Tektronix TMSSY2 mPGA479 User manual

Instruction Manual
TMSSY2
mPGA479 Socket Support
(Includes TMSMPH4 mPGA479
probe head installation instructions)
071-1899-00
www.tektronix.com

Copyright ©Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or
suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
HIn North America, call 1-800-833-9200.
HWorldwide, visit www.tektronix.com to find contacts in your area.

WARRANTY 2
Tektronix warrants that the products that it manufactures and sells will be free from defects in materials and
workmanship for a period of one (1) year from the date of shipment. If a product proves defective during this
warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor,
or will provide a replacement in exchange for the defective product.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by Tektronix, with
shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the Tektronix service center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been
modified or integrated with other products when the effect of such modification or integration increases the time
or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR
THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

WARRANTY 9b
Tektronix warrants that the media on which this software product is furnished and the encoding of the programs on
the media will be free from defects in materials and workmanship for a period of three (3) months from the date of
shipment. If a medium or encoding proves defective during the warranty period, Tektronix will provide a
replacement in exchange for the defective medium. Except as to the media on which this software product is
furnished, this software product is provided “as is” without warranty of any kind, either express or implied.
Tektronix does not warrant that the functions contained in this software product will meet Customer’s
requirements or that the operation of the programs will be uninterrupted or error-free.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period. If Tektronix is unable to provide a replacement that is free from defects in materials and
workmanship within a reasonable time thereafter, Customer may terminate the license for this software product
and return this software product and any associated materials for credit or refund.
THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’
RESPONSIBILITY TO REPLACE DEFECTIVE MEDIA OR REFUND CUSTOMER’S PAYMENT IS
THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS
WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER
TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES.

TMSSY2 mPGA479 Socket Hardware Support i
Table of Contents
General Safety Summary iii...................................
Service Safety Summary v....................................
Environmental Considerations vii...............................
Preface ix...................................................
Getting Started 1............................................
Logic Analyzer Configuration 2......................................
Connect the P6960 Probes and TMSCAB1 Cables 3.......................
Connect the Logic Analyzer to a SUT 5................................
Replaceable Parts List 9.............................................
Logic Analyzer Software Compatibility 10...............................
Installing the Software 10............................................
Support Package Setup 10............................................
Maintenance and Shipping 11..................................
Care and Maintenance 11.............................................
Shipping the Probe Adapter 15........................................
Specifications 17............................................
Circuit Description 17...............................................
Loading Diagrams 18................................................
Specifications 20...................................................
Certifications and Compliances 23.....................................
Appendix 29.................................................
Accessories 29.....................................................
Apply TMSCAB1 Labels 30..........................................
Probe Adapter Notes 31..............................................

Table of Contents
ii TMSSY2 mPGA479 Socket Hardware Support
List of Figures
Figure 1: Master and Slave module configuration 2...............
Figure 2: Module configuration 3..............................
Figure 3: Probe, cable and preprocessor unit 4...................
Figure4:ProbeheadinstallationusingChipcool1&2heatsink
hardware 7.............................................
Figure 5: Install heat sink (Chipcool 1 & 2) 8....................
Figure 6: Preprocessor unit in static-shielding bags 13.............
Figure 7: Folded cables 13.....................................
Figure 8: Probe head storage case 14............................
Figure 9: Probe adapter load model for typical signals 18...........
Figure 10: Preprocessor load model for typical signals 18...........
Figure 11: Receiver topology A 19..............................
Figure 12: Receiver topology B 19..............................
Figure 13: Receiver topology C 19..............................
Figure 14: Eye diagram 21.....................................
Figure 15: Dimensions of the probe head 26......................
Figure 16: Dimensions of the preprocessor unit 27.................
Figure 17: Apply TMSCAB1 labels 30...........................
List of Tables
Table 1: Preprocessor airflow clearance 5.......................
Table 2: Replaceable parts list 9...............................
Table 3: Electrical specifications for the SUT 20..................
Table 4: Electrical specifications for the AC input to the
preprocessor unit 21......................................
Table 5: BCLK timing and electrical specifications at 25 5C 21.....
Table 6: Environmental specifications 21........................

TMSSY2 mPGA479 Socket Hardware Support iii
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
The inputs are not rated for connection to mains or Category II, III, or IV
circuits.
Connect the probe reference lead to earth ground only.
Power Disconnect. The power switch disconnects the product from the power
source. See instructions for the location. Do not block the power switch; it must
remain accessible to the user at all times.
Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.
Do Not Operate With Suspected Failures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
ToAvoidFireor
Personal Injury

General Safety Summary
iv TMSSY2 mPGA479 Socket Hardware Support
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details on installing the product so it has proper ventilation.
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
These terms may appear on the product:
HDANGER indicates an injury hazard immediately accessible as you read the
marking.
HWARNING indicates an injury hazard not immediately accessible as you
read the marking.
HCAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
CAUTION
Refer to Manual
WARNING
High Voltage
Protective Ground
(Earth) Terminal Mains Disconnected
OFF (Power)
Mains Connected
ON (Power)
Terms in this Manual
Symbols and Terms
on the Product

TMSSY2 mPGA479 Socket Hardware Support v
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service
procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.

