HK480
Instruction Manual
507
Hydraulic Installation Tool
Table of Contents
Declaration of Conformity 2
Safety Instructions 4-5
Description 6
Specications 6
Principle of Operation 7
Preparation for Use 8
Operating Instructions 9
Maintenance 10
Disassembly and Assembly Instructions 11-12
Components Drawing 13
Troubleshooting 14
Kits and Accessories 15
Makers of Huck®, Marson®, Recoil®
Brand Fasteners, Tools & Accessories
applifast.com
Toll Free 1 800 563 1293
2
507 Hydraulic Installation Tool (HK480)
applifast.com
Toll Free 1 800 563 1293
3
507 Hydraulic Installation Tool (HK480)
DANGER - IMPORTANT
DO NOT EXCEED HOSE
MINIMUM BEND RADIUS
Failure to heed the warnings below could lead to a damaged hose, damaged tool, damaged
property, personal injury, or death.
•
This high pressure hose is not to be used other than assembled in a genuine HUCK tool or hose
assembly or used as a replacement for the hose of a genuine HUCK tool or hose assembly.
• Improper use of this product can cause property damage, personal injury, and death,
including but not limited to electrocution, uid injection or loss of limb caused by high
pressure leak, dangerously whipping hose or contact with suddenly moving or falling objects.
• Do not exceed rated working pressure (700 bar/10150 psi) or minimum bend radius (see chart
below). Do not use in temperatures less than -40°C (-40°F) or greater than +100°C (+212°F).
+70°C (+158°F).
• Do not use if the hose is kinked, abraded, cut, bulged, or leaking. Do not attempt to repair the
hose.
• Do not carry tool by hoses.
• Refer to a HUCK hydraulic tool manual for hose inspection and maintenance intervals.
• Store hose assemblies in a clean dry area.
Hose Type Minimum Bend Radius
126107 Series 2.76 Inches 70 mm
118944 and
124881 Series 2.17 Inches 55 mm
HA and HPH
Series 1.97 Inches 50 mm
applifast.com
Toll Free 1 800 563 1293
4
507 Hydraulic Installation Tool (HK480)
I. GENERAL SAFETY RULES:
1. A half hour long hands-on training session with
equipment.
2. Huck equipment must be maintained in a safe working
condition at all times. Tools and hoses should be
inspected at the beginning of each shift/day for
damage or wear. Any repair should be done by a
3. For multiple hazards, read and understand the safety
instructions before installing, operating, repairing,
maintaining, changing accessories on, or working near
the assembly power tool. Failure to do so can result in
serious bodily injury.
adjust or use the assembly power tool.
5. Do not modify this assembly power tool. This can
operator risk.
6. Do not discard safety instructions; give them to the
operator.
7. Do not use assembly power tool if it has been
damaged.
8. Tools shall be inspected periodically to verify all ratings
and markings required, and listed in the manual, are
legibly marked on the tool. The employer/operator
shall contact the manufacturer to obtain replacement
marking labels when necessary. Refer to assembly
drawing and parts list for replacement.
9. Tool is only to be used as stated in this manual. Any
other use is prohibited.
manufacturer or your Huck representative.
11.Only genuine Huck parts shall be used for replacements
or spares. Use of any other parts can result in tooling
damage or personal injury.
13.Never install a fastener in free air. Personal injury from
fastener ejecting may occur.
14.Where applicable, always clear spent pintail out of nose
assembly before installing the next fastener.
15.Check clearance between trigger and work piece to
ensure there is no pinch point when tool is activated.
Remote triggers are available for hydraulic tooling if
pinch point is unavoidable.
16.Do not abuse tool by dropping or using it as a hammer.
Never use hydraulic or air lines as a handle or to bend
or pry the tool. Reasonable care of installation tools
by operators is an important factor in maintaining tool
accident which may cause severe personal injury.
17.Never place hands between nose assembly and work
piece. Keep hands clear from front of tool.
18.Tools with ejector rods should never be cycled with out
nose assembly installed.
19.When two piece lock bolts are being used always make
sure the collar orientation is correct. See fastener data
sheet for correct positioning.
II. PROJECTILE HAZARDS:
1. Risk of whipping compressed air hose if tool is
pneudraulic or pneumatic.
2. Disconnect the assembly power tool from energy
source when changing inserted tools or accessories.
3. Be aware that failure of the workpiece, accessories,
or the inserted tool itself can generate high velocity
projectiles.
4. Always wear impact resistant eye protection during tool
operation. The grade of protection required should be
assessed for each use.
5. The risk of others should also be assessed at this time.
7. Check that the means of protection from ejection of
fastener or pintail is in place and operative.
8. There is possibility of forcible ejection of pintails or
spent mandrels from front of tool.
