Tektronix AFG3000C Series Use and care manual

AFG3000C and AFG3000 Series
Arbitrary Function Generators
Specifications and Performance Verification
ZZZ
Technical Reference
xx
www.tek.com
*P077069103*
077-0691-03

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Additional trademark statements can be added here.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
General safety summary .......................................................................................... iv
Service safety summary........................................................................................... 1
Preface............................................................................................................... 3
Finding other information..................................................................................... 4
Manual conventions ........................................................................................... 4
Specifications ....................................................................................................... 5
Electrical specifications ....................................................................................... 5
Input and output specifications.............................................................................. 18
General specifications ........................................................................................ 19
Performance verification.......................................................................................... 23
Self tests ....................................................................................................... 23
Error codes .................................................................................................... 25
Performance tests ............................................................................................. 27
Test record..................................................................................................... 29
Frequency/period test......................................................................................... 51
Amplitude test................................................................................................. 52
DC Offset test ................................................................................................. 54
AC Flatness test............................................................................................... 56
Harmonics Distortion test.................................................................................... 59
Total Harmonic Distortion test .............................................................................. 62
Spurious test................................................................................................... 64
Rise-Fall time test............................................................................................. 67
AFG3000C and AFG3000 Series Specifications and Performance Verification i

Table of Contents
List of Figures
Figure 1: AFG3000 Series dimensions ......................................................................... 21
Figure 2: RM3100 Rackmount dimensions .................................................................... 21
Figure 3: Frequency/period test.................................................................................. 51
Figure 4: 50 Ω terminator accuracy ............................................................................. 52
Figure 5: Amplitude test.......................................................................................... 52
Figure 6: 50 Ω terminator accuracy ............................................................................. 54
Figure 7: DC offset tests.......................................................................................... 54
Figure 8: 50 Ω terminator accuracy ............................................................................. 56
Figure 9: 1 kHz setup for AC Flatness test ..................................................................... 56
Figure 10: >1 kHz setup for AC Flatness test.................................................................. 57
Figure 11: Harmonic distortion tests ............................................................................ 59
Figure 12: Total Harmonic distortion tests ..................................................................... 62
Figure 13: Spurious tests ......................................................................................... 64
Figure 14: Rise-Fall time tests ................................................................................... 67
ii AFG3000C and AFG3000 Series Specifications and Performance Verification

Table of Contents
List of Tables
Table 1: Supported products....................................................................................... 3
Table 2: Operating mode .......................................................................................... 5
Table 3: Waveforms................................................................................................ 6
Table 4: (Category) specifications................................................................................ 6
Table 5: Phase (except DC, Noise, and Pulse) .................................................................. 9
Table 6: Lead delay (pulse)........................................................................................ 9
Table 7: Amplitude................................................................................................. 9
Table 8: DC offset................................................................................................. 10
Table 9: Internal noise add ....................................................................................... 11
Table 10: Output characteristics ................................................................................. 11
Table 11: Modulation ............................................................................................. 15
Table 12: Front panel ............................................................................................. 18
Table 13: Rear panel .............................................................................................. 18
Table 14: Power ................................................................................................... 19
Table 15: Environmental ......................................................................................... 19
Table 16: System characteristics ................................................................................ 19
Table 17: Error codes ............................................................................................. 25
Table 18: Performance test items ............................................................................... 27
Table 19: Test equipment ........................................................................................ 29
Table 20: AFG3000 Series Performance Test Record......................................................... 30
AFG3000C and AFG3000 Series Specifications and Performance Verification iii

General safety summary
General safetysummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
To avoid fire or personal
injury
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Ground the product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power disconnect. The power cord disconnects the product from the power source.
Donotblockthepowercord;itmustremain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels
removed.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Provide proper ventilation. Refer to the manual's installation instructions for details
on installing the product so it has proper ventilation.
iv AFG3000C and AFG3000 Series Specifications and Performance Verification

General safety summary
Terms in this manual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the
product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbols may appear on the product:
AFG3000C and AFG3000 Series Specifications and Performance Verification v

General safety summary
vi AFG3000C and AFG3000 Series Specifications and Performance Verification

Service safety summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service
procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
DisconnectPower. To avoid electric shock, disconnect the mains power by means
of the power cord or, if provided, the power switch.
UseCareWhenServicingWithPowerOn. Dangerousvoltagesorcurrentsmay
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.
AFG3000C and AFG3000 Series Specifications and Performance Verification 1

Service Safety Summary
2 AFG3000C and AFG3000 Series Specifications and Performance Verification

