Telinga PRO-X V.2 User guide

www.telinga.com
V.1.0 INT.
PRO-X V.2 System Manual

1.1 Introduction
Thank you for purchasing a Telinga parabolic reflector. Please before
you use this Telinga read the complete manual.
Telinga Microphones, Sweden, started manufacturing parabolic microphones in
1981. The initial goal was to complete the first portable parabolic reflector
system capable of recording in mono and stereo - without using multiple
cables or preamplifiers.
All our parabolic microphones are designed to be reliable, light-weight and
very easy to use. Great care has been taken to solve the most common
problems with parabolic dishes - wind and handling noise, as well as inherent
noise from the microphone. Telinga designs are developed in co-operation with
film makers, ornithologists and researchers in the field of bio-acoustics.
ASSEMBLING
Parabolic
Dish 22”
Black ring without
thread.
Microphone
Telinga MIC.
Tripod Mount
insert holder.
Fastening
bolt.
Gray
Gray ring with
thread securing dish.
Tube holding
dish and mic.
TELINGA 3,5 mm Mini-Jack connector (PRO-X) TO RECORDERS / MIC INPUT
L/R. Please enable your recorders PLUG -IN POWER (PIP)

CAUTION!
PLEASE DO NOT CONNECT A TELINGA PRO-X SYSTEM DIRECTLY
TO A RECORDER OR PREAMP WITHOUT USING THE HANDLES 3,5
MM MINIJACK ONLY. PLEASE DO NOT CONNECT THE TELINGA
PRO-X USING XLR ADAPTERS WITHOUT OUR RECOMMENDATION.
A INCORRECT XLR ADAPTER SUPPLYING +48V MIGHT DAMAGE
YOUR TELINGA PRO-X!
PLEASE ENABLE YOUR RECORDERS PLUG IN POWER ALSO KNOWN AS
”PIP”.
ASSEMBLING / INSTALLING (AS PICTURE ABOVE)
1. Connect the Stereo MK3 and the mounting kit (gray tube with black and
gray rings) to the handle, make sure the black and gray rings are positioned
so that the back black ring without thread is supporting behind the dish, and
the gray ring with thread is securing inside the dish. As assembling picture
above.
IMPORTANT: Make sure you fasten and secure the rings and tube properly
(tight enough) inside the dish and handle, to avoid handling noise! Use the
large handle knob to fasten the Stereo MK3 inside the gray tube. The dish
should not be able to move between the gray rings or handling noise will
occur. Use a Telinga/or Rycote dish HWC (high wind cover) when recording in
windy conditions, or side winds may cause turbulence inside the dish.
2. Connect the 3,5 minijack connector (PRO-X) going from the
bottom of the handle to the recorder or preamp microphone
inputs. REMEMBER: The cable will always be the weakest link,
treat it with love and care!
3. Connect your quality (!) headphones to your recorder. For
reference we use Beyer DT-990 headphones. Make sure the input and
outputs are not set to high: acoustical feedback may occur! Enable
the "REC" position or "MONITOR" with the Plug In Power (PIP)
ENABLED: ON
PLEASE DO NOT USE THE DISH INSIDE AS REFLECTIONS MAY CAUSE
ACOUSTICAL FEEDBACK.
FINISHED

RECOMMENDED STEREO MK3 FOCUS POSITIONS.
Setting up the correct focus is very easy!
To set the correct focus of your TELINGA STEREO MK3 please mount it in the
the dish with the front of the black foam aligned with the opening of the dish.
The transparent 6” round plate separating left and right channels should be
positioned vertically, not horizontal.
That is the correct position.
The Stereo MK3 should NOT be mounted so that it points outside of the dish.

Recommended
Place a constant sound source outside, such as a small FM-radio, a portable
speaker system or such at medium distance 30 meters / 100 feets or so, away
from the parabola - now use your Telinga as a "radar", move it side to side
and learn how it performs by using your ears!
NEXT PAGE

TELINGA STEREO MK3
The Stereo MK3 microphone has an Equivalent Noise Level of aprx. 12
dB(A)only. Thereby, it does great justice to the dynamic range of
modern recorders.
The focused sound of the dish will be picked up in mono, while the
background will be presented in stereo. Handling and wind noise
suppression is excellent.
The over-all sound characteristics is a "soft" high and a "big" and
very transparent mid and low.
The stereo sound resembles the stereo of a "dummy head". There is no "hole"
between left and right. When using the parabola, a sound can move from one
side to the other without "ping-pong" effects.

