General Description
The ACS-101 (Antenna Combiner Splitter 10 to 1) is an
amplified and filtered broadband splitter-combiner. It
allows up to 10 base stations to use only one transmit
and one receive antenna.
The antenna combiner section contains innovative
hybrid coupling, amplifying and matching technol-
ogy to combine 10 transmitters to 1 output with
very low intermod distortion.
ACS-101 Product Features:
The antenna splitter section has broadband input fil-
tering and amplification to maintain signal levels
through the splitters. High output isolation between
ports is also achieved.
The industrial strength power supply of the ACS-101
supplies voltage and current to two outputs on the prod-
uct. Each output can supply up to 5 Amps at 12 VDC.
·Ideal for use with BTR-1, BTR-500, BTR-600, BTR-700 wireless intercom systems.
·Two power outputs to supply up to 10 transceivers (5 on each daisy-chain run)
which makes large systems easier to implement.
·Standard IEC 320 power input connector
·115 VAC or 230 VAC operation
·High-Quality TNC connectors for consistent impedance across the entire frequency range.
·Rack mount brackets included for 19" (482.6 mm) rack
-1-
TELEX COMMUNICATIONS, INC. 12000 Portland Ave. South, Burnsville, MN 55337
®
SPECIFICATIONS
Overall
Antenna Connectors .........................................................................................................................Standard TNC Receptacles
AC Input Power .......................................................................................................................100 - 120 VAC, 60 Hz, 6A max
AC Input Fuse................................................................................................................................................10 A, 250 V, 3AG
DC Output Power.........................................................................................................................12 VDC, 5 A for each output
DC Output Jacks...........................................................................................................................Two, 5.5mm x 2.1 mm Jacks
DC Output Fuses..............................................................................................................................5 A, 250 V, 5mm x 20 mm
Size ...................................................................................H: 3.50" (88.9 mm) x W: 16.75" (426 mm) x D: 14.63" (372 mm)
Weight ....................................................................................................................................................10 lbs., 4 oz., (4.65 kg)
Antenna Splitter
Frequency Range ................................................................................................................................................614 - 746 MHz
Output IP3..................................................................................................................................................Greater than 30 dBm
Net Gain................................................................................................................................................................. 0 dB Typical
Noise Figure .....................................................................................................................................................Less than 4.5 dB
Minimum Isolation......................................................................................................................20 dB between adjacent ports.
Greater than 20 dB between non-adjacent ports
Antenna Combiner
Frequency Range ................................................................................................................................................470 - 608 MHz
Net Gain...........................................................................................................................................................0 dB (Maximum)
Noise Figure..........................................................................................................................................................10 dB Typical
Output IP3.......................................................................................................-55 dBc @ + 17 dBm input on each transmitter
ACS-101
AMPLIFIED BROADBAND UHF
COMBINER-SPLITTER PN 803984