Preface
This manual provides instructions to verify the performance of the AFG3000C
and AFG3000 Series Arbitrary Function Generators to the module level.
Unless noted otherwise, the term “AFG3000 Series” refers to the models in the
following table.
Table 1: Supported products
AFG3011 AFG3021B AFG3011C
AFG3101 AFG3022B AFG3021C
AFG3102 AFG3022C
AFG3251 AFG3051C
AFG3252 AFG3052C
AFG3101C
AFG3102C
AFG3151C
AFG3152C
AFG3251C
AFG3252C
To prevent personal injury or damage to the instrument, consider the following
before attempting service:
The procedures in this manual should be performed only by a qualified service
person.
Read the General Safety Summary and the Service Safety Summary at the
beginning of this document.
When using this manual for servicing, be sure to follow all warnings, cautions,
and notes.
The manual consists of the following sections:
Specifications contains a description of the instrument and the characteristics
that apply to it.
Performance Verification contains procedures for confirming that the
instrument functions properly and meets warranted limits.
The procedures described in this document should be performed every 12
months or after module replacement.
If the instruments do not meet performance criteria, repair is necessary.
AFG3000C and AFG3000 Series Specifications and Performance Verification 3

Preface
Finding other information
This manual focuses on the performance verification of the instrument. See the
following list for other documents supporting the instrument on www.tek.com.
Document Description
AFG3000C and AFG3000 Series
Quick Start User Manual
A quick reference to major features of the instrument and how they operate. It also provides
several tutorials to familiarize you with basic instrument features.
AFG3000C and AFG3000 Series
Programmer Manual
An encyclopedia of topics that describe the instrument interface and features, and gives
background information on how to use them. It provides Menu Structures, User Interface, and
Programming Information.
AFG3000C and AFG3000 Series
Online Help
A online help system, integrated with the User Interface application that ships with this
product. The help is preinstalled in the instrument.
Manual conventions
This manual uses certain conventions that you should become familiar with.
Some sections of the manual contain procedures for you to perform. To keep those
instructions clear and consistent, this manual uses the following conventions:
Front-panel controls and menu names appear in the same case (initial capitals,
all uppercase, and so on) in the manual as is used on the instrument front panel
and menus. Front-panel labels are all upper case letters (for example, MENU,
SELECT, PULSE GEN, and so on).
Instruction steps are numbered unless there is only one step.
Modules Throughout this manual, any replaceable component, assembly, or part of the
instrument is referred to generically as a module. In general, a module is an
assembly (such as a circuit board). Sometimes a single component is a module;
for example, the chassis of the instrument is a module.
Safety Symbols and terms related to safety appear in the Safety Summary near the
beginning of this manual.
4 AFG3000C and AFG3000 Series Specifications and Performance Verification

Specifications
These specifications apply to all AFG3000C and AFG3000 Series Arbitrary
Function Generators, unless otherwise stated. All specifications are guaranteed
unless labeled “typical”. Typical specifications are provided for your convenience
but are not guaranteed.
Specifications that are check marked with the symbol are checked directly (or
indirectly) in the Performance Verification section.
All specifications apply to the arbitrary function generator unless noted otherwise.
These specifications are valid under the following conditions:
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
The instrument must be operating at an ambient temperature between 0 °C
and +50 °C.
The instrument must have had a warm-up period of at least 20 minutes.
The instrument must be in an environment with temperature, altitude, and
humidity within the operating limits described in these specifications.
Electrical specifications
Table 2: Operating mode
Characteristic Description
Run mode Continuous, Modulation, Sweep, and Burst
Burst count 1 to 1,000,000 cycles or infinite
Internal trigger rate 1.000 μs to 500.0 s
AFG3000C and AFG3000 Series Specifications and Performance Verification 5

Specifications
Table 3: Waveforms
Characteristic Description
Standard Sine, Square, Pulse, Ramp, More (Sin(x)/x, Noise, DC, Gaussian, Lorentz, Exponential Rise,
Exponential Decay, and Haversine)
Arbitrary waveform
Waveform length 2 to 131,072
Sampling rate
AFG3021B / 3022B /
3021C / 3022C / 3011/
3011C
250 MS/s
AFG3101 / 3101C / 3102
/ 3102C / 3151C / 3152C
/ 3051C / 3052C
250 MS/s or 1 GS/s (rate changes automatically at ≤16K)
AFG3251 / 3251C / 3252
/ 3252C
250 MS/s or 2 GS/s (rate changes automatically at ≤16K)
Resolution 14 bits
Number of nonvolatile
waveform memories
4
Table 4: (Category) specifications
Characteristic Description
PV reference
page
Frequency range
Sine 1
AFG3011 / 3011C 1μHz to 10 MHz
AFG3021B / 3021C /
3022B / 3022C
1μHz to 25 MHz
AFG3051C / 3052C 1μHz to 50 MHz
AFG3101 / 3101C / 3102
/ 3102C
1μHz to 100 MHz
AFG3151C / 3152C 1μHz to 150 MHz
AFG3251 / 3251C / 3252
/ 3252C
1μHz to 240 MHz
Square
AFG3011 / 3011C 1μHz to 5 MHz
AFG3021B / 3022B 1μHz to 12.5 MHz
AFG3021C / 3022C 1μHz to 25 MHz
AFG3051C / 3052C 1μHz to 40 MHz
AFG3101 / 3101C / 3102
/ 3102C
1μHz to 50 MHz
AFG3151C / 3152C 1μHz to 100 MHz
6 AFG3000C and AFG3000 Series Specifications and Performance Verification

