Teka Intra ED2-0DF User manual

SATIN
Art. no.
GTIN
ED2-0DF
7393069023602
Overall dimension in mm 331 x 350 x 150
Depth in mm 106
Material AISI 304
Material thickness in mm 0,8
Installation height in mm 900/ 700/ 500
Gross weight in kg 1.80
Made in Norway
Description
Drinkin fountain in stainless steel 18/10 for wall
mountin . Supplied with supportin bracket, rated
waste, wall panel and water bubbler.
Installation
Fix the waste and bubler and connect to water.
Connect the water trap to the outlet in the wall with a
32mm push fit tube (Not supplied). Fix the product
and wall panel to the wall.
Drink. fountain ED2-0DF
FDV Revision 20200512www.intra-teka.com

Installation ED2-0DF
ASSEMBLY:
Included in the box + part number:
* Drinking outain
* Bubbler tap: 79090
* Valve grated waste 1 1/4 "and 1 1/2": 79136
* Sealing o cellprene Ø70: 91099
* Support bracket: 91017
* Mounting kit: YMX01
Addition: Connection o drinking tip, water trap and
drain pipe (not included)
Make sure all parts are in place be ore assembly work
is started.
Existing pipes must be lushed and cleaned well
be ore connecting the drinking ins so that no dirt
gets in the drink tip. Dirt ilter collecting dirt is
recommended mounted in transition between ixed
pipes and lexible hose or water intake.
The shut-o valve must not be used to adjust the
amount o water, as this may cause leakage rom the
drinking tip.
A pressure relie valve should adjust the water
pressure to the recommended operating pressure.
Fit the support bracket and valve on the ball. Fit
drinking tip, connect water supply and water trap.
Attach the sink to the wall through the mounting
holes in the support bracket and the olding edge o
the sink. Screws included.
Mounting height 900mm or adults, 700 - 800mm or
children and 500mm or small children.
ADJUSTMENT OF WATER JET:
The amount o water through the drink tip and the
water jet has been adjusted using the screw on the
underside o the drinking route. This is done easiest
by pressing the trigger while adjusting the screw.
The screw is very small, so it has to be screwed very
care ully so that the screw is not screwed out
completely.
- Screw the screw clockwise and the amount o water
is thrown.
- Turn the screw counterclockwise and increase the
amount o water.
2
FDV Revision 20200512www.intra-teka.com

Maintenance ED2-0DF
SPARE PARTS:
(See ASSEMBLY)
TECHNICAL INFORMATION:
Drinking nozzle:
Ma . working pressure: 5.5 bar
Min. working pressure: 0.5 bar
Recommended working pressure: 3.5 bar
Connection to water:
The amount of water must not be restricted with a
shut-off valve,as this may cause leaks from the
drinking nozzle.
SERVICING IN THE EVENT OF LEAKS:
Leaks by the spout of the drinking nozzle: may be
caused by a damaged O-ring or dirt under O-ring JR2:
Clean piston P312U included in KBP311N.
Apply some grease around the piston before
assembly. If the O ringJR2 is damaged, the entire
drink nozzle should be replaced.
Leakage under the pressure button: most
likelycaused by a damaged or dirty O-ring, JR1:
Clean the piston P312U included in KBP311N.
Apply some grease around the piston before
assembly. If the O ringJR1 is damaged, the entire
drink nozzle should be replaced.
MAINTENANCE:
In order for the product to retain its original quality
and appearance, regular cleaning is recommended.
Use mild soap or products specifically designed for
stainless steel and clean water. Then wipe the surface
with a dry cloth.
Never use detergents containing chlorine, iodine,
fluoride or abrasives. Also avoid contact with acidic
solutions and other substances incompatible with
stainless steel. Remember that foodstuffs and skin
care products may contain such substances; e.g.
ketchup, juice, salt, some cleansers, nail polish, etc.
Promptly remove spills of such products.
* Do not allow water or other liquid to dry in. This is
to avoid staining the surface.
* Even though stainless steel can withstand harsh
treatment, it will easily be scratched by sharp objects.
For products with polished (brushed) finishes, this
will be very visible when the product is new, but after
3
