Telit Wireless Solutions ME910C1 Series User manual

02.2018
Mod.
0871
ME910C1 Quick Start Guide
80529NT11661A Rev. 1 – 2018-03-01

2 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
NOTICE
While reasonable efforts have been made to assure the accuracy of this document, Telit
assumes no liability resulting from any inaccuracies or omissions in this document, or from use
of the information obtained herein. The information in this document has been carefully
checked and is believed to be reliable. However, no responsibility is assumed for inaccuracies
or omissions. Telit reserves the right to make changes to any products described herein and
reserves the right to revise this document and to make changes from time to time in content
hereof with no obligation to notify any person of revisions or changes. Telit does not assume
any liability arising out of the application or use of any product, software, or circuit described
herein; neither does it convey license under its patent rights or the rights of others.
It is possible that this publication may contain references to, or information about Telit products
(machines and programs), programming, or services that are not announced in your country.
Such references or information must not be construed to mean that Telit intends to announce
such Telit products, programming, or services in your country.
COPYRIGHTS
This instruction manual and the Telit products described in this instruction manual may be,
include or describe copyrighted Telit material, such as computer programs stored in
semiconductor memories or other media. Laws in the Italy and other countries preserve for
Telit and its licensors certain exclusive rights for copyrighted material, including the exclusive
right to copy, reproduce in any form, distribute and make derivative works of the copyrighted
material. Accordingly, any copyrighted material of Telit and its licensors contained herein or in
the Telit products described in this instruction manual may not be copied, reproduced,
distributed, merged or modified in any manner without the express written permission of Telit.
Furthermore, the purchase of Telit products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the copyrights, patents or patent
applications of Telit, as arises by operation of law in the sale of a product.
COMPUTER SOFTWARE COPYRIGHTS
The Telit and 3rd Party supplied Software (SW) products described in this instruction manual
may include copyrighted Telit and other 3rd Party supplied computer programs stored in
semiconductor memories or other media. Laws in the Italy and other countries preserve for
Telit and other 3rd Party supplied SW certain exclusive rights for copyrighted computer
programs, including the exclusive right to copy or reproduce in any form the copyrighted
computer program. Accordingly, any copyrighted Telit or other 3rd Party supplied SW
computer programs contained in the Telit products described in this instruction manual may
not be copied (reverse engineered) or reproduced in any manner without the express written
permission of Telit or the 3rd Party SW supplier. Furthermore, the purchase of Telit products
shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any
license under the copyrights, patents or patent applications of Telit or other 3rd Party supplied
SW, except for the normal non-exclusive, royalty free license to use that arises by operation
of law in the sale of a product.

3 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
USAGE AND DISCLOSURE RESTRICTIONS
I. License Agreements
The software described in this document is the property of Telit and its licensors. It is furnished
by express license agreement only and may be used only in accordance with the terms of such
an agreement.
II. Copyrighted Materials
Software and documentation are copyrighted materials. Making unauthorized copies is
prohibited by law. No part of the software or documentation may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or computer language,
in any form or by any means, without prior written permission of Telit
III. High Risk Materials
Components, units, or third-party products used in the product described herein are NOT fault-
tolerant and are NOT designed, manufactured, or intended for use as on-line control
equipment in the following hazardous environments requiring fail-safe controls: the operation
of Nuclear Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic
Control, Life Support, or Weapons Systems (High Risk Activities"). Telit and its supplier(s)
specifically disclaim any expressed or implied warranty of fitness for such High Risk Activities.
IV. Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or service
names are the property of their respective owners.
V. Third Party Rights
The software may include Third Party Right software. In this case you agree to comply with all
terms and conditions imposed on you in respect of such separate software. In addition to Third
Party Terms, the disclaimer of warranty and limitation of liability provisions in this License shall
apply to the Third Party Right software.
TELIT HEREBY DISCLAIMS ANY AND ALL WARRANTIES EXPRESS OR IMPLIED FROM
ANY THIRD PARTIES REGARDING ANY SEPARATE FILES, ANY THIRD PARTY
MATERIALS INCLUDED IN THE SOFTWARE, ANY THIRD PARTY MATERIALS FROM
WHICH THE SOFTWARE IS DERIVED (COLLECTIVELY “OTHER CODE”), AND THE USE
OF ANY OR ALL THE OTHER CODE IN CONNECTION WITH THE SOFTWARE,
INCLUDING (WITHOUT LIMITATION) ANY WARRANTIES OF SATISFACTORY QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE.
NO THIRD PARTY LICENSORS OF OTHER CODE SHALL HAVE ANY LIABILITY FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING WITHOUT LIMITATION LOST PROFITS), HOWEVER CAUSED
AND WHETHER MADE UNDER CONTRACT, TORT OR OTHER LEGAL THEORY, ARISING
IN ANY WAY OUT OF THE USE OR DISTRIBUTION OF THE OTHER CODE OR THE
EXERCISE OF ANY RIGHTS GRANTED UNDER EITHER OR BOTH THIS LICENSE AND
THE LEGAL TERMS APPLICABLE TO ANY SEPARATE FILES, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.