Specifications
Table 4: (Category) specifications (cont.)
Characteristic Description
PV reference
page
AFG3251 / 3251C / 3252
/ 3252C
1μHz to 120 MHz
Pulse
AFG3011 / 3011C 1 mHz to 5 MHz
AFG3021B / 3022B 1 mHz to 12.5 MHz
AFG3021C / 3022C 1mHzto25MHz
AFG3051C / 3052C 1mHzto40MHz
AFG3101 / 3101C / 3102
/ 3102C
1mHzto50MHz
AFG3151C / 3152C 1mHzto100MHz
AFG3251 / 3251C / 3252
/ 3252C
1mHzto120MHz
Ramp, Sin(x)/X, Gaussian, Lorentz, Exponential Rise, Exponential Decay, Haversine
AFG3011 / 3011C 1μHz to 100 kHz
AFG3021B / 3022B 1μHz to 250 kHz
AFG3021C / 3022C 1μHz to 500 kHz
AFG3051C / 3022C 1μHz to 800 kHz
AFG3101 / 3101C / 3102
/ 3102C
1μHz to 1 MHz
AFG3151C / 3152C 1μHz to 1.5 MHz
AFG3251 / 3251C / 3252
/ 3252C
1μHz to 2.4 MHz
Arbitrary 2
AFG3011 / 3011C 1 mHz to 5 MHz
AFG3021B / 3021C /
3022B / 3022C
1 mHz to 12.5 MHz
AFG3051C / 3052C 1mHzto25MHz
AFG3101 / 3101C / 3102
/ 3102C
1mHzto50MHz
AFG3151C / 3152C 1mHzto100MHz
AFG3251 / 3251C / 3252
/ 3252C
1mHzto120MHz
Noise bandwidth (-3 dB), typical
AFG3011 / 3011C 10 MHz
AFG3021B / 3021C /
3022B / 3022C
25 MHz
AFG3051 / 3052C 50 MHz
AFG3000C and AFG3000 Series Specifications and Performance Verification 7
AFG3101 / 3101C / 3102
/ 3102C
100 MHz
AFG3151C / 3152C 150 MHz
AFG3251 / 3251C / 3252
/ 3252C
240 MHz

Specifications
8 AFG3000C and AFG3000 Series Specifications and Performance Verification

Specifications
Table 4: (Category) specifications (cont.)
Characteristic Description
PV reference
page
Resolution 1 μHz or 12 digits
Accuracy stability ±1 ppm, 0 °C to 50 °C (except Arb)
±1ppm±1mHz,0°Cto50°C(Arb)
(See page 51,
Frequency/period
test.)
Accuracy aging ±1 ppm/year
1Triggered/Gated Burst mode:
AFG3011 / 3011C, 1 μHz to 5 MHz;
AFG3021B/3021C/3022B/3022C, 1 μHz to 12.5 MHz;
AFG3051C/3052C, 1 μHz to 25 MHz;
AFG3101/3101C/3102/3102C, 1 μHz to 50 MHz;
AFG3151C/3152C, 1 μHz to 75 MHz;
AFG3251/3251C/3252/3252C,1μHz to 120 MHz
2Triggered/Gated Burst mode:
AFG3011/3011C, 1mHz to2.5MHz;
AFG3021B/3021C/3022B/3022C, 1 mHz to 6.25 MHz;
AFG3051C/3052C, 1 MHz to 12.5 MHz;
AFG3101/3101C/3102/3102C, 1 mHz to 25 MHz;
AFG3151C/3152C, 1 mHz to 50 MHz;
AFG3251/AFG3252, 1 mHz to 60 MHz
Table 5: Phase (except DC, Noise, and Pulse)
Characteristics Description
Range 1–360° to +360°
1Resolution: 0.01° (sine), 0.1° (other standard waveforms)
Table 6: Lead delay (pulse)
Characteristic Description
Range
Continuous mode 0 ps to period
Triggered/Gated Burst mode 0 ps to period – [pulse width + 0.8 * (leading edge time + trailing edge time)]
Resolution 10 ps or 8 digits
Table 7: Amplitude
Characteristic Description
PV reference
page
Range 1,3
AFG3011 / 3011C 20 mVp-p to 20 Vp-p
40 mVp-p to 40 Vp-p (into open circuit load)
AFG3021B / 3021C / 3022B /
3022C / 3051C / 3052C
10 mVp-p to 10 Vp-p
20 mVp-p to 20 Vp-p (into open circuit load)
AFG3101 / 3101C / 3102 /
3102C / 3151C / 3152C
20 mVp-p to 10 Vp-p
40 mVp-p to 20 Vp-p (into open circuit load)
AFG3000C and AFG3000 Series Specifications and Performance Verification 9

