Hubbell Fixed Transmitter 31.350 User manual

Hubbell Industrial Controls, Inc.
Spec Sheet 31.350 • May 2000 • New
Replaces Spec Sheet 31120 of June 96
Fixed
Transmitter
Hubbell Radio Remote Control Systems
HUBBELL
The Hubbell Fixed Transmitter is a microcon-
troller transmitter for use with Hubbell micro-
controller receivers. The fixed transmitter com-
municates to the remote receiver via radio
transmission, eliminating the need for festoon-
ing, cabling, etc.
The Fixed Transmitter is housed in a
NEMA␣ 12 surface-mounting console integrat-
ing several Hubbell operator interface prod-
ucts. The transmitter electronics are essentially
the same as used in the mid-size transmitter.
Internal power supplies are provided for oper-
ation from 120V ac or 250V dc. The antenna
mounts remotely and is conected to the trans-
mitter by coax cable.
Multispeed/bidirectional operator control can
be via a Type 4211 Mini-Master Switch for
each function controlled by the transmitter. The
compact Mini-Master Switch has an operator
head molded with tough fiberglass reinforced
polyester resin and a stainless steel handle.
The switch is available with up to 5 speed
points per direction. Refer to Specification
Sheet 4211 for additional information.
Other operator interface functions (start/stop,
horn, etc.) use toggle switches, and/or push-
buttons & selector switches. Fixed transmitter
consoles are custom designed to meet the us-
er’s specific requirements.

JPS-500-1M © 2000
Printed in U.S.A.
HUBBELL
50 Edwards Street
Madison, Ohio 44057
[phone]
Fax [phone]
4301 Cheyenne Drive
Archdale, NC 27263
[phone]
Fax [phone]
Hubbell Industrial
Controls, Inc.
a subsidiary of
Hubbell Incorporated
Hubbell Industrial Control Solutions
http://www.hubbell-icd.com/radiocontrols/
72 MHz Transmitters 450 MHz Transmitters
Frequency Range 72-76 MHz 406–430, 450–475 MHz
Channel Available per customer license per customer license
Frequency Stability -10 to 60°C ±5ppm ±5ppm
Emission Type 10KOFID 10KOFID
Spurious/Harmonic Output (below carrier) >70db >80db
Output to Antenna 300 mW 300 mW (low) / 1 W (high)
Effective Radiated Power 150 mW 150 mW (low) / 500 mW (high)
Nominal Range (line of sight) 2000 ft* 2500 ft (low) / 3500 ft (high)*
FCC Identifier LRL922206-72 LRL922206-450
Canada Certificate Number 2259-203-224 2259-203-222
Voltage Requirement 120V ac or 250V dc 120V ac or 250V dc
Battery Usage no battery no battery
Recharge Time no battery no battery
Operating Temperature -22°F to 140°F -30°C to 60°C -22°F to 140°F -30°C to 60°C
Relative Humidity 20% to 90% non - condensing 20% to 90% non - condensing
LED Indicator Flashing: transmitting Flashing: transmitting
Function Lever Switches as required as required
Auxiliary Switches as required as required
Weight with Battery No Battery No Battery
* The use of “Whip Antennas”, raised 20 to 30 feet above ground level, on both transmitter
and receiver, increases the nominal range to 2 miles.
Transmitter Specifications
11.00
5.25
4.15
10.25
23.50
22.00
*
*
*
*
*
*
*
BRAKE
APPLY
RELEASE
E-STOP
RUN
R.F.
HOISTTROLLEY
BRIDGEMAGNET
HORN
XMIT
0.31 DIA.
8.00
22.75
UP
DOWN
NORTH
SOUTH
WEST
EASTLIFT
DROP