4 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
APPLICABILITY TABLE
PRODUCTS
ME910 SERIES

5 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
CONTENTS
1INTRODUCTION ...........................................................................6
1.1 Scope ............................................................................................6
1.2 Audience .......................................................................................6
1.3 Contact Information, Support .........................................................6
1.4 Related Documents .......................................................................6
2GENERAL DESCRIPTION............................................................7
2.1 ME910C1 Main Features...............................................................7
2.2 USB/UART port configuration .......................................................8
3APPLICATION MAIN FLOW.........................................................9
4CHECK NETWORK REGISTRATION.........................................10
4.1 Registration AT script example ....................................................11
4.2 Network selection ........................................................................12
5CHECK/SET DATA SERVICE ....................................................13
6FULL UDP SCRIPT.....................................................................14
6.1 UDP script example.....................................................................14
7FULL TCP SCRIPT .....................................................................16
7.1 TCP script example .....................................................................16
8PSM/EDRX..................................................................................18
8.1 PSM/eDRX Timer ......................................................................21
9Document History ........................................................................22

6 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
1 Introduction
1.1 Scope
Scope of this document is to give an overview and basic instructions of how to start using the
ME910C1 module.
1.2 Audience
This document is intended for customers who want to use and test the NE866 product.
1.3 Contact Information, Support
For general contact, technical support services, technical questions and report documentation errors
contact Telit Technical Support at:
[e-mail]
For detailed information about where you can buy the Telit modules or for recommendations on
accessories and components visit:
http://www.telit.com
Our aim is to make this guide as helpful as possible. Keep us informed of your comments and
suggestions for improvements.
Telit appreciates feedback from the users of our information.
1.4 Related Documents
●1VV0301351 ME910 HW user guide r5
●80529ST10815A ME910 _AT_Commands_Reference_Guide_r2
●80529NT11643A ME910 PSM AppNote r0

7 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
2 General Description
2.1 ME910C1 Main Features
The ME910C1 is the Category M1/NB1 evolution of the Telit LE910 Series of LTE modules. Specified
in the approved Release 13 of the 3GPP standard, Cat M1/NB1 devices are specifically tailored for
IoT applications, offering optimized power consumption and enhanced coverage. This model further
enriches the widely deployed Telit xE910 family of 28 x 28 mm LGA modulesBasic Set Up
•LTE UE Category M1/NB1 3GPP release 13 compliant
•Half Duplex FDD
•Single Rx, single antenna
•3GPP Rel. 12 Power Saving Mode (PSM)
•3GPP Rel. 13 Extended Discontinuous Reception (eDRX)
•3GPP Rel. 13 Extended coverage
•Control via AT commands according to 3GPP TS27.005, 27.007 and customized AT
commands
•SIM application Tool Kit 3GPP TS 51.01
•SMS
•IPv4/IPv6 stack with TCP and UDP protocol
•OMA Lightweight M2M (LWM2M)
•Over-the-Air firmware update (for future release)
•Telit Application Development Environment: AppZone C (for future release)
•SSL
• Optional embedded GNSS (GPS, GLONASS, Beidou, Galileo)