Specifications
Table 7: Amplitude (cont.)
Characteristic Description
PV reference
page
AFG3251 / 3252 / 3251C /
3252C
50 mVp-p to5V
p-p
100 mVp-p to 10 Vp-p (into open circuit load)
Accuracy (See page 52,
Amplitude test.)
AFG3011 / 3011C ±(2% of setting +2 mV) (at 1 kHz sine waveform amplitude > 10 mVp-p,
0V offset)
AFG3021B / 3021C / 3022B /
3022C / 3101 / 3101C / 3102 /
3102C / 3151C / 3152C/ 3251
/ 3251C / 3252 / 3252C
±(1% of setting +1 mV) (at 1 kHz sine waveform, amplitude > 10 mVp-p,
0 V offset)
Resolution 0.1 mVp-p,0.1mV
rms, 1 mV, 0.1 dBm or 4 digits
Units 2Vp-p,V
rms, dBm, and Volt (High level and Low level)
Output impedance 50 Ω
Isolation 42 Vpk maximum to earth
1 AFG3251/ 3251C / 3252 / 3252C (frequency range: >200 MHz to 240 MHz): 50 mVp-p to 4 Vp-p into 50 Ω,100mVp-p to 8 Vp-p into open circuit load.
2 dBm is used only for sine waveform. Vrms is not available for Arb and Noise waveforms.
3 AFG3151C/ 3152C (frequency range: >100 MHz to 150 MHz): 20 mVp-p to8Vp-p into 50 Ω,40mVp-p to 16 Vp-p into open circuit load.
Table 8: DC offset
Characteristic Description
PV reference
page
Range
AFG3011 / 3011C ±(10 Vpk ac+dc into 50 Ω
±(20 Vpk ac+dc into open circuit
AFG3021B / 3021C / 3022B /
3022C / 3051C / 3052C
±(5 Vpk ac+dc into 50 Ω
±(10 Vpk ac+dc into open-circuit load
AFG3101 / 3101C / 3102 /
3102C / 3151C / 3152C
±5 V DC into 50 Ωload
±10 Vpk ac+dc into open-circuit load
AFG3251 / 3251C / 3252 /
3252C
±2.5 V DC into 50 Ωload
±5 V DC open circuit
Accuracy 1
±(1% of |setting| +5 mV + 0.5% of amplitude (Vp-p)
±(2% of |setting| +10 mV + 1% of amplitude (Vp-p)) (AFG3011C)
(See page 54,
DC Offset test.)
AFG3011 / 3011C
AFG3021B / 3021C / 3022B /
3022C / 3101 / 3101C / 3102
/ 3102C / 3151C / 3152C /
3251 / 3251C / 3252 / 3252C
±(1% of |setting| +5 mV + 0.5% of amplitude (Vp-p))
Resolution 1 mV
Output impedance 50 Ω
1AFG3011/3011C:Add1.0mVper°Cforoperationoutsidetherangeof20°Cto30°C.
AFG3021B / 3021C / 3022B / 3022C and AFG3101 / 31010C / 3102 / 3102C / 3151C / 3152C: Add 0.5 mV per °C for operation outside the range of 20 °C to
10 AFG3000C and AFG3000 Series Specifications and Performance Verification
30 °C.
AFG3251 / 3251C / 3252 / 3252C: Add 2.0 mV per °C for operation outside the range of 20 °C to 30 °C.

