Tekon PLUS TWP UT Series User manual

PLUS TWP-XUT
INSTALLATION GUIDE
TEKON ELECTRONICS AVEIRO, PORTUGAL
P.: [phone] M.: [phone] E.: [email protected]
IG_PLUS_TWP-XUT_E01A

2
DUOS WIRELESS SYSTEM INSTALLATION GUIDE
01
step WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
Pages 4 to 12
02
step TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
Pages 13 to 19
PLUS TWP-XUT WIRELESS TRANSMITTER
INSTALLATION GUIDE
Table of contents
03
step TWP-XUT TRANSMITTER TEMPERATURE INPUT CONFIGURATION
Pages 20 to 23
04
step TWP-XUT TRANSMITTER DIGITAL OUTPUT CONFIGURATION
Pages 24 to 26
05
step WGW420 GATEWAY ANALOG OUTPUTS CONFIGURATION
Pages 27 to 29

3
DUOS WIRELESS SYSTEM INSTALLATION GUIDE
PLUS TWP-XUT WIRELESS TRANSMITTER
INSTALLATION GUIDE
Table of contents
07
step SITE SURVEY MODE
Pages 36 to 37
06
step WRP001 PLUS WIRELESS REPEATER CONFIGURATION
Pages 30 to 35

01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION

01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
5
INSTALLATION GUIDE PLUS TWP-XUT
01 Connect the antenna to the Gateway.
02 Wiring
Connect the power supply and then the
RS485-USB cable to the Gateway.
TEKON CONFIGURATOR SOFTWARE is only compatible with the Microsoft® Windows® Operating System.
03 Power ON the device.
Wire Indication:
Blue - GND; Brown - +24 VDC; Orange - Data+ (A); Black - GND; Yellow - Data - (B)

6
PLUS TWP-XUT INSTALLATION GUIDE
01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
04 Check device connection state by LED indication.
05 Open Tekon Configurator Software1and select PLUS >> Gateway >> Configuration
2
1
3
1 Tekon Configurator software is free of charge and available at www.tekonelectronics.com
10 Seconds to enter
configuration mode
WIRELESS GATEWAY
Normal mode
Green LEDs
permanently on
Red LEDs
permanently on

01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
7
INSTALLATION GUIDE PLUS TWP-XUT
07 Select corresponding Port name2.
2You can check device’s serial port name in “Device Manager” on Microsoft ® Windows® operating system.
06 Select serial port corresponding to WGW420 PLUS Wireless Gateway
Click on the Rescan Ports button.

8
PLUS TWP-XUT INSTALLATION GUIDE
01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
08 Perform a power cycle on the Gateway.
09 Click on Connect ( ) button to enter configuration mode.
NOTE:
After power up, you have 10 seconds to enter configuration mode by clicking on Connect button ( )
(while green LEDs are permanently on).
In this mode, you can manage device parameters: Modbus Address, Modbus Baudrate, Modbus Parity, Wireless
Network ID and Wireless Channel.

01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
9
INSTALLATION GUIDE PLUS TWP-XUT
NOTE:
When the 10-second time frame to enter configuration mode is exceeded, the LEDs will turn permanently red and
the gateway will enter normal operation mode.
To get back in configuration mode, you need to perform a power cycle - step 8.
Green LEDs performing
scan animation
WIRELESS GATEWAY
Configuration mode
The status string at the bottom of the software window provides feedback on ongoing operations.
10
You can also verify configuration mode activation by checking LEDs on the gateway.

10
PLUS TWP-XUT INSTALLATION GUIDE
01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
12 Click on Disconnect ( ) button.
11 Take note of device configuration data available, namely: Modbus Address, Modbus Baudrate, Modbus Parity,
Wireless Network ID and Wireless Channel.
NOTE:
The wireless network connection between devices is ensured by setting the same Wireless Network ID and
Wireless Channel parameters.

01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
11
INSTALLATION GUIDE PLUS TWP-XUT
13 Modbus Communication
Select Modbus tab of the Gateway and set the previously saved configurations.
Ensure that Port name, Baudrate, Parity and Modbus Address fields are the same as those obtained in
configuration mode.
14
The messages Connected to Modbus and Reading successfully will appear if Serial Port configuration
parameters are correct and the Modbus connection is established.
Click on Connect ( ) button and check operation status at the bottom of the window.

12
PLUS TWP-XUT INSTALLATION GUIDE
01
step
WGW420 PLUS WIRELESS GATEWAY CONFIGURATION
WIRELESS GATEWAY
Red LEDs permanently on
LED flashes on each wireless
communication
NOTE:
See WGW420 Datasheet to access LED indication information - page 4.

02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION

14
PLUS TWP-XUT INSTALLATION GUIDE
02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
01 Loosen the 4 screws of the case and open it.
(Example image)
03 Open a new window of Tekon Configurator Software and select PLUS >> Transmitter menu.
2
1
02 Connect a micro USB cable to the computer
and then to TWP-1UT PLUS Wireless
Transmitter.
(Example image)

02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
15
INSTALLATION GUIDE PLUS TWP-XUT
1You can check device’s serial port name in “Device Manager” on Microsoft® Windows® operating system.
05 Select corresponding Port name1.
04 Click on Rescan Ports button. 04

16
PLUS TWP-XUT INSTALLATION GUIDE
02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
06 Click on Configuration Mode ( ) button.
TWP-1UT
LEDs
permanently
on
LEDs
alternating

02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
17
INSTALLATION GUIDE PLUS TWP-XUT
07 Configure Wireless Network ID and Wireless Channel previously obtained from Gateway.
The wireless connection between both devices is ensured by setting the same Wireless Network ID and Wireless
Channel parameters.
Gateway Modbus Index will define the modbus registers window used to store information sent by the
transmitter.
Each transmitter should have a dierent Gateway Modbus Index in order to avoid information override.
Click on Write button to update Transmitter settings.

18
PLUS TWP-XUT INSTALLATION GUIDE
02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
08 Click on Configuration Mode ( ) button to exit setup and resume normal operating mode.
LEDs
alternating
LED
permanently
o
LEDs flashing
until wireless
connection is
established
When connected
to the Gateway
TWP-1UT

02
step
TWP-XUT PLUS WIRELESS TRANSMITTER CONFIGURATION
19
INSTALLATION GUIDE PLUS TWP-XUT
NOTE:
Make sure that the devices are at a distance of at least 3 meters or remove the antenna from the gateway (in
case both devices are near each other).
After clicking on Disconnect button, the device will permanently attempt to connect to a wireless network.
If there is no communication, the Status LED flashes slowly and the Mode LED flashes quickly.
When there’s a successful connection directly to a wireless network, both status LEDs alternate quickly - during
1 minute if the transmitter is operating as end device or permanently if operating as repeater.

03
step
TWP-XUT TRANSMITTER TEMPERATURE INPUT CONFIGURATION
