Tektronix Tektronix SPG8000 Use and care manual

xx
SPG8000
Master Sync / Clock Reference Generator
Specifications and Performance Verification
ZZZ
Technical Reference
*P077074801*
077-0748-01

SPG8000
Master Sync / Clock Reference Generator
Specifications and Performance Verification
ZZZ
Technical Reference
xx
This document applies to firmware version 1.1 and above.
www.tektronix.com
077-0748-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, with shipping
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
General safety summary .......................................................................................... iv
Preface............................................................................................................. vii
Related user documents..................................................................................... vii
Specifications ....................................................................................................... 1
SPG8000 base unit specifications............................................................................ 1
Option BG specifications ..................................................................................... 9
Option AG specifications .................................................................................... 10
Option SDI specifications.................................................................................... 11
Option GPS specifications................................................................................... 16
Performance verification.......................................................................................... 19
Performance verification preparation....................................................................... 19
Diagnostics tests .............................................................................................. 21
SPG8000 base unit performance verification.............................................................. 26
Option AG performance verification ....................................................................... 59
Option BG performance verification ....................................................................... 64
Option GPS performance verification ...................................................................... 73
Option SDI and Option 3G performance verification..................................................... 88
SPG8000 Specifications and Performance Verification i

Table of Contents
List of Figures
Figure 1: SPG8000 dimensions................................................................................... 8
Figure 2: Setup to verify clock accuracy........................................................................ 31
Figure 3: Setup for genlock test.................................................................................. 32
Figure 4: Setup for genlock bit integrity test................................................................... 38
Figure 5: Setup for LTC input gain and impedance test....................................................... 41
Figure 6: Setup for black output and frame pulse test......................................................... 42
Figure 7: Setup for black output bit integrity test.............................................................. 44
Figure 8: Setup for Black amplitude and offset test (SD)............................... ...................... 45
Figure 9: Setup for trilevel sync output test and black output rise and fall time test....................... 47
Figure 10: Setup for sine amplitude test ........................................................................ 50
Figure 11: Setup for LTC level test.............................................................................. 51
Figure 12: Setup for GPI output test ............................................................................ 53
Figure 13: Setup for GPI input test.............................................................................. 56
Figure 14: Setup for 48 kHz clock output test ................................................................. 57
Figure 15: Oscilloscope setup for serial digital audio outputs test....... .......................... .......... 61
Figure 16: Audio monitor setup for serial digital audio outputs test......................................... 63
Figure 17: Setup for tri-level sync and black (PAL) output tests............................................. 67
Figure 18: Setup for Black amplitude and offset test (SD) – Option BG ..... .............. ................ 69
Figure 19: Setup for Composite offset and gain test........................................................... 70
Figure 20: Setup for luminance and chrominance test ........................................................ 71
Figure 21: Setup for DC antenna output power voltage test.................................................. 77
Figure 22: Setup for the GPS or GLONASS signal lock from antenna test ................................ 80
Figure 23: Setup for frequency accuracy and frame timing accuracy tests ................................. 83
Figure 24: Setup for internal frequency calibration ........................................................... 86
Figure 25: Setup for output and jitter test................................. .................................. .... 95
Figure 26: Setup for reference against the DMM.............................................................. 97
Figure 27: Set up the digital signal analyzer ................................................................... 98
Figure 28: Setup for characterization of the test system ...................................................... 99
Figure 29: Setup for SDI output amplitude test .................. .............. .............. .............. .. 101
ii SPG8000 Specifications and Performance Verification