III. OPERATING HAZARDS:
1. Use of tool can expose the operator’s hands to hazards
including: crushing, impacts, cuts, abrasions and heat.
Wear suitable gloves to protect hands.
2. Operators and maintenance personnel shall be
physically able to handle the bulk, weight and power of
the tool.
3. Hold the tool correctly and be ready to counteract
normal or sudden movements with both hands
available.
4. Maintain a balanced body position and secure footing.
5. Release trigger or stop start device in case of
interruption of energy supply.
manufacturer.
7. Avoid unsuitable postures, as it is likely for these not
to allow counteracting of normal or unexpected tool
movement.
9. Beware of the risk of crushing or pinching if nose
Continued on next page...
Safety Instructions
GLOSSARY OF TERMS AND SYMBOLS:
-Product complies with requirements set forth by
the relevant UK and European directives.
-Read manual prior to using this equipment.
-Eye protection is required while using this
equipment.
-Hearing protection is required while using this
equipment.
Notes: are reminders of required procedures.
Bold, Italic type, and underline:
instruction.
WARNINGS: Must be understood to avoid
severe personal injury.
CAUTIONS: Show conditions that will damage
equipment or structure.
applifast.com
Toll Free 1 800 563 1293
5
507 Hydraulic Installation Tool (HK480)
IV. REPETITIVE MOTION HAZARDS:
1. When using assembly power tool, the operator can
experience discomfort in the hands, arms, shoulders,
neck or other parts of the body.
2. When using tool, the operator should adopt a
comfortable posture while maintaining a secure footing
3. The operator should change posture during extended
tasks to help avoid discomfort and fatigue.
4. If the operator experiences symptoms such as
persistent or recurring discomfort, pain, throbbing,
aching, tingling, numbness, burning sensations or
operator should tell the employer and consult a
V. ACCESSORIES HAZARDS:
1. Disconnect tool from energy supply before changing
inserted tool or accessory.
2. Use only sizes and types of accessories and
consumables that are recommended. Do not use other
types or sizes of accessories or consumables.
VI. WORKPLACE HAZARDS:
1. Be aware of slippery surfaces caused by use of the tool
and of trip hazards caused by the air line or hydraulic
hose.
2. Proceed with caution while in unfamiliar surroundings;
there could be hidden hazards such as electricity or
other utility lines.
3. The assembly power tool is not intended for use in
potentially explosive environments.
4. Tool is not insulated against contact with electrical
power.
5. Ensure there are no electrical cables, gas pipes, etc.,
which can cause a hazard if damaged by use of the
tool.
VII. NOISE HAZARDS:
1. Exposure to high noise levels can cause permanent,
disabling hearing loss and other problems such
as tinnitus, therefore risk assessment and the
implementation of proper controls is essential.
2. Appropriate controls to reduce the risk may include
actions such as damping materials to prevent workpiece
from ‘ringing’.
3. Use hearing protection in accordance with employer’s
instructions and as required by occupational health and
safety regulations.
4. Operate and maintain tool as recommended in the
instruction handbook to prevent an unnecessary
increase in the noise level.
5. Select, maintain and replace the consumable / inserted
tool as recommended to prevent an unnecessary
increase in noise.
6. If the power tool has a silencer, always ensure that it
is in place and in good working order when the tool is
being operated.
VIII. VIBRATION HAZARDS:
1. Exposure to vibration can cause disabling damage to
the nerves and blood supply to the hands and arms.
2. Wear warm clothing when working in cold conditions
and keep hands warm and dry.
3. If numbness, tingling, pain or whitening of the skin
employer and consult a physician.
4. Support the weight of the tool in a stand, tensioner or
balancer in order to have a lighter grip on the tool.
X. HYDRAULIC TOOL SAFETY INSTRUCTIONS:
1. Carry out a daily check for damaged or worn hoses or
hydraulic connections and replace if necessary.
2. Wipe all couplers clean before connecting. Failure to do
so can result in damage to the quick couplers and cause
overheating.
3. Ensure that couplings are clean and correctly engaged
before operation.
purposes and should therefore be positioned in a well
ventilated area free from hazardous fumes.
6. Do not inspect or clean the tool while the hydraulic
power source is connected. Accidental engagement of
the tool can cause serious injury.
7. Be sure all hose connections are tight.
8. Wipe all couplers clean before connecting. Failure to do
so can result in damage to the quick couplers and cause
overheating.
Safety Instructions (continued)
WARNINGS:
Do not exceed maximum pull or return settings
on tool.
