Tektronix MTS415 User manual

xx
MTS400 Series
Generator Applications
ZZZ
User Manual
*P077020400*
077-0204-00

MTS400 Series
Generator Applications
ZZZ
User Manual
xx
www.tektronix.com
077-0204-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
General Safety Summary ........................................................................................ vii
Preface.............................................................................................................. ix
Documentation................................................................................................ xi
Multiplexer - Getting Started........... .......... ........................ .......... ............................... 1
H.264 ES Input Characteristics............................................................................... 4
Starting the Program........................................................................................... 5
Scripts........................................................................................................... 7
Opening a Stream............................................................................................. 12
Closing Files .................................................................................................. 16
Menus and Controls ............................................................................................... 17
Menu Options ................................................................................................. 17
Toolbar......................................................................................................... 21
Status Bar...................................................................................................... 21
User Interface ................................................................................................. 22
Wizards ............................................................................................................. 27
Transport Wizard ............................................................................................. 27
Program Wizard............................................................................................... 31
Views................................................................................................................ 43
Navigator Views .............................................................................................. 43
Section View .................................................................................................. 47
Structure Diagram Manipulation............................................................................ 56
Event Log...................................................................................................... 57
Examine Transport Stream Window........................................................................ 58
SI Filtering......... ........................ .......... ........................ .......... ........................ 60
Component Views ............................................................................................ 64
Common Menu Options...................................................................................... 71
Editing in the Navigator Views ................................ .................. .................. .............. 72
Dragging and Dropping...................................................................................... 72
Transport Stream.............................................................................................. 72
Programs....................................................................................................... 73
Tables .......................................................................................................... 75
Sections ........................................................................................................ 78
ES PIDs........................................................................................................ 86
DSM-CC....................................................................................................... 95
Editing in Section View. .................. .................................................. .................. .... 98
Editing Fields............ .......................... .............................. .......................... .... 98
Multiplexing Transport Streams ..... .................. ................................ .................. ...... 104
Starting the Multiplex Engine ........... .................. ................................ ................ 104
Errors and Reporting ....................................................................................... 105
MTS400 Series Generators User Manual i

Table of Contents
Stopping the Multiplex Engine.... .......... .......................... .......... .......................... 106
Exporting the Multiplex Configuration File ............................................................. 106
Make Seamless................................................................................................... 108
Enabling the Seamless Option............................................................................. 108
Seamless Settings........................................................................................... 108
Reference......................................................................................................... 110
Abbreviations ............................................................................................... 110
Transport Stream Editor ........................................................................................ 113
Starting the Program........................................................................................ 114
Options....................................................................................................... 115
Opening a File............................................................................................... 117
Menus and Controls............................................................................................. 120
Toolbar....................................................................................................... 120
Status Bar.................................................................................................... 120
Slider Bar.................................................................................................... 121
Menu Options ............................................................................................... 123
Hex Editor........................................................................................................ 126
Color Coding................................................................................................ 126
Selecting & Editing............... .................. ................................ .................. ...... 127
Header Editor .................................................................................................... 130
Header Information Tab.................................................................................... 130
Adaptation Field Tab ....................................................................................... 132
Adaptation Field Extension Tab........................................................................... 134
PID Remapping.................................................................................................. 136
PCR Recalculation .............................................................................................. 139
Jitter Functions .. .. .. .. ..... .. .. ..... .. .. .. .. .. .. ........ .. .. .. .. .. .. ..... .. .. ..... .. .. .. .. .. .. .. ..... .. .. ... 146
MPEG Player - Getting Started ...................... .......... .......... .......... .......... .......... ........ 151
Display Elements ........................................................................................... 152
Hierarchical Display........................................................................................ 157
Menus and Controls............................................................................................. 171
Menus in the Play Screen .................................................................................. 171
Menus in the Record Screen............................................................................... 209
Toolbar Buttons ............................................................................................. 215
Reference......................................................................................................... 217
Interface Card (SPI/ASI/310M Option).................................................................. 217
Adding Jitter to PCRs .............................. .............. .............. .............. .............. 218
Using Preset Files........................................................................................... 220
Using the Continuous Recording Feature................................................................ 221
Performing Continuous Recording ....................................................................... 222
Remote Commands......................................................................................... 224
ii MTS400 Series Generators User Manual