Table of Contents
List of Tables
Table 1: Timebase characteristics................................................................................. 1
Table 2: Interface characteristics ................................................................................. 2
Table 3: Power characteristics .................................................................................... 3
Table 4: Black and sine outputs................................................................................... 4
Table 5: LTC outputs............................................................................................... 4
Table 6: Genlock, VITC and LTC input ......................................................................... 5
Table 7: Word clock output specifications....................................................................... 6
Table 8: SPG8000 environmental characteristics............................................................... 6
Table 9: SPG8000 mechanical characteristics................................................................... 7
Table 10: Black and Composite outputs ......................................................................... 9
Table 11: AES/EBU Serial Digital Audio outputs and Silence outputs ..................................... 10
Table 12: Option SDI serial video outputs...................................................................... 11
Table 13: SDI7 video signal content ............................................................................ 12
Table 14: SDI embedded audio and ancillary data..................... .............. .......... .............. .. 13
Table 15: SDI7 SD-525 (720 × 486) ............................................................................ 14
Table 16: SDI7 SD-625 (720 × 576) ............................................................................ 14
Table 17: SDI7 HD-SDI (1920 × 1080)......................................................................... 14
Table 18: SDI7 HD-SDI (1280 × 720).......................................................................... 14
Table 19: SDI7 3G Level A (1920 × 1080) (option 3G only) ................................................ 14
Table 20: SDI7 3G Level A (1280 × 720) (option 3G only).................................................. 14
Table 21: SDI7 3G Level A (2K × 1080) (option 3G only) .................................................. 14
Table 22: SDI7 3G Level B (1920 × 1080) (option 3G only) ................................................ 15
Table 23: SDI7 3G Level B (2K × 1080) (option 3G only)................................................... 15
Table 24: SDI7 3G Level B (2×HD 1920 × 1080) (option 3G only) ........................................ 15
Table 25: SDI7 3G Level B (2xHD 1280 × 720) (option 3G only).......................................... 15
Table 26: GPS or GLONASS antenna input ................................................................... 16
Table 27: GPS timebase .......................................................................................... 16
Table 28: Diagnostics test record................................................................................ 21
Table 29: Required equipment for SPG8000 base unit performance verification.......................... 26
Table 30: SPG8000 base unit test record ....................................................................... 27
Table 31: Required equipment for Option AG performance verification ................................... 59
Table 32: Option AG test record................................................................................. 60
Table 33: Required equipment for Option BG performance verification.................................... 64
Table 34: Option BG test record................................................................................. 65
Table 35: Required equipment for Option GPS performance verification .................................. 73
Table 36: Option GPS test record................................................................................ 75
Table 37: Required equipment for Option SDI performance verification................................... 88
Table 38: Option SDI test record ................................................................................ 89
SPG8000 Specifications and Performance Verification iii

General safety summary
General safetysummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
To avoid fire or personal
injury
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Ground theproduct. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power disconnect. The power cord disconnects the product from the power source.
Donotblockthepowercord;itmustremain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels
removed.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.
Wear eye protection. Wear eye protection if exposure to high-intensity rays or
laser radiation exists.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Provide proper ventilation. Refer to the manual's installation instructions for details
on installing the product so it has proper ventilation.
iv SPG8000 Specifications and Performance Verification

General safety summary
Terms in this manual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the
product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARN ING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
SPG8000 Specifications and Performance Verification v

General safety summary
vi SPG8000 Specifications and Performance Verification

Preface
This manual describes the specifications and performance verification procedures
for the SPG8000 Master Sync / Clock Reference Generator, with or without all of
the available options.
This manual is divided into two sections:
Specifications provides physical and electrical characteristics
Performance verification provides procedures to verify the warranted
characteristics of the base unit and all options.
Related user documents
The following table contains a list of documents that include user information
about the SPG8000 generator.
Availability
Document Tektronix Part Number Description Print Web CD
Quick Start User Manual 071-3080-xx (English)
077-0745-xx (Japanese)
077-0746-xx (Russian)
Describes how to install the
instrument and provides basic
operating information
Technical Reference 077-0747-xx Provides detailed operating
information
Specifications and
Performance Verification
(this document)
077-0748-xx Lists the product specifications and
provides procedures for verifying
the performance of the instrument
Service Manual 077-0749-xx Describes how to service the
instrument to the module level
(such as circuit boards and fuses)
Declassification and
Security Instructions
077-0750-xx Describes how to clear or sanitize
the data storage (memory) devices
in the product for customers with
data security concerns.
Release Notes 077-0751-xx Describes the new features,
improvements, and limitations of
the instrument firmware
Video Sync Pulse
Generator and Electronic
Changeover Unit System
Integration Technical
Reference
077-0563-xx
(ECO422D
077-0877-xx
(ECO8000, ECO8020)
Provides information for system
integrators who are designing
systems for high-definition (HD)
and standard-definition (SD) digital
video content where Tektronix
electronic changeover units and
video sync pulse generators are to
be deployed.
SPG8000 Specifications and Performance Verification vii

