Tektronix PSM3000 Series User manual

xx
PSM3000, PSM4000,
and PSM5000 Series
RF and Microwave Power Sensors/Meters
ZZZ
User Manual
*P077059201*
077-0592-01

PSM3000, PSM4000,
and PSM5000 Series
RF and Microwave Power Sensors/Meters
ZZZ
User Manual
xx
www.tektronix.com
077-0592-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of three
(3) years from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at
its option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W4 – 15AUG04]

Table of Contents
Preface............................................................................................................... v
Safety Information............................................................................................. v
About This Manual............................................................................................ v
Products........................................................................................................ vi
Key Features .................................................................................................. vi
Where To Find More Information ......................................................................... vii
Getting Started ..... .................. ........................................ .................. ..................... 1
Install the Software............................................................................................ 1
Connect to a Computer........................................................................................ 6
Start An Application.......................................................................................... 10
Functional Check ............................................................................................. 10
Operating Basics................................................................................................... 13
Measurement Capabilities ................. .................. ................................ ................ 14
CW (Average) Measurements............................................................................... 14
Pulse Measurements.......................................................................................... 15
PulseProfiling................................................................................................. 16
Configure Instrument for Measurements................................................................... 17
Power Meter Application......................................................................................... 19
Front Panel Elements......................................................................................... 19
Make an Average Power (CW) Measurement ............................................................. 27
Make a Pulse Measurement Using Duty Cycle............................................................ 28
Make a Pulse Power Measurement ......................................................................... 29
Pulse Profiling Application....................................................................................... 31
Menu Features................................................................................................. 31
Toolbar Functions............................................................................................. 36
Make a Marker Measurement ............................................................................... 48
Make a Gated Measurement................................................................................. 49
High Speed Logger Application ................................................................................. 52
Menu Functions............................................................................................... 53
Make a Simple Measurement................................................................................ 58
Troubleshooting............................................................................................... 59
Index
RF and Microwave Power Sensors/Meters i

Table of Contents
List of Figures
Figure 1: Power Meter application interface using a PSM5120.............................................. 19
Figure 2: Diagram of a burst time slot .......................................................................... 23
Figure 3: Pulse Profiling application interface................................................................. 31
Figure 4: Gate positioning diagram ............................................................................. 44
Figure 5: Position of gates for measurement ............. ...................... ...................... .......... 51
Figure 6: High Speed Logger application window ............................................................ 52
ii RF and Microwave Power Sensors/Meters

Table of Contents
List of Tables
Table i: Product documentation................................................................................. vii
Table 1: Functions by instrument model........................................................................ 13
Table 2: Power Meter default values ............................................................................ 25
Table 3: Sweep time values ...................................................................................... 37
RF and Microwave Power Sensors/Meters iii

Table of Contents
iv RF and Microwave Power Sensors/Meters

Preface
Preface
Safety Information
Product general safety information, EMC and safety compliance, and
environmental compliance information for the products discussed in this manual
are located in the Installation and Safety Instructions. You can find this document
in print form in the box that shipped with your product, in electronic form on
the USB memory device in the box that shipped with your product, or online at
www.tektronix.com/manuals. Please refer to that document before installing
and using this product.
About This Manual
This document contains the following information about the Tektronix PSM3000
Series, PSM4000 Series, and PSM5000 Series RF and Microwave Power
Sensors/Meters:
The Getting Started chapter provides an overview of instrument features,
installation instructions, and a functional check procedure. (See page 1.)
The Operating Basics chapter provides information about how measurements
work, how to configure the instrument for making measurements, and
information about averaging, pulse measurements, CW measurements, and
pulse profiling. (See page 13.)
The Power Meter Application chapter provides information about using this
application. (See page 19.)
The Pulse Profiling Application chapter provides information about using this
application. (See page 31.)
The High Speed Logger Application chapter provides information about using
this application. (See page 52.)
RF and Microwave Power Sensors/Meters v

