Telecom FM Fixed Wireless Phone Operation manual

1
3G PHONE
Fixed Wireless Phone
Installation & User Guide
Version 01 –August 2012
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
2
1. Contents
1. Contents ..................................................................................................... 2
2. Notices ....................................................................................................... 3
3. Recommendations ........................................................................................ 3
4. Regulatory Information ................................................................................. 4
5. Introduction................................................................................................. 5
6. Getting Started ............................................................................................ 7
6.1. Setting Up the Phone ................................................................................. 7
6.2. Powering Up the 3G Phone for the First Time ................................................ 9
6.3. Battery Backup ......................................................................................... 9
7. Calling .......................................................................................................10
7.1. Starting a phone call.................................................................................10
7.2. Receiving a phone call ..............................................................................10
7.3. Volume Control and Mute ..........................................................................10
7.4. Ending a phone call ..................................................................................10
8. Menu .........................................................................................................11
8.1. Phone Book Menu.....................................................................................12
8.1.1. Preview.............................................................................................12
8.1.2. Search ..............................................................................................13
8.1.3. Add ..................................................................................................13
8.1.4. Delete All ..........................................................................................13
8.1.5. Copy All ............................................................................................14
8.1.6. Save Position.....................................................................................14
8.1.7. Memory Status ..................................................................................14
8.2. Message Menu .........................................................................................15
8.2.1. SMS .................................................................................................15
8.2.2. Voice Mail..........................................................................................18
8.2.3. Setting .............................................................................................18
8.3. Call Log Menu ..........................................................................................19
8.3.1. Missed Calls.......................................................................................19
8.3.2. Received Calls ...................................................................................19
8.3.3. Dialled Calls ......................................................................................20
8.3.4. Delete Records ..................................................................................20
8.4. Settings Menu..........................................................................................21
8.4.1. Quick Dial .........................................................................................21
8.4.2. Phone Setup ......................................................................................22
8.4.3. Display .............................................................................................22
8.4.4. Call Settings ......................................................................................22
8.4.5. Tone Setting......................................................................................23
8.4.6. Network Setup...................................................................................24
8.4.7. Security Setup ...................................................................................24
8.4.8. Tools ................................................................................................25
8.4.9. Reset................................................................................................25
9. Troubleshooting ..........................................................................................26
10. Hardware Specification.................................................................................27
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
3
Document Control
Date
Doc
Version
Change
August 2012
1
1st release of document
2. Notices
Emergency Calls
This 3G phone operates using wireless signalling which cannot guarantee
connection in all conditions. Therefore, you should never rely solely on the
terminal equipment for essential communications such as medical or emergency
services.
No responsibility is assumed by TFM for the use or reliability of the 3G phone when used
in a situation or with other equipment not supplied or specified by TFM.
TelecomFM shall accept no liability for any error, loss, or damages of any kind resulting
from the use of this document or the equipment it relates to.
The 3G Phone is supplied with a 1 year return to base warranty which covers any defects
in design or manufacture. No other warranties whatsoever are given.
The wording in this document may change from time to time. Please refer to the
TelecomFM web site www.telecomfm.co.uk for the latest release.
3. Recommendations
Do Not clean the 3G phone whilst powered up. Use a Damp cloth for cleaning. Do not
use liquid or aerosol cleaners that could damage the 3G phone.
Do Not put obstructions in the way of the 3G phone that may cause the signal to fade.
Do Not put the 3G phone too close to other electronic devices that may cause
interference when in use
Do Not place the 3G phone in direct sunlight or by any heat source
Do Not disassemble the batteries and always seek professional advice when disposing of
batteries
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
4
4. Regulatory Information
Declaration of Conformity
Applicant: TelecomFM Ltd.
Address: 895 Plymouth Road, Slough,
Berkshire, SL1 4LP, U.K.
Product: 3G Phone
This equipment complies with the European R&TTE
Directive no. 1999/5/EC on radio and telecommunication
terminal equipment.
TelecomFM
June 2012
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
5
5. Introduction
Thank you for purchasing the 3G phone.
The 3G Phone can be used to make and receive phone calls, send and receive SMS
messages and connect to the internet at locations where a fixed telephone line is not
available.
