Telguard ML Series User manual

4G LTE INTErCoM |ML raNGE INSTALLATION GUIDE
Raising Standards
Safety Assured
4G LTE I/o Board CONNECTIONS
The 4G antenna is an external ite that should be
installed in the ost suitable position so that axi u
signal strength is obtained and is ore than 200
fro a hu an body.
This positioning should also allow for avoidance of any
likely vandalis as is able.
4G LTE PCB CONNECTIONS INSTALLATION TIPS
!
A SITE SIGNAL NETWORK TEST IS TO BE UNDERTAKEN
BEFORE INSTALLATION
TGML_IG_ISSUE 1_07.19
in
www.telguard.co.uk/support
z
Use the positioning template for the siting of the mounting holes.
z
Ensure the unit is sealed to prevent water ingress.
z
Use electronic grade silicone sealant to seal around all rear entry holes.
z
Ensure antenna and power leads have a loop before entering the back
of the unit to prevent water ingress along the cable.
z
Use the black plastic gland M20 x 1.5mm, std electrical thread to
secure the power and aerial leads.
z
If drilling out the backbox or steel posts, no metal filings must be left in
the backbox. The speaker has a magnet and may attract metal filings.
Brush out the back box of all debris before screwing in the faceplate.
z
Do a 4G signal test with a 4G analyser to ensure installation of the
best sim card.
z
Ensure the unit is turned off before inserting/removing the SIM and
plugging in/unplugging the aerial.
z
LED status lights: Green OK LED is multi purpose, it shows correct
antenna connection, correct sim card installation and signal strength
(RSSI).
z
The blue LED is the network status LED.
z
Use the faceplate parking slot for ease of installation.
z
e strongly recommend the PIN Defaults are changed at the point
of installation.
z
For full installation manual visit www.telguard.co.uk/support

GSM one aPP APP GUIDE
The settings and features are programmed using Commtel GSM One App and the SMS Short Command Guide which are both downloadable from
www.telguard.co.uk /support
PROGRAMMING APP GSM One
z
Programming the most common settings and features.
THE SMS SHORT COMMAND PROGRAMMING GUIDE
z
The full range and advanced programming of all settings and features.
EU CE Declara ion of Conformi y and Radio Equipmen Direc ive is available a www.comm el-uk.com | GB-RH10 9XN
