PRO-TEK
G3 CHUCK
QUICK START
INSTRUCTION MANUAL
Thank you for purchasing our PRO-TEK G3 Chuck – a new premium addition to our Nova
woodturning chuck range with advanced features to enhance your chuck performance.
It provides a versatile and easy method for fast and secure work holding for all face
turning – bowls, egg cups, vases, boxes, goblets and anendless variety of similar projects.
OPENING AND CLOSING OF JAWS
MOUNTING THE PRO-TEK G3 CHUCK
ON THE LATHE
There are two configurations available for the PRO-TEK G3 chuck:
•Insert model -Requires an insert for chuck to be mounted on the lathe. See full manual
online for a list of lathe spindle thread inserts available.
•Direct Thread models: 1” 8TPI & M33 Eurolock
1. If the chuck is an insert model,
ensure the insert is bottomed out
in the chuck body before mounting
on the lathe.
2. For Both Insert & Direct Thread
model: Wind the chuck on the
lathe spindle until the chuck comes
firmly in contact with the
bearing/spindle shoulder with no
gaps between.
3.
Place red thread protector washer
into the M6 Threaded hole. Then
wind the M6 grub screw in position
and tighten
with M3 Allen head
wrench (provided) to
prevent the
chuck from loosening
on lathe
spindle.
Using the Nova M33 Eurolock Chuck with Locking Ring (Only applicable to EU model)
Step 1:
Tighten the EU chuck to the spindle on the
lathe, make sure the rings on the spindle and
chuck have been clamped.
Note: EU Lock Ring
is provided with
the lathe
Step 2
:
Put the lower part of locking ring under the
clamped rings.
Step 3
:
Put upper part of the locking ring to the
clamped rings as well.
Step 4
:
Using the Allen key to tighten up two bolts on
the locking ring.
YOUR SAFETY
Keep these instructions ina safe place for future reference.
WARNING: This chuck iscapable ofcontributing toserious injury (as with any other power
tool accessory) ifthis manual guidance isnot followed or ifit isused improperly on the
lathe. Read and understand also the lathe owner's manual. Ifyou do nothave a manual,
contact the supplier ofyour lathe toobtain one before using the lathe and chuck. User
must be professionally trained to usethis chuck. Vocational school courses orother expert
tuition is recommended.
As with other work holding methods, an extremely cautious and sensible approach is
necessary. With the PRO-TEK G3 Chuck it is not possible to give exact directions as to the
amount of tightening pressure required for adequate work holding or approved chisel
cutting techniques. Follow closely strict guidelines in this manual for different jaw types
on wood blank diameters and length, plus strictly follow recommended lathe speeds.
Safe Operation:
Eye Protection: Woodturning operations can result in objects being thrown into your eyes
which can result insevere eye damage. Protective eye wear must be used atall times.
Everyday vision wear is not protective eye wear. We recommend a full-face shield. Always
wear eye protection which complies with current ANSI Standard Z87 (USA)
Noise Protection: Use ear plugs oreardefenders. Particularly if the noise exceeds 85dB.
Exposure tohigh levels ofnoise can lead to hearing problems.
Dust Protection: Use respiratory protective equipment (dust mask, portable respirator
device). Exposure to high levels of irritating dust when turning or sanding hardwoods, soft
woods and manufactured composite boards (MDF) can result in serious health problems.
In addition, adequate workshop dust extraction must be used.
Chuck is properly secured on lathe spindle: Follow mounting instructions for your lathe
for faceplates and other spindle fixtures. Do not rotate chuck under power unless
workpiece is firmly clamped.
WARNING: LATHE SPEED: Excessive speed is a serious lathe hazard. Always turn at the
slowest speed possible. Ideal speed will vary with wood blank size. The larger the blank
the slower the speed. Consult your lathe manual or lathe information plate for speed
guidelines. Do not attempt to use the chuck unless the recommended lathe speeds to size
of wood blank are known. In addition, you must strictly follow the maximum speed limits
set out in the operating section of this manual. Do not exceed them under any
circumstances.
CHECK WORKPIECE: Examine wood blank carefully before mounting on chuck/lathe.
Only mount wood that hasno cracks, splits, holes orany other weaknesses (e.g. rotten or
spongy sections). Do not use poorly jointed or laminated wood. Irregular or outof balance
stock needs tobe turned at the slowest possible speed until itisin balance.