The 3G Phone incorporates:
Rear View:
Top View:
Power (On/Off) button
Power Adapter connection
Micro-USB connection
Dial Key
Programmable Keys
Mute (secrecy) Key
Handsfree Key
Function Keys
Hangup Key
Handset
Numeric Keys
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
6
Side View:
Bottom View:
Microphone Connection
Headphone Connection
Feet
Battery Cover
SIM Card slot
Battery connector
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
7
6. Getting Started
Remove the 3G Phone from the packaging, and proceed as follows:
Warning! To avoid damage do not connect power until you have inserted the SIM
and battery pack
6.1. Setting Up the Phone
Install the SIM card and battery pack
Unscrew the battery cover screw and remove the
battery cover.
Slide the SIM card into position making sure that the
gold pins make contact
Connect the battery pack into its connector
and position in place
Replace the battery cover and screw.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
8
(Optional) Attach the 2 feet to the underside of the phone
Attach the Handset
Plug one end of the handset cord into the bottom of
the handset and the other end to the RJ11 connector
found on the side of the 3G Phone
Connecting the power Supply
Connect the power supply unit to the mains AC outlet and to
the power supply connector on the phone (marked DC 5v)
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
9
6.2. Powering Up the 3G Phone for the First Time
Press the power button on the back of the unit and wait for the display to light up and
for the 3G phone to initialise.
The 3G Phone will now carry out an auto test and log onto your chosen network. If
successful the following will be displayed on the LCD screen:
6.3. Battery Backup
Note: To optimize battery life and performance it is recommended that once powered up
for the first time you leave the mains power connected for a minimum of 5 hours before
operating the phone from battery power.
If there is a power outage the AC power symbol will go out and the 3G phone
will automatically switch to battery backup mode and show the battery symbol
charge status.
When in battery mode the battery provides approximately 100 hours standby
time and approximately 2 hours talk time (subject to network signal and
environmental conditions).
2G/3G indicator
(displays “G” when connected
to 2G network and “3G” when
connected to 3G network)
Signal Strength
Mains Power indicator
Battery Level
Network
Name
Date and Time
Function key operations
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
10
7. Calling
7.1. Starting a phone call
Either lift the handset or press the Handsfree key . After hearing dial tone,
dial the required number followed by either the Green Dial key or the OK key
. The call will then be connected.
7.2. Receiving a phone call
When an incoming call is received the caller’s number (if available) will be displayed on
the phone display and the ring tone will be heard. To answer the call either lift the
handset, press the Handsfree key or press the Green key .
7.3. Volume Control and Mute
To reduce the speaker volume during a phone call press the Left arrow key .
To increase the speaker volume during a phone call press the Right arrow key .
To mute the microphone during a phone call (secrecy function) press the Mute key
. Press the Mute key a second time to un-mute the microphone.
7.4. Ending a phone call
A call may be ended at any time by pressing the Red Hangup key .
If the Handset is in use a call may also be ended by replacing the handset.
If the phone is in Handsfree (speakerphone) mode a call may also be ended by pressing
the Handsfree button .
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
11
8. Menu
The phones menu system can be accessed by pressing the
Left function key whenever “Menu” is displayed on the
screen:
There are 4 menus available –use the Left and Right arrow keys to select the required
menu and then press the OK key.
After entering one of the 4 menus use the Up and Down arrow keys to select between
the options and sub-menus and press the OK key to select.
The menu structure is as follows:
These menus are described in detail in the following pages.
Phonebook
Messages
Call Log
Settings
1 Preview
2 Search
3 Add
4 Delete All
5 Copy All
6 Group
7 Save Position
8 Memory Status
1 SMS
2 Voice Mail
3 Settings
1 Missed Calls
2 Received Calls
3 Dialled Calls
4 Delete Records
1 Quick Dial
2 Phone Setup
3 Display
4 Call Settings
5 Tone Settings
6 Network Setup
7 Security Setup
8 Tools
9 Reset
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
12
8.1. Phone Book Menu
The phone book allows the storage of names and numbers for commonly used contacts.
Up to 1000 contacts can be stored on the telephone. Additional contacts can be stored on
the SIM card.
8.1.1. Preview
Displays a list of all of the current contacts in the phone book.
Use the Up and Down arrow keys to move through the list of contacts.
Press the OK key to select a contact and display a new menu of options:
1 New Message
2 Voice Call
3 Preview
4 Edit
5 Delete
6 Copy
7 Move
8 Add to Blacklist
9 Send V/Card
1. New Message:
Send an SMS message to the selected contact.
2. Voice Call:
Start a new voice call to the selected contact
3. Preview:
View the selected contact name and telephone number
4. Edit:
Edit the selected contact details
5. Delete:
Delete the selected contact.