Be sure all hose connections are tight. All tool
hoses must be connected.
applifast.com
Toll Free 1 800 563 1293
6
507 Hydraulic Installation Tool (HK480)
Description
MAX OPERATING TEMP: 125° F (51.7° C)
MAX FLOW RATE: 2 gpm (7.5 l/m)
PULL CAPACITY: 75,500 lbs @ 5,700 psi
(337 kN @ 393 bar)
MAX PULL PRESSURE: 5,700 psi (393 bar)
MAX RETURN PRESSURE: 2,400 psi (165 bar)
STROKE: 2.5 inches (6.3 cm)
WEIGHT: 43 lbs (19.5 kg)
POWER SOURCE: Huck POWERIG®Hydraulic Unit
HOSE KITS: Use only genuine HUCK Hose Kits rated @
10,000 psi (689.5 bar) working pressure.
HYDRAULIC FLUID: ®
III, DEXRON VI, MERCON®, Allison C-4 or equivalent
as Quintolubric®
shall NOT be used as serious damage to equipment will
occur.
Where the following trade names are used in this manual, please
note:
DEXRON is a registered trademark of General Motors Corporation.
Loctite is a registered trademark of Henkel Corporation, U.S.A.
LUBRIPLATE is a registered trademark of Fiske Brothers Rening Co.
MERCON is a registered trademark of Ford Motor Corp.
Never-Seez is a registered trademark of Bostik, Inc.
Quintolubric is a registered trademark of Quaker Chemical Corp.
Slic-tite is a registered trademark of LA-CO Industries, Inc.
Spirolox is a registered trademark of Smalley Steel Ring Company
Teon is a registered trademark of E. I. du Pont de Nemours and
Company.
Threadmate is a registered trademark of Parker Intangibles LLC.
TRUARC is a trademark of TRUARC Co. LLC.
Vibra-Tite is a registered trademark of ND Industries, Inc. USA.
Specifications
(cm)
The Huck 507 inline Hydraulic Installation Tool installs
C50L HUCKBOLT®Fasteners and HLC50L HUCKLOK®
Fasteners. When equipped with the proper (optional)
nose assembly, it can install:
-32 (1” diameter) and
-36 (1-1/8” diameter) fasteners.
Each tool has a cylinder and piston assembly. A relief
valve, designed to relieve the hydraulic pressure at both
ends of the stroke, is situated near the piston. The pintail
ejector ejects broken pintails from the nose assembly.
The end of the piston rod is threaded, and a nose
adapter and retaining rings are included for attaching
nose assemblies.
The operating pressures for the 507 tool are:
•PULL: 5400–5700 psi (372–393 bar) and
•RETURN: 2200–2400 psi (152–165 bar)
as supplied by a Huck POWERIG®Hydraulic Unit, models
940 and 918—or an equivalent hydraulic unit.
The correct PULL and RETURN pressures are important
for the proper function of the tool and Nose Assemblies,
as well as for the safety of the operator. Huck has
available a gauge (P/N T-124833CE) for checking
hydraulic pressures; instructions for its use are included
with the gauge and the Powerig.
UPDATING OLDER TOOLS
Changes were made to the 507 tool, starting with serial
number 0847. Replacement parts are still available for
the earlier models. If your tool’s serial number is lower
than 0847, Huck recommends that the tool be updated
representative for the part numbers.
OPTIONAL ACCESSORY
A Suspension Bracket that alleviates operator fatigue is
available from Huck. When the bracket is used with a
balance spring suspension system, much of the tool’s
weight is supported. Contact Huck Customer Service for
the part number and availability. See .
applifast.com
Toll Free 1 800 563 1293
7
507 Hydraulic Installation Tool (HK480)
Principle of Operation
When tool hoses and cord are connected to POWERIG
hoses and control cord, PULL and RETURN strokes of
tool are controlled by a Trigger in the handle.
When the trigger is pressed, a solenoid-operated valve
Hydraulic Hose to the front side of piston, and allows
The piston and nose assembly collet moves rearward
causing follower O-rings and/or spring to impart a
forward motion to the follower.
If tool and nose assembly is in position on a fastener pin
and collar, this forward motion causes the jaws to clamp
onto pintail of fastener and installation cycle begins.
Clamping pressure is applied to the sheets. The anvil
is forced forward, swaging the collar into locking
grooves of the fastener. When the anvil hits the sheet,
Piston reaches the end of its PULL stroke, it uncovers
from PULL side to RETURN side of piston, “unloading”
When the trigger is released, the solenoid is
This causes piston and collet to move forward and
fastener. Nose assembly jaw release contacts jaws,
The Ejector Rod hydraulically ejects the pintail out the
front of the nose assembly. When the piston reaches the
end of its RETURN stroke, pressure is built up causing
the POWERIG idler valve (except on models 910 and 911)
to go to idling pressure. Idling pressure keeps the tool
piston and nose assembly collet, jaws, etc. in the forward
position ready for the next installation cycle.
of piston to PULL side of piston and back to tank.
