Telco T-Marc 3306 User manual

MN100280 Revision A
T-Marc 3306
CE 2.0 1GE
Business Services
NID
Installation Guide
For the latest product documentation, log on to the Telco
Systems website at http://support.telco.com.

T-Marc 3306 Installation Guide
ii
The information in this document is subject to change without notice and describes only the product defined in the introduction of this
document. This document is intended for the use of customers of Telco Systems only for the purposes of the agreement under which the
document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written permission of
Telco Systems. The document is intended for use by professional and properly trained personnel, and the customer assumes full
responsibility when using it. Telco Systems welcomes customer comments as part of the process of continuous development and
improvement of the documentation.
If the Release Notes that are shipped with the device contain information that conflicts with the information in the user guide or supplements
it, the customer should follow the Release Notes.
The information or statements given in this document concerning the suitability, capacity, or performance of the relevant hardware or
software products are for general informational purposes only and are not considered binding. Only those statements and/or representations
defined in the agreement executed between Telco Systems and the customer shall bind and obligate Telco Systems. Telco Systems however
has made all reasonable efforts to ensure that the instructions contained in this document are adequate and free of material errors and
omissions. Telco Systems will, if necessary, explain issues which may not be covered by the document.
Telco Systems’ sole and exclusive liability for any errors in the document is limited to the documentary correction of errors. TELCO
SYSTEMS IS NOT AND SHALL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN THIS DOCUMENT OR FOR ANY
DAMAGES OR LOSS OF WHATSOEVER KIND, WHETHER DIRECT, INCIDENTAL, OR CONSEQUENTIAL (INCLUDING
MONETARY LOSSES), that might arise from the use of this document or the information in it.
This document and the product it describes are the property of Telco Systems, which is the owner of all intellectual property rights therein,
and are protected by copyright according to the applicable laws.
Telco Systems logo is a registered trademark of Telco Systems, a BATM Company. CloudMetro™, TelcoOrchestrator™,
TelcoController™, TelcoNFVController™, ViNOX™, TVE™, BiNOX®, BiNOS®, BiNOSCenter®, T-Marc®, T-Metro®, EdgeGenie™,
EdgeLink®, EdgeGate®, Access60®, AccessIP™, AccessMPLS™, AccessTDM™, AccessEthernet™, NetBeacon®, Metrobility®,
TMC3306™, T5 Compact™, and OutBurst® are trademarks of Telco Systems.
Other product and company names mentioned in this document reserve their copyrights, trademarks, and registrations; they are mentioned
for identification purposes only.
Copyright © Telco Systems 2016. All rights reserved.

T-Marc 3306 Installation Guide
iii
Table of Contents
Preface...................................................................................................1
Intended Audience ..........................................................................................1
Reference Documentation .............................................................................1
Downloading Product Documentation .......................................................1
Conventions Used ...........................................................................................2
Contacting Technical Support ..............................................................3
Safety Information.................................................................................2
Safety & Electromagnetic Compatibility (EMC)........................................4
Safety Compliance ..................................................................................4
EMC Emissions......................................................................................4
EMC Immunity.......................................................................................4
Environment Compliance.....................................................................5
FCC 47 CFR Part 15 Class A ........................................................................5
CISPR 22 CLASS A Warning........................................................................5
VCCI (Japan) (Class A)...................................................................................5
RoHS and WEEE............................................................................................5
Hardware Overview ..............................................................................6
Connectivity......................................................................................................6
Performance .....................................................................................................7
Management Features .....................................................................................7
Front Panel Interfaces...........................................................................8
Device Ports .....................................................................................................8
Device LEDs..................................................................................................10
Reset Button...................................................................................................10
Rear Panel Components ..................................................................... 11
Power Supply..................................................................................................11
Grounding Post .............................................................................................11
Device MAC Address ...................................................................................11
Package Contents................................................................................ 12