6. Copy:
Copy the selected contact from the Phone memory to the SIM card or from the
SIM card to the Phone memory
7. Move:
Move the selected contact from the Phone memory to the SIM card or from the
SIM card to the Phone memory
8. Add to Blacklist:
Add the selected contact to a Blacklist that will block inbound calls from the
contact number
9. Send Vcard:
Send the contact details as a Vcard to another device. Enter the number for the
other device or choose “Search” to select from the phone book.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
13
8.1.2. Search
Search for a contact in the phone book.
Enter the first character(s) of the contacts name and then press the OK key to view a list
of contacts which match.
Use the Up and Down arrow keys to move through the list of matched contacts.
Press the OK key to select a contact and display a new menu of options:
1 New Message
2 Voice Call
3 Preview
4 Add to Blacklist
5 Send V/Card
1. New Message:
Send an SMS message to the contact.
2. Voice Call:
Start a new voice call to the contact
3. Preview:
View the contact name and telephone number
4. Add to Blacklist:
Add the contact to a Blacklist that will block inbound calls from the contact
number
5. Send Vcard:
Send the contact details as a Vcard to another device. Enter the number for the
other device or choose “Search” to select from the phone book.
8.1.3. Add
Add a new contact to the Phonebook
Press the OK key to enter the contact’s name. Use the phone keypad to enter the name
and then press OK.
Press the Down Arrow key to select the number entry (indicated by either a phone or SIM
card icon depending on which memory is in use) and then press OK to enter the contact’s
phone number. Use the phone keypad to enter the number and then press OK.
Press the “Done” (Right) function key when the name and number have been entered.
Press the OK key to save the contact or the “Cancel” (Right) function key to exit without
saving the contact.
8.1.4. Delete All
Delete all contacts from the Phonebook.
Press the OK key to confirm or the “Cancel” (Right) function key to return to the menu
without deleting.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
14
8.1.5. Copy All
Copy all of the contacts from the phone memory to the SIM card or from the SIM card to
the phone memory.
Choose whether contacts should be copied from “SIM to Phone” or from “Phone to SIM”
and press OK to begin the copy.
8.1.6. Save Position
Select whether new contacts should be saved to the phone memory or the SIM card.
Choose between “Mobile” (for the phone memory) and SIM card and press the OK button
to confirm.
8.1.7. Memory Status
Display the number of contacts saved and total number of available contacts for the
phone memory and SIM card.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
15
8.2. Message Menu
The Message menu allow access to text message (SMS) and Voicemail services.
8.2.1. SMS
Access the SMS menu which has the following options:
1. Write MSG
Send an SMS message.
Use the phone keypad to type the message. The following keys have special functions:
0 insert a space
* insert a symbol
# switch between uppercase letters, lowercase letters and numbers
Once a message has been written press the OK key for the following options:
Send To:
Sends the SMS message.
Enter the destination phone number using the phone keypad and press the OK
key to send the message. Multiple recipients can be entered by pressing the down
arrow key to move to the next line.
Alternatively, press the OK key without entering a number to display the
phonebook. Select the name(s) of recipients and then press the “Finish” (Right)
function key. Press the OK key again to send the message.
Insert Template:
Choose from a list of common messages. The text will be inserted automatically
into the message.
Save:
Save the message to the “Draftbox” for use later.
Exit:
Return to the main screen.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
16
2. Inbox
Display a list of received SMS messages.
Select a message and press the OK key to display the following menu:
1 Preview
2 Reply
3 Forward
4 Voice Call
5 Save Number
6 Deleted
7 Delete All
8 Exit
Preview:
Display the content of the selected SMS message
Reply:
Reply to the original sender of the SMS message.
Forward:
Forward the selected SMS message to a new recipient.
Voice Call:
Make a voice call to the original sender of the SMS message.
Save Number:
Create a new contact in the phonebook for the original sender of the SMS
message.
Delete:
Delete the selected SMS message. Press OK to confirm or the “Cancel” (Right)
function key to return to the menu.
Delete All:
Delete all SMS messages from the Inbox. Press OK to confirm or the “Cancel”
(Right) function key to return to the menu.
Exit:
Return to the main screen
3. Outbox
Display a list of sent SMS messages.
Select a message and press the OK key to display the following menu:
1 Preview
2 Send Again
3 Delete
4 Delete All
5 Exit
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
17
Preview:
Display the content of the SMS message
Send Again:
Send this SMS message again. The message and/or recipients can be edited
before sending the message.
Delete:
Delete the SMS message. Press OK to confirm or the “Cancel” (Right) function key
to return to the menu.