WARNING: Huck recommends that a Huck
POWERIG®be used to power Huck tools.
Hydraulic power units that deliver high PULL and
RETURN pressures—but which are NOT equipped
with RELIEF VALVESNOT
RECOMMENDED and may be dangerous.
Set the
in . Failure to properly set these
pressures may result in serious personal injury.
Huck Pressure Gauge (P/N T-124883CE) is
available, and should be used as indicated in its
instruction manual.
applifast.com
Toll Free 1 800 563 1293
8
507 Hydraulic Installation Tool (HK480)
Preparation for Use
NOTE: Model 507 tools with a serial numbers 0847
and higher have a deeper pocket in the end of the
piston rod. This allows clearance for the pintail. A
longer jaw follower cap (P/N 122686) is required in
the nose assembly. Cap P/N 104411 is required for
earlier models of the tool.
POWER SOURCE CONNECTIONS
Apply Parker Threadmate®, Loctite®567, or Slic-Tite®to
male pipe threads per manufacturer’s instructions.
1. Screw PULL pressure hose (P/N 104490), with coupler
nipple (P/N 103391), into tool port “P.” Screw RETURN
pressure hose (P/N 104490), with coupler body (P/N
103392), into tool port ‘‘R.’’
2. Use a Huck POWERIG (or equivalent hydraulic unit)
that has been prepared for operation per applicable
instruction manual. Check the PULL and RETURN
pressures, and adjust as necessary. Use Huck Gauge
(P/N T-124833CE) to check POWERIG pressures.
3. Turn OFF the POWERIG, and couple the tool hoses
to the POWERIG hoses. (Be sure that the larger hoses
run from tool port “P” to POWERIG port “P” and the
smaller hoses run from tool port “R” to POWERIG port
“R”.).
4. Connect trigger control cord assembly to the POWERIG
cord.
5. Turn ON the POWERIG, and press and release the
6. Attach the proper Nose Assembly to the tool.
If fasteners do not pass inspection, see
to investigate possible causes.
WARNINGS:
- Read entire manual before using tool.
personnel is recommended before using Huck
equipment.
- When operating Huck equipment, always wear
approved eye and hearing protection.
- Be sure there is adequate clearance for the
operator’s hands before proceeding.
- Connect the tool’s hydraulic hoses to the
POWERIG®Hydraulic Unit before connecting the
tool’s switch control cord to it. If not connected
in this order, severe personal injury may occur.
- Correct PULL and RETURN pressures (see
) are required for operator’s
safety and proper tooI function. Huck Pressure
Gauge (P/N T-124883CE) is available, and should
be used as indicated in its instruction manual.
Improper pressure settings may result in severe
personal injury.
CAUTION:®tape on pipe
threads. Tape can shred and break free into
CAUTIONS:
•Keep disconnected hoses, couplers, and
and free of foreign matter. Contaimated
POWERIG.
•Apply Parker Threadmate®, Loctite® 567,
or Slic-Tite® to male pipe threads per
manufacturer’s instructions.
•Hose couples must be securely attached
to ensure that the ball checks in the
nipple and the body are completely open.
Improperly assembled couplers will cause
overheating and malfunctions in the tool
and POWERIG.
•Hand tighten couplers; do NOT use a pipe
wrench.
applifast.com
Toll Free 1 800 563 1293
9
507 Hydraulic Installation Tool (HK480)
Operating Instructions
TO INSTALL A HUCKBOLT® FASTENER:
1. Check work and remove excessive gap.
NOTE: “Gap” is the space between sheets. It
is excessive if not enough of the pintail sticks
through the collar for the nose assembly jaws to
grasp.
2. Put a HuckBolt pin in the hole.
3. Slide HuckBolt collar over the pin.
NOTE: The beveled end of the collar must be
towards the nose assembly and tool.
4. Push the nose assembly onto the pin until the nose
assembly anvil stops against the collar. The tool
and nose assembly must be held at right angles (90
degrees) to the work.
5. Press the trigger to start the installation cycle.
6. When the forward motion of the nose assembly
installed fastener, and eject the pintail.
The tool and nose assembly are ready for the next
installation cycle.
CAUTION: Remove excess gap from between
the sheets to permit correct fastener
installation and prevent jaw damage. ALL
jaw teeth must engage pintail to avoid damaging
teeth.
WARNINGS:
- Wear approved eye and hearing protection.
- Ensure adequate clearance for operator’s hands
before installing fasteners.
personnel.
tool and directed away from all personnel.
- Do not pull on a pin without placing a fastener/
collar in a workpiece. Make sure that the collar
chamfer is out, toward the tool. Pins eject with
grooves strip, which could cause serious injury.
- Do NOT bend tool to free if stuck.
