Teledyne FLIR Triton FH-Series User manual

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
Triton™ FH-Series
Quick Install Guide
1 Check Contents
The camera kit includes a bag containing:
· a T10 Torx wrench
· two 10-pin connectors for I/O terminal blocks
· one three-pin connector for 12 VDC terminal block
· three two-pin connectors for 24 VAC output / input terminal blocks
In addition, watertight cable glands and seal plugs are attached to the camera's
rear cable ingress holes.
If any of these items are missing or damaged, contact your dealer or Teledyne
FLIR Support.
2 Select a Location
Triton FH-Series cameras are intended to be mounted on a medium-duty fixed
pedestal mount or wall mount commonly used in the CCTV industry, at an
installation height of at least 4 m (13 ft). The mount must support up to 30 lbs (15
kg). For the full list of mounting and other accessories available for the camera
from Teledyne FLIR, see the FLIR Security - Accessory Guide.
If you are powering the camera with PoE 70W class 8 or 24V AC / DC, verify that
the operating temperature is -40°C to 70°C (-40°F to 158°F) with cold start at -40°
C (-40°F), 0-95% relative humidity. Other power sources limit low-temperature
operation. For more information, see the camera's installation and user guide.
For further advice on positioning and orienting the camera, see the camera's
installation and user guide.
Supplying Power to the Camera
The camera can be powered by 12 VDC (±10%); 24 VDC (±10%); 24 VAC
(±10%); or PoE IEEE 802.3bt 50W class 6 or 70W class 8. Teledyne FLIR
recommends using PoE class 8 or 24 VAC / VDC.
Nominal power consumption is 15W; 48W on 12 VDC with heaters enabled; and
70W on all other input voltages with heaters enabled.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
3 Connect the Camera
To install the camera, Teledyne FLIR recommends connecting the camera on a
bench or in a lab and configuring it for networking before mounting and aiming it.
However, circumstances can dictate adjusting the sequence of the steps. For
example, you can mount the camera before configuring it for networking, or
connect the camera before mounting it.
Warning
The camera itself does not have a power on/off switch. Do
not supply power to the camera until you have completely
finished connecting it.
The camera's interfaces and connections are inside the camera body. A microSD
card slot and reset / default button are located on a panel on the side of the
camera. To access the side panel, loosen and remove the screws that secure the
access cover. Before closing and locking the access cover, make sure to store the
anti-drop strap inside the camera to ensure that the camera remains waterproof.
Access Cover
Side Panel
Side Panel
1
LED status indicator—Solid green indicates
the camera is powered and operating.
· To reboot and reset the camera to its
previously saved settings, press the
button for between 1-3 seconds.
· To reboot and reset the camera to its
factory default settings, press the
button for at least 10 seconds.
2
Recessed Default / Reset button—To press
the button, Teledyne FLIR recommends using
a cell phone SIM or memory card tray eject
tool or something similar.
3
microSD card slot
The USB port is reserved for future use.
Important
Use a preformatted microSD card or format it with a single
partition using the camera's web page or a PC. For more
information about using the camera's web page to format a
microSD card, see the camera's installation and user guide.
Tip
Access the camera's web page, open the Recording page, and make
sure the camera recognizes the microSD card.
To open the camera's top cover:
a. Through slots in the sunshield, use the Torx wrench supplied with the camera
to loosen and remove the two screws that secure the camera's top cover that
are closest to the hinges. Then, loosen and remove the other two screws.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
You do not need to remove the sunshield to open the cover. Nonetheless, if
you want to remove the sunshield, loosen and remove the screws that attach it
to the camera body. Then, carefully remove the sunshield.
b. Open the camera cover to expose the inside of the camera body and the
following connections.
Camera Connections
Connection
Description
1
LAN (56V 1.6A)
PoE 802.3bt
Attach a Cat 6 cable from the network switch to the RJ45
port for 100/1000 Mbps Ethernet and PoE.
LED—Solid green indicates an active connection. Flashing
orange indicates data traffic between the camera and the
network.
2
BNC
x 2
T/V—Analog visible
or thermal video
output; supports
OSD
Attach to these connectors analog
video cables rated RG59U or
higher.
You can configure the video format
of the T/V connector and the on-
screen display (OSD) using the
camera's web page.
3
Analog thermal video
output; no OSD

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
Connection
Description
4
10-pin terminal
block x 2
Connect wires from alarm or audio I/O devices, or from IR LED
illuminators, to the appropriate pins on a ten-pin connector included
in the camera kit. Then, plug the connectors into the terminal blocks.
To use the camera's external IR illumination feature to turn
illuminators on and off, connect them to ALARM OUT 2.
Pin
Connection
Pin
Connection
1
AUDIO IN
1
ALARM IN 1
2
GND
2
GND
3
AUDIO OUT
3
ALARM IN 2
4
GND
4
GND
5
GND
5
ALARM OUT 1 NO
6
RS-485-TX-N
6
ALARM OUT 1 COM
7
RS-485-TX-P
7
ALARM OUT 1 NC
8
RS-485-RX-P
8
ALARM OUT 2 NO
9
RS-485-RX-N
9
ALARM OUT 2 COM
10
GND
10
ALARM OUT 2 NC
5
DC12V (IN)
Connect wires from an external power supply
to the three-pin connector included in the
camera kit. Then, plug the connector into the
terminal block.