Preface
Products
The Tektronix PSM3000 Series, PSM4000 Series, and PSM5000 Series RF
and Microwave Power Sensors/Meters convert radio frequency (RF) and
microwave power into digital data at the point of measurement. They are ideal
for troubleshooting and characterization in the lab, and can be used for radio
frequency (RF) component testing. These products connect directly to a desktop
or laptop computer with a USB 2.0 port and cable.
Product Description Connector type
PSM3110 10MHz-8GHz 3.5mm-male
PSM3120 10MHz-8GHz N-Type male
PSM3310 10MHz-18GHz 3.5mm-male
PSM3320 10MHz-18GHz N-Type male
PSM3510 10MHz-26.5GHz 3.5mm-male
PSM4110 10MHz-8GHz 3.5mm-male
PSM4120 10MHz-8GHz N-Type male
PSM4320 50MHz-18GHz N-Type male
PSM4410 50MHz-20GHz 3.5mm-male
PSM5110 100MHz-8GHz 3.5mm-male
PSM5120 100MHz-8GHz N-Type male
PSM5320 50MHz-18GHz N-Type male
PSM5410 50MHz-20GHz 3.5mm-male
Key Features
Reading rates up to 2000 readings per second
Meters are calibrated over full temperature range: No zero or cal needed
before making measurements, saving time and avoiding poor-quality data
Average power, duty cycle corrected pulse power, and measurement logging
on all models
Max hold and relative measurement modes
Offset, frequency response, and 75 Ωminimum loss pad correction
Flexible averaging modes for quick, stable measurements
TTL trigger input and output allow synchronization with external instruments
Pass/Fail limit mode
The PSM3000 series offers True Average power measurements that give
accurate results regardless of signal shape or modulation
vi RF and Microwave Power Sensors/Meters

Preface
The PSM4000 and PSM5000 series offer average power, pulse power, duty
cycle, peak power, and crest factor measurements
The PSM5000 series includes a Pulse Profiling application for making
measurements on repetitive, pulsed signals
Where To Find More Information
You can find more information about your instrument in the following
documents. These documents can be found on the Tektronix Web site at
www.tektronix.com/manuals, on the product documentation USB device that
shipped with your instrument, or both.
Table i: Product documentation
To read about Use these documents
Product compliance, safety, and
set up and installation information
Installation and Safety Instructions available printed, on the product documentation USB device
that shipped with your instrument, and for download at www.tektronix.com/manuals.
Operation, configuration, and
application information
User manual (this manual) available in English, German, French, Spanish, Italian, Portuguese,
Russian, Korean, Japanese, Simplified Chinese, and Traditional Chinese on the product
documentation USB device that shipped with your instrument and for download at
www.tektronix.com/manuals.
Specifications and field verification
procedures
Specifications and Field Verification Technical Reference available on the product
documentation USB device that shipped with your instrument, and for download at
www.tektronix.com/manuals.
Declassification and security Declassification and Security Instructions available for download at www.tektronix.com/manuals.
Programming information Programmer’s Manual available on the product documentation USB device that shipped with
your instrument, and for download at www.tektronix.com/manuals.
Online help Online help is available in the SW application you load onto your computer when you first
install the instrument.
RF and Microwave Power Sensors/Meters vii