- Use tool to install fasteners ONLY; never use tool
as a jack/spreader or hammer.
applifast.com
Toll Free 1 800 563 1293
10
507 Hydraulic Installation Tool (HK480)
See
accordance with local environmental regulations. Recycle
steel, aluminum, and plastic parts in accordance with local
lawful and safe practices.
PREVENTIVE MAINTENANCE
For supplementary information, see , the
and procedures, and the
in this manual.
SYSTEM INSPECTION
performance of the entire system, including the tool, nose
assembly, hydraulic hoses, control trigger assembly, and
maintenance program includes scheduled inspections of
the system to detect and correct minor troubles.
- Inspect the tool and nose daily for damage and wear.
Inspect the tool before each use for leaks.
electrical connections are secure, and free of leaks
and damage. (Replace hoses at six-month to one-year
intervals, depending on use.) Clear air-lines of dirt and
water.
- Inspect tool, hoses, and POWERIG during operation to
detect abnormal heating, leaks, or vibration.
- Service the tool in a clean, well-lighted area. Be sure
to prevent contamination of pneumatic and hydraulic
systems.
- Carefully handle all parts and components. Before
reassembly, examine for damage and wear; replace
when necessary.
- Have available all necessary hand tools (standard and
special); a half-inch brass drift and wood block; arbor
press; and soft-jaw vise. Unsuitable hand tools could
cause tool damage.
- Follow the disassembly and assembly procedures in
this manual. If Huck recommended procedures are not
followed, the tool could be damaged.
- Disassemble and assemble tool components in a
straight line. Do NOT bend, twist, or apply undue force.
Never force a component if it is misaligned; reverse the
procedure to correct the misalignment and start again.
- Apply continuous steady pressure to components.
An arbor press provides steady pressure to press a
component into or out of an assembly.
- Apply Parker Threadmate®, Loctite®567, or Slic-Tite®to
male pipe threads per manufacturer’s instructions (to
ease assembly and to prevent leaks).
- Smear LUBRIPLATE®130-AA (P/N 502723) or SUPER-O-
LUBE®(P/N 505476) on rings and mating parts to ease
assembly to prevent nicking/pinching rings on rough/
tight spots.
POWERIG MAINTENANCE
Maintenance instructions and repair procedures are in the
appropriate POWERIG Instruction Manual.
TOOL MAINTENANCE
Whenever disassembled, and at regular intervals
depending on use, replace all O-rings and Back-up rings.
Keep Spare Parts Service Kit, 507KIT, on hand.
Inspect cylinder bore, piston, piston rod, and unloading
valve for scored surfaces, excessive wear, and damage;
replace as necessary.
NOSE ASSEMBLY MAINTENANCE
Clean nose assemblies daily in mineral spirits (or other
suitable solvent) to clear jaws and rinse metal chips and
dirt. For a more thorough cleaning, disassemble the nose
assembly. Use a pointed “pick” to remove embedded
particles from the pull grooves of the jaws.
Maintenance
CAUTIONS:
Consult the Material Safety Data Sheet (MSDS)
before servicing tool.
Keep foreign matter out of hydraulic system, and
separated parts away from dirty work surfaces.
failures in tool and Powerig®.
Check the Assembly Drawings in this manual for
valve.
®tape on pipe threads. Tape
in malfunctions.
Always replace all seals, wipers, and rings when
the tool is disassembled for any reason.
Hydraulic Couplings
and burrs from diameter A and leading edge
to prevent damage to O-ring.
O-ring (P/N 504438)Back-up ring (P/N 501102)
applifast.com
Toll Free 1 800 563 1293
11
507 Hydraulic Installation Tool (HK480)
General Disassembly and Assembly Guidelines
Take the following precautions to avoid damaging tool or
components:
Always work on a clean surface.
Use relatively soft materials, such as brass, aluminum, or
wood to protect the tool when applying pressure.
Apply a continuous strong pressure, rather than sharp
blows, to disassemble or assemble a component. An arbor
press provides steady pressure to press a component in
or out.
Never continue to force a component if it “hangs up”
due to misalignment. Reverse the procedure to correct
misalignment and start over.
Smear LUBRIPLATE®130-AA (Huck P/N 502723) or
equivalent, on O-rings and mating surfaces to aid
assembly and prevent damage to O-rings.
A special Spanner Wrench is available from Huck to aid in
the disassembly and assembly of Locking Ring, reference
No. 11. A Piston Rod Guide is available to prevent damage
to the piston rod seals when assembling the piston. See
.
Standard hand tools, such as wrenches, drifts, copper or
lead hammers, screwdrivers, socket screw hexagon keys,
long forceps (tweezers), etc., which may be purchased
recommends having available an arbor press and a vise
with soft jaws.
