Teka Intra GUB3 User manual

SATIN
Art. no.
GTIN
GUB3
7393069023114
Overall dimension in mm 455 x 340 x 412
Depth in mm 217
Bowl dim. in mm 400 x 290 x 217
Material AISI 304
Material thickness in mm 0,9
Installation height in mm 600
Product load in N 1000
Gross weight in kg 4.50
eight, pallet 135.40
Pcs per pallet 24
Description
Bucket sink in stainless steel fo wall mounting.
Supplied with wall panel, Ø100mm g ated waste and
a bucket g id. Waste and wall b acket in mounted onto
the sink f om the supplie .
Installation
Waste and wall b acket a e p e-mounted on the sink
by the supplie . Fasten the mounting desc iption to
the wall and d ill holes and fasten the sink
acco dingly. Secu e the wall panel to sink and wall.
445
172,50 172,50
5,35
170
266 ±5
148
375
217 ±5
123
400
455 ±2
290
340±2
Bucket sink GUB3
FDV Revision 20200210www.intra-teka.com

Installation GUB3
INSTALLATION:
Included in the box:
• Bucket sink
• Wall panel
• Installation equipment fo GUB 3
• Bucket g id
• Assembly inst uctions
The sink comes with a p e-mounted valve and
suppo t b acket, eady to be installed on the wall.
Attach the mounting inst uctions to the wall at the
co ect height and d ill holes acco ding to this. Attach
the two lowe sc ews to the wall and place the sink in
the suppo t b acket. Then tighten the sc ews in the
suppo t b acket befo e attaching the othe sc ews.
Plugs and sc ews a e included.
2
FDV Revision 20200210www.intra-teka.com

Maintenance GUB3
SPARE PARTS:
Wall panel: ZVBGUB
Bucket grid: GUBRIST
Valve 1 1/ " (lower part): 79006
Sealing (lower part): 79030
Sealing celleprene: 91099
Support bracket: 91019
Bracket plate: ZGUB3BRPL
Strainer: 79110
Assembly instructions: YMONTGUB3