Make sure wood is clamped firmly. Follow mounting instructions for different gripping
modes and jaw types. In the expansion mode do notuseundue force orjaws may split the
wood.
Do notexceed maximum guidelines in this manual for wood blank diameters/length set
out in this manual for different modes and jaw types.
Check wood is securely held in chuck, before operation. Check grip by vigorously
wrenching wood blank back and forth. Ifany loosening occurs, re-examine holding area
for adequate grip (Following mounting guidelines) and any damage toholding area. Rotate
manually to make sure ofclearance before switching power on.
DUPLICATOR OR JIGS:Donotusechuck for work holding with aduplicator orjigs.
Safe Practice:
CHISEL USE: Use only hand held woodturning chisels toshape wood being held in chuck.
Use the recommended chisel for the job. Use safe and commonly approved techniques.
WARNING: Never attempt to place hands on a moving chuck on a lathe. Wait for the chuck
to come to a complete stop before hands are anywhere near the chuck. Trying to grab at
a moving chuck could result in SERIOUS INJURY. Jaw Slides: For safe operation do not
extend the jaw slides beyond the chuck body under any circumstances.
Wherever possible stand to one side ofthe revolving wood.
WEAR SUITABLE CLOTHING: Do notwear any loose clothing, neck ties, gloves, bracelets,
rings or other jewellery that could get caught in moving parts. Wear protective hair
covering tocontain long hair.
DRUGS, ALCOHOL, MEDICATION: Do notoperate chuck orlathe while underthe influence
of drugs, alcohol orany medication.
KEEP CHILDREN AND VISITORS AWAY: All children and visitors should be kept safe
distance from the work area.
ATTACHING AND REMOVING JAWS
The standard PRO-TEK G3 chuck comes included with a set ofPRO-TEK 50mm (#6075)
add-on jaws.
The jaws must be properly attached on the chuck tofunction as intended.
Before installation, ensure the jaw slide top surfaces are clear ofany dustordebris
before attaching the jaws on the chuck.
Follow thesteps shown below to attach thejaws onthechuck:
Loosely attach the jaw segments on the jaw
slide
with the Nova Star head
screws
included and firmly close the jaws to make
sure no light is visible
between the
jaw
segm
ents.
Note:
Ensure the number indented on the
jaw edge matches the jaw slide number
Firmly tighten the Nova Star head screws
with
the Nova Star head T-
bar handle
included.
Loosen and remove the
Nova Star
head
screws when removing the jaws from the
chuck.
No light visible between jaws
Open
Close
Place red thread protector washer into
M6 threaded hole.
Then wind the M6
grub screw in place and tighten
Make sure there
is no gap
all around this
contact line
Insert
bottomed out
(If insert
version)

SCREW CHUCK - WOODWORM SCREW
The woodworm screw (screw chuck) provides a convenient method for holding a bowl blank
tocut a recess tomount on the PRO-TEK G3 50mm (2in) jaws.
Jaws must be mounted on the chuck before the wood worm screw – See diagram
Open the jaw slide and insert the wood
worm screw in the centre hole of the
chuck.
Position the woodworm screw as shown
in illustration
.
Note:
All 4 flat sides of the wood worm
screw should be in contact with the flat
end of the jaw slides.
The wood worm screw is used to secure the wood to
cut either a recess or spigot on the open
‘face’ end.
Pre
-
drill a hole of size 8mm (5/16in) diameter with
19mm (3/4in) depth to mount the blank using the
woodworm screw.
The wood must be seated firmly and
flat against the top surface of the mounted jaws.
For
first stage rounding of bowl blanks; extra support can
be used with live centre support from the lathe
tails
tock. See full manual online for more details.
DO NOT USE WOOD BLANKS LARGER THAN 250mm
DIAMETER X 100mm DEPTH (10inx4in)
DO NOT EXCEED 600RPM
TURNING ON A SPIGOT OR DOVETAIL
Spigot is where the jaw contracts onto the workpiece to grip.
This is mainly for box, goblet and vase turning (End grain items
with a fair degree of overhang).
EXTREME CAUTION WITH THIS OPERATION MUST BE
EXERCISED. DO NOT EXCEED 850 RPM FOR THIS OPERATION.
Spigot Diameter (For 50mm Jaws)
Min Diameter
Max Diameter
Cylinder
45mm (1 3/4in)
65mm (2 9/16in)
Square
40mm (1 9/16in)
50mm (2in)
Dovetail is where the jaw expands into a recess of a workpiece
to grip. This operation is mainly for bowl and platter (Items with
parallel wood grain).