Disassembly
This procedure is for complete disassembly of the tool.
Disassemble only those components necessary to replace
damaged rings, and worn or damaged components.
Always replace O-rings, Back-up rings, and wipers of
disassembled sub-assemblies. Always use a soft-jaw vise
to avoid damaging the tool.
see Figure 1.
NOTE: Be sure POWERIG is OFF when removing the nose
assembly to clean or replace components. See applicable
Nose Assembly Data Sheet for additional instructions.
To disassemble the tool:
1. Remove the retaining ring from the split ring. Slide
the nose assembly anvil and unscrew the nose collet
assembly.
2. Remove the four socket-head screws and lock-washers
from the handle. The handle assembly and cushion are
now separated from the tool.
3. Remove one locater button and unscrew locking ring
using spanner wrench. Remove the second locater
button.
4. Screw the locking ring partially in. Screw two socket-
head screws into the cylinder cap. Use pry bars under
the heads of the screws to gradually pry the cylinder
cap out of the cylinder assembly.
5. Remove the unloading valve.
6.
7. Unscrew the hoses.
8. Press the piston out of the cylinder assembly. Use an
arbor press if available.
9. Unscrew the ejector cartridge assembly using a 7/16”
socket wrench. Slide the ejector out of the cartridge
assembly. Unscrew the retaining screw from cartridge
assembly using 3/16” Allen wrench.
10.Remove the retaining ring.
11.Press the adapter out of the cylinder assembly.
12.Use a small dull-pointed rod to remove the O-rings
and Back-up rings from all components.
NOTE: Disassemble control trigger systems only when
necessary to rewire or replace the switch/trigger. Once the
tool has been properly disassembled, store all re-usable
parts (screws and disassembled components) in a clean,
dry area.
WARNING: Disconnect the tool’s control
trigger system from the POWERIG®Hydraulic
Unit before disconnecting the hydraulic hoses
from it. If not disconnected in this order, serious
personal injury may occur.
Assembly of NPTF Threaded Components
AIR FITTINGS
1) Apply TEFLON®stick to male threads which do
not have pre-applied sealant per manufacturer’s
recommendations. (Proceed to All Fittings step 2)
HYDRAULIC FITTINGS
1) Apply Threadmate™to male and female threads which
do not have pre-applied sealant per manufacturer’s
recommendations. (Proceed to All Fittings step 2)
ALL FITTINGS:
4) Final thread engagement can be checked (optional)
assembly.
Thread size Final thread engagement at full make-up
1/8-27 NPTF .235 inch (.59 cm)
1/4-18 NPTF .339 inch (.86 cm)
3/8-18 NPTF .351 inch (.89 cm)
applifast.com
Toll Free 1 800 563 1293
12
507 Hydraulic Installation Tool (HK480)
re-assembling the tool:
NOTE: When re-assembling the tool, always replace
damaged and defective parts, and all seals, wipers,
and rings of sub-assemblies.
- Inspect components for scoring, excessive wear, and
damage; replace as necessary.
- Clean components in mineral spirits or other solvent
compatible with O-ring seals. Clean O-ring grooves.
- Replace all O-rings, Quad-rings, and Back-up rings.
See Figure 1 for guidance on positioning these rings.
Take care not to damage rings. Use the rings that are
in Spare Parts Service Kit 507KIT.
standard components are shown in Table 5 so that
they may be purchased locally.
- Smear LUBRIPLATE®130-AA (P/N 502723) or SUPER-
O-LUBE®(P/N 505476) on rings and mating parts to
prevent damage and to ease assembly.
- Apply Parker Threadmate®, Loctite®567, or Slic-Tite®
to male pipe threads per manufacturer’s instructions.
To re-assemble the tool:
1. Press nose assembly adapter into the cylinder.
2. Place the O-ring and washer into the ejector
cartridge. Use a 3/16” Allen wrench to install the
retaining screw. Push the pintail ejector into the
ejector cartridge. Install O-ring and Back-up ring on
outside of cartridge. Screw cartridge assembly into
piston; tighten with a 7/16” socket wrench.
NOTE: Step 4 can be completed before
assembling pintail ejector and ejector cartridge
to piston.
3. Place Piston Rod Guide (P/N 102862) over the
threads of piston rod and press the piston into the
cylinder and adapter.
4. Place the relief valve in the hole in the piston.
5. Press the cylinder cap into the cylinder so that the
locater scallop in the cap matches the scallop in the
cylinder.
6. Place one locater in matching scallops.
NOTE: The cap can be turned by putting a screw
into one of the tapped holes to use as a handle.
7. Use the spanner wrench to screw the locking ring
into the cylinder.
