Tektronix Keithley 2260B Series User manual


2260B Series
www.keithley.com

Multi-Range Programmable DC Power Supplies



ATektronix Company
A Greater Measure of Confidence
ser Manual
U
077-1046-01/ August2015

ADDENDUM
Please replace the “Set up”section on page 40 through page 41 of
the 2260B user manual with the following replacement:
Set Up
Line Voltage Connection –1080W Models
Background
The 1080W (2260B-30-108/80-40/ 250-13/800-
4) models use a universal power input that can
be used with 100 and 200 VAC systems. To
connect or replace the power cord, use the
procedure below:
Warning
The following procedure should only be attempted
by competent persons.
Ensure the AC power cord is not connected to
power.
Removal
1. Turn off the power switch.
1
2. Unscrew the power cord
strain relief.
3. Remove the 2 screws
holding the power cord
cover and remove.
3
2

4. Slide the cover off the AC
terminals.
5. Remove the AC power
cord wires.
5
4
Installation
1. Thread the power cord through the strain relief
and through the power cord cover.
1
2. Connect the AC power cord
wires to the AC input
terminals.
White/Blue /Black(India)
Neutral (N)
Green/Green-yellow
GND ( )
Black/Brown/Red(India)
Line (L)
LN
Line
Neutral
Ground
3. Set the cover over the AC
terminals.
3

4. Screw the power cord cover
onto the rear panel using
the supplied screws.
5. Screw the strain relief onto
the power cord cover.
4
5

Series 2260B
Multi-Range Programmable DC Power Supplies
USER MANUAL
ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent.
The information in this manual was correct at the time of printing.
However, we continue to improve products and reserves the rights to
change specification, equipment, and maintenance procedures at any
time without notice.

Table of Contents
3
Table of Contents
SAFETY INSTRUCTIONS .................................................. 5
GETTING STARTED .......................................................... 9
2260B Series Overview........................................... 11
Appearance ............................................................ 18
Theory of Operation............................................... 25
OPERATION .................................................................. 38
Set Up ................................................................... 40
Basic Operation ..................................................... 60
Parallel / Series Operation..................................... 75
Test Sequence ........................................................ 90
CONFIGURATION.........................................................102
Configuration....................................................... 103
ANALOG CONTROL......................................................122
Analog Remote Control Overview......................... 123
Remote Monitoring.............................................. 139
COMMUNICATION INTERFACE ....................................144
Interface Configuration ........................................ 145
FIRMWARE UPGRADE PROCEDURE ..............................158
Firmware Update ................................................. 159
Check the Firmware Version................................. 162
Kernel Update ...................................................... 164
Check the Kernel Version ..................................... 167
MAINTENANCE ............................................................169

2260B Series User Manual
4
FAQ..............................................................................171
APPENDIX ....................................................................173
2260B Default Settings ........................................ 173
Error Messages & Messages ................................ 176
LED Display Format ............................................. 176
2260B Specifications............................................ 177
2260B Dimensions ............................................... 194
INDEX ..........................................................................201