MUST NOT BE USED FOR ANY LONG WORK (OVER 100mm or
4 inches)
. DO NOT EXCEED 600RPM WITH THIS
OPERATION.
OUT OF BALANCE STOCK MUST BE TURNED AT THE SLOWEST
SPEED POSSIBLE.
Recess Dovetail Diameter (For 50mm Jaws)
Min
Max
50mm (2in)
70mm (2 3/4in)
FORMING A SPIGOT OR RECESS
Recess
Spigot
Using a Nova Dovetail Chisel #6008 (or any
other suitable tool), cut into the wood
, rest the
flat side of the chisel on the bottom surface of
the recess to form a profile of between
75~80deg with 10mm (25/64in) depth.
Using a suitable chisel, turn the outer
diameter of the wood to form the spigot. The
length of the spigot should match
the internal
height of the jaws.
CONTACT
● Teknatool International Ltd Phone: [phone] ● Teknatool USA Phone: [phone] CUSTOMER SOLUTIONS For all worldwide Inquiries, Repairs or Services (issues must be in writing) Email: [e-mail]
Or you can contact the retailer where you purchased your NOVA Chuck, for the contact details please see our website www.teknatool.com
NEW AND IMPROVED FEATURES
•Rust resistant nickel-plated body for longer protection and less
maintenance.
•Stronger and more versatile PRO-TEK 50mm (2in) Jaws. Dovetail and
serrated internal profile for maximum holding power.
•Right hand, standard clockwise scroll tightening for ease ofuse. •Easier to read, laser etched numbering on edge ofPRO-TEK 50mm
(2in) jaws.
•Fastener upgrade to Nova Star head jaw screws. No-slip star head
for positive T-
bar handle location and better tightening power. Star
profile to minimize strip out of screw heads
•Nova Star head T-
bar Handle for easy grip and quicker tightening of
screws
•Sliding T-bar Chuck scroll key to enable easier jaw operation. Designed and manufactured by
Teknatool International, USA and PRC © 2020 Teknatool
nova
TM
PRO-TEK
G3 CHUCK
REF#
QTY.
PART#
DESCRIPTION
1
1
48206, 48239, 1359011
PRO-TEK G3 Body
2
1
1359010
Pinion T-Handle
3
1
23109
Scroll ring right hand
4
1
23051, 23051E
Jawslide #1
5
1
23052
Jawslide #2
6
1
23053
Jawslide #3
7
1
23054
Jawslide #4
8
1
EC48, EC50
Circlip
9
1
NS1000
Fibre (Washer) WAD
10
1
G0606
Grub Screw
11 8 CM5010182
NOVA Star head screws -
C/Sunk
12
1
10006
Woodworm screws
13
1
13049
Star head screw T-handle
14
1
AK3
Allen Key 3mm
15
1
6075
PRO-TEK 50mm (2in) Jaws
ACCURACY
The PRO-TEK Chucks are sample tested from each batch
and are made to run within the following tolerance limits
on the PRO-TEK 50mm (2in) jaws:
-
Maximum Face/Axial Runout: 0.08mm (0.0031 in)
-
Maximum Radial Runout: 0.15mm (0.0060 in)
However, wood is aflexible material with varying densities
and liable towarp while turning.
Under these circumstances pursuing accuracies asabove,
measured on the wood project clamped in the chuck, can be
very difficult toachieve. For most wood turning projects
there is usually little requirement to achieve such tolerances.
See trouble shooting guide for detailed guide on accuracy
in full PRO-TEK manual online at www.teknatool.com
WARRANTY
Your Nova PRO-TEK Chuck iscovered by a 6-year Limited Warranty. Gotowww.teknatool.com for a full warranty statement in full version manual PRO-TEK
G3 Chuck. The full online manual also covers trouble shooting, maintenance, list ofNova lathe spindle thread inserts, jaw and chuck accessories.
Optional Accessory Jaws
Chuck is compatible with all nova jaws
including
the jaws shown above
.
Note:
Excluding jaws that are specific for Nova
Titan chucks
Make sure this flat face is
coming in contact with the
tip of the jaw slide
Side to cut
recess or
spigot
Chuck Gripping
Direction
(Spigot)
Chuck Gripping
Direction
(Dovetail)
Download the NOVA App!