8. Unscrew the locking ring 1/4 turn (or less) until the
scallop in the locking ring matches the scallop in the
cylinder cap. Place locater in matching scallops.
9. Position the cushion and handle assembly, and
insert four socket-head screws with lockwashers.
Torque the screws to: 490 in-lbs (if screws are
plated) or 655 in-lbs (if not plated).
10. Apply Parker Threadmate®, Loctite®567, or Slic-
Tite®to threads (per manufacturer’s
instructions), and screw the hoses into the cylinder.
11. Screw the coupler nipple onto the hose that is
attached to cylinder port “P”.
12. Screw the coupler body onto the hose that is
attached to cylinder port “R”.
NOTE: The tool will malfunction if the coupler
nipple and body are not properly assembled.
13. Attach the tool hoses to the POWERIG hoses and
actuate the tool a few times to check its operation;
inspect for leaks caused by damaged O-rings.
14. Assemble the split ring, sleeve, and retaining ring
when attaching the nose assembly.
HANDLE ASSEMBLY
1. Screw the body of the cord grip part of the strain
relief into the handle.
2. Slide the strain relief cap over the cord.
3. Slide the strain relief grommet over the cord.
4. Place the cord in the handle so that leads come out
the switch pocket.
5. Assemble the leads to the rear of the switch.
6. Push the switch into the handle and retain with set
screw.
7. Slide the cover (not shown) over the other end of
the cord.
8. Assemble the cap (two-prong plug) to the cord, and
slide the cover over the cap.
Assembly
WARNING: Do not omit any seals during
servicing or re-assembly; leaks will result and
serious personal injury can occur.
CAUTION: Do not use TEFLON®tape on
threads. Tape can shred and break free into
WARNING: Make sure the tool is properly
re-assembled, with all components included.
CAUTION: Do not use TEFLON®tape on
threads. Tape can shred and break free into
applifast.com
Toll Free 1 800 563 1293
13
507 Hydraulic Installation Tool (HK480)
Components Drawing
applifast.com
Toll Free 1 800 563 1293
14
507 Hydraulic Installation Tool (HK480)
Troubleshooting
1. Tool fails to operate when trigger is pressed.
a. Inoperative POWERIG®Hydraulic Unit. Check
power source. See applicable instruction
manual.
b. Loose or disconnected control cord.
c. Damaged trigger assembly.
d. Loose or faulty hydraulic hose couplings.
2. Tool leaks hydraulic uid.
a. Defective O-rings or loose hose connections at tool.
3. Hydraulic couplers leak uid.
a. Damaged or worn O-rings in coupler body.
4. Hydraulic uid overheats.
a. POWERIG not operating properly.
b. Hydraulic couplers not completely tightened.
c. Restriction in hydraulic line.
5. Tool operates erratically and fails to install
fastener properly.
a. Low or erratic hydraulic pressure; air in system.
b. Damaged or worn piston/anvil O-ring in tool.
c. Excessive wear on sliding surfaces of tool parts.
d. Relief Valve too short, worn, or peened over.
6. Collar of HuckBolt®Fastener not completely swaged.
a. Improper tool operation. See Trouble 5.
b. Scored anvil.
7. Tool “hangs-up” on swaged collar of HuckBolt
Fastener.
a. Improper tool operation. See Trouble 5.
b. RETURN pressure too low.
8. Pintail of fastener fails to break.
a. Improper tool operation. See Trouble 5.
b. Pull grooves on fastener stripped. See Trouble 10.
c. PULL pressure too low.
9. Jaw segments do not maintain proper position in
piston.
a. Incorrect amount of follower O-rings. Clean before
reassembling.
10. Pull grooves on fastener pintail stripped during PULL
stroke.
a. Broken pintail not removed from tool.
b. Anvil was not slid completely onto fastener pintail.
c. Incorrect fastener length.
d. Worn or damaged jaw segments.
e. Metal particles accumulated in pull grooves of
jaw segments.
f. Excessive sheet gap.
11. Tool operates in reverse.
a. Reversed hydraulic hose connections between
POWERIG and tool.
12. Anvil will not slide completely over fastener pintail.
a. Broken pintail not removed from tool.
b. Incorrect fastener length.
Always check the simplest possible cause (such as a
loose or disconnected trigger line) of a malfunction
causes until the cause is discovered. Where possible,
substitute known good parts for suspected defective
parts. Use this troubleshooting information to aid in
locating and correcting trouble.
applifast.com
Toll Free 1 800 563 1293
15
507 Hydraulic Installation Tool (HK480)
Kits & Accessories
KITS
Use 507KIT when using this tool and when performing
maintenance on it.
This kit contains the following parts, and is shown
below.
PART NO. DESCRIPTION QTY.