T-Marc 3306 Installation Guide
iv
Unpacking the Device ..................................................................................12
Mounting the Device .......................................................................... 13
Mounting the Device on a Desktop...........................................................13
Rack Mounting the Device ..........................................................................14
Wall Mounting the Device...........................................................................15
Grounding the Device......................................................................... 17
Connecting to Power Source............................................................... 18
Connecting to AC Power Source................................................................18
Connecting to DC Power Source ...............................................................18
Connecting to the Console Port.......................................................... 21
Establishing Network Connection .....................................................22
Connecting Network Devices .....................................................................22
Fiber Optic Connections (SFP) ..................................................................22
Inserting an SFP Transceiver into an SFP Socket ..........................23
Connecting an SFP Transceiver.........................................................24
Extracting an SFP Transceiver...........................................................25
Troubleshooting..................................................................................26
Initial Device Configuration ...............................................................27
Saving Startup Configuration to a TFTP Server ......................................29
Saving Startup Configuration via GUI..............................................30
Downloading Startup Configuration from TFTP Server .......................30
Transferring Startup Configuration via GUI ...................................31
Reloading Factory Defaults .........................................................................31
Restarting........................................................................................................31
Downloading the Software..................................................................32
Before Downloading Software....................................................................32
Step-By-Step Procedure ...............................................................................32
Transferring images via GUI..............................................................33
Appendix I: Ordering Information .....................................................34
Appendix II: Specifications.................................................................35
Physical Specifications..................................................................................35
Power Supply .................................................................................................35

T-Marc 3306 Installation Guide
v
Operating Conditions ...................................................................................35
List of Figures
Figure 1: T-Marc 3306 .......................................................................................6
Figure 2: Front panel ports ...............................................................................8
Figure 3: Internal AC power supply ..............................................................11
Figure 4: DC power supply.............................................................................11
Figure 5: Attaching the mounting brackets ..................................................14
Figure 6: Installing the device in a rack.........................................................15
Figure 7: Wall mounting the device...............................................................16
Figure 8: Universal grounding symbol ..........................................................17
Figure 9: SFP transceiver without bail clasp latch.......................................23
Figure 10: Removing an SFP ..........................................................................25
Figure 11: T-Marc 3306 GUI..........................................................................29
List of Tables
Table 1: Device Ports.........................................................................................8
Table 2: Port LEDs..........................................................................................10
Table 3: Console Port Pinout .........................................................................21
Table 4: Troubleshooting Chart.....................................................................26

T-Marc 3306 Installation Guide
1 Preface
Preface
This document describes the procedure for installation and initial
configuration of the T-Marc 3306. If the information in future release notes
differs from the information in this guide, follow the information presented
in the release notes for that version.
Intended Audience
This installation guide is intended for trained and qualified service personnel
who are proficient with network switching and routing concepts and
understand how to work with the Command Line Interface (CLI).
Installation, replacement, and maintenance of the equipment described in
this guide may only be done by trained and qualified service personnel.
Reference Documentation
This document forms part of the documentation suite provided with the
product, which includes the following documents:
Document Function
Installation
Guide
Contains information about installing the hardware and
software, including site preparation, testing, and safety
information.
User Guide Contains information about configuring and using the
system.
Release Notes Contains information about the current release,
including new features, resolved issues (bug fixes),
known issues, and late-breaking information that
supersedes information in other documentation.
Downloading Product Documentation
Log on to the Telco Systems support website to download the latest
product documentation. If you have not yet registered as a customer on our
support website, log on to http://support.telco.com to register.
During registration, indicate the product you purchased from Telco Systems
so that you can access information specific to your device on the support

T-Marc 3306 Installation Guide
Preface 2
website. Once you complete registration, you will receive a user name and
password by return email.
Our Professional Services Group continues to provide the best possible service
and support for your Telco Systems products.
Conventions Used
The following conventions are used to highlight important information.
Shock Hazard
Indicates instructions intended to prevent possible injury as a
result of an electric shock.
Laser Warning
Indicates instructions intended to prevent an injury caused by
laser transmission.
Danger
Indicates instructions intended to prevent possible injury or death.
Caution
Indicates instructions intended to prevent possible damage to the
product.
Note
Indicates information to which the user needs to pay special
attention.