Specifications
Table 9: Internal noise add
Characteristic Description
Range 0% to 50% of amplitude setting
Resolution 1%
Table 10: Output characteristics
Characteristic Description
PV reference
page
Sine wave
Flatness (at 1.0 Vp-p amplitude (+4 dBm), relative to 1 kHz) (See page 56,
AC Flatness
test.)
AFG3011 / 3011C <5MHz: ±0.15dB
5MHz≤frq ≤10 MHz: ±0.3 dB
AFG3021B / 3021C /
3022B / 3022C
<5MHz: ±0.15dB
5MHz≤frq < 20 MHz: ±0.3 dB
20 MHz ≤frq ≤25 MHz: ±0.5 dB
AFG3051C / 3052C <5MHz: ±0.15dB
5MHz≤frq < 45 MHz: ±0.3 dB
45MHz ≤frq ≤50 MHz: ±0.5 dB
AFG3101 / 3101C / 3102
/ 3102C
<5MHz: ±0.15dB
5MHz≤frq < 25 MHz: ±0.3 dB
25 MHz ≤frq ≤100 MHz: ±0.5 dB
AFG3151C / 3152C <5MHz: ±0.15dB
5MHz≤frq < 25 MHz: ±0.3 dB
25 MHz ≤frq ≤150 MHz: ±0.5 dB
AFG3251 / 3251C / 3252
/ 3252C
<5MHz: ±0.15dB
5MHz≤frq < 25 MHz: ±0.3 dB
25 MHz ≤frq < 100 MHz: ±0.5 dB
100 MHz ≤frq < 200 MHz: ±1.0 dB
200 MHz ≤frq ≤240 MHz: ±2.0 dB
Harmonic distortion (at 1.0 Vp-p amplitude) (See page 59,
Harmonics
Distortion test.)
AFG3011 / 3011C 10 Hz ≤frq < 20 kHz: < –60 dBc
20 kHz ≤frq < 1 MHz: < –55 dBc
1MHz≤frq ≤10 MHz: < –45 dBc
AFG3021B / 3021C /
3022B / 3022C
10 Hz ≤frq < 20 kHz: < –70 dBc
20 kHz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 10 MHz: < –50 dBc
10 MHz ≤frq ≤25 MHz: < –40 dBc
AFG3000C and AFG3000 Series Specifications and Performance Verification 11

Specifications
Table 10: Output characteristics (cont.)
Characteristic Description
PV reference
page
AFG3051C / 3052C 10 Hz ≤frq < 20 kHz: < –70 dBc
20 kHz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 5 MHz: < –50 dBc
5MHz≤frq ≤50 MHz: < –40 dBc
AFG3101 / 3101C / 3102
/ 3102C
10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 5 MHz: < –50 dBc
5MHz≤frq ≤100 MHz: < –37 dBc
AFG3151C / 3152C 10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 5 MHz: < –50 dBc
5MHz≤frq ≤150 MHz: < –37 dBc
AFG3251 / 3251C / 3252
/ 3252C
10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 5 MHz: < –50 dBc
5MHz≤frq < 25 MHz:< –37 dBc
25 MHz ≤frq ≤240 MHz: < –30 dBc
Total harmonic distortion
(at 1 Vp-p amplitude)
10 Hz to 20 kHz: < 0.2% (See page 62,
Total Harmonic
Distortion test.)
Spurious 1(nonharmonic) (at 1 Vp-p amplitude) (See page 64,
Spurious test.)
AFG3011 / 3011C 10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq ≤10 MHz: < –50 dBc
AFG3021B / 3021C /
3022B / 3022C
10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq ≤25 MHz: < –50 dBc
AFG3051C / 3052C 10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq ≤50 MHz: < –50 dBc
AFG3101 / 3101C / 3102
/ 3102C
10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 25 MHz: < –50 dBc
25 MHz ≤frq ≤100 MHz: –50 dBc + 6 dBc/octave
AFG3151C / 3152C 10 Hz ≤frq < 1 MHz: < –60 dBc
1MHz≤frq < 25 MHz: < –50 dBc
25 MHz ≤frq ≤150 MHz: –50 dBc + 6 dBc/octave
AFG3251 / 3251C / 3252
/ 3252C
10 Hz ≤frq < 1 MHz: < –50 dBc
1MHz≤frq < 25 MHz: < –47 dBc
25 MHz ≤frq ≤240 MHz: –47 dBc + 6 dBc/octave
Phase noise, typical (at 1 Vp-p amplitude)
AFG3011 / 3011C 10 MHz: < –110 dBc/Hz at 10 kHz offset
AFG3021B / 3021C /
3022B / 3022C / 3051C
/ 3052C / 3101 / 3101C /
3102 / 3102C / 3151C /
3152C
20 MHz: < –110 dBc/Hz at 10 kHz offset
Residual clock noise, typical
12 AFG3000C and AFG3000 Series Specifications and Performance Verification
