Nokia DNT2Mi-fp User manual

DN0445814 © Nokia Corporation 1 (60)
Issue 2-0 en Nokia Proprietary and Confidential
DNT2Mi-fp
Data Network Terminal
User manual
C33999.21 B0

DNT2Mi-fp Data Network Terminal User manual
2 (60) © Nokia Corporation DN0445814
Nokia Proprietary and Confidential Issue2-0en
The information in this documentation is subject to change without notice and describes only
the product defined in the introduction of this documentation. This documentation is intended
for the use of Nokia's customers only for the purposes of the agreement under which the
documentation is submitted, and no part of it may be reproduced or transmitted in any form or
means without the prior written permission of Nokia. The documentation has been prepared to
be used by professional and properly trained personnel, and the customer assumes full
responsibility when using it. Nokia welcomes customer comments as part of the process of
continuous development and improvement of the documentation.
The information or statements given in this documentation concerning the suitability, capacity,
or performance of the mentioned hardware or software products cannot be considered binding
but shall be defined in the agreement made between Nokia and the customer. However, Nokia
has made all reasonable efforts to ensure that the instructions contained in the documentation
are adequate and free of material errors and omissions. Nokia will, if necessary, explain issues
which may not be covered by the documentation.
Nokia's liability for any errors in the documentation is limited to the documentary correction of
errors. NOKIA WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN THIS
DOCUMENTATION OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING MONETARY LOSSES), that might arise from the use of this documentation or
the information in it.
This documentation and the product it describes are considered protected by copyright
according to the applicable laws.
NOKIA logo is a registered trademark of Nokia Corporation.
Other product names mentioned in this documentation may be trademarks of their respective
companies, and they are mentioned for identification purposes only.
Copyright © Nokia Corporation 2005. All rights reserved.
The following products comply with the protection requirements of the European Union Council
Directive 89/336/EEC relating to electromagnetic compatibility (EMC), provided that installed
using EMC-compatible installation practices (installation in mechanical housings stated to be
EMC-compatible and using cabling material [at least as well shielded] and practices as stated
in relevant Nokia user manuals):
Product code Product versions
T65690.01 DNT2Mi-fp 2w G.704
T65690.02 DNT2Mi-fp 4w G.704

DN0445814 © Nokia Corporation 3 (60)
Issue 2-0 en Nokia Proprietary and Confidential
Contents
Contents 3
Summary of changes 5
1 About this document 7
2 Introduction to DNT2Mi-fp 9
3 Front view 11
4 Rear panel 13
4.1 Line interface 14
4.2 Power supply 14
4.3 Terminal interface 21
5 Management 23
6 Commissioning 27
6.1 Management 28
6.2 Timing source 28
6.3 Line settings 29
6.4 Port settings 30
6.5 Protection settings 30
6.6 Measurements 31
7 Maintenance 33
7.1 Getting general information 33
7.2 Monitoring alarms 34
7.3 Testing 35
7.4 Checking measurements and statistics 37
8 Technical specifications 39
9 Factory settings 45
Appendix A. Q1 menu diagrams 47

DNT2Mi-fp Data Network Terminal User manual
4 (60) © Nokia Corporation DN0445814
Nokia Proprietary and Confidential Issue2-0en

DN0445814 © Nokia Corporation 5 (60)
Issue 2-0 en Nokia Proprietary and Confidential
Summary of changes
Product collection and disposal within the European Union
Guidelines for product collection and safe disposal of the equipment are indicated
with a sticker placed on the equipment, shown in the figure below.
Figure 1. Product collection and disposal within the European Union
Document Date Comment
DN0445814 issue 2–0 en Aug 2005
DN0445814 Issue 1–0 en Mar 2004
P
ro
d
uct co
ll
ect
i
on an
d
di
sposa
l
w
i
t
hi
n
E
uropean
U
n
i
on
Do not dispose the
product as unsorted
municipal waste.
The crossed-out
wheeled bin means that
at the product end-of life
the product must be taken
to separate collection.
Note: this is applicable only
within European Union
(see WEEE Directive 2002/96/EC)
DN0577953

DNT2Mi-fp Data Network Terminal User manual
6 (60) © Nokia Corporation DN0445814
Nokia Proprietary and Confidential Issue2-0en

About this document
DN0445814 © Nokia Corporation 7 (60)
Issue 2-0 en Nokia Proprietary and Confidential
1About this document
This manual introduces the DNT2Mi-fp network terminal and provides
information needed for its installation and use.
This manual is intended for those who use DNT2Mi-fp as a network terminal. If
you use it in a ACL2i-DNT2Mi-fp connection, refer to the ACL2i User Manual,
which contains descriptions of the ACL2i, its functions and Q1 menus.

DNT2Mi-fp Data Network Terminal User manual
8 (60) © Nokia Corporation DN0445814
Nokia Proprietary and Confidential Issue2-0en

Introduction to DNT2Mi-fp
DN0445814 © Nokia Corporation 9 (60)
Issue 2-0 en Nokia Proprietary and Confidential
2Introduction to DNT2Mi-fp
Nokia DNT2Mi-fp is a fixed port data access network terminal intended for
customer premises. It provides a two-wire or four-wire SHDSL line interface
(ITU-T G.991.2) and symmetrical 2M data interface (ITU-T G.704).
The DNT2Mi-fp Data Network Terminal can be used for example for BTS and
PABX (E1) connections (see Figure 2). DNT2Mi-fp can be controlled,
configured, and tested using Nokia’s common network management system
(NMS). It can also be controlled locally using MSTE or Craft Terminal running
on a PC or ST (hand held service terminal).
Figure 2. Example of DNT2Mi-fp connection
PABX
Local
Exchange
SHDSL
DNT2Mi-fp
BSC
BTS
DNT2Mi-fp
PDH
Network

DNT2Mi-fp Data Network Terminal User manual
10 (60) © Nokia Corporation DN0445814
Nokia Proprietary and Confidential Issue2-0en
Figure 3. DNT2Mi-fp used in a point-to-point application
DNT2Mi-fp can also be used in point-to-point connections with a DNT2Mi-fp
terminal at both ends of the line (see Figure 3)
DNT2Mi-fpDNT2Mi-fp
BTS BTS
SHDSL