Table of Contents
Make Seamless Wizard ......................................................................................... 225
Starting the Wizard ......................................................................................... 225
Selecting an Input File ..................................................................................... 227
Select a Program to Make Seamless...................................................................... 230
Selecting a Multiplex Output File........... .................. ................................ ............ 233
Transport Stream Cutter ........................................................................................ 235
Starting the Wizard ......................................................................................... 237
Cutting a File ...... .......... .......... .......... .......... .......... .......... .............................. 237
Script Pad - Getting Started .................... .................................. .... .......................... 241
Setting Up ............. ........................ ........................ .............. .......... .............. 241
Starting the Program........................................................................................ 241
Initial Appearance .......................................... .............. .............. .............. ...... 242
Initial Menu Options ....................................................................................... 242
Script File Appearance..................................................................................... 243
Opening a File............................................................................................... 243
Menu and Controls .............................................................................................. 246
Menu Bar .................................................................................................... 246
Toolbar....................................................................................................... 248
Status Bar.................................................................................................... 249
Script File Editing and Encryption ........................................ .................. .................. 250
Keyword Color-Coding .................................................................................... 250
Parsing ....................................................................................................... 250
Encryption................................................................................................... 250
Index
MTS400 Series Generators User Manual iii

Table of Contents
List of Figures
Figure 1: Expert mode ............................................................................................ 54
Figure 2: Standard mode.......................................................................................... 55
Figure 3: Optional status bar................................................................................... 156
Figure 4: IP status bar........................................................................................... 156
Figure 5: Example of the hierarchical display................................................................ 158
Figure 6: PCR Inaccuracy dialog box......................................................................... 169
Figure 7: Clock dialog box for Option Interface............................................................. 174
Figure 8: Clock dialog box for IP interface................................................................... 174
Figure 9: Default Clock Dialog box........................................................................... 177
Figure 10: PCR Initial Value dialog box ........ ................................................ .............. 179
Figure 11: Start/Stop Position dialog box..... .................................................... ............ 180
Figure 12: Timer Play/Record dialog box .................................................................... 182
Figure 13: Others dialog box................................................................................... 183
Figure 14: TDT/TOT dialog box .............................................................................. 184
Figure 15: ISDB/P-TS dialog box............................................................................. 185
Figure 16: Select Update Item dialog box.................................................................... 186
Figure 17: IP Configuration for IPv4.......................................................................... 188
Figure 18: IP Configuration for IPv6.......................................................................... 189
Figure 19: Advanced Protocol Settings dialog box for IPv4 ..... .. ..... ..... .. ............ ............ .... 191
Figure 20: Advanced Protocol Settings dialog box for IPv6 ... ............ ............ ............ .. ...... 191
Figure 21: Stream Replication Settings for IPv4............................................................. 193
Figure 22: Stream Replication Settings for IPv6............................................................. 193
Figure 23: Error Insertion dialog box ......................................................................... 197
Figure 24: Windows Firewall/Internet Connection Sharing (ICS)........................... .............. 202
Figure 25: Automatic Updates Properties .................................................................... 203
Figure 26: IIS Admin Properties............................................................................... 204
Figure 27: Java Control Panel.................................................................................. 205
Figure 28: Java Update-Warning .............................................................................. 205
Figure 29: Registry Editor...................................................................................... 206
Figure 30: Edit DWORD Value................................................................................ 207
Figure 31: Communication dialog box........................................................................ 208
Figure 32: PCR Inaccuracy dialog box ....................................................................... 218
iv MTS400 Series Generators User Manual

Table of Contents
List of Tables
Table i: Overview of the applications........................................................................... ix
Table 1: PTS/DTS Timestamp Updations ...... .................................. .... ........................... 4
Table 2: File menu options ........................................................................................ 6
Table 3: View menu options....................................................................................... 7
Table 4: Script management...................................................................................... 11
Table 5: File menu options ....................................................................................... 17
Table 6: Edit menu options....................................................................................... 18
Table 7: View menu options...................................................................................... 18
Table 8: Options menu options .................................................................................. 19
Table 9: Multiplex menu options ................................................................................ 20
Table 10: Window menu options ................................................................................ 20
Table 11: Help menu options..................................................................................... 21
Table 12: Icons..................................................................................................... 23
Table 13: Examine TS - File menu options..................................................................... 58
Table 14: Examine TS - Edit menu options .................................................................... 58
Table 15: File menu options.................................................................................... 123
Table 16: Edit menu options ................................................................................... 124
Table 17: View menu options .................................................................................. 124
Table 18: Tools menu options.................................................................................. 125
Table 19: Help menu options................................................................................... 125
Table 20: Icons used for MPEG-2, ARIB, DVB, and ATSC formats...................................... 159
Table 21: Icons specific to DVB format ...................................................................... 162
Table 22: Icons specific to ARIB format...................................................................... 163
Table 23: Icons specific to ATSC format ..................................................................... 165
Table 24: Icon text............................................................................................... 166
Table 25: PCR Inaccuracy dialog box parameters........................................................... 169
Table 26: File menu commands (Play screen)................................................................ 171
Table 27: View menu commands (Play screen).............................................................. 172
Table 28: Play menu commands (Play screen)............................................................... 172
Table 29: SPI/ASI/310M menu commands (Play screen)................................................... 187
Table 30: IP menu commands.................................................................................. 187
Table 31: Utility menu commands. .............. .............. .............. .............. .................... 207
Table 32: File menu commands (Record screen) ............................................................ 210
Table 33: Record menu commands............................................................................ 211
Table 34: SPI/ASI/310M menu command (Record screen) ................................................ 215
Table 35: Toolbar button descriptions......................................................................... 215
Table 36: File options........................................................................................... 242
Table 37: View menu options .................................................................................. 243
MTS400 Series Generators User Manual v