Delete All:
Delete all SMS messages from the Outbox. Press OK to confirm or the “Cancel”
(Right) function key to return to the menu.
Exit:
Return to the main screen
4. Draftbox
Display a list of previously saved SMS messages.
Select a message and press the OK key to display the following menu:
1 Edit
2 Delete
3 Delete All
4 Exit
Edit:
Display the SMS message. The message can be edited and then sent or saved
again.
Delete:
Delete the SMS message. Press OK to confirm or the “Cancel” (Right) function key
to return to the menu.
Delete All:
Delete all SMS messages from the Draftbox. Press OK to confirm or the “Cancel”
(Right) function key to return to the menu.
Exit:
Return to the main screen
5. Templates
Manage pre-defined message templates.
The following options are available:
1 Edit
2 Add
3 Delete
4 New Message
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
18
Edit:
Edit the selected template.
After editing the template press the OK key to save and return to the list of
templates.
Add:
Add a new template. Enter the template and press the OK key to save.
Delete:
Delete the template. Press the OK key to confirm or press the “Cancel” (Right)
function key to return to the list of templates.
New Message:
Start a new message using the selected template.
8.2.2. Voice Mail
Call
Call the network provider’s voicemail service (subject to network support).
Voice No.
Edit the voicemail service phone number. Enter the new number and press the OK key to
Save. The voicemail number is provided by the network service provider.
8.2.3. Setting
Edit settings relating to the message services. Options are:
Send and Save:
Select whether sent SMS messages should be saved in the Outbox.
Info Centre:
Edit the SMS Service centre number. Enter the new number and click the OK key
to Save.
Memory Location:
Select whether received messages should be stored in the phones memory
(“Mobile First”) or on the SIM Card (“Sim Card First”). When the selected memory
is full any new messages will be automatically stored in the alternate memory (if
space is available).
Storage Status:
View the number of stored messages and total amount of message storage for the
phone and SIM card.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
19
8.3. Call Log Menu
Review Missed calls, Dialled calls and Received calls.
Call Log Sub-Menus
1 Missed Calls
2 Received Calls
3 Dialled Calls
4 Delete Records
8.3.1. Missed Calls
View a list of recent unanswered calls.
Select an entry on the list and press the OK key to view details including the name (if
available), the phone number and the time/date of the call.
Press the “Options” (Left) function key to display a menu and choose from the following
options:
Voice Call
Start a new call to the selected number
New Message
Start a new SMS message to the selected number
Preview
View call details including the name (if available), the phone number and the
time/date of the call
Add to Blacklist
Add the number to a blacklist to stop inbound calls being received from that
number
Save Number
Create a new contact in the phonebook for the selected the number
Delete
Delete the entry from the list. Press the OK key to confirm or the “Cancel” (Right)
function key to return to the menu without deleting the entry.
8.3.2. Received Calls
View a list of recent received calls.
Select an entry on the list and press the OK key to view details including the name (if
available), the phone number and the time/date of the call.
Press the “Options” (Left) function key to display a menu and choose from the following
options:
Voice Call
Start a new call to the selected number
New Message
Start a new SMS message to the selected number
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011

3G Phone
User Manual
20
Preview
View call details including the name (if available), the phone number and the
time/date of the call
Add to Blacklist
Add the number to a blacklist to stop inbound calls being received from that
number
Save Number
Create a new contact in the phonebook for the selected the number
Delete
Delete the entry from the list. Press the OK key to confirm or the “Cancel” (Right)
function key to return to the menu without deleting the entry.
8.3.3. Dialled Calls
View a list of recent dialled calls.
Select an entry on the list and press the OK key to view details including the name (if
available), the phone number and the time/date of the call.
Press the “Options” (Left) function key to display a menu and choose from the following
options:
Voice Call
Start a new call to the selected number
New Message
Start a new SMS message to the selected number
Preview
View call details including the name (if available), the phone number and the
time/date of the call
Add to Blacklist
Add the number to a blacklist to stop inbound calls being received from that
number
Save Number
Create a new contact in the phonebook for the selected the number
Delete
Delete the entry from the list. Press the OK key to confirm or the “Cancel” (Right)
function key to return to the menu without deleting the entry.
8.3.4. Delete Records
Erase one or all of the call record lists.
Select whether to erase “All Records”, “Missed Records”, “Received Records” or “Dialled
Records” and press the OK key. Press the OK key again to confirm or press the “Cancel”
(Right) function key to return to the menu without deleting the records.
3G Desk Phone
www.gsmdeskphone.co.uk
0800 928 8011