FOCUS
Smaller than actual size.
Microphone movable for
optimal performance.
STEREO MK3: The plate separates the two sides from each other, while the
focused sound will affect the two microphones equally Result: the focused
sound will be recorded mono, while the background will be presented in
stereo, to L&R channels. NOT M/S! (3 channels)

THE FOLDABLE 22” TELINGA DISH
The V2 Telinga foldable dish is 22" (57 cm) and weighs only 0.33 kg /
0.72 lbs. The improved polycarbonate mix offers greater performance and
plastic memory. Compatible with ALL Telinga handles and microphones -
including earlier models such as the PRO-5/6/7/8 handles and microphones.
Folding the dish is very easy, and you may fold it over and over again for
travelling. Simply use your hands until it is folded together properly (as the
above photo) - this so you can place it inside the Soft Case or a Suitcase. The
V2 dish comes with 2 years international warranty, so you don´t have to be
afraid of accidently breaking it.

PACKING THE COMPLETE SYSTEM
PLEASE NOTE: YOU CAN ONLY FOLD THE V2 FOLDABLE 22” DISH
(STANDARD WITH PRO-9 MK2 AND PRO-X)
Pack your complete Telinga setup with the handle, microphone and
cables protected inside the rolled dish - with some padding in between: a
High Wind Cover for example. After travelling the dish will retain it´s shape
quickly. If you go for longer travels, 8-12 hours (+) where your Telinga is
stored inside an airplane as carry on luggage (for example) let the dish rest for
some time, unfolded, to retain it´s shape before recording.
Please DO NOT store your Telinga permanently with the dish folded
for longer periods of time, when not used. The dish might deform.
Complete weight including cables is only 1.2 kilo / 2.6 lbs (or less depending
on model)

ATTACHING A (OPTIONAL) TELINGA OR RYCOTE DISH HIGH WIND COVER (HWC)
Turbulence inside a parabolic dish, caused by side winds, can only effectively
be reduced by covering the entire opening of a dish. The windshield will also
serve as extra protection against rain and prevent insects from buzzing
around inside the dish while recording. When storing your complete setup
inside the Telinga Soft Case you may also use it as a good "wrap around"
cloth, protecting your microphone further. The Rycote HWC offers up to 35
dB in wind noise reduction.

USING THE (OPTIONAL) TRIPOD MOUNT: Place the Tripod Mount in the top
handle screw, and secure it with the "bridge" of the mount into the handle. Make sure
it is fastened properly before attaching it to the stand.

IMPORTANT NOTES!
CAUTION! Never point with the parabola and microphone directly towards
the sun! The foam might burn. Never leave unattended in a sun exposed
vehicle or other areas.
DURING FIELD WORK: Do not leave the Telinga with the microphone and dish
facing down into the ground due to risk of condensation. Allow a free air flow.
THE DISH: Keep the dish rolled up only when necessary. For storage longer periods
of time please keep the dish stored UN-FOLDED. If you store the dish FOLDED in
the SOFT-CASE for longer periods of time, it may deform over time! Please leave it
unfolded for 48-72 hours to retain shape. Clean the dish with water and soap. The
dish can be polished with car wax. Do NOT use mosquito spray on the dish!
THE HANDLE AND STEREO MK3: On dusty roads, keep in a plastic bag or case.
Wipe off now and then with a piece of cloth. The PRO-X is designed for outdoor use
connected to battery powered equipment only.
AFTER USE: When the Telinga is not used for several days - loosen the screw
tightening the handle, and the rings holding the dish.
Contact us for any QUESTIONS / SUPPORT: [e-mail]
MADE IN SWEDEN by Telinga Microphones
Botarbo 129, S-74896 Tobo, Sweden. Phone nr: + 46 (0) 702 979 979.
For more information please visit: www.telinga.com
ALL RIGHTS RESERVED. © COPYRIGHT TELINGA MICROPHONES
ERRORS AND OMISSIONS EXCEPTED.