Preface
viii SPG8000 Specifications and Performance Verification

Specifications
The information in this section provides electrical, mechanical, and environmental
specifications for the SPG8000 generator.
The performance requirements listed in the electrical characteristics portion of
these specifications apply over an ambient temperature range of 0 °C to +50 °C.
The rated accuracies are valid when the instrument is calibrated at an ambient
temperature range of +20 °C to +30 °C, after a warm-up time of 20 minutes.
SPG8000 base unit specifications
The following tables list certification and compliance information, and the
electrical, environmental, and mechanical characteristics of the SPG8000 base
unit.
Table 1: Timebase characteristics
Characteristic Performance requirements Reference information
Frequency accuracy in Internal
mode
±135 x 10-9 over 1 year calibration
interval
After 20 minute instrument warm up. Includes
drift and temperature variation. Initial setting
after adjustment will typically be within 10 x 10-9.
Frequency accuracy over
temperature
±2 x 10-9 for ±5 °C variation, ±10 x 10-9
for 0 to50°C
Frequency drift, aging <±10
0x10
-9 per year for internal, stay
current frequency and stay genlock
modes at constant temperature
Frequency variation from vibration
and shock
±25 x 10-9 typical from 6 ms half-sine
shocks over 20 g
Genlock range ±7.5 x 10-6
SPG8000 Specifications and Performance Verification 1

Specifications
Table 2: Interface characteristics
Characteristic Performance requirements Reference information
Keyboard 17 buttons with green LED backlight, 6 Fault
indicators with Red / Green backlight.
Display LCD with 2 line x 40 characters with
backlight, 153 x 15 mm active area.
Ethernet functionality 1000base-T, 100BASE-TX and 10BASE-T
Compliant with IEEE 802.3-2000 and ANSI
X3.263-1995 standards
Ethernet connector 8P8C connector supporting 10/100 BaseT The 8P8C (also known as RJ45) connector
has built in LEDs. The Green LED indicates
an active connection. The Yellow LED
indicates speed. ON = 100, OFF = 10.
Wiring follows TIA/EIA-568-B T568A
standard Ethernet pin assignments.
GPI General Purpose Interface for uses such as
setting presets or driving alarms. The 15
pin connection has 1 configurable input and
2configurable outputs. The 9 pin carries
the same signal as the 15 pin plus three
inputs used to select presets and one more
configurable output.
Logical functions The function of some of the input and outputs
may be set from the user interface.
Ground closure
Input signaling TTL thresholds of 0.8 V low and 2.0 V high,
5 V max input, –0.5 V min input.
Pull low to assert.
Has internal 10 kΩpull-up to +5 V on each
input.
Input timing Inputs must be asserted and stable for at
least 60 ms to be recognized reliably. Inputs
that are stable for 40 ms or less will not be
recognized.
Output characteristics Three open collector outputs Has internal 10 kΩpull-up to +5 V.
Max current allowed is 100 mA.
On resistance is approximately 4 Ohms
Maximum output current 250 mA On resistance is approximately 4 Ohms
Output duration Signal alarms asserted as long as the
error condition exists. Timer based outputs
asserted for the 1 second that the selected
time counter matches the user defined time.
USB
Type Host
Speed USB 1.0 and 2.0 full-speed (12 Mb/s)
2 SPG8000 Specifications and Performance Verification