8 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
2.2 USB/UART port
configuration
The ME910C1 is provided by 2 asynchronous serial port (CMOS 1.8) and one integrated
universal serial bus (USB 2.0 HS) transceiver with the following composition:
-2 x Telti USB Modem ports
-1 x Telit HS-USB WWAN
-1 x Telit Serial Diagnostic Interface
The screenshot below reports an example of the port composition listed on Windows 10
Device Manager.
USB Modem ports are ACM devices and
can be used as AT Command interface.
Telit HS-USB WWAN is a RMNET adapter
that can be used with Linux
ModemManager and NetworkManager.
On Windows 10 WWAN Adapter should be
automatically loaded as Cellular
Connection in Network & Internet settings
(see image below).
Telit Serial Diagnostic Interface is used for
debug purposes and for firmware upgrade.

9 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
3 Application Main Flow
In the following paragraphs different registration states will be described and finally on the
paragraphs UDP and TCP script, you will find the full script to have an UDP or TCP
connection.
Loop
POWER ON
&
CONFIGURATION
CHECK NETWORK
REGISTRATION
CHECK DATA
REGISTRATION
NETWORK
REGISTRATION
ACTIVATE DATA
SERVICE AND
SEND DATA
“Check_n
et_timer”
is
expired?
“data_ser
vice_timer
” is
expired?
Yes
Yes
No
No
No
No
SHUTDOWN
or others
YesYes
Bad signal
Yes
Yes
No
No
Yes

10 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
4 Check Network
Registration
By default the device perform auto attach and receive an IP from the network.
In this case the active <cid> is 1 and APN will be filled automatically from the network.
If different APN is required an new <cid> should be defined with
AT+CGDCONT=<cid>,APN.
This behaviour can be seen with
Command syntax: AT+CGCONTRDP=
Possible response(s):
+CGSCONTRDP:<cid>,<p_cid>,<bearer_id>[<CR><LF>
+CGSCONTRDP: <cid>, <p_cid>,<bearer_id> […]]
Example:
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"lte.tim.it.mnc001.mcc222.gprs","10.0.105.40.255.0.0.0","10.0.105.41","213.230.130.222"
,"213.230.130.222","0.0.0.0","0.0.0.0"
OK
Command syntax:: AT+CGPADDR=
+CGPADDR: <cid>,<PDP_addr>[<CR><LF>+CGPADDR: <cid>,
<PDP_addr>[…]]
Example
AT+CGPADDR=
+CGPADDR: 1,"10.0.105.40"
+CGPADDR: 2,""
OK
This APN lte.tim.it.xxx has been set by the network.
If you need to use a different APN you can set it with the command described before

11 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
AT+CGDCONT=1,ibox.tim.it
In order to activate this new APN you need to send AT+CGATT=0
and after AT+CGATT=1, that means detach and attach to the network.
4.1 Registration AT script example
Without setting APN
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"lte.tim.it.mnc001.mcc222.gprs","10.0.105.40.255.0.0.0","10.0.105.41","213.230.130.222"
,"213.230.130.222","0.0.0.0","0.0.0.0"
OK
AT+CGPADDR=
+CGPADDR: 1,"10.0.105.40"
+CGPADDR: 2,""
OK
After setting the new APN
AT+CGDCONT=1,"IP",ibox.tim.it
OK
AT+CGATT=0
OK
AT+CGATT=1
OK
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"ibox.tim.it.mnc001.mcc222.gprs","10.69.26.6.255.0.0.0","10.69.26.7","213.230.134.107",
"213.230.134.107","0.0.0.0","0.0.0.0"
OK
AT+CGPADDR=
+CGPADDR: 1,"10.69.26.6"
+CGPADDR: 2,""
OK
You can also check the registration with:
AT+CEREG?
+CEREG: 0,1
OK

12 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
4.2 Network selection
AT#WS46 is the command that allows to set access technology on the module. Description
of the command here below:
AT#WS46=<n> set command selects the IoT technology to operate with.
Parameter:
<n> - integer type, it is the technology to be used:
0 – CAT-M1
1 – NB-IoT
2 – CAT-M1 and NB-IoT
The parameter is stored in NVM and the settings is available at next reboot.
If AT#WS46=2 (CAT M1 and NB IoT) the module starts to search for CAT M1 networks first,
if it doesn't find any it starts searching for NB IoT networks.

