TEKSAN GO ON Solar Panel 200W User manual

User Manual

3
Dear Customer,
Teksan Thank you for choosing our Teksan GO ON Solar Panel 200W
product. We want your product, manufactured with high quality
and technology, to offer you the best efficiency. Therefore, please
read this entire manual and the other documents provided carefully
before using the product and keep them as a reference. If you give
the product to someone else, hand over the instruction manual with
it. Observe all information and warnings in the user manual and
follow the instructions. This product uses sunlight to power your
devices whenever and wherever you need it. Designed to the highest
specifications and standards, it provides a high amount of free green
energy.
For more information:
Simply scan this code
with your smartphone.

5
TEKSAN JENERATÖR ELEKTRİK SANAYİ VE TİCARET A.Ş.
Yenidoğan Mah. Edebali Cad. No:12 34791 Sancaktepe / İSTANBUL
TABLE OF CONTENTS
1. What is in the Box?....................................................................... 6
2. Specifications ............................................................................... 6
3. How to Charge Your Device .......................................................... 7
4. Frequently Asked Questions ...................................................... 7-8
5. Notes ............................................................................................ 8
6. Terms of Warranty................................................................... 9-13
7. Contact Us ............................................................................. 14-15

6
TEKSAN GO ON SOLAR PANEL 200W X1 Instruction Manual
X1
Model TEKSAN GO ON SOLAR PANEL 200W
Maximum Power 200±10%
Open Circuit Voltage/Voc(V) 21.00
Maximum Power Voltage/Vmp (V) 18.00
Maximum Power Current/Imp(A) 11.10
Short Circuit Current/Isc(A) 13.30
Efficiency %23
Charging Interface MC4 cable
Unfolded Dimensions 2326*600*4.0MM±5
Folded Dimensions 647*600*50MM
Operating Temperature -20°C~85°C
Weight 8.8 kg
1. What is in the Box?
2. Specifications

7
3. How to Charge Your Device
1. Please try to hold the solar panel at a 90° angle to the sunlight to
get more sunlight.
2. Connect the device to the solar panel using an MC4 cable. If the
cable is not suitable, you will need a patch cable to connect it.
3. Place the charged product under the solar panel, inside the solar
panel connection pocket or in any shade to prevent the charged
product from overheating.
4. Frequently Asked Questions
1. Why is my Solar Panel not Charging?
a. Please check the connections of the output cable or plug. Try
reinstalling the cable or replacing it with a new one.
b. Please check whether the sunlight is directly on the solar panel.
Reposition the solar panel to ensure that the solar panel receives
sufficient sunlight.
c. Please check the surface of the solar panel for stains or blockage. To
prevent blockage of the solar panel surface, you may clean the surface
of the solar panel using a cloth.

8
2. Why Do Devices Charge Slowly?
a. Please check the weather. It may be cloudy or rainy. Bad weather
conditions reduce the efficiency of solar panels.
b. Please replace the connection cable with a new one or use the device
in a sunny environment.
c. Please do not leave your electronic device in the sun for a long period
of time or in an overheated environment.
3. Does a Solar Panel Work in Cloudy Weather?
Yes, but the charging efficiency is reduced, resulting in a longer charging
time.
5. Notes
1. Place the solarpanel in direct sunlight and make sure that no other
objects are covering the solar panel.
2. Connect the equipment to be charged using a cable compatible with
the solar panel.
3. To get the maximum amount of energy from the sun, position the
solar panel perpendicular to the sunlight.
4. Do not leave your cell phone or tablet in direct sunlight for a long
period of time as this can cause overheating or damage.
5. Do not puncture, throw, drop, bend or modify this product.
6. Do not allow children to play with this product

