact
pressure ports while the opposite side of the tube may have a single or multiple static pressure
ports. These ports are connected together to a secondary device such as a differential pressure
transmitter.
When the liquid comes in contact with the tube, the kinetic energy of the liquid is converted into
potential energy and velocity is reduced to zero. The pressure now measured at the upstream
ports is called the total impact pressure, which is the sum of the static pressure and the dynamic

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
5
pressure of the liquid. The impact pressure is directly proportional to the flow rate of the liquid.
As the liquid flows around the Tek-DP 1650A DProbar, the static pressure ports measure the
decrease in pressure downstream of the flow. These pressure differentials are then averaged to
determine the flow rate of the liquid using the following formulas:
To calculate the volumetric flow rate:
QA= N * K * D2* Faa * (√DP/GF)(For liquids)
QA= N * K * D2* Faa *(√DP/ρF)(For gases)
To calculate the mass flow rate:
QMASS = N * K * D2* Ya* Faa * √(P*DP) /T (For gases and steam)
2.3 Dimensional Drawings
•Permanently Installed Type • Retractable Type
*Note: Dimensions are subject to vary at time of manufacturing based on final Beta selected.
Dimensional drawing with a final engineering sizing sheet will be provided within 1-2 weeks of order
acceptance.
Inserted
Retracted
Fig 1: Fixed Dimensions
Fig 2: Retracted Dimension

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
6
2.4 Specifications
Accuracy
± 1 % with 95 % confidence
Process Media
Liquid, Gas, and Steam
Line Sizes
2” to 72”
Sizes
3/25/60 mm
Operating Temperature
Standard at -20°F to 100°F, optional -40°F to 1200°F
Material
316L SS
304L SS
Valve Material
316 SS
Carbon Steel
DProbar Material
All standard materials available including Brass, steel,
stainless steel and Hastelloy
Bolt Material
ASTM A193 B7 / ASTM A194 2H
ASTM A193 B8M / ASTM A194 8MA
Process Connection
Flanged
Weld prepared ends
Threaded BSPT
Threaded NPT
Others on request
Mounting
Flanged ball and gate access valve
2.5 Model chart
Example
Tek-DP
1650A
F G100 S 01 A 02 A BO01#TEK-DP 1650A-F-G-100-S-01-
A-02-A-B-O-01
Series
Tek-DP
1650A
DProbar Multiport Self-Averaging
Flow Meter
Type
F
Fixed
Media
L
Liquid
G
Gas
S
Steam
Size
050
2”
065
2 ½”
080
3”
085
3 ½”
100
4”
125
5”
150
6”
175
7”
200
8”
250
10”
300
12”
350
14”
400
16”

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
7
450
18”
500
20”
600
24”
750
30”
Meter Body
S
316 SS
Pipe Schedule
01
STD (Standard Pipe SCH)
02
10S
03
10
04
20
05
30
06
40S
07
40
08
80S
09
80
10
120
11
160
12
XS
13
XXS
XX
Special
Transmitter
Connection
A Remote mount; NPT connection
Pressure Rating
01
Threaded Connection (300psi)
02
150# RF ANSI
XX
Special
Pipe Fitting
Material (Weld
and Thread)
A
316SS
X Special
Process
Connections
A
1-½” mNPT
B
1-½” 150# Flange
C
1-½” weldolet
Temperature
Measurement
O
No Temperature Sensor
T
Integral RTD
X
Remote thermowell and RTD
Flow
Transmitters /
Computers
01
None (Customer Supplied)
02
Tek-Bar 3110 (Liquids) - Smart
DP
03
Tek-Bar 3800 (MVT Steam &
Compressed Gases)
04
Tek-FC 8000 (Natural Gas - Flow
Computer)
05
TekValsys DPRO (Insitu Flow
Validation)
06
TekValsys DPRO WFGM (Wet
Gas)
XX
Special
MTR
Material Test Report EN3.1
Options
MC
Material Cert EN2.1
COC
Certificate of Conformity
O2C
O2 Cleaned
TAG
SS TAG PLATE
CDE
Certified Drawing Electronic (As
Built)
MRB
Manufacturing Record Book
DFT
Dry Film Thickness - Custom
Paint Spec