T-Marc 3306 Installation Guide
3 Contacting Technical Support
Contacting Technical Support
Telco Systems provides technical assistance for customers and partners.
Contact the Professional Services team at our international headquarters, or
the technical support center for your region.
International
Headquarters
Telco Systems Professional
Services
13 HaYetzira St., New
Industrial Park, Yokneam Ilit,
20692, Israel
Tel: [phone]
Fax: [phone]
Email: [email protected]
US: North America and
Latin America
Telco Systems
15 Berkshire Rd
Mansfield, MA 02048
Tel: [phone]
Fax: [phone]
Email: [email protected]
Europe, Middle East
and Africa (EMEA)
BATM Advanced
Communications GmbH
Peterstr. 2-4
52062 Aachen
Tel: [phone]
Fax: [phone]
Email: [email protected]

T-Marc 3306 Installation Guide
Safety Information 2
Safety Information
Before handling the T-Marc 3306, read the instructions and safety guidelines
on the following pages to prevent damage to the product and to ensure your
own personal safety. If you have any questions regarding the material
presented here, please contact the Telco Systems Support Center.
Shock Hazard
To avoid shock, do not perform any servicing other than those
contained in the unpacking instructions.
Shock Hazard
HIGH VOLTAGE
Removing the cover is forbidden.
Shock Hazard
GROUNDING
Before connecting the product to the power line, make sure that the
protective ground terminal of the device is connected to the safety
ground conductor of the mains power cord.
The main power supply plug should only be inserted in a socket
outlet provided with a connected safety ground. The protective
action must not be negated by use of an extension cord (power
cable) without a protective conductor (grounding). Any interruption
of the protective (grounding) conductor or disconnection of the
protective ground terminal can make the device unsafe to use.
Intentional interruption is prohibited.
This equipment has a connection between the earthed conductor of
the DC supply circuit and the grounding conductor.
Shock Hazard
LINE VOLTAGE
Before connecting the product to the power line, make sure the
voltage of the power source matches the requirements of the
product, as marked on the label located near the power connectors.

T-Marc 3306 Installation Guide
3 Safety Information
Shock Hazard
DC POWER SOURCE
The DC power source should be protected with a branch circuit
over-current protection rated at 15Amp, located in the building
installation
Danger
Install this equipment only in a Restricted Access Location per UL
60950-1 clause 1.2.7.3.
Laser Warning
The equipment is designed to be used with Class 1 Laser fiber optic
transmitters which may endanger your eyes.
Do not look directly into the fiber optic cables or transmitter.
Laser Warning
The device is provided with SFP sockets in which fiber optic
transceivers may be installed.
In order to meet the safety requirement of Class 1 fiber optic laser
emission, use only fiber optic transceivers which comply with IEC
60825-1 or IEC 60825-2 and FDA 21 CFR 1040.10 and CFR
1040.1.
Caution
This equipment contains Electrostatic Discharge (ESD) sensitive
components. Use ESD protection before servicing or installing
components of this system.
Caution
Changes or modifications made to this device that are not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