13 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
5 Check/Set data service
When registration has been executed you can activate the context with the AT#SGACT
command:
AT#SGACT=<cid>,<status>
e.g. if we want to activate context 1, AT#SGACT=1,1
in case we want to use the <cid> 3 (e.g. Verizon in US) AT#SGACT=3,1.
See in the next paragraph a full example.

14 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
6 Full UDP script
Below the full script for UDP communication, including APN setting and using <cid> 1:
AT+CFUN=1 // Full functionality
AT+CGDCONT=1,"IP",”<APN>” // Set <cid>=1 with APN (setting can be done only one time)
AT+CGATT=0 // Network deactivation
AT+CGATT=1 // Network ativation
AT+CEREG? // Check Network Registration
AT+CGPADDR=1 // Check IP address <cid> 1
AT#SCFG=1,1,300,90,600,50 // Socket Configuration (see AT command manual for the
details of the command)
AT#SGACT=1,1 // Internal modem process (expect to receive: ERROR)
AT#SGACT? // Confirm Context activated
AT#SD=1,1,<Dest. Port>,<"IP address">,0,1234,1 // Open a UDP socket to remote server
AT#SSEND=1 // After that command you will recieve a prompt > and you
// can send the data just typing it and end them with Crtl^Z
//Transmit the data and end the string with Crtl^Z to send it
SRING: 1 // message sent
AT#SH=1 // Close the socket
6.1 UDP script example
AT+CFUN=1
OK
AT+CGPADDR=
+CGPADDR: 1,"10.0.50.204"
OK
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"lte.tim.it.mnc001.mcc222.gprs","10.0.50.204.255.0.0.0","10.0.50.205","213.230.130.222"
,"213.230.130.222","0.0.0.0","0.0.0.0"
OK

15 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
AT+CGDCONT=1,"IP",ibox.tim.it
OK
AT+CGATT=0
OK
AT+CGATT=1
OK
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"ibox.tim.it.mnc001.mcc222.gprs","10.69.211.11.255.0.0.0","10.69.211.12","213.230.134.
107","213.230.134.107","0.0.0.0","0.0.0.0"
OK
AT+CGPADDR=
+CGPADDR: 1,"10.69.211.11"
OK
AT+CEREG?
+CEREG: 0,1
OK
AT#SCFG=1,1,300,90,600,50
OK
AT#SGACT=1,1
#SGACT: 10.69.211.11
OK
AT#SGACT?
#SGACT: 1,1
OK
AT#SD=1,1,10510,modules.telit.com,0,0,1
OK
AT#SSEND=1
> data sent_
OK
SRING: 1
AT#SH=1
OK

16 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
7 Full TCP script
AT+CFUN=1 // Full functionality
AT+COPS=2 // Disable networkj registration
AT+CGDCONT=1,"IP",”<APN>” // Set <cid>=1 with APN
AT+COPS=0 // Enable network registration with automatic selection
AT#SCFG=1,1,300,90,600,50 // Socket Configuration (see AT command manual for the
details of the command)
AT#SGACT=1,1 // Internal modem process (expect to receive: ERROR)
AT+CEREG? // Check Network registration , 2 or 5 is the positive answer
// for that.
AT#SGACT? // Confirm Context activated
AT+CGPADDR=1 // Read IP address
AT#SD=1,0,<Dest. Port>,<"IP address">,0,1234,1 // Open a TCP socket to remote server
AT#SSEND=1 // After that command you will recieve a prompt > and you
// can send the data just typing it and end them with Crtl^Z
// Transmit the data and end the string with Crtl^Z to send it
SRING: 1 // message sent
AT#SH=1 // Close the socket
7.1 TCP script example
AT+CFUN=1
OK
AT+CGPADDR=
+CGPADDR: 1,"10.0.50.204"
OK
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"lte.tim.it.mnc001.mcc222.gprs","10.0.50.204.255.0.0.0","10.0.50.205","213.230.130.222"
,"213.230.130.222","0.0.0.0","0.0.0.0"
OK
AT+CGDCONT=1,"IP",ibox.tim.it
OK
AT+CGATT=0
OK
AT+CGATT=1