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
8
CPC
Custom Product Code
3Installation
This section covers instructions on installation and commissioning. Installation of the device must
be carried out by trained; qualified specialists authorized to perform such works.
•Recommended upstream and downstream distances
CAUTION
•When removing the instrument from hazardous processes, avoid direct contact with the
fluid and the meter
•All installation must comply with local installation requirements and local electrical code
WARNING
•This section offers instructions for installation, wiring, operation, and troubleshooting.
The user must read this manual carefully before installation and operation because
improper installation may cause incorrect measurement and even damage the
flowmeter.
NOTE
3D8D
8D 3D
24D 4D
3D
7D (in plane)
9D (out of plane)
3D
19D (in plane)
24D (out of plane)
3D
9D (in plane)
14D (out of plane)
Fig 3: Upstream and Downstream Installation

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
9
Improper installation has the potential to cause injury and to damage instrument.
Periodically inspect the power cables, transducer cables, cable glands and the enclosure for
signs of damage. Inspect transducer installation and mounting hardware for loose
connections.
3.1 Selection of Installation of Locations
•Correct location of the Fluid Bar-in the pipeline is important because disturbance in flow
produced by the pipe layout may affect the accuracy of measurement. The following
standard practices should be reviewed before selecting a mounting location.
•Straight Run Requirements
The minimum straight length requirement between various fittings located upstream of
Fluid Bar are given in Table 1. Use of recommended straight pipe lengths of uniform
diameter ensures that the flow measurement will be made with fully developed
characteristics.
Included gate, globe, & other throttling valves that are partially opened. If the valve is full
open, use valves shown for 4 & 5. Values shown are the recommended spacing in terms of
internal diameters for normal industrial metering requirements. For laboratory of high
accuracy work, add 25% to above values.
•Flow Conditioners
Flow conditioner may be used to reduce the length of straight pipe required in many cases.
Any flow conditioner used shall be installed in the upstream straight length between the
Fluid Bar & disturbance or fittings closest to the Fluid Bar. Unless it can be verified that the
flow conditions at the inlet of Fluid Bar shall confirm fully developed profile & are free from
swirl.
3.1.1 NPE FBR-61 FLUlD BAR
Fig 4: NPE FBR-61 Fluid Bar

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
10
3.1.2 TYPE FBR-73 & FBR-75 FLUID BAR
3.1.3 TYPE FBR-76 FLUID BAR
Fig 5: Type FBR-73 Fluid Bar
Fig 7: Type FBR-76 Fluid Bar
Fig 6: Type FBR-75 Fluid Bar

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
11
3.1.4 TYPE FBF-61 FLUID BAR
3.1.5 TYPE FBF-75 & FBF-76 FLUID BAR
3.1.6 TYPE FBF-85 FLUID BAR
Fig 8: Type FBF-61 Fluid Bar
Fig 9: Type FBF-75 Fluid Bar
Fig 10: Type FBF-76 Fluid Bar
Fig 11: Type FBF-85 Fluid Bar

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
12
3.1.7 TYPE FTL-73, FTL-75 & FTL-76 FLUID BAR
3.2 Installation Procedure
1. Verify that the line pressure & temperature are within the rated limits for respective models.
2. Grind off paint or other coatings from the pipe in the area where the Flow-Tap is to be
installed. (Except for steam applications, Flow-Tap may be installed at any angle around the
pipe.)
3. Drill or bum a 35.0 mm diameter hole in the pipe &for Type FTM-76 & FrH-76 drill or burn. a
35.0 rim diameter hole on the opposite side of the pipe for end support.
4. Tack weld the 40 NB weld coupling to the pipe. The coupling must be aligned perpendicular to
the pipe axis & square to its plane. For Type FTM-76 & FTH-76, tack weld the end support on
the opposite side of the weld coupling. Ensure the end support is aligned perpendicular to the
pipe axis & in line with the weld coupling.
5. Install the Flow-Tap unit-isolating valve on the process connection. Verify that the valve is in
the fully open position, & that the stem is in line with the pipe to ensure clearance for the
insert-retract rods.
6. Install the Flow-T ap cage nipple into the unit-isolating valve.
7. Inspect Flow-Tap assembly to ensure that the insert-retract mechanism is fully retracted.
8. Install the Flow-Tap assembly on the cage nipple. When tight, the flow arrow on the top of the
Flow-Tap head must point in the direction of flow.
9. Initiate sensor insertion by rotating the drive nuts clockwise as viewed from the top, using the
ratchet wrench supplied with the unit. The nuts must be tightened alternately, about two
turns at a time to prevent binding resulting from unequal loading. Continue this procedure
until the sensor contacts the opposite side of the pipe or end support.
Fully inserted
Fully retractable
Fig 12: Type FTL-73, FTL-75 & FTL-76 Fluid Bar