9
6. Terms of Warranty
This warranty undertakes to repair the product free of charge under the
conditions set out in the following terms.
Please read the warranty document carefully and keep it in a safe place.
1. The warranty period starts from the invoice date of the product and is
1 year.
2. Provided that the product is used as shown in the product
identification and user manual and has not been serviced, repaired or
otherwise interfered with by persons other than authorized after sales
staff of Teksan Generator A.Ş., it gives warranty for the whole product
including all of its parts against material, workmanship and production
defects for the period specified above from the invoice date of the
product.
3. In the event that it is understood that the product is defective;
a. Rescission of the contract
b. Request for free repair,
c. Satış bedelinden indirim isteme,
d. Request for the replacement of the sold product with a
defectfree equivalent
4. If the consumer chooses the right to free repair from these rights,
the seller shall be obliged to repair or have the product repaired without
any charge under labor cost, replacement part cost or any other name
whatsoever. The consumer may also exercise the right to free repair
against the manufacturer or importer. The seller, manufacturer and

10
importer are jointly and severally liable for the exercise of this right by
the consumer.
5. If the consumer exercises the right to free repair, and;
- The same malfunction recurs within the warranty period,
- The maximum time required for repair is exceeded, or
- A report is issued by the authorized service station, seller,
manufacturer or importer indicating that it is irreparable;
The consumer may demand from the seller the return of the product,
the price discount in proportion to the defect or, if possible, the
replacement of the product with a defect-free equivalent.
The seller may not refuse the consumer’s request. If this request is
not fulfilled, the seller, manufacturer and importer shall be jointly and
severally liable.
6. The maximum repair period of the product shall not exceed 20
business days during the service time as specified in the relevant
legislation. This period starts on the date of notification of the product
failure to the authorized service station or the seller within the warranty
period, or from the date of delivery of the product to the authorized
service station outside the warranty period. If the failure of the product
under warranty is not repaired in 20 business days, the manufacturer
or importer shall have to allocate another product with similar
features to the consumer until the repair of the product is completed.
Manufacturers or importers are released from this obligation if another
product with similar characteristics is not desired by the consumer. If
the product fails within the warranty period, the time spent in repair
shall be added to the warranty period.

11
7. Damages and malfunctions arising from the use of the product
contrary to the user manual are not covered by the warranty. Under the
following contrary conditions, warranty support shall not be provided.
a. Malfunction or damage caused by failure to observe the
precautionary measures described in the user manual.
b. Failure or damage caused by improper repair, disassembly or
modification of the product outside authorized service.
c. Failure or damage caused by dropping, vibration, water leakage,
condensation or similar reasons after purchase.
d. Failures or damages caused by other natural disasters such as
fire, earthquake, flood.
e. Any change in appearance or discoloration caused by use or
ambient conditions.
f. Failure or damage caused by use at temperatures other than the
declared operating temperature.
8. In the case of disputes that may arise regarding the exercise of
rights arising from the warranty, the consumer may apply to the
Consumer Arbitration Committee or the Consumer Court in the place of
residence or in the place where the consumer transaction is made.
9. In the case that this Warranty Certificate is not provided by the
Seller, the consumer may apply to the General Directorate of Consumer
Protection and Market Surveillance affiliated with the Ministry of Trade.
10. To receive product repair service under warranty, please send the
warranty card and product invoice together with the product.

12
11. The customer is responsible for delivering the product to Teksan
Service Centers (Regional Offices) for repair service under warranty and
taking it back after repair.
12. There is no warranty for collateral damage resulting from the failure
of this product. We are not responsible for any malfunction or damage to
other equipment caused by the use of this product.
13. This manual applies only in the case of the sale of this product and
the company reserves the right of final interpretation.
14. This manual will not be republished, so you are advised to keep it in
a safe place.