Specifications
Table 3: Power characteristics
Characteristic Performance requirements Reference information
AC power source
Rating voltage 100 V to 240 V WARNING. To reduce the risk of fire and
shock, ensure the mains supply voltage
fluctuations do not exceed 10% of the
operating voltage range.
Frequency 50/60 Hz
Maximum power 130 VA Actual power varies with type and number of
modules installed. Base instrument without
modules typically draws 20 watts.
Surge current, typical 20 A peak (25 °C) for ≤5 line cycles, after
the instrument has been turned off for at
least 30 seconds.
Inrush current, typical 10 A RMS half cycle at initial turn on as per
EN55103-1:2009 Annex B.
Supply connection Detachable IEC cord set, locking versions
available for some geographies.
Locking cords for: USA, Japan, UK, Europe,
Switzerland, China, and Australia.
Dual supply hot swap The instrument can run with either or both
supplies. Any plugging or un-plugging
supplies or AC input to the supplies will not
cause disruption in the system, as long as at
least one supply is active. The supplies take
1-2 sec to power up after AC is applied.
Dual supply operation When two supplies are present, one will be
used to power the instrument and the other
will be in an unloaded backup mode.
Keeping the backup supply unloaded
minimizes its aging and maximizes the life
available if the primary supply fails.
Power supply life tracking Each supply maintains a usage history,
which provides the ability to recommend
replacement. Each supply tracks the
time in use, the time in standby, and the
Temperature Weighted Hours calculation that
helps predict the end of life on the supply.
The Temperature Weighted Hour calculation
uses the temperature at each hour to predict
the failure point on the supply.
Power supply life expectancy,
typical
15 years (131,400 hours) at 25 °C outside
air, 5 years at 50 °C outside air temperature.
The Temperature Weighed Hours calculation
accounts for the aging acceleration at higher
temperatures and normalizes it to hours at
25 °C.
Power supply load testing The backup supply will periodically be tested
to insure it can support the instrument load
should the primary supply fail. This load is
approximately 55 watts and is applied for
about 6 sec.
SPG8000 Specifications and Performance Verification 3

Specifications
Table 4: Black and sine outputs
Characteristic Performance requirements
Number of outputs Three outputs, all can be black, or Black #3 can be configured as 10 MHz sine wave. Black #2
can be configured to blank during certain errors to trigger an ECO change-over.
Formats Each output is individually selectable between Bi-level NTSC with or without field ref, NTSC No
setup with or without field pulse, PAL with or without field ref, or Tri-level. The base outputs
can only generate tri-leval at one clock rate, so all three can be any one of the two sets: Set
1: 1080i59.94, 720p59.94, 1080p23.98, 1080sf23.98. Set 2: 1080p29.97 1080i60, 1080i50,
720p60, 720p50, 1080p24, 1080p30, 1080sf24, 1080p25.
Standards supported RS170A, SMPTE RP154, SMPTE318M, EBU N14, SMPTE240M, 274M, 296M, and RP211.
Output impedance 75 Ohms
Return loss, typical 40 dB from 300kHzto5MHz,30dBto30MHz
Amplitude in DC output mode ±1% on difference of 0 and 700 mv DC levels
Amplitude Standard level for selected format ±2%
Offset 0±50mV
Offset in DC output mode 0±40mV
Bi-Level sync rise and fall time,
typical
140 ns for NTSC, 250 ns for PAL
Tri-Level sync rise and fall time,
typical
50 ns
SCH ±5 deg for NTSC and PAL
Timing adjust composite Each output individually adjustable over ± ½ the color frame with 0.5 deg of subcarrier
resolution.
Timing Adjust HD rates Each output individually adjustable over ±½ the frame with <20 ns resolution.
Signal-to-Noise ratio, typical >60 dB RMS noise relative to 700 mV. DC to 20 MHz.
Sine output amplitude 1.5 Vp-p ±10%
Table 5: LTC outputs
Characteristic Performance requirements
Formats 23.98, 24, 25, 30, 30 drop as per SMPTE 12M
Output level accuracy 5 V ±10% at max level. Differential into 600 Ω
Output level range Adjustable from 0.5 to 5 V into 600 Ω
Output level adjust resolution,
typical
0.5 V steps
Output rise and fall time, typical 40 μs
Output Impedance 30 Ωfor each output
Output load 600 nominal, 150 min
Timing adjust range ±1 half a frame for selected format
Timing adjust resolution 10 μs steps
Timecode offset range 24 hours
Timecode offset resolution 1 frame
4 SPG8000 Specifications and Performance Verification