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
13
10. Connect instrument lines to the instrument valves 8 to the appropriate meter, recorder,
transmitter w controller.
11. Retract the sensor by rotating the drive nuts counter-clockwise as viewed from the top. The
nuts must be turned alternately, about two turns at a time, to prevent binding resulting from
unequal loading. Continue this procedure until the sensor is fully retracted.
NOTE
If flow rate higher than 66 lb.ft/sec (90Nm/s) or pipe size larger than 8”(DN400), will require
19mm diameter probe, mounted in 1” ball valve and 1” socket and 22mm hole
4Electrical Connection
This section covers the all electrical connection requirement. Electrical connection of the device
must be carried out by trained, qualified specialists authorized to perform such work by the
installation site.
WARNING
•Connect all electrical cables when the power is switched off. If the device does not
have switch-off elements, then, overcurrent protection devices, lightning protection
and/or energy isolating devices must be provided by the customer.
•The device must be grounded to a spot in accordance with regulations in order to
protect personnel against electric shocks.
NOTE
•When using the measuring device in hazardous areas, installation must comply with
the corresponding national standards and regulations and the Safety Instructions or
Installation or Control Drawings.

Instruction Manual
Tek-DP 1650A
www.tek-trol.com
Technology Solutions
14
4.1 Grounding of Measuring Device
5Troubleshooting
Fluid Bar operates on natural scientific principles. No moving parts are used in the design, & wear
has negligible effect on accuracy. If installed correctly, Fluid Bar will provide a correct flow indication
if there is a flow in the pipe. To solve a discrepancy, interpretation of the Fluid Bar signal & other
components of the flow system should be examined closely.
Fluid Bar installation - Ensure that the Fluid Bar flow arrow is pointing directly downstream. The
Fluid bar accuracy will be influenced by installation misalignment. To ensure meeting stated
accuracy, alignment must be within limits shown below.
Pipe size - The Fluid Bar may have been designed for a
different pipe size than that in which it is being used.
Measure pipes the ID & compare with the size printed
on identification tag attached to the Fluid Bar.
Insufficient straight run - If the Fluid Bar is installed in
less than recommended straight uniform pipe length,
accuracy may be affected. Refer straight run
requirements
Calculation - The calculation for a particular Fluid Bar
may be in error. Recheck the calculation or graph used
for conversion. Changes in operating temperature or
pressure are critical for air, gas, or steam applications.
Recheck actual operating temperature & pressure
compared to values used in the calculation.
POWER
SUPPLY
3°
5°
3°
Fig 13: Grounding of Measuring Device
Fig 14: Fluid Bar installation

TEKMATION LLC reserves the right to change the designs and/or materials of its products without notice. The contents of this publication are the property of
TEKMATION and cannot be reproduced by any other party without written permission. All rights reserved. Copyright © 2021 TEKMATION LLC TEKMATION LLC DOC#TEK/PO/MNL/211103/1650A/r00.1
www.tek-trol.com
Flow | Level | Temperature | Pressure | Valves | Analyzers | Accessories | TekValSys
Tek-Trol is a fully owned subsidiary of TEKMATION LLC. We oer our customers a comprehensive range of
products and solutions for process, power and oil & gas industries. Tek-Trol provides process measurement
and control products for Flow, Level, Temperature & Pressure Measurement, Control Valves & Analyzer
systems. We are present in 15 locations globally and are known for our knowledge, innovative solutions,
reliable products and global presence.
796 Tek Drive Crystal Lake, IL 60014, USA
Sales: [phone]
Tek-Trol LLC
PO Box 121 Windsor,
Colorado 80550, USA
Sales: [phone]
Tek-DPro Flow Solutions
Florijnstraat 18, 4879 AH
Etten-Leur, Netherlands
Sales: [phone]
Tek-Trol Solutions BV
SAIF Zone, Y1-067, PO BOX No. 1125,
Sharjah, UAE
Sales: [phone]
Tek-Trol Middle East FZE
Support: [phone] Email: [e-mail] www.tek-trol.com