130027 Hose Bracket 1
130028 Hose Clamp 1
502492 Button Head Screw 1/4-20 4
500137 Socket-head Cap Screw .38-24 4
ACCESSORIES
Hex Keys
502446
(for socket-head screws in the handle)
501623
(for setscrew in the trigger switch)
Spanner Wrench - 110362
(to disassemble/assemble the locking ring)
Piston Rod Guide - 102862
(for assembling the piston)
Spare Parts Service
Kits that contain various perishable parts. The types
and quantities of spare parts that should be available
vary with the application and tools in use. Have the
appropriate kit accessible when using this tool and
when performing maintenance on it.
Huck also recommends having the following
Accessories available when preparing, using, and
performing maintenance on this tool.
applifast.com
Toll Free 1 800 563 1293
16
507 Hydraulic Installation Tool (HK480)
Notes
applifast.com
Toll Free 1 800 563 1293
17
507 Hydraulic Installation Tool (HK480)
Limited Warranties
Limited Lifetime Warranty on BobTail® Tools:
Huck International, Inc. warrants to the original purchaser
that its BobTail® installation tools manufactured after
12/1/2016 shall be free from defects in materials and
workmanship for its useful lifetime. This warranty does
not cover special order / non-standard products, or part
failure due to normal wear, tool abuse or misapplication,
or user non-compliance with the service requirements and
conditions detailed in the product literature.
Two Year Limited Warranty on Installation Tools:
Huck International, Inc. warrants that its installation tools
and Powerigs®manufactured after 12/1/2016 shall be
free from defects in materials and workmanship for a
period of two years from date of purchase by the end
user. This warranty does not cover special order / non-
standard products, or part failure due to normal wear,
tool abuse or misapplication, or user non-compliance with
the service requirements and conditions detailed in the
product literature.
90 Day Limited Warranty on Nose Assemblies and
Accessories:
Huck International, Inc. warrants that its nose assemblies
and accessories shall be free from defects in materials
and workmanship for a period of 90 days from date of
purchase by the end user. This warranty does not cover
special clearance noses, or special order / non-standard
product, or part failure due to normal wear, abuse or
misapplication, or user non-compliance with the service
requirements and conditions detailed in the product
literature.
Useful lifetime
product is expected to last physically, up to the point
when replacement is required due to either normal
in-service wear, or as part of a complete overhaul.
Determination is made on a case-by case basis upon
return of parts to Huck International, Inc. for evaluation.
Tooling, Part(s) and Other Items not manufactured by
Huck:
HUCK makes no warranty with respect to the tooling,
part(s), or other items manufactured by third parties.
HUCK expressly disclaims any warranty expressed
or implied, as to the condition, design, operation,
other items thereof not manufactured by HUCK. HUCK
shall not be liable for any loss or damage, directly or
indirectly, arising from the use of such tooling, part(s),
or other items or breach of warranty or for any claim for
incidental or consequential damages.
Huck shall not be liable for any loss or damage resulting
reason or reasons beyond the control of the Huck or its
suppliers.
Huck Installation Equipment:
Huck International, Inc. reserves the right to make
models without notice.
Huck Installation Equipment should be serviced by trained
service technicians only.
Always give the serial number of the equipment when
corresponding or ordering service parts.
Complete repair facilities are maintained by Huck
below.
Eastern
One Corporate Drive Kingston, New York 12401-0250
Telephone (845) 331-7300 FAX (845) 334-7333
Outside USA and Canada
Contact your nearest Huck International location (see
reverse).
In addition to the above repair facilities, there are
Authorized Tool Service Centers (ATSC’s) located
repair services, spare parts, Service Parts Kits, Service
Tool Kits and Nose Assemblies. Please contact your Huck
Representative or the nearest Huck International location
(see reverse) for the ATSC in your area.
applifast.com
Toll Free 1 800 563 1293
Howmet Inc. (NYSE: HWM) creates breakthrough products that
shape industries. Working in close partnership with our customers,
we solve complex engineering challenges to transform the way
Through the ingenuity of our people and cutting-edge advanced
manufacturing, we deliver these products at a quality and
CERTIFIED
MANAGEMENT
SYSTEM
ISO 9001-2015
ISO 14001-2015
© 2021 Howmet Aerospace, Inc.
Howmet Fastening Systems
Kingston Operations
Huck provides technical assistance
regarding the use and application of
Huck fasteners and tooling. NOTICE: The
information contained in this publication
is only for general guidance with regard
to properties of the products shown and/
or the means for selecting such products,
and is not intended to create any warranty,
express, implied, or statutory; all warranties are contained
only in Huck’s written quotations, acknowledgments, and/
or purchase orders. It is recommended that the user secure
application and/or use of such products.
applifast.com
Toll Free 1 800 563 1293
Table of contents
Other Applifast Tools manuals