Pin
1
2
3
-
NC
+
6
ILLUMINATION
POWER OUT 1
AC24V
Connect wires from illuminators and an external power supply to the
two-pin connectors included in the camera kit. Then, plug the
connectors into the terminal blocks.
· Do not connect a DC12V power supply to the DC24V
connection.
· Do not use the DC12V and AC24V / DC24V IN
connections at the same time.
· The ILLUMINATION POWER OUT 1 + 2 AC24V
connections can supply a maximum 4.2A total to
external illuminators. They must be connected to
equipment with fireproof enclosures. FH-Series cameras
support Raytec Long-Range Infra-Red illuminator models
VAR2-i6-1, VAR2-i6-2, VAR2-i8-1, VAR2-i8-2, and
VAR2-i16-1. For information about which Raytec
illuminator each model supports, see the FLIR Security -
Accessory Guide.
7
POWER INPUT
24V AC / DC
7.2A
8
ILLUMINATION
POWER OUT 2
AC24V
9
Anchor a ground strap to this grounding lug and connect it to the
nearest earth-grounding point.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
Caution
Make sure the camera is properly grounded. Failure to
properly ground the camera can permanently damage the
camera.
4 Configure for Networking
To discover the camera on the network, Teledyne FLIR recommends using the
FLIR Discovery Network Assistant (DNA) tool. Version 2.3.0.20 or higher supports
Triton FH-Series, does not require a license to use, and is a free download from
the product's web page on the Teledyne FLIR website. You can also configure the
camera for networking using the camera's web page, or a supported VMS. Using
the DNA tool or the camera's web page for initial configuration requires using the
default admin user or any user assigned the admin or expert role.
Task
DNA tool
Camera's web
page
Discover camera IP address
•
Configure IP address, mask, and gateway
•
•
Configure IP address, mask, and gateway for more than
one camera at the same time
•
Configure DNS settings, MTU, and Ethernet speed
•
Notes
· For information about using the supported VMS to configure the
camera, see the VMS documentation.
· For information about accessing the camera's web page, see the
camera's installation and user guide.
By default, DHCP is enabled on the camera and a DHCP server on the network
assigns the camera an IP address. For example, if the camera is managed by
Teledyne FLIR's Horizon or Meridian VMS and the VMS is configured as a DHCP
server, the VMS automatically assigns the camera an IP address.
If the camera is managed by Teledyne FLIR’s Latitude VMS or is on a network
with static IP addressing, you can manually specify the camera’s IP address using
the DNA tool or the camera's web page. The camera's default IP address is
192.168.0.250.
To manually specify the camera's IP address using the DNA tool:
a. Run the DNA tool (DNA.exe) by double-clicking .
The Discover List
appears, showing
compatible
devices on the
LAN segment and
their current IP
addresses.
In the DNA Discover List, verify that the camera's status is Online.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
If this is the first time you are configuring the camera or if it is the first time after
resetting the camera to its factory defaults, DNA automatically authenticates
the camera with the default password for the camera's admin user (admin).
If the admin user password has been
changed, you need to authenticate the
camera.
In the DNA Discover List, right-click the
camera and select Login.
In the DNA - Login window, type the
password for the admin user. If you do
not know the admin user password,
contact the person who configured the
camera's users and passwords.
Click Login, wait for Ok status to
appear, and then click Close.
In the DNA Discover List, verify that the camera's status is Authenticated.
b. Change the camera’s IP address.
Right-click the camera and select IP Setup.
In the DNA - IP Setup window, clear
Use DHCP and specify the camera's IP
address. You can also specify the Mask
(default: 255.255.255.0) and Gateway.
Then, click Update, wait for Ok
status to appear, and then click Close.
Close the Cover
Disconnect the camera.
Then, to prevent damaging the camera's internal components while moving it from
the bench or lab to its mounting location, close the camera cover and either re-
attach the sunshield or make sure to bring it to the mounting location.
At the mounting location, to connect the camera, remove the sunshield if
necessary and open the cover again.
5 Mount the Camera
Teledyne FLIR offers accessories to mount the camera on a wall, on a large pole,
on a small pole, in a corner, or on a pedestal. For more information about the
accessories required for each mounting option, see the camera's installation and
user guide.
Be sure to have the required accessories and tools available.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
Install the mounting hardware for the camera according to the instructions for the
hardware. If relevant, route power, network, and other cables into the mounting
hardware so that they are accessible when the camera is mounted.
Typically, point the camera towards the
ground while ensuring that the field of
view includes as little of the skyline as
possible. Teledyne FLIR recommends
mounting the camera with zero
horizontal rotation; that is, a 0º
installation roll angle. For accurate video
analytics, mount the camera with an
installation roll angle within ±5º.
Attach the camera to the mounting
surface using four 1/4"-20 UNC SUS
19mm screws, each with a metal flat
washer, a spin washer, and a 1/4"-20
UNC nut.