Preface
viii RF and Microwave Power Sensors/Meters

Getting Started
This section provides the following information:
How to install the software
How to install the USB driver and connect to a computer
How to start and application and perform a functional check
Install the Software
Before connecting the instrument to a computer, you need to first load
the software provided on the USB memory device that shipped with your
instrument. You can also find the latest software on the Tektronix Web site at
www.tektronix.com/software.
Computer, System, and
USB Requirements
Computer hardware requirements. The computer onto which you are downloading
the instrument software must have at least 2 GB RAM and a USB 2.0 port that
supplies more than 450 mA at 5 V.
Power requirements. This instrument is powered through the USB cable when
connected to a computer. The USB 2.0 port of the computer must supply more
than 450 mA at 5 V. Tektronix recommends using the USB cable supplied with
this product. The supplied cable has 20 AWG power conductors that are a heavier
gauge than most USB cables.
NOTE. Refer to the Specifications section of the PSM3000, PSM4000, and
PSM5000 Series RF and Microwave Power Sensors/Meters Specifications and
Field Verification Technical Reference for additional information on electrical
requirements.
Hub recommendations. A USB host port on a computer will provide adequate
power for the instrument under normal circumstances. However, if you use a
USB cable longer than 3 to 5 meters, are connecting multiple instruments, or
are using a portable computer that runs on battery power, you will need to use
an active or self-powered hub.
The instrument typically draws 450 mA at a nominal 5 VDC. An active hub
compensates for the DC voltage drop in a USB cable longer than 3 to 5 meters.
It also conserves battery life in a portable computer.
System Requirements. The instrument software you are downloading is
compatible with the following operating systems:
RF and Microwave Power Sensors/Meters 1

Getting Started
Windows XP, Service Pack 3
Windows Vista
Windows 7 (32 or 64-bit, or XP mode)
Software Installation
Procedure
This procedure allows you to install one or more of the following software
applications or programs:
Power Meter application: provides a virtual power meter front panel for your
instrument. Use the application software to make power meter measurements.
High-speed Logging application: allows you to take raw, high-speed
readings from your instrument.
Pulse Profiling application: (PSM5000 series only) provides the tools for
complete characterization of a modulated signal.
Sample Code: provides programming examples for remote control of
the instrument. You can read more about remote programming in the
PSM3000, PSM4000, and PSM5000 Series RF and Microwave Power
Sensors/Meters Programming Manual available on the Tektronix Web site at
www.tektronix.com/manuals.
2 RF and Microwave Power Sensors/Meters

Getting Started
1Go to www.tektronix.com and search for the most
recent software version for this product and download
it to your computer. Once downloaded, double click on
the .exe file to start installation.
NOTE. You can also insert the USB memory device
that shipped with your instrument into the computer
USB drive. The installation should start automatically.
If the installation does not start automatically, select
Start > Run and the media drive and a semicolon (D:
for example), and then \setup.exe or the location of the
setup.exe file you downloaded from the Tektronix Web
site, and then press OK.
2The installer will open and guide you through the
installation procedure. Select Next to continue.
3If you have a previous version of the instrument
software, uninstall it before proceeding.
If you are ready to continue installation, click Next.
RF and Microwave Power Sensors/Meters 3

Getting Started
4Read the license agreement and select Iagreeand
then click Next to continue.
5The installer is ready to install the following software
on your computer (this will vary depending on options
and instrument model):
Power Meter application
Pulse Profiling application
High Speed Logger
Sample Code
Click Next to continue.
4 RF and Microwave Power Sensors/Meters

Getting Started
6Confirm location for download or provide a location,
and then click Next.
7When prompted, confirm installation by selecting Next.
RF and Microwave Power Sensors/Meters 5

Getting Started
8When the installation is complete, a dialog box will
appear stating that the software was successfully
installed. Select Close to exit.
9Each downloaded application will now have an
associated icon on the Desktop of your computer.
Before opening the application, connect the instrument
to your computer. (See page 6, Connect to a
Computer.)
Connect to a Computer
Install the USB Driver This instrument is powered through a USB cable that you attach to a computer.
Use the following procedure to install the USB driver so that the computer can
communicate with the instrument. Once the driver is installed, you can start the
Power Meter application software and any other instrument applications that
were installed.
NOTE. Tektronix recommends using the USB cable supplied with this product.
The supplied cable has 20 AWG power conductors that are a heavier gauge than
most USB cables.
6 RF and Microwave Power Sensors/Meters