13
If you purchased the product from our online shop, you must provide proof of the date
of purchase, such as a screenshot of the invoice, order number or order history for this
warranty card. Otherwise, the warranty shall be void.
Manufacturer’s or Importer Company’s; Product’s
Trade Name: TEKSAN JENERATÖR
ELEKTRİK SANAYİ VE
TİC. A.Ş.
Brand: TEKSAN
Address: Yenidoğan Mah.
Edebali Cd. No: 12
PK:34791 Sancaktepe
/ İSTANBUL
Type: Solar Panel
Model: GO ON 200W
Tel: [phone] Banderole and Serial No: ..............................
Fax: [phone] Warranty Period: 1 YEAR
web adresi: www.teksan.com Maximum Repair Time: 20 business days
Seller’s:
Trade Name: ..................................... Invoice Date and Number ..............................
Address: ..................................... Delivery Date and Place: ..............................
.................................................................. Authorized person’s signature:
Tel No: ..................................... Company Seal
Fax: .....................................
e-mail: .....................................
This section shall be signed and sealed by the
Authorized Dealer you purchased the product from.
GENERAL MANAGER ASSISTANT GENERAL MANAGER

14
7. Contact Us
This product is globally warranted for 12 MONTHS from the date of
purchase. To ask a QUESTION or SUGGESTION about this product,
please [email protected] or contact the most convenient service
provider in the service list below. You can contact our nearest service
center.
Our friendly customer service staff will always be there to help you and
is ready to provide you with answers that will satisfy you.
HEADQUARTER & ISTANBUL FACTORY
Yenidogan Nbrhd. Edebali St. No: 12 Zip Code:34791 Sancaktepe / ISTANBUL
Tel: [phone] Fax: [phone]
Email: [email protected]
TEKSAN UK
Unit 8, Frankley Industrial Estate, Tay Road, Rubery, B45 0LD, UNITED KINGDOM
Tel: [phone]
Email: [email protected]
TEKSAN USA LLC
901 Mittel Drive Wood Dale IL 60191 USA
Tel: [phone]
Email: [email protected]
ISTANBUL EUROPE REGION SALES AND TECHNICAL SERVICE CENTER
Mehmet Akif Nbrhd. Basın Ekspres Road Uzay St. No:50
Halkali-Küçükçekmece / ISTANBUL
Tel: [phone] Fax: [phone]
Email: [email protected]
ISTANBUL ANATOLIA REGION SALES AND TECHNICAL SERVICE CENTER
Merkez Nbrhd. Katip Çelebi St. No:9/2 Zip Code: 34956 Orhanlı - Tuzla / ISTANBUL
Tel: [phone] Fax: [phone]
Email: [email protected]

15
KOZYATAĞI REGION SALES AND TECHNICAL SERVICE CENTER
19 Mayıs Nbrhd. Atatürk St. Sıtkı Bey Plaza
Blok No:82/1D Kadıköy / ISTANBUL
Tel: [phone] Fax: [phone]
Email: k[email protected]
ANKARA REGION SALES AND TECHNICAL SERVICE CENTER
Bagdat St. 364 Zip Code:6374 OSTIM Yenimahalle / ANKARA
Tel: [phone] Fax: [phone]
Email: [email protected]
AEGEAN REGION SALES AND TECHNICAL SERVICE CENTER
Evka- 3 Nbrhd., 129/29 St. No: 25A, Zip Code: 35050 Bornova / İZMİR
Tel: [phone] Fax: [phone]
Email: [email protected]
BURSA REGION SALES AND TECHNICAL SERVICE CENTER
Nilüfer Trade Center Electricians-Hardwares Sit. 65. St. No:11 Zip Code:16120
Nilüfer / BURSA
Tel: [phone] Fax:[phone]
Email: [email protected]
CUKUROVA REGION SALES AND TECHNICAL SERVICE CENTER
Fevzipasa Nbrhd. Turhan Cemal Beriker Boulevard 336 Zip Code:1190 A
Seyhan / ADANA
Tel: [phone] Fax:[phone]
Email: [email protected]
BODRUM REGION SALES AND TECHNICAL SERVICE CENTER
Ataturk Boulevard Balkanoglu Business Center B Block No:5 Zip Code:48480
Konacik- Bodrum / MUĞLA
Tel: [phone] Fax: [phone]
Email: [email protected]
MARMARIS REGION SALES AND TECHNICAL SERVICE CENTER
Yeni Datça Road, No:105 Z1 Marmaris / MUĞLA
Tel: [phone] Fax: [phone]
Email: [email protected]