Attaching the Camera to a
Bracket (Example)
6 Connect the Camera
Caution
Carefully following these instructions makes sure water does
not enter the camera and ensures its long-term reliability.
Teledyne FLIR is not responsible for damage to the camera
due to not adhering to these instructions.
Cables enter the camera body through
liquid-tight 3/4" NPT compression
glands, each with a gland seal insert
and plugs for unused holes. To ensure
watertight seals, the cable outer
diameter must be between 0.23"-0.29".
Carefully loosen and remove the gland
nuts.
Remove the appropriate number of
cable gland seal plugs. However, make
sure seal plugs are securely in place for
all unused gland seal holes.
Route the cables through the gland
seals before terminating and connecting
them. Leave the gland nuts loose until
you have finished routing and
connecting all of the cables.
Allow enough space for cable egress
through the gland. The typical cable
bend radius is 50-75mm (2-3").
According to the information in Connect
the Camera, terminate the cables and
then connect them.
Cable Glands (Seal Inserts Not Shown)
Cable Egress Space
(75mm / 3" Bend Radius)

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
To ensure a watertight seal, fully tighten the gland nuts.
Close and Secure the Cover
Using the Torx wrench, alternately tighten the four screws that secure the cover to
the camera; torque to 8+0.5 kgf-cm.
Caution
To ensure the camera's IP66 and IP67 dust and water ingress
ratings, properly and securely close the camera cover and
tighten the screws. Failure to do so can void the camera's
warranty.
Re-attach the sunshield, if relevant.
7 Aim the Camera
The camera itself is stationary and does not provide physical aiming adjustment.
For information about how to adjust mounting hardware to aim the camera, refer to
the instructions for the mounting hardware.
Tips
· Aim the camera while you are or someone else is monitoring the
camera's live video on the camera web page or in a video stream.
· Aim the camera while supporting the camera's weight with your
hand or with the help of someone else.
8 Check the Boresight
At the factory, the visible video image was aligned with the thermal video image.
Users assigned the role of admin or expert can fine tune the video image
alignment to the scene using the camera's web page. For more information, see
the camera's installation and user guide.
Caution
When adjusting the camera's boresight, exercise extreme
caution.
9 Configure the Analytics
Before creating analytics regions, check the camera's video analytics calibration.
a. Log in to the camera's web page. For instructions on logging in to the camera's
web page, see the camera's installation and user guide.
b. On the camera's View Settings page, click Georeference.
c. On the Georeference page, specify the
camera's installation height, tilt angle,
and roll angle. You can copy the
camera's installation tilt and installation
roll angles from the camera's onboard
gyroscope.
d. Click Save.
e. Click Video Analytics. Then, on the Video Analytics page, expand the Overlay
Settings, and enable the overlay.
f. On the Visible tab, make sure analytics are enabled.
g. Make sure that a person about 1.8m (5" 11') tall is in the camera's field of view.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
h. Click Display Target.
A box simulating a 1.8m (5"
11') person appears in the live
video. Make sure the height of
the box corresponds to the
size of the person standing in
the camera's field of view.
If it does not, on the
Georeference page, verify the
camera's installation height, tilt
angle, and roll angle. On the
Boresight page, make sure the
visible and thermal video
vertical fields of view are
properly aligned.
i. On the Thermal tab, make
sure analytics are enabled,
and repeat the previous two
steps.
To create an analytics region:
a. Under Add Region, click the
appropriate icon.
b. Specify each point of the
region by clicking and releasing on the live video image. Do not click and drag.
Also, do not draw one region line or border over another. For tripwires, the
maximum number of points is 16.
To finish creating the
region, double-click the last
point. To cancel creating a
region, press Esc.
c. For tripwires and detection
areas, you can specify
direction, human or vehicle
classification, or loitering
time.
Direction
Classification
Loitering
time
Tripwire
•
•
Intrusion
•
Loitering
•
•
Masking
N/A
d. After drawing at least two tripwires or detection areas for either the visible or
the thermal video images, you can establish dependency between them.
e. When you have finished configuring the regions, click Save.
Tips
· Remember to create analytics regions for the visible video image
and for the thermal video images, if desired.
· By default, alarm rules triggered by the camera's video analytics are
defined and disabled. Enable or modify these alarms, or define
additional alarms, on the Alarm page in System Settings.
· For more information about the camera's video analytics and
alarms, see the camera's installation and user guide.

427-0102-00-28 Triton FH-Series QIG Rev 110
November 2021
This document does not contain any export-controlled information.
10 Attach the Camera to a Supported VMS
After you have mounted the camera and discovered or defined its IP address,
attach the camera to a supported VMS using its discovery/attach procedure.
11 Camera Dimensions
The Triton FH-Series camera’s dimensions are:
12 Register the Product
Register the product at https://customer.flir.com.
For warranty information, see https://www.flir.com/support-
center/warranty/security/flir-security-product-warranties/.
13 Contact Information
Americas
6769 Hollister Avenue
Goleta, CA 93117
27700 SW Parkway Ave.
Wilsonville, OR 97070
Support: https://support.flir.com/