Specifications
Table 6: Genlock, VITC and LTC input
Characteristic Performance requirements
Genlock input type Two 75 ΩBNC connectors; passive loop through
Genlock input formats Bi-Level NTSC, NTSC with SMPTE318 10 field flag, PAL; Tri-level HD 1080i59.94, 1080i50,
720p59.94, 720p60, 1080p23.98, 1080p24. 1080p29.97, 1080p30, 1080p25; CW 10 MHz
Genlock input video signal level
range, typical
-8 to +6 dB with nominal operation
Genlock input CW signal level
range, typical
0.5to2V
p-p signal
Genlock input DC tolerance +5 V max or damage may occur
Genlock hum tolerance -3 dB of 50 or 60 Hz hum
Genlock white noise tolerance -33 dB Min SNR of 5 MHz BW noise
Genlock SCH tolerance +40 deg
Genlock return loss, typical ≥30 dB from 300 kHz to 10 MHz
Jitter in NTSC and PAL Burst Lock,
typical
<0.5° with ±3 dB amplitude change and >40 dB S/N ratio
Jitter in Tri- level Sync Lock, typical <1 ns with ±3 dB amplitude change and >40 dB S/N ratio
JitterinCWLock,typical <1nswith1V
p-p ±3 dB amplitude change and >40 dB S/N ratio
LTC input LTC1 output can be configured as an input
LTC input – formats supported 23.98, 24, 25, 29.97 drop frame, and 30 Hz
LTC input – timing to video To correctly associate the LTC with a given video frame, the LTC start bit should be from 32 μs
before to 160 μs after the start of the first broad pulse in vertical blanking of a compatible frame
rate being used as the genlock input. This is as specified in SMPTE12M
Will accept input timing anywhere in the frame, however near the middle of the video frame
the timing may be interpreted as related to the previous or next video frame. A status screen
indicates the detected timing in ms
LTC input – signal voltage range 0.5 to 10 Vp-p differential, 1 V to 5 Vp-p single ended
LTC input – noise tolerance -30 dB SNR RMS white noise with 10 kHz BW to the p-p signal level, or -10 dB SNR for
5 MHz white noise
LTC input – hum tolerance 0 dB hum to signal ratio
LTC input – error immunity 100 consecutive frames with consistent time code must be detected for time to be considered
valid
LTC input impedance, typical Nominal 600 Ωdifferential, 300 Ωsingle-ended
VITC – video formats supported +VITS can be decoded from NTSC and PAL as per SMPTE 12M-1 2008
VITC – lines on which VITC is
detected
+VITC is detected on lines 6 to 22 for all formats (ERI) 12M specified range for NTSC is
lines 10 to 20
VITC – timing in line VITC conforming to the standard timing will be detected. VITC slightly outside the normal
timing range may also be detected, but it must not run into burst or sync
VITC – allowed video SNR VITC will be correctly decoded for signals with more than 30 dB SNR
SPG8000 Specifications and Performance Verification 5

Specifications
Table 7: Word clock output specifications
Characteristic Description
Connector BNC
Output 48 kHz clock
Output level range and coupling Selectable as 1 V AC coupled or 2.5 V DC coupled into 75 Ω. Unterminated, this gives 2 V
ora5Vswing
Output rise and fall time, typical 33 ns
Output Impedance 75 Ω
Returnloss,typical 46dBto10MHz
Association to video May be configured to be phased up with any of the three internal frame pulses
Alignment to video, typical At default timing, a positive going Word Clock transition will align to the appropriate event
in the selected video signal within ±1.0 μs
Table 8: SPG8000 environmental characteristics
Characteristic Description
Operating 0 °C to +50 °C, with 15 °C/hour maximum gradient, noncondensing, derated 1 °C per 300 m
above 1,500 m altitude.
Temperature
Nonoperating –20 °C to +60 °C, with 15 °C/hour maximum gradient, without disk media installed in disk
drives.
Operating 20% to 80% at up to +30 °C, maximum wet-bulb temperature of +29 °C (derates relative
humidity to 20% relative humidity at +50 °C)
Relative
Humidity
Nonoperating 5% to 90% (relative humidity) at up to +40 °C, maximum wet-bulb temperature of 40.0 °C
(derates relative humidity to 30% relatgive humidity at +60 °C)
Operating To 3.0 km (10,000 feet)
Maximum operating temperature decreases 1 °C each 300 m above 1.5 km.
Altitude
Nonoperating To 15 km (50,000 feet)
Operating 0.27 GRMS, 5 Hz to 500 Hz, 10 min per axis, three axes
Vibration
Nonoperating 2.28 GRMS, 5 Hz to 500 Hz, 10 min per axis, three axes
Shock, operating Half-sine mechanical shocks, 30 g peak amplitude, 11 ms duration, 3 drops in each direction
of each axis (18 total)
Side 5cm Clearance
Rear 5cm
6 SPG8000 Specifications and Performance Verification