Service Safety Summary
vi TMSSY2 mPGA479 Socket Hardware Support

TMSSY2 mPGA479 Socket Hardware Support vii
Environmental Considerations
This section provides information about the environmental impact of the
product.
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the
product’s end of life. In order to avoid release of such substances into the
environment and to reduce the use of natural resources, we encourage you to
recycle this product in an appropriate system that will ensure that most of the
materials are reused or recycled appropriately.
The symbol shown to the left indicates that this product
complies with the European Union’s requirements
according to Directive 2002/96/EC on waste electrical and
electronic equipment (WEEE). For information about
recycling options, check the Support/Service section of the
Tektronix Web site (www.tektronix.com).
Battery Recycling. This product may contain a Nickel Cadmium (NiCd) or
lithium ion (Li--ion) rechargeable battery, which must be recycled or disposed of
properly. Please properly dispose of or recycle the battery according to local
government regulations.
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive. This product complies
with the RoHS Directive requirements except for the presence of hexavalent
chromium in the surface coating of the aluminum chassis parts, assembly
hardware, and 63/37 tin/lead solder used in the fabrication of the circuit boards.
Product End-of-Life
Handling
Restriction of Hazardous
Substances

Environmental Considerations
viii TMSSY2 mPGA479 Socket Hardware Support

TMSSY2 mPGA479 Socket Hardware Support ix
Preface
This manual contains specific information about the TMSSY2 preprocessor unit
and the TMSMPH4 probe head that combine to make a probe adapter. This
manual is part of a set of information on how to operate this product on
compatible Tektronix Logic Analyzers.
If you are familiar with operating microprocessor support probe adapters with the
logic analyzer, you need only this manual to set up and run the probe adapter.

Preface
xTMSSY2 mPGA479 Socket Hardware Support

TMSSY2 mPGA479 Socket Hardware Support 1
Getting Started
The TMSSY2 support product (preprocessor unit) is an interposer design that
allows the logic analyzer to acquire data from a microprocessor in the operating
environment with little affect on the SUT.
To accomplish this, the probe adapter (preprocessor unit and probe head) is
connected to the SUT, and then the microprocessor is connected to the probe
adapter. Signals from the microprocessor-based system flow through the probe
adapter cables to the logic analyzer where the loaded support software disas-
sembles data acquired from the SUT.
The TMSSY2 support product includes:
HTMSSY2 preprocessor unit
HCD-ROM with PUB32G15 support software and instruction manual
NOTE. To acquire signals from the SUT you also need compatible cables, probes,
and probe head to complete the connection between the logic analyzer and the
SUT. Contact your Tektronix sales representative for information about these
other products.
For optional and standard accessories for this product, see Accessories on
page 29.

Getting Started
2TMSSY2 mPGA479 Socket Hardware Support
Logic Analyzer Configuration
To use the probe adapter to acquire state signals, you need a Tektronix Logic
Analyzer equipped with four, merged 235 MHz, TLA7Ax4 logic analyzer
modules.
The modules must be configured and merged as shown in Figure 1. The memory
depth is automatically based on the shallowest memory depth of the modules.
The term Master module refers to the second module of a 4-wide module
configuration. (See Figure 1). The term Slave module refers to the modules to
the left or right of the Master module.
M
A
S
T
E
R
S
L
A
V
E
2
S
L
A
V
E
1
S
L
A
V
E
3
Figure 1: Master and Slave module configuration
All signals are acquired through probes connected to the logic analyzer. Use the
logic analyzer modules and the P6960 probes to connect to the probe adapter.
The probes should already be labeled; if you need to apply labels, refer to the
instructions that came with your probe documentation.
CAUTION. To prevent damage to the P6960 connectors on the preprocessor unit,
Tektronix recommends that you use the strain relief method that is described in
the P69XX Series Instruction Manual, Tektronix part number 071-1528-XX, after
connecting the P6960 probes.
You can access the P69XX Series Instruction Manual from the Tektronix.com
Web site.