Table of Contents
Table 38: File menu options.................................................................................... 246
Table 39: Edit menu options ................................................................................... 247
Table 40: View menu options .................................................................................. 247
Table 41: Window menu options .............................................................................. 247
Table 42: Script menu options ................................................................................. 248
Table 43: Help menu options................................................................................... 248
vi MTS400 Series Generators User Manual

General Safety Summary
General SafetySummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
To Avoid Fire or Personal
Injury
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power Disconnect. The power cord disconnects the product from the power source.
Do not block the power cord; it must remain accessible to the user at all times.
Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.
Do Not Operate With Suspected Failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Use Proper Fuse. Use only the fuse type and rating specified for this product.
Wear Eye Protection. Wear eye protection if exposure to high-intensity rays or
laser radiation exists.
MTS400 Series Generators User Manual vii

General Safety Summary
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details on installing the product so it has proper ventilation.
TermsinthisManual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION.Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
viii MTS400 Series Generators User Manual

Preface
Preface
The MTS400 Series MPEG systems are described in three user manuals. The
applications are available on the following MTS400 Series products:
MTS415
MTS430
MTS400P
MTX100B (where installed)
Table i: Overview of the applications
Application Desktop icon
MTS400 Series analyzer application
Transport Stream Compliance Analyzer (TSCA) - Real-time transport stream analysis with user-selectable
MPEG-2, DVB, ATSC and ISDB conformance tests. Shows transport structure, header contents,
hexadecimal packet contents, PCR timing/transport rate graphs, and error message logs.
Transport Stream Compliance Analyzer (TSCA) - Deferred transport stream analysis with user-selectable
MPEG-2, DVB, ATSC and ISDB conformance tests. Shows transport structure, header contents,
hexadecimal packet contents, PCR timing/transport rate graphs, and error message logs.
Packetized Elementary Stream (PES) Analyzer - PES analysis with selectable test options. Shows PES
program structure, header contents, packet contents, PTS/DTS timing graphs, and analysis reports.
Transport Stream - System Target Decoder (T-STD) - Buffer Analyzer analyzes program streams modeling
their behavior in, and their conformance to, the MPEG-2 T STD Buffer Model.
Elementary Stream Analyzer - Elementary Stream analysis at video picture and audio level. This includes
vector graphs and macroblock picture quality.
‘
Carousel Analyzer - Data analysis showing structure, bit rate, repetition rate, syntax and semantics of
data items.
MTS400 Series Generators User Manual ix

Preface
Table i: Overview of the applications (cont.)
Application Desktop icon
MTS400 Series generators application
Multiplexer - Multiplexes table information and packetized elementary streams together to synthesize new
transport streams. A fine level of control is provided to allow nonconformances and test cases to be
specified for new transport streams.
TS Editor - Viewing and editing transport stream packets, using a hexadecimal view of the packet contents
and semantic interpretation of the header. Provides facilities to remap PIDs, recalculate PCR values and
introduce PCR inaccuracies.
MPEG Plyer- Records and plays MPEG-2 streams. (The MTX100B/RTX100B/RTX130B players are
described in: MTX100B Quick Start User Manual, Tektronix part number 071-2593-xx and RTX100B Quick
Start User Manual, Tektronix part number 071-2595-xx)
Make Seamless Wizard - Guides the user through the process of creating an MPEG-2 file for use by
Stream Player in continuously looped operation.
TS Cutter - Extracts sections of MPEG-2 files to new files.
Script Pad - Enables users to create and modify System Information (SI) scripts.
TTS Utility - Converts time stamped transport streams to standard transport stream format.
MTS400 Series carousel applications
Carousel Generator - Provides in-depth off-line generation of MPEG-2, DVB transport streams containing
a range of data broadcast protocols.
Carousel Analyzer Data analysis showing structure, bit rate, repetition rate, syntax and semantics of
data items.
x MTS400 Series Generators User Manual