17 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
OK
AT+CGCONTRDP=
+CGCONTRDP:
1,5,"ibox.tim.it.mnc001.mcc222.gprs","10.69.211.11.255.0.0.0","10.69.211.12","213.230.134.
107","213.230.134.107","0.0.0.0","0.0.0.0"
OK
AT+CGPADDR=
+CGPADDR: 1,"10.69.211.11"
OK
AT+CEREG?
+CEREG: 0,1
OK
AT#SCFG=1,1,300,90,600,50
OK
AT#SGACT=1,1
#SGACT: 10.69.211.11
OK
AT#SGACT?
#SGACT: 1,1
OK
AT#SD=1,0,10510,”modules.telit.com”,0,0,1
OK
AT#SSEND=1
> data sent_
OK
SRING: 1
AT#SH=1

18 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
8 PSM/eDRX
For detailed description how PSM works, refer to the dedicate Applicatone Note.
Below there is a simple script that shows how to enter and exit from the PSM mode.
AT+COPS?
+COPS: 0,0,"Telstra Mobile",8
OK
AT+CPSMS?
+CPSMS: 0,,,"01100000","00000000" // PSM disabled
OK
AT+CPSMS=1,,,"10100011","00100100" // power saving proposed values:
// T3412 = 3 min (<Requested_Periodic-TAU>),
// T3324 = 4 min (<Requested_Active-Time>)
OK // consider that T3412 is always greater than
// T3324 by definition so the first parameter
// will be probably changed by the network
// the PSM request is sent to the network during the attach procedure or a TAU
// after +CPSMS command is issued the module triggers automatically a TAU in order
// to transfer the PSM request to the network
AT+CPSMS?
+CPSMS: 1,,,"00000001","00100100" // power saving parameters accepted/defined by
// the network: T3412 = 28 min, T3324 = 4 min
another example:
AT+CPSMS=1,,,"00000001","00100100" // power saving proposed values:
// T3412 = 10 min (<Requested_Periodic-TAU>),
// T3324 = 4 min (<Requested_Active-Time>)
OK

19 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
AT#RFSTS
#RFSTS: "505 01",9410,-103,-72,-
13.0,20c6,A8,,64,3,0,"7F0D40B","505013421612017","Telstra Mobile",3,28,720,3240
OK
AT#MONI
#MONI: Telstra Mobile RSRP:-103 RSRQ:-11 TAC:20C6 Id:7F0D40B EARFCN:9410 PWR:-
78dbm DRX:64
OK
// T3412 and T3324 values will be exchanged
// and negotiated during attach or TAU procedure
// to "force negotiation" with the network you can
// de-register and register the module or
// de-attach - attach
AT+CGATT=0 // or COPS=2
OK
AT+CGREG?
+CGREG: 0,0
OK
AT+CGATT=1
OK
AT+CGREG?
+CGREG: 0,1

20 of 23
Reproduction forbidden without Telit Communications PLC written authorization – All Rights Reserved
This is a simple script that shows how enable the use of eDRX:
AT+CPIN?
+CPIN: READY
+CEREG: 1,,"0000",8 // network registration unsolicited result code: module is EPS
// registered and connected to CAT M1 network
AT+CEDRXS=2,4,"0001" // enable the use of eDRX and enable the unsolicited result code
OK // in this example the proposal is to have eDRX set to 10,24 sec.
// ("0001")
// the eDRX request is sent to the network during the attach procedure or a TAU
// after +CEDRXS command is issued the module triggers automatically a TAU in order
// to transfer the eDRX request to the network
CEDRXP: 4,"0001","0010","0011"
// network has processed the eDRX request, unsolicited reports the following values:
// <AcT-type>[,<Requested_eDRX_value>[,<NWprovided_eDRX_value>[,<Paging_time_window>]]]
// see Table 10.5.5.32/3GPP TS 24.008 to decode binary values
AT+CEDRXRDP
CEDRXP: 4,"0001","0010","0011"
// if the network doesn't support eDRX AT+CEDRXRDP should answer CEDRXP: 0