T-Marc 3306 Installation Guide
Safety Information 4
Caution
Remove the power cord from a power-supply unit before you
install it or remove it from the device. Otherwise, as a result, the
power supply or the device could be damaged. (The device can be
running while a power supply is being installed or removed, but the
power supply itself should not be connected to a power source.)
Safety & Electromagnetic Compatibility (EMC)
Safety Compliance
•UL 60950
•CSA 22.2 No. 950
•EN 60950
•IEC 60950
•Eye Safety
EMC Emissions
•FCC 47 CFR Part 15 Class A
•ICES-003 Issue 4 Class A (Canada)
•EN 300386, devices in communications center INDOOR use
•European CE marking
•EN 55022 Class A
•CISPR 22 Class A
•EN55024:1998+A1
EMC Immunity
•Harmonics: EN 61000-3-2/ IEC 61000-3-2
•Voltage fluctuations: EN 61000-3-3/ IEC 61000-3-3
•ESD: EN 61000-4-2/ IEC 61000-4-2
•RFI-AM: EN 61000-4-3/ IEC 61000-4-3
•EFT: EN 61000-4-4/ IEC 61000-4-4
•Surges: EN 61000-4-5/ IEC 61000-4-5
•Conducted: EN 61000-4-6/ IEC 61000-4-6
•Voltage DIP: EN 61000-4-11/ IEC 61000-4-11

T-Marc 3306 Installation Guide
5 Safety Information
Environment Compliance
•Full RoHS WEEE
FCC 47 CFR Part 15 Class A
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy. If not
installed and used in accordance with the instruction manual, it may cause
harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the
user is required to correct the interference at his/her own expense.
Caution
Changes or modifications made to this device, which are not
expressly approved by the party responsible for compliance,
could void the user’s authority to operate the equipment.
CISPR 22 CLASS A Warning
This is a class A product. In a domestic environment this product may cause
radio interference, in which case the user may be required to take adequate
measures.
VCCI (Japan) (Class A)
This is a Class A product based on the standard of the Voluntary Control
Council for Interference by Information Technology Equipment (VCCI). In
a domestic environment this product may cause radio interference in which
case the user may be required to take corrective actions.
RoHS and WEEE
The device complies with European RoHS and WEEE requirements. The
device also complies with Chinese RoHS legislations.

T-Marc 3306 Installation Guide
Hardware Overview 6
Hardware Overview
The T-Marc 3306 is an advanced business services network interface device
(NID) with 8 x 1GE port density Ethernet demarcation device for wireless
and mobile backhaul. It offers a comprehensive demarcation solution that
supports carrier class HQoS, OAM, resiliency, and redundancy.
The T-Marc 3306 is easy to deploy and configure and provides 8G capacity
in a compact size: only 1RU in height, ½ shelf width. T-Marc 3306
supports advanced security management capabilities and network features to
support data, voice, security, and wireless technologies. T-Marc 3306 uses
store-and-forward technology to ensure maximum data integrity.
Figure 1: T-Marc 3306
Connectivity
•8 x 1GE density supporting any port any role
4 x 10M/100M/1G RJ45
4 x 100M/1G SFP
•Network Interfaces:
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5, 5e or 6)
*Maximum Cable Length - 100 m (328 ft)
•Supports up to 4K VLANs (VID Range: 1-4094)
•IEEE 802.3 compliance ensures compatibility with standards-based network
cards and switches from any vendor
•Compliant with safety requirements, EMC emissions, EMC immunity and
full RoHS WEEE compliance

T-Marc 3306 Installation Guide
7 Hardware Overview
Performance
•8 Gbps switching capacity
•1392KB on-chip frame buffer
•11.904 Mpps (64-bit packets)
•Up to 8K MAC address entries
•Jumbo frames supported on Gigabit interfaces: frame sizes up to 10056 Bytes
•Supports up to 256 ACL entries
Drop or rate limitation based on source and destination MAC, VLAN ID or
IP address, protocol, port, differentiated services code point (DSCP) / IP
precedence, TCP/ UDP source and destination ports, 802.1p priority,
Ethernet type, Internet Control Message Protocol (ICMP) packets, IGMP
packets, TCP flag
Management Features
•In-band Management: SSH, Telnet, SNMP, HTTP
•Software loading: HTTP: TFTP in-band, console out-of-band

T-Marc 3306 Installation Guide
Front Panel Interfaces 8
Front Panel Interfaces
The front panel of the T-Marc 3306 has the following interfaces:
•RJ45 and SFP ports
•Port Status LEDs
•Power Supply LED
•Recessed reset button
This section describes the ports and LEDs present on the front panel of the
device.
Figure 2: Front panel ports
Device Ports
The following ports are available on the front panel.
Table 1: Device Ports
Port Description
4x Copper Ports
(10/100/1000BASE-T)
4 x (1/1-1/4) RJ45 ports. Each port
supports auto-negotiation for
10/100/1000.