Preface
Documentation
The following related documentation for the instrument is available:
Item Purpose Location
MTS400 Series Quick Start User Manual
(071-2607-xx English, 071-2608-xx
Japanese)
Describes how to install and get
started using the test systems.
MTS400 Series Analyzer Applications User
Manual (077-0205-xx)
Describes the operation of the
following analyzer applications:
TSCA, PES Analyzer, T-STD Buffer
Analyzer, and ES Analyzer.
MTS400 Series Generator Applications
User Manual (077-0204-xx)
Describes the operation of the
following generator applications:
Multiplexer, MPEG Player, TS
Editor, Make Seamless Wizard,
Transport Stream Cutter, and Script
Pad.
MTS400 Series Carousel Applications User
Manual (077-0203-xx)
Optional manual supporting
module-level servicing of the
instrument.
MTS400 Series Release Notes
(077-0200-xx)
Describes known issues with the
test systems.
MTS400 Series Programmer Manual
(077-0206-xx)
Describes the operation of the
MTS4EA application software.
MTS4EA Compressed Video Elementary
Stream Analyzer User Manual
(071-1641-xx)
Describes the operation of the
MTS4EA application software.
MTS4CC Elementary Stream Compliance
Checker User Manual (071-2075-xx)
Describes the operation of the
MTS4CC application software.
MTS400 Series Generators User Manual xi

Preface
xii MTS400 Series Generators User Manual

Multiplexer - Getting Started
The Tektronix Multiplexer provides off-line multiplexing of ATSC, MPEG-2,
DVB, and ISDB transport streams.
Transport streams (TS), Elementary Streams (ES), Packetized Elementary Streams
(PES), and Packet Identifiers (PID) can be selected, manipulated and recombined
to form customized, synthesized transport streams. Program Specific Information
(PSI), Service Information (SI), and Program and System Information Protocol
(PSIP) are often referred to as simply SI in this section.
MTS400 Series Generators User Manual 1

Multiplexer - Getting Started
The functions provided include:
Wizards for common tasks, such as populating streams with Program Specific
Information/Service Information/Program and System Information Protocol
(PSI/SI/PSIP), and programs.
Table contents that are displayed in and edited from structure diagrams (tree
diagrams).
Transport Streams that either conform strictly to the standards selected for
interpretation or have precisely engineered, known, nonconformances.
Two or more instances of Multiplexer can run concurrently. This allows table
information to be copied from one file to another.
The source data for nonconformant streams can be saved in a raw format,
which can be quickly reloaded as the basis for generating more stream data.
Conformance of edits to the standards is checked interactively and enforced
by default. Checking and enforcement may be turned off when specifying
nonconformances to be introduced into the new transport stream.
On opening, streams are analyzed and displayed according to the selected
standard: MPEG, DVB, ATSC, or ISDB. Scripts are used by the analysis process;
this allows private PSI/SI tables and descriptors to be defined.
NOTE. Most examples given in this section of the manual are based on DVB SI.
You should remember that the Multiplexer is equally at home with all major DTV
standards, MPEG-2, DVB, ATSC, and ISDB as well as the major extensions to
those standards.
The Transport Stream Analyzer program should always be used for reliable
analysis of transport streams containing DSM-CC or MPE addressable sections.
In the absence of TS Analyzer, it is acceptable to use Multiplexer for analysis,
provided that the DSM-CC or MPE scripts are first applied using Expert mode in
the Stream Interpretation dialog box (See page 7, Scripts.).
However, when multiplexing streams containing DSM-CC or MPE addressable
sections, the related scripts must not be active.
Multiplexer in Playout
Mode
You can initiate a playout in the Muliplexer application using the playout feature
as soon as the multiplex operation is complete. Multiplexer creates a temporary
transport stream in the location specified by the Playout Settings and then initiates
a playout by loading this file into the player. To play the stream in the loop mode,
enable the loop mode in the Playout settings.
To open Playout Settings dialog box, select Multiplex >Playout settings.
2 MTS400 Series Generators User Manual
