M1xx/M2xx/M3xxSeriesCameraInstallationaddendum
Importantinstallationupdate
Sincethepublicationandprintingofthemanualsuppliedwithyourcamera,themountingprocedureforthecamera
haschanged,followingadditionalinstallationfeedbackfromRaymarine'sdealernetwork.Thefollowingmounting
procedureMUSTbefollowedwhenmountingyourcamera,andsupersedesthemountingproceduresdetailed
intheprintedmanualsuppliedwithyourcamera.
Installationxings
Thefollowingxingsaresuppliedwithyourcamera.Thislistsupersedesthexingsinformationprovidedinthe
printedmanualsuppliedwithyourcamera.Allothersuppliedpartsremainthesameasthoselistedinthemanual.
1.Flatnuts(M6,A4stainless)x2.Mustonlybeusedtoassistinwindingthestudsintothecamera’sbase.
2.Domenuts(M6,A4stainless)x3.Ifneeded,ttostudstocoverexposedends.DoNOTusewithriser.
3.Threadedstud(M6,60mm,A4stainless)x3.
4.Flatwashers(M6,A4stainless)x3.
5.Nylocnuts(M6,A4stainless)x3.
ApplyingLoctite
Beforeinsertingthethreadedstudsintothebaseofthecamera,youMUSTrstapply“Loctite243”threadlocker(or
equivalent),toall3studs.
Important:Ifthesuppliedthreadedstudsarenotlongenoughtoaccommodateallthexingsandthethicknessof
themountingsurface,obtainlongerreplacementmarine-gradestainlesssteelM6threadedstuds(e.g.316/A4).
1.Cleanandde-greasethe3suppliedthreadedstudsandthecamerabaseplate'stappedthreads.
2.Allowtodrybeforeproceedingtothenextstep.
3.Applygenerousamountsof"Loctite243"threadlocker(orequivalent)toeachofthestuds.
4.Insertthethreadedstudsintothecamera'sbaseplateimmediately,ensuringsufcientthreadprotrudes,toallowthe
ttingofwasherandnuts.Ifnecessary,xthesuppliedatnuts(x2)(temporarily)tothestuds,toassistyou
inwindingthestudsfullyintothecamera'sthreads.Discardatnutsoncedone.
5.RemoveanyexcessLoctite.AnyremainingLoctitemustbethoroughlycleanedfromthestudsandbase.
6.AllowtheLoctiteonthethreadedstudstocurefor24hours,beforeproceedingtothenextstep.
Note:Ifusingtherisertomountthecamera,doNOTallowanyLoctitetocomeintocontactwiththeriser,as
theLoctitemaydamagetherisermaterial.
Documentnumber:82429(Rev1)AA;27716;2022-03-31T15:13:23Date:04-2022

Mountingthecamera
ThefollowingmountingprocedureMUSTbefollowedwhenmountingyourcamera,andsupersedesthemounting
proceduresdetailedintheprintedmanualsuppliedwithyourcamera.
1.Ensurethatyou’vecarefullyfollowedtheinstructionsprovidedinthe“ApplyingLoctite”sectiontoinsertthe
studscorrectlyintothecamerabase.
2.Usethesuppliedmountingtemplatetodrilltheholesforthecamerabase(orriser,ifused),andthecables
(asrequired).
3.Placethegasketonthebottomofthecamera,carefullyaligningthegasketholeswiththethreadedstuds.
Note:Ifmountingthecameraballdown,doNOTtthegasketbetweenthecameraandtheriser.
4.Optionally ,(temporarily)securetherisertothecamerawithafewhandturnsofthenylocnutsonthestuds,to
preventtheriserfromfallingwhileyouconnectthecables.Checkthatthecamera'sgasketremainsrmlyinplace.
Note:Observethecameraforwardmarkingonthetopsurfaceoftheriser.Y oumustensurethattheriserismounted
sothatthecameraisorientedproperly,relativetothevessel'sbow.
5.Connectthecablestothecamera.Ifusingtheriser,loopthecablesroundwithintheriserbasesothattheycanbe
threadedthroughthebottomoftheriser,andintothecableroutingholedrilledinthemountingsurface.
6.Securethecameraassemblytothemountingsurface(orriser,ifused),usingthesuppliedatwashersandnyloc
nuts.Paycarefulattentiontothecorrectarrangementofthexings,asshownintheimageabove.
Note:Ifyouarereplacinganexistingcamerainstallationorhavepurchasedanolderriser,doNOTusethe
existingspringwasherssuppliedwiththecameraorriser.
7.Tightenthenylocnutstoatorqueof5.0-6.0N·m(3.7-4.4lbf·ft).
8.Fitthesuppliedbasesealtotheriser.
9.Securetherisertothemountingsurfaceusingscrewssuitableforthemountingsurfacematerialandthickness.
(Fixingsnotsupplied).
2M1xx/M2xx/M3xxSeriesCameraInstallationaddendum