T-Marc 3306 Installation Guide
9 Front Panel Interfaces
Port Description
4 x Unpopulated SFP ports 4 x (1/5-1/8) unpopulated SFP ports,
for dual rate support of Fast Ethernet
or Gigabit Ethernet SFP compliant,
fiber-optic transceivers. These are dual
rate SFP ports supporting 100Base-
Fx/1000Base-X.
Copper SFP is fully supported.
Note: The SFP sockets comply with
Multi-Source Agreement (MSA)
standard; however Telco
Systems guarantees the proper
functionality of SFP
transceivers that were tested
and approved by Telco Systems
only. To verify the use of a
specific SFP transceiver,
contact Telco Systems
Technical Support.
For more information about SFP
cabling, refer to Fiber Optic Connections
(SFP).
Console Port The Console Port, which is EIA-232
VT100 compatible, is used for secure
device management. For device
management only, plug the DB9-to-
RJ45 console cable directly into the
Console Port on the device.
Note: The console cable is shipped
with the device.

T-Marc 3306 Installation Guide
Front Panel Interfaces 10
Device LEDs
The following LED are located on the front panel and reflect the status of
the port.
Table 2: Port LEDs
LED Description Status
STS General
Platform Status
•Off: Processing the boot loader
•Blinking Green: Initializing the
application
•Green: Normal operation
PWR Power •Off: No power
•
Green: Power is on
LNK/ACT
(SFP Ports)
SFP Port Link
Status and
Activity
•Green:Port has link established
•Blinking Green: Current port
activity
•Off:No link detected
LNK/ACT
(Copper Ports)
RJ45 Port Link
Status and
Activity
•Green:Port has link established
•Blinking Green: Current port
activity
•
Off:No link detected
Reset Button
The front panel contains a reset button. Pressing this button momentarily
rests the device. Pressing the reset button for between 0.5–5 seconds resets
the device to factory default setting.

T-Marc 3306 Installation Guide
11 Rear Panel Components
Rear Panel Components
Power Supply
The AC model has an internal AC power supply of 100 - 240VAC on the
rear panel.
Figure 3: Internal AC power supply
The DC model has a 24/48VDC power supply unit on the rear panel.
Figure 4: DC power supply
Grounding Post
Danger
Before connecting power to the device, make sure that the
grounding post is firmly connected to a reliable ground as
described in Grounding the Device.Disconnect all power cables to
the device before grounding the device.
The grounding post is located on the back panel.
Device MAC Address
The MAC address is located on an ID label attached to the bottom of the
chassis.

T-Marc 3306 Installation Guide
Package Contents 12
Package Contents
The T-Marc 3306 package includes the following items:
T-Marc 3306 device
One power cord with country-specific AC connector (United States,
Continental Europe, United Kingdom) (for the AC power supply model
only)
Four adhesive foot pads (for mounting the device on a flat surface)
RS-232 to RJ-45 Console cable (2m)
Product Warranty
19” mounting kit (includes two brackets and screws)
For ordering information, see Appendix I: Ordering Information.
Unpacking the Device
The package contents are factory tested and inspected prior to shipment.
Telco Systems recommends that you retain the original shipping package
until the device is installed and you have verified that it is operational.
•Before you unpack the device, inspect the packaging for damage during
shipment. If the package appears to be damaged, do not open. Instead,
contact your local dealer immediately.
•Check the contents of the package to be sure that all components were
received.