Getting Started
TMSSY2 mPGA479 Socket Hardware Support 3
Connect the P6960 Probes and TMSCAB1 Cables
Use the P6960 probes and the TMSCAB1 cables to connect to the TLA7Ax4
logic analyzer modules to the preprocessor unit.
NOTE. If you need to attach labels to TMSCAB1 cables, refer to Appendix 30.
Modules
TMSCAB1
cables
P6960
probes Description
Support
Software
45(M,S1,S2) 6(M,S3) Does not acquire auxiliary
common clock signals
PUB32G15
M
A
S
T
E
R
S
L
A
V
E
2
S
L
A
V
E
1
S
L
A
V
E
3
TMSCAB1 cables (5) P6960 probes (4)
P6960 probes (2)
Figure 2: Module configuration
1. From the Master module, match the label on the TMSCAB1 cable with the
corresponding connector label on the preprocessor unit and connect the
cable. The TMSCAB1 cable connector is keyed for correct alignment to the
preprocessor unit.
2. Use care to evenly tighten both screws on the module end of the probes or
cables until they are snug. First slightly tighten both screws, then snug each
screw to 4 in-lbs (max).
3. Repeat step 1 to attach the TMSCAB1 cables with the Slave1 and Slave2
modules.
TMSCAB1 Cables

Getting Started
4TMSSY2 mPGA479 Socket Hardware Support
CAUTION. To prevent damage to the probe and preprocessor unit, always
position the probes perpendicular to the footprint on the circuit board. Incorrect
handling of the probe while connecting to or disconnecting from the preproces-
sor unit can damage the probe.
When attaching the probe head, use care to evenly tighten the probe head screws
until they are snug. First, tighten both screws until the nut bar makes contact
with the board surface, and then snug each screw to 1 in-lbs (max). Under-tight-
ening the screws can result in intermittence. Over-tightening can result in
damage to the elastomer holder and stripped screws.
4. Match the A, D, C, and E probes from the Slave3 and Master module with
the corresponding D3/D2 and A3/A2, D1/D0 and A1/A0, C1/C0 and C3/C2,
and E3/E2 and E1/E0 connector labels on the preprocessor unit. The P6960
probe connector is keyed for correct alignment to the preprocessor unit.
NOTE. To prevent faulty connections and loss of data, check that the probe board
connections are clean and free of debris.
TMSCAB1 cable
P6960
Single-ended probe
Figure 3: Probe, cable and preprocessor unit
P6960 Probes

Getting Started
TMSSY2 mPGA479 Socket Hardware Support 5
Connect the Logic Analyzer to a SUT
CAUTION. To prevent static damage to the microprocessor, the probe adapters,
the probes, and the module, handle components only in a static-free environment.
Always wear a grounding wrist strap, heel strap, or similar device while
handling the microprocessor and probe adapter.
WARNING. To prevent harm to yourself or damage to the preprocessor unit, do
not open the preprocessor unit. There are no operator serviceable parts inside
the preprocessor unit. Refer servicing of internal parts in the preprocessor unit
to Tektronix authorized personnel only. External parts may be replaced by
qualified service personnel.
Table 1 lists airflow clearances for the preprocessor unit.
Table 1: Preprocessor airflow clearance
Characteristic Description
Required airflow clearances for the
preprocessor
Front, top, left side 5.08 cm (2 in)
Back 7.60 cm (3 in)
Bottom, right side 0.635 cm (0.250 in)
Following is a list of tools:
HRequired. Use a flatbladed screwdriver (0.1-in tip width) to lock the ZIF
socket.
HRequired. Phillips (P1) screwdriver to tighten the screws that attach the
heatsink brackets.
HOptional. A torque wrench helps to ensure reliable connections to meet the
nominal torque values that may be listed in these instructions. When
attaching screws to the probe head use 2 in-lbs (0.226 Newton meters) of
torque, unless stated otherwise.
NOTE. For storage and shipping, retain the cardboard cartons and packing
material that are shipped with the probe adapter.
For a list of replaceable parts, see page 9.
Airflow Clearance
Tools

Getting Started
6TMSSY2 mPGA479 Socket Hardware Support
Read the following instructions before removing or installing parts.
Use the following steps to connect the logic analyzer to the SUT:
1. Power off the SUT. It is not necessary to power off the logic analyzer.
2. Power off any preprocessor units that may be attached to your SUT.
NOTE. To discharge static electricity, touch the ground connector located on the
logic analyzer.
3. Remove the heat sink and any retention brackets from the SUT.
CAUTION. To prevent damage to the probe head and pins, you must always
handle the probe head carefully and use care to properly align the probe head
pins to the ZIF socket on the SUT. Also, reinstall the pin protector on the bottom
of the probe head when the probe head is not in use.
4. Attach the TMSMPH4 probe head.
To attach the probe head to the SUT use the Chipcool 1&2 heat sink
attachment kit (020-2616-XX) and follow the steps shown in Figures 4 & 5
startingonpage7.
Connect the Logic
Analyzer
